Getting Started with
Geospatial Data in MongoDB
Buzz Moschetti
Enterprise Architect
buzz.moschetti@mongodb.com
@buzzmoschetti
2
Agenda
• What is MongoDB?
• What does “geospatial capabilities” mean?
• GeoJSON
• Combining GeoJSON with non-geo data
• APIs and Use Cases
• Comparison to OGC (Open Geospatial Consortium)
• Indexing
• Using Geo Capabilities for non-Geo Things
• Esri and shapefiles
3
MongoDB:
The Post-Relational General Purpose Database
Document
Data Model
Open-
Source
Fully Featured
High Performance
Scalable
{
name: “John Smith”,
pfxs: [“Dr.”,”Mr.”],
address: “10 3rd St.”,
phone: {
home: 1234567890,
mobile: 1234568138 }
}
Nexus Architecture
Scalability
& Performance
Always On,
Global Deployments
Flexibility
Expressive Query Language
& Secondary Indexes
Strong Consistency
Enterprise Management
& Integrations
5
MongoDB Company Overview
~800 employees 2500+ customers
Over $311 million in funding
Offices in NY & Palo Alto and
across EMEA, and APAC
6
What is “Geo”?
At least 4 levels of capability
7
The Geo Stack
Efficiently store, query, and index arbitrary points, lines
and polygons in the DB
8
The Geo Stack
Platform for data analysis of peer data (trades/house
value/population/sales/widgets) grouped by geo data
Efficiently store, query, and index arbitrary points, lines
and polygons in the DB
9
The Geo Stack
Graphical rendering of geo shapes on a map
Platform for data analysis of peer data (trades/house
value/population/sales/widgets) grouped by geo data
Efficiently store, query, and index arbitrary points, lines
and polygons in the DB
10
The Geo Stack
Application(s) to browse and manipulate all the data
Graphical rendering of geo shapes on a map
Platform for data analysis of peer data (trades/house
value/population/sales/widgets) grouped by geo data
Efficiently store, query, and index arbitrary points, lines
and polygons in the DB
11
Important: Sometimes there is NO Map
• Geo stack must support geo functions WITHOUT a Map
• Offline reporting
• “Nightly fleet management report”
• “Distributor loss by assigned area”
• Compute/analytical processing
• Dynamic polygon generation
• Weather catastrophe simulation
• Other geo-filtering as input to analytics
12
MongoDB: The Data “Base”
Application(s) to browse and visualize
Graphical rendering of geo shapes on a map
Platform for data analysis of peer data
(trades/value/population/sales/widgets) grouped by
geo data
Efficiently store, query, and index arbitrary points,
lines, and polygons in the DB
Peer Data
Geo Data
13
One Persistor for All Applications & Use Cases
Google Map APIs
Browser / Mobile
Other Javascript
Peer Data
Geo Data
MongoDB node.js Driver
MongoDB python
Driver
Quant / Analytics
with pandas
Web Service Code
MongoDB Java
Driver
Nightly Reporting
Enterprise
Integration
MongoDB BI
Connector
Tableau
ClickView
PowerBI
Talend
Mule
Informatica
14
Balanced Reporting
• Most other NoSQL DBs do not have this capability
• Oracle, Postgres, MySQL, SQLServer do offer it and
subscribe to Open GeoS Consortium (OGC) standards
15
MongoDB data model is the major difference
MongoDB: Simple, parse-free, type-correct APIs and data to
manipulate and interrogate geo shapes
a.k.a. arrays (of arrays (of arrays))
OpenGIS: Piles of “ST_” functions:
http://postgis.net/docs/reference.html#Geometry_Accessors
SELECT ST_MakePolygon(
ST_GeomFromText(
'LINESTRING(75.15 29.53,77 29,77.6 29.5, 75.15 29.53)'));
16
Data & APIs
17
Legacy: 2D points
{
name: {f: “Buzz”, l: “Moschetti”},
favoritePets: [ “dog”, “cat” ],
house: [ -95.12345, 43.23423 ]
}
18
Better: GeoJSON
{
name: {f: “Buzz”, l: “Moschetti”},
favoritePets: [ “dog”, “cat” ],
house: {
type: “Point”,
coordinates: [ -95.12345, 43.23423 ]
}
}
19
Better: GeoJSON
{
name: “Superfund132”,
location: {
type: “Polygon”,
coordinates: [
[ [-95.12345, 43.2342],[-95.12456,43.2351],…]
[ [-92.8381, 43.75], … ] // “hole”
]
}
}
20
The GeoJSON Family
{
type: “Point”, “MultiPoint”, “LineString”,”MultiLineString”, “Polygon”,
“MultiPolygon”
coordinates: [ specific to type ]
}
{
type: “GeometryCollection”
geometries: [
{ type: (one of above),
coordinates: [ . . . ]
}
]
NO COMPUTED SHAPES
(Circle, Arc, Box, etc.)
We use the WGS84 standard:
http://spatialreference.org/ref/epsg/4326/
21
MongoDB Data Types are Geo-friendly
var poly = [
[ [-95.12345,43.2342],[-95.12345,43.2351],
[-95.12211,43.2351],[-95.12211,43.2342],
[-95.12345,43.2342] // close the loop!
]
];
db.myCollection.insert(
{name: {f: "Buzz", l: "Moschetti"},
favoritePets: ["dog", "cat"],
geo: { type: "Polygon“, coordinates: poly }
}));
22
… even with Java
Document doc = new Document();
doc.put("name", ”Superfund132");
List ring = new ArrayList();
addPoint(ring, -95.12345, 43.2342);
addPoint(ring, -95.12345, 43.2351);
addPoint(ring, -95.12211, 43.2351);
addPoint(ring, -95.12211, 43.2342);
addPoint(ring, -95.12345, 43.2342);
List poly = new ArrayList();
poly.add(ring);
Map mm = new HashMap();
mm.put("type", "Polygon");
mm.put("coordinates", poly);
doc.put("geo", mm);
coll.insertOne(doc);
static void addPoint(List ll,
double lng,
double lat) {
List pt = new ArrayList();
pt.add(lng);
pt.add(lat);
ll.add(pt);
}
23
All Types Are Preserved Correctly
Document doc = coll.find().first();
recursiveWalk(doc);
name: java.lang.String: Superfund132
geo: com.mongodb.BasicDBObject
type: java.lang.String: Polygon
coordinates: com.mongodb.BasicDBList
0: com.mongodb.BasicDBList
0: com.mongodb.BasicDBList
0: java.lang.Double: -95.12345
1: java.lang.Double: 43.2342
1: com.mongodb.BasicDBList
0: java.lang.Double: -95.12345
1: java.lang.Double: 43.2351
2: com.mongodb.BasicDBList
0: java.lang.Double: -95.12211
1: java.lang.Double: 43.2351
24
Comparison to “Good” PostGIS
import org.postgis.PGgeometry; // extended from org.postgresql.util.PGobject
((org.postgresql.Connection)conn).addDataType("geometry","org.postgis.PGgeometry"
)
String sql = "select geom from someTable”;
ResultSet r = stmt.executeQuery(sql);
while( r.next() ) {
PGgeometry geom = (PGgeometry)r.getObject(1);
if( geom.getType() = Geometry.POLYGON ) {
Polygon pl = (Polygon)geom.getGeometry();
for( int r = 0; r < pl.numRings(); r++) {
LinearRing rng = pl.getRing(r);
. . .
}
}
25
Comparison to most OpenGIS
String sql = "select ST_AsText(geom) from someTable”;
ResultSet r = stmt.executeQuery(sql);
while( r.next() ) {
String wkt = r.getString(1);
// wkt is ”POLYGON((0 0,0 1,1 1,1 0,0 0))”
// http://en.wikipedia.org/wiki/Well-known_text
// Now we have to parse the string into
// an array of array of doubles.
// Don’t want to introduce a 3rd party dependency…
// So . . . We write our own parser.
}
26
Checkpoint
We have data in and out of the DB using basic operations
(insert and find)
Now we need to make it performant!
27
Indexing
collection.createIndex({loc:”2d”})
When to use:
• Your database has legacy location data from MongoDB 2.2 or earlier
• You do not intend to store any location data as GeoJSON objects
• “Special Use Cases” e.g. arbitrary two numeric dimension indexing
collection.createIndex({loc:”2dsphere”})
When to use:
• Supports all GeoJSON objects and legacy [x,y] pairs
collection.createIndex({loc:”geoHaystack”})
When to use:
• Special small area flat (planar) lookup optimization
28
Indexing
collection.createIndex({loc:”2d”})
When to use:
• Your database has legacy location data from MongoDB 2.2 or earlier
• You do not intend to store any location data as GeoJSON objects
• “Special Use Cases” e.g. arbitrary two numeric dimension indexing
collection.createIndex({loc:”2dsphere”})
When to use:
• Supports all GeoJSON objects and legacy [x,y] pairs
collection.createIndex({loc:”geoHaystack”})
When to use:
• Special small area flat (planar) lookup optimization
29
find()/$match and Indexing
Operator Geometry Arg Type 2d 2dsphere
$geoWithin $box,$center,$polygon Y N
$geometry: { type, coordinates } N Y
$centerSphere: [ [x,y], radians ] Y Y
$geoIntersects $geometry only N Y
$near,$nearSphere [x,y] R -
(output sorted by distance) $geometry: {type, coordinates} - R
+ $minDistance N Y
+ $maxDistance Y Y
Y = will assist
N = will not assist
R = REQUIRED
Syntax helper:
find(“loc”:{$geoWithin: {$box: [ [x0,y0], [x1,y2] }});
find(“loc”:{$geoWithin: {$geometry: { type: “Polygon”, coordinates: [ …. ] }}} );
30
Aggregation Framework: $geoNear
Option 2D 2dsphere
$geoNear
(output sorted by distance)
near: { type: “Point”, coordinates } - R - and
spherical:true
near: [ x, y ] R (or) R
query: { expression INCL geo find()
on previous page EXCEPT $near}
N N
Y = will assist
N = will not assist
R = REQUIRED
Important Considerations:
1. You can only use $geoNear as the first stage of a pipeline.
2. You must include the distanceField option.
3. The collection must have only one geospatial index: one 2d index or one 2dsphere index.
4. You do not need to specify which field in the documents hold the coordinate pair or point.
Because $geoNear requires that the collection have a single geospatial index, $geoNear
implicitly uses the indexed field.
31
Use Cases
How do we bring data representation, fast lookup, and . . .
32
Case #1: Find Things in a Given Area + More
• Docs contain Points (or possibly “small” polygons)
• $geoWithin
db.site.aggregate([
{$match: { "loc": { $geoWithin: { $geometry:
{ type: "Polygon", coordinates: [ coords ] }}}
,"portfolio_id": portid
,“insuredValue“: {$gt: 1000000}
,“insuredDate“: {$gt: new ISODate(„2016-01-01“) }}
,{$bucket: {groupBy: „$insuredValue“,
boundaries: [ 1000000, 2000000, 5000000, 10000000,
20000000, Infinity] }}
. . .
33
Case #2: Find Things in an Area Stored in DB
• Get the shape from the “shapes” collection via query:
db.shapes.findOne({predicate},{theShape:1});
• Turn around and query the target collection, e.g.
buildingSites with shape:
db.buildingSites.find({loc:{$geoWithin: theShape}})
34
Case #3: Find Things Closest to where I am
db.buildingSites.aggregate([{$geoNear: { point … }});
• Results returned already in sorted order by closeness
35
Case #3.5: Find Things Closest to where I am but
within some bounds
• db.buildingSites.aggregate([
{$geoNear: {
query: { “loc”: {$geoWithin:
{$centerSphere: … }} }
(or)
query: { “loc”: {$geoWithin: {$geometry:
GeoJSON }} }
}} ])
36
When the Database isn’t enough
37
When the Database isn’t enough
• VERY fast intersection/within for many objects given
probes at high velocity (10000s/sec).
• Geo manipulation: unions, deltas, layering
• Dynamic/programmatic geo construction
• Advanced features: smoothing, simplifiers, centroids,
…
38
You Need Three Things
• Basic geo objects
• Geo operators like intersects, within, etc.
• Algos and smoothers, etc.
39
com.vividsolutions.jts
Map m = (Map) dbo.get("loc"); // get a GeoJSON object from MongoDB
List coords = (List) m.get("coordinates");
List outerRing = (List) coords.get(0); // polygon is array of array of pts
CoordinateSequence pseq = new CoordinateGeoJSONSequence(outerRing, true);
LinearRing outerlr = new LinearRing(pseq, gf);
int numHoles = coords.size() - 1; // -1 to skip outer ring;
LinearRing[] holes = null;
if(numHoles > 0) {
holes = new LinearRing[numHoles];
for(int k = 0; k < numHoles; k++) {
List innerRing = (List) coords.get(k+1); // +1 adj for outer ring
CoordinateSequence psx = new CoordinateGeoJSONSequence(innerRing, true);
holes[k] = new LinearRing(psx, gf);
}
}
Polygon poly1 = new Polygon(outerlr, holes, gf); // ok if holes was null
Point pt1 = new Point(pseq2, gf);
boolean a = pt1.intersects(poly1);
Geometry simplified = TopologyPreservingSimplifier.simplify(poly1, tolerance);
40
The Ecosystem
• OpenGeo runs over MongoDB!
http://suite.opengeo.org/docs/latest/dataadmin/mongodb/index.html
• BoundlessGeo: Commerical support for OpenGeo over MongoDB
* Provides top 2 tiers (viz, analysis)
* https://boundlessgeo.com
41
Geo Capabilities beyond “Simple Geo”
42
Geo as Date Range
{
who: ‘john’
where: ‘mongodb’
what: ‘lightning talk’
start: ISODate(“2016-06-30T15:00:00”)
end: ISODate(“2016-06-30T15:05:00”)
}
What events were happening at 15:03?
collection.find({
start : { $lte:ISODate(“2016-06-30T15:05:03”)},
end: { $gte:ISODate(“2016-06-30T15:05:03”)}
})
43
Geo as Date Range
• Ranges on 2 attributes – Two BTree walks (intersection)
• Assuming time can be anywhere in range of records, index walk is average 50% of index
• Test: Macbook Pro, i5, 16GB RAM, data fits in WT Cache easily. Warmed up. Average of
100 runs
694ms /query using index
487ms /query – COLLSCAN!
(StartDate,EndDate)  Range Type using Geo
LineString “Query”
longitude = t
Lat=“quantized”variable
0
1
2
{
who: ‘john’
where: ‘mongodb’
what: ‘lightning talk’
start: ISODate(“2016-06-30T15:00:00”)
end: ISODate(“2016-06-30T15:05:00”)
se_equiv: { type: “LineString”,
coordinates: [[ -123.1232, 1], [-121.6253, 1]]
}
45
Over 10X performance improvement!
start2 = (((start / yearsecs) - 45) *90) – 90
end2 = (((end / yearsecs) - 45) *90) – 90
event = { type: "LineString", coordinates: [ [ start2, 1 ], [end2, 1 ] ] }
// dx = is the LineString “query”
query = {
g: {
$geoIntersects: {
$geometry: { type: "LineString",
coordinates: [ [ dx, 0 ], [dx, 2 ] ] }
}
}
} 45ms!

46
Mr. Smiley
db.participatingVendors.aggregate([
// Stage 1: The Bounding Box
{$match: { "loc": { $geoWithin: { $geometry:
{ type: "Polygon", coordinates: mapBoundingBox}}}
}}
// Stage 2: Compute distance from Mr. Smiley to the points: Pythagorean theorem:
,{$addFields: {dist: {$sqrt: {$add: [
{$pow:[ {$subtract: [ {$arrayElemAt:[ "$loc.coordinates",0]}, mslng]} , 2]}
,{$pow:[ {$subtract:[ {$arrayElemAt:[ "$loc.coordinates", 1]}, mslat]} , 2]}
]}
}}}
// Stage 3: If the distance between points is LTE the sum of the radii, then
// Mr. Smiley's circle intersects that of the participant:
// Project 0 (no touch) or 1 (touch)
,{$addFields: {"touch": {$cond: [
{$lte: [ {$add: [ "$promoRadius", msr ]}, "$dist" ]}, 0, 1
]}}}
,{$match: {"touch": 1}}
]);
// Assume Mr. Smiley has these params:
var mslng = -90.00;
var mslat = 42.00;
var msr = 0.005; // ~1500 ft radius around him
47
The Pusher
var pts = [ [-74.01,40.70], [-73.99,40.71], . . .];
db.foo.insert({_id:1,
loc: { type:"LineString", coordinates: [ pts[0], pts[1] ]}});
// Push points onto LineString to "extend it” in an index optimized way!
for(i = 2; i < pts.length; i++) {
db.foo.update({_id:1},{$push: {"loc.coordinates”: pts[i]}});
// Perform other functions, e.g.
c=db.foo.find({loc: {$geoIntersects:
{$geometry: { type: ”Polygon", coordinates: … } } });
}
48
Perimeter of Simple Polygon
> db.foo.insert({_id:1, "poly": [ [0,0], [2,12], [4,0], [2,5], [0,0] ] });
> db.foo.insert({_id:2, "poly": [ [2,2], [5,8], [6,0], [3,1], [2,2] ] });
> db.foo.aggregate([
{$project: {"conv": {$map: { input: "$poly", as: "z", in: {
x: {$arrayElemAt: ["$$z”,0]}, y: {$arrayElemAt: ["$$z”,1]}
,len: {$literal: 0} }}}}}
,{$addFields: {first: {$arrayElemAt: [ "$conv", 0 ]} }}
,{$project: {"qqq":
{$reduce: { input: "$conv", initialValue: "$first", in: {
x: "$$this.x”, y: "$$this.y"
,len: {$add: ["$$value.len", // len = oldlen + newLen
{$sqrt: {$add: [
{$pow:[ {$subtract:["$$value.x","$$this.x"]}, 2]}
,{$pow:[ {$subtract:["$$value.y","$$this.y"]}, 2]}
] }} ] } }}
,{$project: {"len": "$qqq.len"}}
{ "_id" : 1, “len" : 35.10137973546188 }
{ "_id" : 2, "len" : 19.346952903339393 }
49
Geospatial = 2D Numeric Indexable Space
Find all branches close to my location:
target = [ someLatitude, someLongitude ];
radians = 10 / 3963.2; // 10 miles
db.coll.find({"location": { $geoWithin :
{ $center : [ target, radians ] }}});
Find nearest investments on efficient frontier:
target = [ risk, reward ];
closeness = someFunction(risk, reward);
db.coll.find({”investmentValue": { $geoWithin :
{ $center : [ target, closeness]}}});
50
Basic Tips & Tricks
• We use [long,lat], not [lat,long] like Google Maps
• Use 2dsphere for geo; avoid legacy $box/$circle/$polygon
• Use 2d for true 2d numeric hacks
• 5 digits beyond decimal is accurate to 1.1m:
• var loc = [ -92.12345, 42.56789] // FINE
• var loc = [ -92.123459261145, 42.567891378902] // ABSURD
• $geoWithin and $geoIntersects do not REQUIRE index
• Remember to close loops (it’s GeoJSON!)
51
esri-related Tips & Tricks
• Shapefiles are everywhere; google shapefile <whatever>
• Crack shapefiles to GeoJSON with python pyshp module
import shapefile
import sys
from json import dumps
reader = shapefile.Reader(sys.argv[1])
field_names = [field[0] for field in reader.fields[1:] ]
buffer = []
for sr in reader.shapeRecords():
buffer.append(dict(geometry=sr.shape.__geo_interface__,
properties=dict(zip(field_names, sr.record))))
sys.stdout.write(dumps({"type": "FeatureCollection”, "features": buffer},
indent=2) + "n”)
Q & A
Thank You!
Buzz Moschetti
Enterprise Architect
buzz.moschetti@mongodb.com
@buzzmoschetti
54
Agenda
• What does geospatial capabilities mean?
• The "levels": DB with geo types, rendering, analytics
• MongoDB brings together geo AND non-geo data
• Geo Data model
• GeoJSON
• Combining GeoJSON with non-geo data
• APIs and Use Cases
• Looking up things contained in a polygon
• Finding things near a point
• Summary of geo ops e.g. $center
• $geoNear and the agg framework
• The power of the document model and MongoDB APIs
• Arrays and rich shapes as first class types
• Comparison to Postgres (PostGIS)

Indexing
• Geospatial queries do not necessarily require an index
• 2d vs. 2dsphere
• Geo stacks and the Ecosystem
• MongoDB and OpenGIS and OpenGEO
• Google Maps
• MEAN
• A Sampling of Geo Solutions
• Mr. Smiley, etc.
• Integration with esri and shapefiles
• esri shapefile cracking
55
Clever Hacks
• John Page date thing
• Mr. Smiley
• Wildfire
• Push pts on a LineString and check for intersects
• Perimeter & Area of simple polygon
• makeNgon
56
MongoDB handles your data + geo
Google handles the maps
Our Drivers
Google Map APIs
Chrome
Other Javascript
Your Data
GeoJSON
• Organization unit is document, then
collection
• Geo data can contain arbitrary peer
data or higher scope within doc
• Proper handling of int, long, double,
and decimal128
• Dates are REAL datetimes
• Uniform indexability and querability
across geo and “regular” data
Your Server-side
code

More Related Content

What's hot

Introduction to mongodb
Introduction to mongodbIntroduction to mongodb
Introduction to mongodb
neela madheswari

Introduction to MongoDB.pptx
Introduction to MongoDB.pptxIntroduction to MongoDB.pptx
Introduction to MongoDB.pptx
Surya937648

Introduction to PostgreSQL
Introduction to PostgreSQLIntroduction to PostgreSQL
Introduction to PostgreSQL
Mark Wong

Mongo DB Presentation
Mongo DB PresentationMongo DB Presentation
Mongo DB Presentation
Jaya Naresh Kovela

RTree Spatial Indexing with MongoDB - MongoDC
RTree Spatial Indexing with MongoDB - MongoDC RTree Spatial Indexing with MongoDB - MongoDC
RTree Spatial Indexing with MongoDB - MongoDC
Nicholas Knize, Ph.D., GISP

Indexing with MongoDB
Indexing with MongoDBIndexing with MongoDB
Indexing with MongoDB
MongoDB

Python and MongoDB
Python and MongoDBPython and MongoDB
Python and MongoDB
Christiano Anderson

Introducing DocumentDB
Introducing DocumentDB Introducing DocumentDB
Introducing DocumentDB
James Serra

Apache sqoop with an use case
Apache sqoop with an use caseApache sqoop with an use case
Apache sqoop with an use case
Davin Abraham

Mongodb basics and architecture
Mongodb basics and architectureMongodb basics and architecture
Mongodb basics and architecture
Bishal Khanal

Introduction to Graph Databases
Introduction to Graph DatabasesIntroduction to Graph Databases
Introduction to Graph Databases
Max De Marzi

MongoDB at Scale
MongoDB at ScaleMongoDB at Scale
MongoDB at Scale
MongoDB

Webinar: When to Use MongoDB
Webinar: When to Use MongoDBWebinar: When to Use MongoDB
Webinar: When to Use MongoDB
MongoDB

An Enterprise Architect's View of MongoDB
An Enterprise Architect's View of MongoDBAn Enterprise Architect's View of MongoDB
An Enterprise Architect's View of MongoDB
MongoDB

Introduction to MongoDB
Introduction to MongoDBIntroduction to MongoDB
Introduction to MongoDB
MongoDB

Postgresql
PostgresqlPostgresql
Introduction to MongoDB
Introduction to MongoDBIntroduction to MongoDB
Introduction to MongoDB
NodeXperts

MongoDB
MongoDBMongoDB
MongoDB
nikhil2807

Webinar: Working with Graph Data in MongoDB
Webinar: Working with Graph Data in MongoDBWebinar: Working with Graph Data in MongoDB
Webinar: Working with Graph Data in MongoDB
MongoDB

Content Management with MongoDB by Mark Helmstetter
 Content Management with MongoDB by Mark Helmstetter Content Management with MongoDB by Mark Helmstetter
Content Management with MongoDB by Mark Helmstetter
MongoDB


What's hot (20)

Introduction to mongodb
Introduction to mongodbIntroduction to mongodb
Introduction to mongodb

Introduction to MongoDB.pptx
Introduction to MongoDB.pptxIntroduction to MongoDB.pptx
Introduction to MongoDB.pptx

Introduction to PostgreSQL
Introduction to PostgreSQLIntroduction to PostgreSQL
Introduction to PostgreSQL

Mongo DB Presentation
Mongo DB PresentationMongo DB Presentation
Mongo DB Presentation

RTree Spatial Indexing with MongoDB - MongoDC
RTree Spatial Indexing with MongoDB - MongoDC RTree Spatial Indexing with MongoDB - MongoDC
RTree Spatial Indexing with MongoDB - MongoDC

Indexing with MongoDB
Indexing with MongoDBIndexing with MongoDB
Indexing with MongoDB

Python and MongoDB
Python and MongoDBPython and MongoDB
Python and MongoDB

Introducing DocumentDB
Introducing DocumentDB Introducing DocumentDB
Introducing DocumentDB

Apache sqoop with an use case
Apache sqoop with an use caseApache sqoop with an use case
Apache sqoop with an use case

Mongodb basics and architecture
Mongodb basics and architectureMongodb basics and architecture
Mongodb basics and architecture

Introduction to Graph Databases
Introduction to Graph DatabasesIntroduction to Graph Databases
Introduction to Graph Databases

MongoDB at Scale
MongoDB at ScaleMongoDB at Scale
MongoDB at Scale

Webinar: When to Use MongoDB
Webinar: When to Use MongoDBWebinar: When to Use MongoDB
Webinar: When to Use MongoDB

An Enterprise Architect's View of MongoDB
An Enterprise Architect's View of MongoDBAn Enterprise Architect's View of MongoDB
An Enterprise Architect's View of MongoDB

Introduction to MongoDB
Introduction to MongoDBIntroduction to MongoDB
Introduction to MongoDB

Postgresql
PostgresqlPostgresql
Postgresql

Introduction to MongoDB
Introduction to MongoDBIntroduction to MongoDB
Introduction to MongoDB

MongoDB
MongoDBMongoDB
MongoDB

Webinar: Working with Graph Data in MongoDB
Webinar: Working with Graph Data in MongoDBWebinar: Working with Graph Data in MongoDB
Webinar: Working with Graph Data in MongoDB

Content Management with MongoDB by Mark Helmstetter
 Content Management with MongoDB by Mark Helmstetter Content Management with MongoDB by Mark Helmstetter
Content Management with MongoDB by Mark Helmstetter


Similar to Getting Started with Geospatial Data in MongoDB

Mongodb intro
Mongodb introMongodb intro
Mongodb intro
christkv

Fast querying indexing for performance (4)
Fast querying   indexing for performance (4)Fast querying   indexing for performance (4)
Fast querying indexing for performance (4)
MongoDB

Conceptos básicos. Seminario web 4: Indexación avanzada, índices de texto y g...
Conceptos básicos. Seminario web 4: Indexación avanzada, índices de texto y g...Conceptos básicos. Seminario web 4: Indexación avanzada, índices de texto y g...
Conceptos básicos. Seminario web 4: Indexación avanzada, índices de texto y g...
MongoDB

Geoindexing with MongoDB
Geoindexing with MongoDBGeoindexing with MongoDB
Geoindexing with MongoDB
leafnode

Webinar: General Technical Overview of MongoDB for Dev Teams
Webinar: General Technical Overview of MongoDB for Dev TeamsWebinar: General Technical Overview of MongoDB for Dev Teams
Webinar: General Technical Overview of MongoDB for Dev Teams
MongoDB

OSDC 2012 | Building a first application on MongoDB by Ross Lawley
OSDC 2012 | Building a first application on MongoDB by Ross LawleyOSDC 2012 | Building a first application on MongoDB by Ross Lawley
OSDC 2012 | Building a first application on MongoDB by Ross Lawley
NETWAYS

Building web applications with mongo db presentation
Building web applications with mongo db presentationBuilding web applications with mongo db presentation
Building web applications with mongo db presentation
Murat Çakal

2016 feb-23 pyugre-py_mongo
2016 feb-23 pyugre-py_mongo2016 feb-23 pyugre-py_mongo
2016 feb-23 pyugre-py_mongo
Michael Bright

Using MongoDB and Python
Using MongoDB and PythonUsing MongoDB and Python
Using MongoDB and Python
Mike Bright

TDC2016SP - Trilha NoSQL
TDC2016SP - Trilha NoSQLTDC2016SP - Trilha NoSQL
TDC2016SP - Trilha NoSQL
tdc-globalcode

Back to Basics Webinar 4: Advanced Indexing, Text and Geospatial Indexes
Back to Basics Webinar 4: Advanced Indexing, Text and Geospatial IndexesBack to Basics Webinar 4: Advanced Indexing, Text and Geospatial Indexes
Back to Basics Webinar 4: Advanced Indexing, Text and Geospatial Indexes
MongoDB

Geospatial Enhancements in MongoDB 2.4
Geospatial Enhancements in MongoDB 2.4Geospatial Enhancements in MongoDB 2.4
Geospatial Enhancements in MongoDB 2.4
MongoDB

Social Data and Log Analysis Using MongoDB
Social Data and Log Analysis Using MongoDBSocial Data and Log Analysis Using MongoDB
Social Data and Log Analysis Using MongoDB
Takahiro Inoue

1403 app dev series - session 5 - analytics
1403   app dev series - session 5 - analytics1403   app dev series - session 5 - analytics
1403 app dev series - session 5 - analytics
MongoDB

MongoDb and NoSQL
MongoDb and NoSQLMongoDb and NoSQL
MongoDb and NoSQL
TO THE NEW | Technology

Mongodb ExpressJS HandlebarsJS NodeJS FullStack
Mongodb ExpressJS HandlebarsJS NodeJS FullStackMongodb ExpressJS HandlebarsJS NodeJS FullStack
Mongodb ExpressJS HandlebarsJS NodeJS FullStack
Narendranath Reddy

Webinar: Applikationsentwicklung mit MongoDB : Teil 5: Reporting & Aggregation
Webinar: Applikationsentwicklung mit MongoDB: Teil 5: Reporting & AggregationWebinar: Applikationsentwicklung mit MongoDB: Teil 5: Reporting & Aggregation
Webinar: Applikationsentwicklung mit MongoDB : Teil 5: Reporting & Aggregation
MongoDB

MongoDB for Coder Training (Coding Serbia 2013)
MongoDB for Coder Training (Coding Serbia 2013)MongoDB for Coder Training (Coding Serbia 2013)
MongoDB for Coder Training (Coding Serbia 2013)
Uwe Printz

LocationTech Projects
LocationTech ProjectsLocationTech Projects
LocationTech Projects
Jody Garnett

Indexing Strategies to Help You Scale
Indexing Strategies to Help You ScaleIndexing Strategies to Help You Scale
Indexing Strategies to Help You Scale
MongoDB


Similar to Getting Started with Geospatial Data in MongoDB (20)

Mongodb intro
Mongodb introMongodb intro
Mongodb intro

Fast querying indexing for performance (4)
Fast querying   indexing for performance (4)Fast querying   indexing for performance (4)
Fast querying indexing for performance (4)

Conceptos básicos. Seminario web 4: Indexación avanzada, índices de texto y g...
Conceptos básicos. Seminario web 4: Indexación avanzada, índices de texto y g...Conceptos básicos. Seminario web 4: Indexación avanzada, índices de texto y g...
Conceptos básicos. Seminario web 4: Indexación avanzada, índices de texto y g...

Geoindexing with MongoDB
Geoindexing with MongoDBGeoindexing with MongoDB
Geoindexing with MongoDB

Webinar: General Technical Overview of MongoDB for Dev Teams
Webinar: General Technical Overview of MongoDB for Dev TeamsWebinar: General Technical Overview of MongoDB for Dev Teams
Webinar: General Technical Overview of MongoDB for Dev Teams

OSDC 2012 | Building a first application on MongoDB by Ross Lawley
OSDC 2012 | Building a first application on MongoDB by Ross LawleyOSDC 2012 | Building a first application on MongoDB by Ross Lawley
OSDC 2012 | Building a first application on MongoDB by Ross Lawley

Building web applications with mongo db presentation
Building web applications with mongo db presentationBuilding web applications with mongo db presentation
Building web applications with mongo db presentation

2016 feb-23 pyugre-py_mongo
2016 feb-23 pyugre-py_mongo2016 feb-23 pyugre-py_mongo
2016 feb-23 pyugre-py_mongo

Using MongoDB and Python
Using MongoDB and PythonUsing MongoDB and Python
Using MongoDB and Python

TDC2016SP - Trilha NoSQL
TDC2016SP - Trilha NoSQLTDC2016SP - Trilha NoSQL
TDC2016SP - Trilha NoSQL

Back to Basics Webinar 4: Advanced Indexing, Text and Geospatial Indexes
Back to Basics Webinar 4: Advanced Indexing, Text and Geospatial IndexesBack to Basics Webinar 4: Advanced Indexing, Text and Geospatial Indexes
Back to Basics Webinar 4: Advanced Indexing, Text and Geospatial Indexes

Geospatial Enhancements in MongoDB 2.4
Geospatial Enhancements in MongoDB 2.4Geospatial Enhancements in MongoDB 2.4
Geospatial Enhancements in MongoDB 2.4

Social Data and Log Analysis Using MongoDB
Social Data and Log Analysis Using MongoDBSocial Data and Log Analysis Using MongoDB
Social Data and Log Analysis Using MongoDB

1403 app dev series - session 5 - analytics
1403   app dev series - session 5 - analytics1403   app dev series - session 5 - analytics
1403 app dev series - session 5 - analytics

MongoDb and NoSQL
MongoDb and NoSQLMongoDb and NoSQL
MongoDb and NoSQL

Mongodb ExpressJS HandlebarsJS NodeJS FullStack
Mongodb ExpressJS HandlebarsJS NodeJS FullStackMongodb ExpressJS HandlebarsJS NodeJS FullStack
Mongodb ExpressJS HandlebarsJS NodeJS FullStack

Webinar: Applikationsentwicklung mit MongoDB : Teil 5: Reporting & Aggregation
Webinar: Applikationsentwicklung mit MongoDB: Teil 5: Reporting & AggregationWebinar: Applikationsentwicklung mit MongoDB: Teil 5: Reporting & Aggregation
Webinar: Applikationsentwicklung mit MongoDB : Teil 5: Reporting & Aggregation

MongoDB for Coder Training (Coding Serbia 2013)
MongoDB for Coder Training (Coding Serbia 2013)MongoDB for Coder Training (Coding Serbia 2013)
MongoDB for Coder Training (Coding Serbia 2013)

LocationTech Projects
LocationTech ProjectsLocationTech Projects
LocationTech Projects

Indexing Strategies to Help You Scale
Indexing Strategies to Help You ScaleIndexing Strategies to Help You Scale
Indexing Strategies to Help You Scale


More from MongoDB

MongoDB SoCal 2020: Migrate Anything* to MongoDB Atlas
MongoDB SoCal 2020: Migrate Anything* to MongoDB AtlasMongoDB SoCal 2020: Migrate Anything* to MongoDB Atlas
MongoDB SoCal 2020: Migrate Anything* to MongoDB Atlas
MongoDB

MongoDB SoCal 2020: Go on a Data Safari with MongoDB Charts!
MongoDB SoCal 2020: Go on a Data Safari with MongoDB Charts!MongoDB SoCal 2020: Go on a Data Safari with MongoDB Charts!
MongoDB SoCal 2020: Go on a Data Safari with MongoDB Charts!
MongoDB

MongoDB SoCal 2020: Using MongoDB Services in Kubernetes: Any Platform, Devel...
MongoDB SoCal 2020: Using MongoDB Services in Kubernetes: Any Platform, Devel...MongoDB SoCal 2020: Using MongoDB Services in Kubernetes: Any Platform, Devel...
MongoDB SoCal 2020: Using MongoDB Services in Kubernetes: Any Platform, Devel...
MongoDB

MongoDB SoCal 2020: A Complete Methodology of Data Modeling for MongoDB
MongoDB SoCal 2020: A Complete Methodology of Data Modeling for MongoDBMongoDB SoCal 2020: A Complete Methodology of Data Modeling for MongoDB
MongoDB SoCal 2020: A Complete Methodology of Data Modeling for MongoDB
MongoDB

MongoDB SoCal 2020: From Pharmacist to Analyst: Leveraging MongoDB for Real-T...
MongoDB SoCal 2020: From Pharmacist to Analyst: Leveraging MongoDB for Real-T...MongoDB SoCal 2020: From Pharmacist to Analyst: Leveraging MongoDB for Real-T...
MongoDB SoCal 2020: From Pharmacist to Analyst: Leveraging MongoDB for Real-T...
MongoDB

MongoDB SoCal 2020: Best Practices for Working with IoT and Time-series Data
MongoDB SoCal 2020: Best Practices for Working with IoT and Time-series DataMongoDB SoCal 2020: Best Practices for Working with IoT and Time-series Data
MongoDB SoCal 2020: Best Practices for Working with IoT and Time-series Data
MongoDB

MongoDB SoCal 2020: MongoDB Atlas Jump Start
 MongoDB SoCal 2020: MongoDB Atlas Jump Start MongoDB SoCal 2020: MongoDB Atlas Jump Start
MongoDB SoCal 2020: MongoDB Atlas Jump Start
MongoDB

MongoDB .local San Francisco 2020: Powering the new age data demands [Infosys]
MongoDB .local San Francisco 2020: Powering the new age data demands [Infosys]MongoDB .local San Francisco 2020: Powering the new age data demands [Infosys]
MongoDB .local San Francisco 2020: Powering the new age data demands [Infosys]
MongoDB

MongoDB .local San Francisco 2020: Using Client Side Encryption in MongoDB 4.2
MongoDB .local San Francisco 2020: Using Client Side Encryption in MongoDB 4.2MongoDB .local San Francisco 2020: Using Client Side Encryption in MongoDB 4.2
MongoDB .local San Francisco 2020: Using Client Side Encryption in MongoDB 4.2
MongoDB

MongoDB .local San Francisco 2020: Using MongoDB Services in Kubernetes: any ...
MongoDB .local San Francisco 2020: Using MongoDB Services in Kubernetes: any ...MongoDB .local San Francisco 2020: Using MongoDB Services in Kubernetes: any ...
MongoDB .local San Francisco 2020: Using MongoDB Services in Kubernetes: any ...
MongoDB

MongoDB .local San Francisco 2020: Go on a Data Safari with MongoDB Charts!
MongoDB .local San Francisco 2020: Go on a Data Safari with MongoDB Charts!MongoDB .local San Francisco 2020: Go on a Data Safari with MongoDB Charts!
MongoDB .local San Francisco 2020: Go on a Data Safari with MongoDB Charts!
MongoDB

MongoDB .local San Francisco 2020: From SQL to NoSQL -- Changing Your Mindset
MongoDB .local San Francisco 2020: From SQL to NoSQL -- Changing Your MindsetMongoDB .local San Francisco 2020: From SQL to NoSQL -- Changing Your Mindset
MongoDB .local San Francisco 2020: From SQL to NoSQL -- Changing Your Mindset
MongoDB

MongoDB .local San Francisco 2020: MongoDB Atlas Jumpstart
MongoDB .local San Francisco 2020: MongoDB Atlas JumpstartMongoDB .local San Francisco 2020: MongoDB Atlas Jumpstart
MongoDB .local San Francisco 2020: MongoDB Atlas Jumpstart
MongoDB

MongoDB .local San Francisco 2020: Tips and Tricks++ for Querying and Indexin...
MongoDB .local San Francisco 2020: Tips and Tricks++ for Querying and Indexin...MongoDB .local San Francisco 2020: Tips and Tricks++ for Querying and Indexin...
MongoDB .local San Francisco 2020: Tips and Tricks++ for Querying and Indexin...
MongoDB

MongoDB .local San Francisco 2020: Aggregation Pipeline Power++
MongoDB .local San Francisco 2020: Aggregation Pipeline Power++MongoDB .local San Francisco 2020: Aggregation Pipeline Power++
MongoDB .local San Francisco 2020: Aggregation Pipeline Power++
MongoDB

MongoDB .local San Francisco 2020: A Complete Methodology of Data Modeling fo...
MongoDB .local San Francisco 2020: A Complete Methodology of Data Modeling fo...MongoDB .local San Francisco 2020: A Complete Methodology of Data Modeling fo...
MongoDB .local San Francisco 2020: A Complete Methodology of Data Modeling fo...
MongoDB

MongoDB .local San Francisco 2020: MongoDB Atlas Data Lake Technical Deep Dive
MongoDB .local San Francisco 2020: MongoDB Atlas Data Lake Technical Deep DiveMongoDB .local San Francisco 2020: MongoDB Atlas Data Lake Technical Deep Dive
MongoDB .local San Francisco 2020: MongoDB Atlas Data Lake Technical Deep Dive
MongoDB

MongoDB .local San Francisco 2020: Developing Alexa Skills with MongoDB & Golang
MongoDB .local San Francisco 2020: Developing Alexa Skills with MongoDB & GolangMongoDB .local San Francisco 2020: Developing Alexa Skills with MongoDB & Golang
MongoDB .local San Francisco 2020: Developing Alexa Skills with MongoDB & Golang
MongoDB

MongoDB .local Paris 2020: Realm : l'ingrédient secret pour de meilleures app...
MongoDB .local Paris 2020: Realm : l'ingrédient secret pour de meilleures app...MongoDB .local Paris 2020: Realm : l'ingrédient secret pour de meilleures app...
MongoDB .local Paris 2020: Realm : l'ingrédient secret pour de meilleures app...
MongoDB

MongoDB .local Paris 2020: Upply @MongoDB : Upply : Quand le Machine Learning...
MongoDB .local Paris 2020: Upply @MongoDB : Upply : Quand le Machine Learning...MongoDB .local Paris 2020: Upply @MongoDB : Upply : Quand le Machine Learning...
MongoDB .local Paris 2020: Upply @MongoDB : Upply : Quand le Machine Learning...
MongoDB


More from MongoDB (20)

MongoDB SoCal 2020: Migrate Anything* to MongoDB Atlas
MongoDB SoCal 2020: Migrate Anything* to MongoDB AtlasMongoDB SoCal 2020: Migrate Anything* to MongoDB Atlas
MongoDB SoCal 2020: Migrate Anything* to MongoDB Atlas

MongoDB SoCal 2020: Go on a Data Safari with MongoDB Charts!
MongoDB SoCal 2020: Go on a Data Safari with MongoDB Charts!MongoDB SoCal 2020: Go on a Data Safari with MongoDB Charts!
MongoDB SoCal 2020: Go on a Data Safari with MongoDB Charts!

MongoDB SoCal 2020: Using MongoDB Services in Kubernetes: Any Platform, Devel...
MongoDB SoCal 2020: Using MongoDB Services in Kubernetes: Any Platform, Devel...MongoDB SoCal 2020: Using MongoDB Services in Kubernetes: Any Platform, Devel...
MongoDB SoCal 2020: Using MongoDB Services in Kubernetes: Any Platform, Devel...

MongoDB SoCal 2020: A Complete Methodology of Data Modeling for MongoDB
MongoDB SoCal 2020: A Complete Methodology of Data Modeling for MongoDBMongoDB SoCal 2020: A Complete Methodology of Data Modeling for MongoDB
MongoDB SoCal 2020: A Complete Methodology of Data Modeling for MongoDB

MongoDB SoCal 2020: From Pharmacist to Analyst: Leveraging MongoDB for Real-T...
MongoDB SoCal 2020: From Pharmacist to Analyst: Leveraging MongoDB for Real-T...MongoDB SoCal 2020: From Pharmacist to Analyst: Leveraging MongoDB for Real-T...
MongoDB SoCal 2020: From Pharmacist to Analyst: Leveraging MongoDB for Real-T...

MongoDB SoCal 2020: Best Practices for Working with IoT and Time-series Data
MongoDB SoCal 2020: Best Practices for Working with IoT and Time-series DataMongoDB SoCal 2020: Best Practices for Working with IoT and Time-series Data
MongoDB SoCal 2020: Best Practices for Working with IoT and Time-series Data

MongoDB SoCal 2020: MongoDB Atlas Jump Start
 MongoDB SoCal 2020: MongoDB Atlas Jump Start MongoDB SoCal 2020: MongoDB Atlas Jump Start
MongoDB SoCal 2020: MongoDB Atlas Jump Start

MongoDB .local San Francisco 2020: Powering the new age data demands [Infosys]
MongoDB .local San Francisco 2020: Powering the new age data demands [Infosys]MongoDB .local San Francisco 2020: Powering the new age data demands [Infosys]
MongoDB .local San Francisco 2020: Powering the new age data demands [Infosys]

MongoDB .local San Francisco 2020: Using Client Side Encryption in MongoDB 4.2
MongoDB .local San Francisco 2020: Using Client Side Encryption in MongoDB 4.2MongoDB .local San Francisco 2020: Using Client Side Encryption in MongoDB 4.2
MongoDB .local San Francisco 2020: Using Client Side Encryption in MongoDB 4.2

MongoDB .local San Francisco 2020: Using MongoDB Services in Kubernetes: any ...
MongoDB .local San Francisco 2020: Using MongoDB Services in Kubernetes: any ...MongoDB .local San Francisco 2020: Using MongoDB Services in Kubernetes: any ...
MongoDB .local San Francisco 2020: Using MongoDB Services in Kubernetes: any ...

MongoDB .local San Francisco 2020: Go on a Data Safari with MongoDB Charts!
MongoDB .local San Francisco 2020: Go on a Data Safari with MongoDB Charts!MongoDB .local San Francisco 2020: Go on a Data Safari with MongoDB Charts!
MongoDB .local San Francisco 2020: Go on a Data Safari with MongoDB Charts!

MongoDB .local San Francisco 2020: From SQL to NoSQL -- Changing Your Mindset
MongoDB .local San Francisco 2020: From SQL to NoSQL -- Changing Your MindsetMongoDB .local San Francisco 2020: From SQL to NoSQL -- Changing Your Mindset
MongoDB .local San Francisco 2020: From SQL to NoSQL -- Changing Your Mindset

MongoDB .local San Francisco 2020: MongoDB Atlas Jumpstart
MongoDB .local San Francisco 2020: MongoDB Atlas JumpstartMongoDB .local San Francisco 2020: MongoDB Atlas Jumpstart
MongoDB .local San Francisco 2020: MongoDB Atlas Jumpstart

MongoDB .local San Francisco 2020: Tips and Tricks++ for Querying and Indexin...
MongoDB .local San Francisco 2020: Tips and Tricks++ for Querying and Indexin...MongoDB .local San Francisco 2020: Tips and Tricks++ for Querying and Indexin...
MongoDB .local San Francisco 2020: Tips and Tricks++ for Querying and Indexin...

MongoDB .local San Francisco 2020: Aggregation Pipeline Power++
MongoDB .local San Francisco 2020: Aggregation Pipeline Power++MongoDB .local San Francisco 2020: Aggregation Pipeline Power++
MongoDB .local San Francisco 2020: Aggregation Pipeline Power++

MongoDB .local San Francisco 2020: A Complete Methodology of Data Modeling fo...
MongoDB .local San Francisco 2020: A Complete Methodology of Data Modeling fo...MongoDB .local San Francisco 2020: A Complete Methodology of Data Modeling fo...
MongoDB .local San Francisco 2020: A Complete Methodology of Data Modeling fo...

MongoDB .local San Francisco 2020: MongoDB Atlas Data Lake Technical Deep Dive
MongoDB .local San Francisco 2020: MongoDB Atlas Data Lake Technical Deep DiveMongoDB .local San Francisco 2020: MongoDB Atlas Data Lake Technical Deep Dive
MongoDB .local San Francisco 2020: MongoDB Atlas Data Lake Technical Deep Dive

MongoDB .local San Francisco 2020: Developing Alexa Skills with MongoDB & Golang
MongoDB .local San Francisco 2020: Developing Alexa Skills with MongoDB & GolangMongoDB .local San Francisco 2020: Developing Alexa Skills with MongoDB & Golang
MongoDB .local San Francisco 2020: Developing Alexa Skills with MongoDB & Golang

MongoDB .local Paris 2020: Realm : l'ingrédient secret pour de meilleures app...
MongoDB .local Paris 2020: Realm : l'ingrédient secret pour de meilleures app...MongoDB .local Paris 2020: Realm : l'ingrédient secret pour de meilleures app...
MongoDB .local Paris 2020: Realm : l'ingrédient secret pour de meilleures app...

MongoDB .local Paris 2020: Upply @MongoDB : Upply : Quand le Machine Learning...
MongoDB .local Paris 2020: Upply @MongoDB : Upply : Quand le Machine Learning...MongoDB .local Paris 2020: Upply @MongoDB : Upply : Quand le Machine Learning...
MongoDB .local Paris 2020: Upply @MongoDB : Upply : Quand le Machine Learning...


Recently uploaded

Russian Girls Call Mumbai 🛵🚡9833363713 💃 Choose Best And Top Girl Service And...
Russian Girls Call Mumbai 🛵🚡9833363713 💃 Choose Best And Top Girl Service And...Russian Girls Call Mumbai 🛵🚡9833363713 💃 Choose Best And Top Girl Service And...
Russian Girls Call Mumbai 🛵🚡9833363713 💃 Choose Best And Top Girl Service And...
dream girl

Predicting Test Results without Execution (FSE 2024)
Predicting Test Results without Execution (FSE 2024)Predicting Test Results without Execution (FSE 2024)
Predicting Test Results without Execution (FSE 2024)
andrehoraa

VVIP Girls Call Mumbai 9910780858 Provide Best And Top Girl Service And No1 i...
VVIP Girls Call Mumbai 9910780858 Provide Best And Top Girl Service And No1 i...VVIP Girls Call Mumbai 9910780858 Provide Best And Top Girl Service And No1 i...
VVIP Girls Call Mumbai 9910780858 Provide Best And Top Girl Service And No1 i...
jealousviolet

SAP implementation steps PDF - Zyple Software
SAP implementation steps PDF - Zyple SoftwareSAP implementation steps PDF - Zyple Software
SAP implementation steps PDF - Zyple Software
Zyple Software

SEO Cheat Sheet with Learning Resources by Balti Bloggers.pdf
SEO Cheat Sheet with Learning Resources by Balti Bloggers.pdfSEO Cheat Sheet with Learning Resources by Balti Bloggers.pdf
SEO Cheat Sheet with Learning Resources by Balti Bloggers.pdf
Balti Bloggers

Empowering Businesses with Intelligent Software Solutions - Grawlix
Empowering Businesses with Intelligent Software Solutions - GrawlixEmpowering Businesses with Intelligent Software Solutions - Grawlix
Empowering Businesses with Intelligent Software Solutions - Grawlix
Aarisha Shaikh

Busty Girls Call Mumbai 9930245274 Unlimited Short Providing Girls Service Av...
Busty Girls Call Mumbai 9930245274 Unlimited Short Providing Girls Service Av...Busty Girls Call Mumbai 9930245274 Unlimited Short Providing Girls Service Av...
Busty Girls Call Mumbai 9930245274 Unlimited Short Providing Girls Service Av...
revolutionary575

Vip Girls Call ServiCe Hyderabad 0000000000 Pooja Best High Class Hyderabad A...
Vip Girls Call ServiCe Hyderabad 0000000000 Pooja Best High Class Hyderabad A...Vip Girls Call ServiCe Hyderabad 0000000000 Pooja Best High Class Hyderabad A...
Vip Girls Call ServiCe Hyderabad 0000000000 Pooja Best High Class Hyderabad A...
ashiklo9823

Hotel Management Software Development Company
Hotel Management Software Development CompanyHotel Management Software Development Company
Hotel Management Software Development Company
XongoLab Technologies LLP

Crafting highly scalable and performant Modern Data Platforms
Crafting highly scalable and performant Modern Data PlatformsCrafting highly scalable and performant Modern Data Platforms
Crafting highly scalable and performant Modern Data Platforms
Sameer Paradkar

Il Data Streaming per un’AI real-time di nuova generazione
Il Data Streaming per un’AI real-time di nuova generazioneIl Data Streaming per un’AI real-time di nuova generazione
Il Data Streaming per un’AI real-time di nuova generazione
confluent

Independent Girls Call ServiCe Hyderabad 0000000000 Tanisha Best High Class H...
Independent Girls Call ServiCe Hyderabad 0000000000 Tanisha Best High Class H...Independent Girls Call ServiCe Hyderabad 0000000000 Tanisha Best High Class H...
Independent Girls Call ServiCe Hyderabad 0000000000 Tanisha Best High Class H...
aslasdfmkhan4750

High Girls Call Chennai 000XX00000 Provide Best And Top Girl Service And No1 ...
High Girls Call Chennai 000XX00000 Provide Best And Top Girl Service And No1 ...High Girls Call Chennai 000XX00000 Provide Best And Top Girl Service And No1 ...
High Girls Call Chennai 000XX00000 Provide Best And Top Girl Service And No1 ...
singhlata50dh

PathSpotter: Exploring Tested Paths to Discover Missing Tests (FSE 2024)
PathSpotter: Exploring Tested Paths to Discover Missing Tests (FSE 2024)PathSpotter: Exploring Tested Paths to Discover Missing Tests (FSE 2024)
PathSpotter: Exploring Tested Paths to Discover Missing Tests (FSE 2024)
andrehoraa

A Step-by-Step Guide to Selecting the Right Automated Software Testing Tools.pdf
A Step-by-Step Guide to Selecting the Right Automated Software Testing Tools.pdfA Step-by-Step Guide to Selecting the Right Automated Software Testing Tools.pdf
A Step-by-Step Guide to Selecting the Right Automated Software Testing Tools.pdf
kalichargn70th171

Odoo E-commerce website development guides
Odoo E-commerce website development guidesOdoo E-commerce website development guides
Odoo E-commerce website development guides
jhkdigitalmarketing

Celebrity Girls Call Mumbai 🛵🚡9910780858 💃 Choose Best And Top Girl Service A...
Celebrity Girls Call Mumbai 🛵🚡9910780858 💃 Choose Best And Top Girl Service A...Celebrity Girls Call Mumbai 🛵🚡9910780858 💃 Choose Best And Top Girl Service A...
Celebrity Girls Call Mumbai 🛵🚡9910780858 💃 Choose Best And Top Girl Service A...
norina2645

bangalore Girls call 👀 XXXXXXXXXXX 👀 Rs.9.5 K Cash Payment With Room Delivery
bangalore Girls call  👀 XXXXXXXXXXX 👀 Rs.9.5 K Cash Payment With Room Deliverybangalore Girls call  👀 XXXXXXXXXXX 👀 Rs.9.5 K Cash Payment With Room Delivery
bangalore Girls call 👀 XXXXXXXXXXX 👀 Rs.9.5 K Cash Payment With Room Delivery
sunilverma7884

Applitools Autonomous 2.0 Sneak Peek.pdf
Applitools Autonomous 2.0 Sneak Peek.pdfApplitools Autonomous 2.0 Sneak Peek.pdf
Applitools Autonomous 2.0 Sneak Peek.pdf
Applitools

Amadeus Travel API, Amadeus Booking API, Amadeus GDS
Amadeus Travel API, Amadeus Booking API, Amadeus GDSAmadeus Travel API, Amadeus Booking API, Amadeus GDS
Amadeus Travel API, Amadeus Booking API, Amadeus GDS
aadhiyaeliza


Recently uploaded (20)

Russian Girls Call Mumbai 🛵🚡9833363713 💃 Choose Best And Top Girl Service And...
Russian Girls Call Mumbai 🛵🚡9833363713 💃 Choose Best And Top Girl Service And...Russian Girls Call Mumbai 🛵🚡9833363713 💃 Choose Best And Top Girl Service And...
Russian Girls Call Mumbai 🛵🚡9833363713 💃 Choose Best And Top Girl Service And...

Predicting Test Results without Execution (FSE 2024)
Predicting Test Results without Execution (FSE 2024)Predicting Test Results without Execution (FSE 2024)
Predicting Test Results without Execution (FSE 2024)

VVIP Girls Call Mumbai 9910780858 Provide Best And Top Girl Service And No1 i...
VVIP Girls Call Mumbai 9910780858 Provide Best And Top Girl Service And No1 i...VVIP Girls Call Mumbai 9910780858 Provide Best And Top Girl Service And No1 i...
VVIP Girls Call Mumbai 9910780858 Provide Best And Top Girl Service And No1 i...

SAP implementation steps PDF - Zyple Software
SAP implementation steps PDF - Zyple SoftwareSAP implementation steps PDF - Zyple Software
SAP implementation steps PDF - Zyple Software

SEO Cheat Sheet with Learning Resources by Balti Bloggers.pdf
SEO Cheat Sheet with Learning Resources by Balti Bloggers.pdfSEO Cheat Sheet with Learning Resources by Balti Bloggers.pdf
SEO Cheat Sheet with Learning Resources by Balti Bloggers.pdf

Empowering Businesses with Intelligent Software Solutions - Grawlix
Empowering Businesses with Intelligent Software Solutions - GrawlixEmpowering Businesses with Intelligent Software Solutions - Grawlix
Empowering Businesses with Intelligent Software Solutions - Grawlix

Busty Girls Call Mumbai 9930245274 Unlimited Short Providing Girls Service Av...
Busty Girls Call Mumbai 9930245274 Unlimited Short Providing Girls Service Av...Busty Girls Call Mumbai 9930245274 Unlimited Short Providing Girls Service Av...
Busty Girls Call Mumbai 9930245274 Unlimited Short Providing Girls Service Av...

Vip Girls Call ServiCe Hyderabad 0000000000 Pooja Best High Class Hyderabad A...
Vip Girls Call ServiCe Hyderabad 0000000000 Pooja Best High Class Hyderabad A...Vip Girls Call ServiCe Hyderabad 0000000000 Pooja Best High Class Hyderabad A...
Vip Girls Call ServiCe Hyderabad 0000000000 Pooja Best High Class Hyderabad A...

Hotel Management Software Development Company
Hotel Management Software Development CompanyHotel Management Software Development Company
Hotel Management Software Development Company

Crafting highly scalable and performant Modern Data Platforms
Crafting highly scalable and performant Modern Data PlatformsCrafting highly scalable and performant Modern Data Platforms
Crafting highly scalable and performant Modern Data Platforms

Il Data Streaming per un’AI real-time di nuova generazione
Il Data Streaming per un’AI real-time di nuova generazioneIl Data Streaming per un’AI real-time di nuova generazione
Il Data Streaming per un’AI real-time di nuova generazione

Independent Girls Call ServiCe Hyderabad 0000000000 Tanisha Best High Class H...
Independent Girls Call ServiCe Hyderabad 0000000000 Tanisha Best High Class H...Independent Girls Call ServiCe Hyderabad 0000000000 Tanisha Best High Class H...
Independent Girls Call ServiCe Hyderabad 0000000000 Tanisha Best High Class H...

High Girls Call Chennai 000XX00000 Provide Best And Top Girl Service And No1 ...
High Girls Call Chennai 000XX00000 Provide Best And Top Girl Service And No1 ...High Girls Call Chennai 000XX00000 Provide Best And Top Girl Service And No1 ...
High Girls Call Chennai 000XX00000 Provide Best And Top Girl Service And No1 ...

PathSpotter: Exploring Tested Paths to Discover Missing Tests (FSE 2024)
PathSpotter: Exploring Tested Paths to Discover Missing Tests (FSE 2024)PathSpotter: Exploring Tested Paths to Discover Missing Tests (FSE 2024)
PathSpotter: Exploring Tested Paths to Discover Missing Tests (FSE 2024)

A Step-by-Step Guide to Selecting the Right Automated Software Testing Tools.pdf
A Step-by-Step Guide to Selecting the Right Automated Software Testing Tools.pdfA Step-by-Step Guide to Selecting the Right Automated Software Testing Tools.pdf
A Step-by-Step Guide to Selecting the Right Automated Software Testing Tools.pdf

Odoo E-commerce website development guides
Odoo E-commerce website development guidesOdoo E-commerce website development guides
Odoo E-commerce website development guides

Celebrity Girls Call Mumbai 🛵🚡9910780858 💃 Choose Best And Top Girl Service A...
Celebrity Girls Call Mumbai 🛵🚡9910780858 💃 Choose Best And Top Girl Service A...Celebrity Girls Call Mumbai 🛵🚡9910780858 💃 Choose Best And Top Girl Service A...
Celebrity Girls Call Mumbai 🛵🚡9910780858 💃 Choose Best And Top Girl Service A...

bangalore Girls call 👀 XXXXXXXXXXX 👀 Rs.9.5 K Cash Payment With Room Delivery
bangalore Girls call  👀 XXXXXXXXXXX 👀 Rs.9.5 K Cash Payment With Room Deliverybangalore Girls call  👀 XXXXXXXXXXX 👀 Rs.9.5 K Cash Payment With Room Delivery
bangalore Girls call 👀 XXXXXXXXXXX 👀 Rs.9.5 K Cash Payment With Room Delivery

Applitools Autonomous 2.0 Sneak Peek.pdf
Applitools Autonomous 2.0 Sneak Peek.pdfApplitools Autonomous 2.0 Sneak Peek.pdf
Applitools Autonomous 2.0 Sneak Peek.pdf

Amadeus Travel API, Amadeus Booking API, Amadeus GDS
Amadeus Travel API, Amadeus Booking API, Amadeus GDSAmadeus Travel API, Amadeus Booking API, Amadeus GDS
Amadeus Travel API, Amadeus Booking API, Amadeus GDS


Getting Started with Geospatial Data in MongoDB

  • 1. Getting Started with Geospatial Data in MongoDB Buzz Moschetti Enterprise Architect buzz.moschetti@mongodb.com @buzzmoschetti
  • 2. 2 Agenda • What is MongoDB? • What does “geospatial capabilities” mean? • GeoJSON • Combining GeoJSON with non-geo data • APIs and Use Cases • Comparison to OGC (Open Geospatial Consortium) • Indexing • Using Geo Capabilities for non-Geo Things • Esri and shapefiles
  • 3. 3 MongoDB: The Post-Relational General Purpose Database Document Data Model Open- Source Fully Featured High Performance Scalable { name: “John Smith”, pfxs: [“Dr.”,”Mr.”], address: “10 3rd St.”, phone: { home: 1234567890, mobile: 1234568138 } }
  • 4. Nexus Architecture Scalability & Performance Always On, Global Deployments Flexibility Expressive Query Language & Secondary Indexes Strong Consistency Enterprise Management & Integrations
  • 5. 5 MongoDB Company Overview ~800 employees 2500+ customers Over $311 million in funding Offices in NY & Palo Alto and across EMEA, and APAC
  • 6. 6 What is “Geo”? At least 4 levels of capability
  • 7. 7 The Geo Stack Efficiently store, query, and index arbitrary points, lines and polygons in the DB
  • 8. 8 The Geo Stack Platform for data analysis of peer data (trades/house value/population/sales/widgets) grouped by geo data Efficiently store, query, and index arbitrary points, lines and polygons in the DB
  • 9. 9 The Geo Stack Graphical rendering of geo shapes on a map Platform for data analysis of peer data (trades/house value/population/sales/widgets) grouped by geo data Efficiently store, query, and index arbitrary points, lines and polygons in the DB
  • 10. 10 The Geo Stack Application(s) to browse and manipulate all the data Graphical rendering of geo shapes on a map Platform for data analysis of peer data (trades/house value/population/sales/widgets) grouped by geo data Efficiently store, query, and index arbitrary points, lines and polygons in the DB
  • 11. 11 Important: Sometimes there is NO Map • Geo stack must support geo functions WITHOUT a Map • Offline reporting • “Nightly fleet management report” • “Distributor loss by assigned area” • Compute/analytical processing • Dynamic polygon generation • Weather catastrophe simulation • Other geo-filtering as input to analytics
  • 12. 12 MongoDB: The Data “Base” Application(s) to browse and visualize Graphical rendering of geo shapes on a map Platform for data analysis of peer data (trades/value/population/sales/widgets) grouped by geo data Efficiently store, query, and index arbitrary points, lines, and polygons in the DB Peer Data Geo Data
  • 13. 13 One Persistor for All Applications & Use Cases Google Map APIs Browser / Mobile Other Javascript Peer Data Geo Data MongoDB node.js Driver MongoDB python Driver Quant / Analytics with pandas Web Service Code MongoDB Java Driver Nightly Reporting Enterprise Integration MongoDB BI Connector Tableau ClickView PowerBI Talend Mule Informatica
  • 14. 14 Balanced Reporting • Most other NoSQL DBs do not have this capability • Oracle, Postgres, MySQL, SQLServer do offer it and subscribe to Open GeoS Consortium (OGC) standards
  • 15. 15 MongoDB data model is the major difference MongoDB: Simple, parse-free, type-correct APIs and data to manipulate and interrogate geo shapes a.k.a. arrays (of arrays (of arrays)) OpenGIS: Piles of “ST_” functions: http://postgis.net/docs/reference.html#Geometry_Accessors SELECT ST_MakePolygon( ST_GeomFromText( 'LINESTRING(75.15 29.53,77 29,77.6 29.5, 75.15 29.53)'));
  • 17. 17 Legacy: 2D points { name: {f: “Buzz”, l: “Moschetti”}, favoritePets: [ “dog”, “cat” ], house: [ -95.12345, 43.23423 ] }
  • 18. 18 Better: GeoJSON { name: {f: “Buzz”, l: “Moschetti”}, favoritePets: [ “dog”, “cat” ], house: { type: “Point”, coordinates: [ -95.12345, 43.23423 ] } }
  • 19. 19 Better: GeoJSON { name: “Superfund132”, location: { type: “Polygon”, coordinates: [ [ [-95.12345, 43.2342],[-95.12456,43.2351],…] [ [-92.8381, 43.75], … ] // “hole” ] } }
  • 20. 20 The GeoJSON Family { type: “Point”, “MultiPoint”, “LineString”,”MultiLineString”, “Polygon”, “MultiPolygon” coordinates: [ specific to type ] } { type: “GeometryCollection” geometries: [ { type: (one of above), coordinates: [ . . . ] } ] NO COMPUTED SHAPES (Circle, Arc, Box, etc.) We use the WGS84 standard: http://spatialreference.org/ref/epsg/4326/
  • 21. 21 MongoDB Data Types are Geo-friendly var poly = [ [ [-95.12345,43.2342],[-95.12345,43.2351], [-95.12211,43.2351],[-95.12211,43.2342], [-95.12345,43.2342] // close the loop! ] ]; db.myCollection.insert( {name: {f: "Buzz", l: "Moschetti"}, favoritePets: ["dog", "cat"], geo: { type: "Polygon“, coordinates: poly } }));
  • 22. 22 … even with Java Document doc = new Document(); doc.put("name", ”Superfund132"); List ring = new ArrayList(); addPoint(ring, -95.12345, 43.2342); addPoint(ring, -95.12345, 43.2351); addPoint(ring, -95.12211, 43.2351); addPoint(ring, -95.12211, 43.2342); addPoint(ring, -95.12345, 43.2342); List poly = new ArrayList(); poly.add(ring); Map mm = new HashMap(); mm.put("type", "Polygon"); mm.put("coordinates", poly); doc.put("geo", mm); coll.insertOne(doc); static void addPoint(List ll, double lng, double lat) { List pt = new ArrayList(); pt.add(lng); pt.add(lat); ll.add(pt); }
  • 23. 23 All Types Are Preserved Correctly Document doc = coll.find().first(); recursiveWalk(doc); name: java.lang.String: Superfund132 geo: com.mongodb.BasicDBObject type: java.lang.String: Polygon coordinates: com.mongodb.BasicDBList 0: com.mongodb.BasicDBList 0: com.mongodb.BasicDBList 0: java.lang.Double: -95.12345 1: java.lang.Double: 43.2342 1: com.mongodb.BasicDBList 0: java.lang.Double: -95.12345 1: java.lang.Double: 43.2351 2: com.mongodb.BasicDBList 0: java.lang.Double: -95.12211 1: java.lang.Double: 43.2351
  • 24. 24 Comparison to “Good” PostGIS import org.postgis.PGgeometry; // extended from org.postgresql.util.PGobject ((org.postgresql.Connection)conn).addDataType("geometry","org.postgis.PGgeometry" ) String sql = "select geom from someTable”; ResultSet r = stmt.executeQuery(sql); while( r.next() ) { PGgeometry geom = (PGgeometry)r.getObject(1); if( geom.getType() = Geometry.POLYGON ) { Polygon pl = (Polygon)geom.getGeometry(); for( int r = 0; r < pl.numRings(); r++) { LinearRing rng = pl.getRing(r); . . . } }
  • 25. 25 Comparison to most OpenGIS String sql = "select ST_AsText(geom) from someTable”; ResultSet r = stmt.executeQuery(sql); while( r.next() ) { String wkt = r.getString(1); // wkt is ”POLYGON((0 0,0 1,1 1,1 0,0 0))” // http://en.wikipedia.org/wiki/Well-known_text // Now we have to parse the string into // an array of array of doubles. // Don’t want to introduce a 3rd party dependency… // So . . . We write our own parser. }
  • 26. 26 Checkpoint We have data in and out of the DB using basic operations (insert and find) Now we need to make it performant!
  • 27. 27 Indexing collection.createIndex({loc:”2d”}) When to use: • Your database has legacy location data from MongoDB 2.2 or earlier • You do not intend to store any location data as GeoJSON objects • “Special Use Cases” e.g. arbitrary two numeric dimension indexing collection.createIndex({loc:”2dsphere”}) When to use: • Supports all GeoJSON objects and legacy [x,y] pairs collection.createIndex({loc:”geoHaystack”}) When to use: • Special small area flat (planar) lookup optimization
  • 28. 28 Indexing collection.createIndex({loc:”2d”}) When to use: • Your database has legacy location data from MongoDB 2.2 or earlier • You do not intend to store any location data as GeoJSON objects • “Special Use Cases” e.g. arbitrary two numeric dimension indexing collection.createIndex({loc:”2dsphere”}) When to use: • Supports all GeoJSON objects and legacy [x,y] pairs collection.createIndex({loc:”geoHaystack”}) When to use: • Special small area flat (planar) lookup optimization
  • 29. 29 find()/$match and Indexing Operator Geometry Arg Type 2d 2dsphere $geoWithin $box,$center,$polygon Y N $geometry: { type, coordinates } N Y $centerSphere: [ [x,y], radians ] Y Y $geoIntersects $geometry only N Y $near,$nearSphere [x,y] R - (output sorted by distance) $geometry: {type, coordinates} - R + $minDistance N Y + $maxDistance Y Y Y = will assist N = will not assist R = REQUIRED Syntax helper: find(“loc”:{$geoWithin: {$box: [ [x0,y0], [x1,y2] }}); find(“loc”:{$geoWithin: {$geometry: { type: “Polygon”, coordinates: [ …. ] }}} );
  • 30. 30 Aggregation Framework: $geoNear Option 2D 2dsphere $geoNear (output sorted by distance) near: { type: “Point”, coordinates } - R - and spherical:true near: [ x, y ] R (or) R query: { expression INCL geo find() on previous page EXCEPT $near} N N Y = will assist N = will not assist R = REQUIRED Important Considerations: 1. You can only use $geoNear as the first stage of a pipeline. 2. You must include the distanceField option. 3. The collection must have only one geospatial index: one 2d index or one 2dsphere index. 4. You do not need to specify which field in the documents hold the coordinate pair or point. Because $geoNear requires that the collection have a single geospatial index, $geoNear implicitly uses the indexed field.
  • 31. 31 Use Cases How do we bring data representation, fast lookup, and . . .
  • 32. 32 Case #1: Find Things in a Given Area + More • Docs contain Points (or possibly “small” polygons) • $geoWithin db.site.aggregate([ {$match: { "loc": { $geoWithin: { $geometry: { type: "Polygon", coordinates: [ coords ] }}} ,"portfolio_id": portid ,“insuredValue“: {$gt: 1000000} ,“insuredDate“: {$gt: new ISODate(„2016-01-01“) }} ,{$bucket: {groupBy: „$insuredValue“, boundaries: [ 1000000, 2000000, 5000000, 10000000, 20000000, Infinity] }} . . .
  • 33. 33 Case #2: Find Things in an Area Stored in DB • Get the shape from the “shapes” collection via query: db.shapes.findOne({predicate},{theShape:1}); • Turn around and query the target collection, e.g. buildingSites with shape: db.buildingSites.find({loc:{$geoWithin: theShape}})
  • 34. 34 Case #3: Find Things Closest to where I am db.buildingSites.aggregate([{$geoNear: { point … }}); • Results returned already in sorted order by closeness
  • 35. 35 Case #3.5: Find Things Closest to where I am but within some bounds • db.buildingSites.aggregate([ {$geoNear: { query: { “loc”: {$geoWithin: {$centerSphere: … }} } (or) query: { “loc”: {$geoWithin: {$geometry: GeoJSON }} } }} ])
  • 36. 36 When the Database isn’t enough
  • 37. 37 When the Database isn’t enough • VERY fast intersection/within for many objects given probes at high velocity (10000s/sec). • Geo manipulation: unions, deltas, layering • Dynamic/programmatic geo construction • Advanced features: smoothing, simplifiers, centroids, …
  • 38. 38 You Need Three Things • Basic geo objects • Geo operators like intersects, within, etc. • Algos and smoothers, etc.
  • 39. 39 com.vividsolutions.jts Map m = (Map) dbo.get("loc"); // get a GeoJSON object from MongoDB List coords = (List) m.get("coordinates"); List outerRing = (List) coords.get(0); // polygon is array of array of pts CoordinateSequence pseq = new CoordinateGeoJSONSequence(outerRing, true); LinearRing outerlr = new LinearRing(pseq, gf); int numHoles = coords.size() - 1; // -1 to skip outer ring; LinearRing[] holes = null; if(numHoles > 0) { holes = new LinearRing[numHoles]; for(int k = 0; k < numHoles; k++) { List innerRing = (List) coords.get(k+1); // +1 adj for outer ring CoordinateSequence psx = new CoordinateGeoJSONSequence(innerRing, true); holes[k] = new LinearRing(psx, gf); } } Polygon poly1 = new Polygon(outerlr, holes, gf); // ok if holes was null Point pt1 = new Point(pseq2, gf); boolean a = pt1.intersects(poly1); Geometry simplified = TopologyPreservingSimplifier.simplify(poly1, tolerance);
  • 40. 40 The Ecosystem • OpenGeo runs over MongoDB! http://suite.opengeo.org/docs/latest/dataadmin/mongodb/index.html • BoundlessGeo: Commerical support for OpenGeo over MongoDB * Provides top 2 tiers (viz, analysis) * https://boundlessgeo.com
  • 41. 41 Geo Capabilities beyond “Simple Geo”
  • 42. 42 Geo as Date Range { who: ‘john’ where: ‘mongodb’ what: ‘lightning talk’ start: ISODate(“2016-06-30T15:00:00”) end: ISODate(“2016-06-30T15:05:00”) } What events were happening at 15:03? collection.find({ start : { $lte:ISODate(“2016-06-30T15:05:03”)}, end: { $gte:ISODate(“2016-06-30T15:05:03”)} })
  • 43. 43 Geo as Date Range • Ranges on 2 attributes – Two BTree walks (intersection) • Assuming time can be anywhere in range of records, index walk is average 50% of index • Test: Macbook Pro, i5, 16GB RAM, data fits in WT Cache easily. Warmed up. Average of 100 runs 694ms /query using index 487ms /query – COLLSCAN!
  • 44. (StartDate,EndDate)  Range Type using Geo LineString “Query” longitude = t Lat=“quantized”variable 0 1 2 { who: ‘john’ where: ‘mongodb’ what: ‘lightning talk’ start: ISODate(“2016-06-30T15:00:00”) end: ISODate(“2016-06-30T15:05:00”) se_equiv: { type: “LineString”, coordinates: [[ -123.1232, 1], [-121.6253, 1]] }
  • 45. 45 Over 10X performance improvement! start2 = (((start / yearsecs) - 45) *90) – 90 end2 = (((end / yearsecs) - 45) *90) – 90 event = { type: "LineString", coordinates: [ [ start2, 1 ], [end2, 1 ] ] } // dx = is the LineString “query” query = { g: { $geoIntersects: { $geometry: { type: "LineString", coordinates: [ [ dx, 0 ], [dx, 2 ] ] } } } } 45ms! 
  • 46. 46 Mr. Smiley db.participatingVendors.aggregate([ // Stage 1: The Bounding Box {$match: { "loc": { $geoWithin: { $geometry: { type: "Polygon", coordinates: mapBoundingBox}}} }} // Stage 2: Compute distance from Mr. Smiley to the points: Pythagorean theorem: ,{$addFields: {dist: {$sqrt: {$add: [ {$pow:[ {$subtract: [ {$arrayElemAt:[ "$loc.coordinates",0]}, mslng]} , 2]} ,{$pow:[ {$subtract:[ {$arrayElemAt:[ "$loc.coordinates", 1]}, mslat]} , 2]} ]} }}} // Stage 3: If the distance between points is LTE the sum of the radii, then // Mr. Smiley's circle intersects that of the participant: // Project 0 (no touch) or 1 (touch) ,{$addFields: {"touch": {$cond: [ {$lte: [ {$add: [ "$promoRadius", msr ]}, "$dist" ]}, 0, 1 ]}}} ,{$match: {"touch": 1}} ]); // Assume Mr. Smiley has these params: var mslng = -90.00; var mslat = 42.00; var msr = 0.005; // ~1500 ft radius around him
  • 47. 47 The Pusher var pts = [ [-74.01,40.70], [-73.99,40.71], . . .]; db.foo.insert({_id:1, loc: { type:"LineString", coordinates: [ pts[0], pts[1] ]}}); // Push points onto LineString to "extend it” in an index optimized way! for(i = 2; i < pts.length; i++) { db.foo.update({_id:1},{$push: {"loc.coordinates”: pts[i]}}); // Perform other functions, e.g. c=db.foo.find({loc: {$geoIntersects: {$geometry: { type: ”Polygon", coordinates: … } } }); }
  • 48. 48 Perimeter of Simple Polygon > db.foo.insert({_id:1, "poly": [ [0,0], [2,12], [4,0], [2,5], [0,0] ] }); > db.foo.insert({_id:2, "poly": [ [2,2], [5,8], [6,0], [3,1], [2,2] ] }); > db.foo.aggregate([ {$project: {"conv": {$map: { input: "$poly", as: "z", in: { x: {$arrayElemAt: ["$$z”,0]}, y: {$arrayElemAt: ["$$z”,1]} ,len: {$literal: 0} }}}}} ,{$addFields: {first: {$arrayElemAt: [ "$conv", 0 ]} }} ,{$project: {"qqq": {$reduce: { input: "$conv", initialValue: "$first", in: { x: "$$this.x”, y: "$$this.y" ,len: {$add: ["$$value.len", // len = oldlen + newLen {$sqrt: {$add: [ {$pow:[ {$subtract:["$$value.x","$$this.x"]}, 2]} ,{$pow:[ {$subtract:["$$value.y","$$this.y"]}, 2]} ] }} ] } }} ,{$project: {"len": "$qqq.len"}} { "_id" : 1, “len" : 35.10137973546188 } { "_id" : 2, "len" : 19.346952903339393 }
  • 49. 49 Geospatial = 2D Numeric Indexable Space Find all branches close to my location: target = [ someLatitude, someLongitude ]; radians = 10 / 3963.2; // 10 miles db.coll.find({"location": { $geoWithin : { $center : [ target, radians ] }}}); Find nearest investments on efficient frontier: target = [ risk, reward ]; closeness = someFunction(risk, reward); db.coll.find({”investmentValue": { $geoWithin : { $center : [ target, closeness]}}});
  • 50. 50 Basic Tips & Tricks • We use [long,lat], not [lat,long] like Google Maps • Use 2dsphere for geo; avoid legacy $box/$circle/$polygon • Use 2d for true 2d numeric hacks • 5 digits beyond decimal is accurate to 1.1m: • var loc = [ -92.12345, 42.56789] // FINE • var loc = [ -92.123459261145, 42.567891378902] // ABSURD • $geoWithin and $geoIntersects do not REQUIRE index • Remember to close loops (it’s GeoJSON!)
  • 51. 51 esri-related Tips & Tricks • Shapefiles are everywhere; google shapefile <whatever> • Crack shapefiles to GeoJSON with python pyshp module import shapefile import sys from json import dumps reader = shapefile.Reader(sys.argv[1]) field_names = [field[0] for field in reader.fields[1:] ] buffer = [] for sr in reader.shapeRecords(): buffer.append(dict(geometry=sr.shape.__geo_interface__, properties=dict(zip(field_names, sr.record)))) sys.stdout.write(dumps({"type": "FeatureCollection”, "features": buffer}, indent=2) + "n”)
  • 52. Q & A
  • 53. Thank You! Buzz Moschetti Enterprise Architect buzz.moschetti@mongodb.com @buzzmoschetti
  • 54. 54 Agenda • What does geospatial capabilities mean? • The "levels": DB with geo types, rendering, analytics • MongoDB brings together geo AND non-geo data • Geo Data model • GeoJSON • Combining GeoJSON with non-geo data • APIs and Use Cases • Looking up things contained in a polygon • Finding things near a point • Summary of geo ops e.g. $center • $geoNear and the agg framework • The power of the document model and MongoDB APIs • Arrays and rich shapes as first class types • Comparison to Postgres (PostGIS) Indexing • Geospatial queries do not necessarily require an index • 2d vs. 2dsphere • Geo stacks and the Ecosystem • MongoDB and OpenGIS and OpenGEO • Google Maps • MEAN • A Sampling of Geo Solutions • Mr. Smiley, etc. • Integration with esri and shapefiles • esri shapefile cracking
  • 55. 55 Clever Hacks • John Page date thing • Mr. Smiley • Wildfire • Push pts on a LineString and check for intersects • Perimeter & Area of simple polygon • makeNgon
  • 56. 56 MongoDB handles your data + geo Google handles the maps Our Drivers Google Map APIs Chrome Other Javascript Your Data GeoJSON • Organization unit is document, then collection • Geo data can contain arbitrary peer data or higher scope within doc • Proper handling of int, long, double, and decimal128 • Dates are REAL datetimes • Uniform indexability and querability across geo and “regular” data Your Server-side code
