Extending the Platform
Kenny Bastani
@kennybastani
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ 2
@kennybastani
Spring Developer Advocate
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
What makes an application
legacy?
3
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
What makes an application legacy?
• How fast can you make changes to the application and deliver it into
production?
• How much work is it to upgrade the application framework?
4
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
Legacy is an architecture problem
5
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
Monolith
6
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ 7
Microservices…
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
If we're creating 10x the number of apps,
we're creating 10x the technical debt
8
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
What does your microservice architecture look
like in 10 years?
9
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
If you have to implement the same thing
in every application, it should be provided
by the platform as a service
10
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
Do this successfully, and the only thing is left
is the valuable business logic
11
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
The two road blocks of cloud native
• Legacy applications
• Legacy culture
12
Legacy culture looks
like this
Legacy applications look like this
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
How do we do better?
15
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
Platform Engineering
16
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
Platform Engineering
• Everything that sits around your applications is vital to supporting the health of
your applications
• Unfortunately, anything that is not business logic is going to make it harder to
upgrade your application later
• Platform engineering is the art of automating standards in an application
architecture by reducing redundancy across applications
17
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
Redundancy in code creates technical debt.
In microservices, multiply that debt by the
number of apps
18
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
Spring Boot + Cloud Foundry Service Brokers
19
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
Backing services
20
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
Online Store Example
21
Extending the Platform with Spring Boot and Cloud Foundry
Backing services
Microservices
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
Spring Boot
24
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
Platform engineers can take an opinionated
view on how application developers will
consume services
25
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
Cloud Foundry Service Brokers
• The Cloud Foundry marketplace is similar to the idea of starter projects in Spring
Boot
• Services can be offered on Cloud Foundry and bound to your application
deployments
• These marketplace services can be seen as backing services for your
applications
26
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ 27
Microservices…
Backing services
Microservices
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
Amazon S3 Service Broker
• The demo for this presentation is going to create an Amazon S3 service broker
• We’ll release the broker to PCF Dev
• Extend Spring Boot to automatically consume service instances from the
broker
• Deploy Spring Boot S3 browser that uses a starter project to connect to
Amazon S3
29
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
Cloud Controller
• The Cloud Controller is the contract that Cloud Foundry exposes over HTTP as a
REST API
• We can create service brokers that implement expectations from this contract to
allow CF and other broker applications to talk to each other
30
Extending the Platform with Spring Boot and Cloud Foundry
Extending the Platform with Spring Boot and Cloud Foundry
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
Spring Boot Service Broker Template
• The Spring team maintains an example project that provides the boiler plate for
creating custom service brokers using Spring Boot
• https://github.com/spring-cloud/spring-cloud-cloudfoundry-service-broker
33
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
Implementing the service contracts
• Service Catalog
• Service Instances
• Service Bindings
34
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
Service Catalog
35
Extending the Platform with Spring Boot and Cloud Foundry
Extending the Platform with Spring Boot and Cloud Foundry
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
Service Instances
• Each method in the interface represents the implementation of a repository
pattern
• Controls the lifecycle of resources on AWS that provide exclusive access to a
S3 bucket
• The two resources that we will manage are:
• S3 buckets
• IAM users
38
Extending the Platform with Spring Boot and Cloud Foundry
Extending the Platform with Spring Boot and Cloud Foundry
Extending the Platform with Spring Boot and Cloud Foundry
Extending the Platform with Spring Boot and Cloud Foundry
Extending the Platform with Spring Boot and Cloud Foundry
Extending the Platform with Spring Boot and Cloud Foundry
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
Service Bindings
• The goal of the Amazon S3 Broker is to create S3 buckets that can be
automatically bound to an application
• Further, we want to make the service as easy to consume in a cloud native
environment using Spring Boot starter projects to auto-configure the connection
• The result of this is that a service binding will attach to a Cloud Foundry
deployment and inject the environment variables into the application’s container
• Our Spring Boot application will look for those environment variables at runtime
and automatically configure an S3 connection
45
Extending the Platform with Spring Boot and Cloud Foundry
Extending the Platform with Spring Boot and Cloud Foundry
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
Releasing the Service Broker
• There are multiple options for releasing service brokers
• Deploy as a CF app
• Release with BOSH
48
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
Why should we use BOSH to release a service broker
instead of deploying the application with Cloud Foundry?
49
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
It depends on the virtualized compute
resources you intend to manage with your
custom broker
50
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
When to use BOSH
• When you need to orchestrate resources with the IaaS provider that your CF
deployment uses
• Virtual machines
• Network resources
• BOSH provides a director API you can use to manage IaaS resources
• Portable with different IaaS providers that have a BOSH CPI
51
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
When not to use BOSH
• When you do not need to manage resources using the IaaS
• Example:
• Amazon S3
• Basically any AWS service that has an SDK
• Sometimes we just want to wrap another cloud service in a service broker, and
that is OK
52
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
Releasing with Cloud Foundry
• Let’s jump into code and release the S3 service broker as a CF deployment
53
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
Release steps
• Create MySQL database as a service binding for the S3 broker
• Build and push the S3 broker app
• Bind Amazon AWS credentials as environment variables
• Restage the S3 broker
• Create service broker using CF CLI
• Enable marketplace access to S3 broker
• Create new service instance named s3-service
54
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
Extending Spring Boot
• We can create a starter project that includes an Amazon S3 template for
consuming S3 service instances
• All we need to do is to include the Amazon S3 starter project as a dependency
55
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
Custom Spring Boot starter projects
• We need to create two project modules
• Auto-configuration project with the client libraries to consume a service
instance (Amazon S3 Template)
• Basic starter dependency project that includes the auto-configuration
project using Maven
56
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
Conclusion
57
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
Platforms are forever
58
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
Build value into the platform and reduce
redundancies early in microservice
architectures
59
Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
Learn More. Stay Connected.
Thanks!
@kennybastani on Twitter
@springcentral
spring.io/blog
@pivotal
pivotal.io/blog
@pivotalcf
http://engineering.pivotal.io

More Related Content

What's hot

Cloud Native Application
Cloud Native ApplicationCloud Native Application
Cloud Native Application
VMUG IT

2015 cloud trend and cloud DR
2015 cloud trend and cloud DR2015 cloud trend and cloud DR
2015 cloud trend and cloud DR
bizmerce

Evolving to Cloud-Native - Anand Rao
Evolving to Cloud-Native - Anand RaoEvolving to Cloud-Native - Anand Rao
Evolving to Cloud-Native - Anand Rao
VMware Tanzu

Dipping Your Toes Into Cloud Native Application Development
Dipping Your Toes Into Cloud Native Application DevelopmentDipping Your Toes Into Cloud Native Application Development
Dipping Your Toes Into Cloud Native Application Development
Matthew Farina

CF SUMMIT: Partnerships, Business and Cloud Foundry
CF SUMMIT: Partnerships, Business and Cloud FoundryCF SUMMIT: Partnerships, Business and Cloud Foundry
CF SUMMIT: Partnerships, Business and Cloud Foundry
Nima Badiey

LIVE DEMO: Pivotal Cloud Foundry
LIVE DEMO: Pivotal Cloud FoundryLIVE DEMO: Pivotal Cloud Foundry
LIVE DEMO: Pivotal Cloud Foundry
VMware Tanzu

Pivotal Cloud Foundry: A Technical Overview
Pivotal Cloud Foundry: A Technical OverviewPivotal Cloud Foundry: A Technical Overview
Pivotal Cloud Foundry: A Technical Overview
VMware Tanzu

Introduction to Cloud Native Computing
Introduction to Cloud Native ComputingIntroduction to Cloud Native Computing
Introduction to Cloud Native Computing
Saju Thomas

Cloud Event Driven Architectures with Spring Cloud Stream 2.0 - Oleg Zhurakousky
Cloud Event Driven Architectures with Spring Cloud Stream 2.0 - Oleg ZhurakouskyCloud Event Driven Architectures with Spring Cloud Stream 2.0 - Oleg Zhurakousky
Cloud Event Driven Architectures with Spring Cloud Stream 2.0 - Oleg Zhurakousky
VMware Tanzu

Microservices Best Practices
Microservices Best PracticesMicroservices Best Practices
Microservices Best Practices
Aliasgar Muchhala

Agile integration: Decomposing the monolith
Agile integration: Decomposing the monolithAgile integration: Decomposing the monolith
Agile integration: Decomposing the monolith
Judy Breedlove

micro services architecture (FrosCon2014)
micro services architecture (FrosCon2014)micro services architecture (FrosCon2014)
micro services architecture (FrosCon2014)
smancke

LIVE DEMO: Pivotal Cloud Foundry
LIVE DEMO: Pivotal Cloud FoundryLIVE DEMO: Pivotal Cloud Foundry
LIVE DEMO: Pivotal Cloud Foundry
VMware Tanzu

How to Overcome Data Challenges When Refactoring Monoliths to Microservices
How to Overcome Data Challenges When Refactoring Monoliths to MicroservicesHow to Overcome Data Challenges When Refactoring Monoliths to Microservices
How to Overcome Data Challenges When Refactoring Monoliths to Microservices
VMware Tanzu

Continuous Delivery de vos applications dans un environnement multi-cloud et ...
Continuous Delivery de vos applications dans un environnement multi-cloud et ...Continuous Delivery de vos applications dans un environnement multi-cloud et ...
Continuous Delivery de vos applications dans un environnement multi-cloud et ...
VMware Tanzu

Cloud Native Infrastructure Automation
Cloud Native Infrastructure AutomationCloud Native Infrastructure Automation
Cloud Native Infrastructure Automation
VMware Tanzu

"The Cloud Native Enterprise is Coming"
"The Cloud Native Enterprise is Coming" "The Cloud Native Enterprise is Coming"
"The Cloud Native Enterprise is Coming"
James Watters

Cloud Native Runtime Platform
Cloud Native Runtime Platform Cloud Native Runtime Platform
Cloud Native Runtime Platform
VMware Tanzu

Think Small To Go Big - Introduction To Microservices
Think Small To Go Big - Introduction To MicroservicesThink Small To Go Big - Introduction To Microservices
Think Small To Go Big - Introduction To Microservices
Ryan Baxter

API Microservices with Node.js and Docker
API Microservices with Node.js and DockerAPI Microservices with Node.js and Docker
API Microservices with Node.js and Docker
Apigee | Google Cloud


What's hot (20)

Cloud Native Application
Cloud Native ApplicationCloud Native Application
Cloud Native Application

2015 cloud trend and cloud DR
2015 cloud trend and cloud DR2015 cloud trend and cloud DR
2015 cloud trend and cloud DR

Evolving to Cloud-Native - Anand Rao
Evolving to Cloud-Native - Anand RaoEvolving to Cloud-Native - Anand Rao
Evolving to Cloud-Native - Anand Rao

Dipping Your Toes Into Cloud Native Application Development
Dipping Your Toes Into Cloud Native Application DevelopmentDipping Your Toes Into Cloud Native Application Development
Dipping Your Toes Into Cloud Native Application Development

CF SUMMIT: Partnerships, Business and Cloud Foundry
CF SUMMIT: Partnerships, Business and Cloud FoundryCF SUMMIT: Partnerships, Business and Cloud Foundry
CF SUMMIT: Partnerships, Business and Cloud Foundry

LIVE DEMO: Pivotal Cloud Foundry
LIVE DEMO: Pivotal Cloud FoundryLIVE DEMO: Pivotal Cloud Foundry
LIVE DEMO: Pivotal Cloud Foundry

Pivotal Cloud Foundry: A Technical Overview
Pivotal Cloud Foundry: A Technical OverviewPivotal Cloud Foundry: A Technical Overview
Pivotal Cloud Foundry: A Technical Overview

Introduction to Cloud Native Computing
Introduction to Cloud Native ComputingIntroduction to Cloud Native Computing
Introduction to Cloud Native Computing

Cloud Event Driven Architectures with Spring Cloud Stream 2.0 - Oleg Zhurakousky
Cloud Event Driven Architectures with Spring Cloud Stream 2.0 - Oleg ZhurakouskyCloud Event Driven Architectures with Spring Cloud Stream 2.0 - Oleg Zhurakousky
Cloud Event Driven Architectures with Spring Cloud Stream 2.0 - Oleg Zhurakousky

Microservices Best Practices
Microservices Best PracticesMicroservices Best Practices
Microservices Best Practices

Agile integration: Decomposing the monolith
Agile integration: Decomposing the monolithAgile integration: Decomposing the monolith
Agile integration: Decomposing the monolith

micro services architecture (FrosCon2014)
micro services architecture (FrosCon2014)micro services architecture (FrosCon2014)
micro services architecture (FrosCon2014)

LIVE DEMO: Pivotal Cloud Foundry
LIVE DEMO: Pivotal Cloud FoundryLIVE DEMO: Pivotal Cloud Foundry
LIVE DEMO: Pivotal Cloud Foundry

How to Overcome Data Challenges When Refactoring Monoliths to Microservices
How to Overcome Data Challenges When Refactoring Monoliths to MicroservicesHow to Overcome Data Challenges When Refactoring Monoliths to Microservices
How to Overcome Data Challenges When Refactoring Monoliths to Microservices

Continuous Delivery de vos applications dans un environnement multi-cloud et ...
Continuous Delivery de vos applications dans un environnement multi-cloud et ...Continuous Delivery de vos applications dans un environnement multi-cloud et ...
Continuous Delivery de vos applications dans un environnement multi-cloud et ...

Cloud Native Infrastructure Automation
Cloud Native Infrastructure AutomationCloud Native Infrastructure Automation
Cloud Native Infrastructure Automation

"The Cloud Native Enterprise is Coming"
"The Cloud Native Enterprise is Coming" "The Cloud Native Enterprise is Coming"
"The Cloud Native Enterprise is Coming"

Cloud Native Runtime Platform
Cloud Native Runtime Platform Cloud Native Runtime Platform
Cloud Native Runtime Platform

Think Small To Go Big - Introduction To Microservices
Think Small To Go Big - Introduction To MicroservicesThink Small To Go Big - Introduction To Microservices
Think Small To Go Big - Introduction To Microservices

API Microservices with Node.js and Docker
API Microservices with Node.js and DockerAPI Microservices with Node.js and Docker
API Microservices with Node.js and Docker


Viewers also liked

Using Docker, Neo4j, and Spring Cloud for Developing Microservices
Using Docker, Neo4j, and Spring Cloud for Developing MicroservicesUsing Docker, Neo4j, and Spring Cloud for Developing Microservices
Using Docker, Neo4j, and Spring Cloud for Developing Microservices
Kenny Bastani

Building REST APIs with Spring Boot and Spring Cloud
Building REST APIs with Spring Boot and Spring CloudBuilding REST APIs with Spring Boot and Spring Cloud
Building REST APIs with Spring Boot and Spring Cloud
Kenny Bastani

Cloud Native Java Microservices
Cloud Native Java MicroservicesCloud Native Java Microservices
Cloud Native Java Microservices
Kenny Bastani

Introduction To The DANE Protocol (DNSSEC)
Introduction To The DANE Protocol  (DNSSEC)Introduction To The DANE Protocol  (DNSSEC)
Introduction To The DANE Protocol (DNSSEC)
Deploy360 Programme (Internet Society)

Ethernet Over Dwdm Whitepaper
Ethernet Over Dwdm WhitepaperEthernet Over Dwdm Whitepaper
Ethernet Over Dwdm Whitepaper
Sarmad Saleem Gul

Top 10 deputy director interview questions and answers
Top 10 deputy director interview questions and answersTop 10 deputy director interview questions and answers
Top 10 deputy director interview questions and answers
JoshHartnett123

Introduction to Data Collection
Introduction to Data CollectionIntroduction to Data Collection
Introduction to Data Collection
National Resource Center for Paraprofessionals

Demand forecasting
Demand forecastingDemand forecasting
Demand forecasting
PT Education, Indore

The Fashion Channel - A case Analysis
The Fashion Channel - A case AnalysisThe Fashion Channel - A case Analysis
The Fashion Channel - A case Analysis
Devanand Hariperumal

Distributed System Management
Distributed System ManagementDistributed System Management
Distributed System Management
Ibrahim Amer

Fixed Income Trading System Architecture
Fixed Income Trading System ArchitectureFixed Income Trading System Architecture
Fixed Income Trading System Architecture
Khader Shaik

Procurement Plan
Procurement PlanProcurement Plan
Digital Engagement Strategies
Digital Engagement StrategiesDigital Engagement Strategies
Digital Engagement Strategies
Drew Diskin

Enterprise Architecture Frameworks
Enterprise Architecture FrameworksEnterprise Architecture Frameworks
Enterprise Architecture Frameworks
Stephen Lahanas

Developingan Export Strategy Marketing Plan (1)
Developingan Export Strategy Marketing Plan (1)Developingan Export Strategy Marketing Plan (1)
Developingan Export Strategy Marketing Plan (1)
Rob Perhamus MBA, PMP® ASQ SS Black Belt, CGBP

Mga isyu at problema sa pilipinas bunga ng mga pagbabago sa asya
Mga isyu at problema sa pilipinas bunga ng mga pagbabago sa asyaMga isyu at problema sa pilipinas bunga ng mga pagbabago sa asya
Mga isyu at problema sa pilipinas bunga ng mga pagbabago sa asya
Rodel Sinamban

Mobile Money Business Models
Mobile Money Business ModelsMobile Money Business Models
Mobile Money Business Models
NetHopeOrg

A project report on evaluation of financial performance based on ratio analysis
A project report on  evaluation of financial performance based on ratio analysisA project report on  evaluation of financial performance based on ratio analysis
A project report on evaluation of financial performance based on ratio analysis
Babasab Patil

Introduction to fixed partial denture
Introduction to fixed partial dentureIntroduction to fixed partial denture
Introduction to fixed partial denture
jinishnath

内容组织
内容组织内容组织
内容组织
flydream


Viewers also liked (20)

Using Docker, Neo4j, and Spring Cloud for Developing Microservices
Using Docker, Neo4j, and Spring Cloud for Developing MicroservicesUsing Docker, Neo4j, and Spring Cloud for Developing Microservices
Using Docker, Neo4j, and Spring Cloud for Developing Microservices

Building REST APIs with Spring Boot and Spring Cloud
Building REST APIs with Spring Boot and Spring CloudBuilding REST APIs with Spring Boot and Spring Cloud
Building REST APIs with Spring Boot and Spring Cloud

Cloud Native Java Microservices
Cloud Native Java MicroservicesCloud Native Java Microservices
Cloud Native Java Microservices

Introduction To The DANE Protocol (DNSSEC)
Introduction To The DANE Protocol  (DNSSEC)Introduction To The DANE Protocol  (DNSSEC)
Introduction To The DANE Protocol (DNSSEC)

Ethernet Over Dwdm Whitepaper
Ethernet Over Dwdm WhitepaperEthernet Over Dwdm Whitepaper
Ethernet Over Dwdm Whitepaper

Top 10 deputy director interview questions and answers
Top 10 deputy director interview questions and answersTop 10 deputy director interview questions and answers
Top 10 deputy director interview questions and answers

Introduction to Data Collection
Introduction to Data CollectionIntroduction to Data Collection
Introduction to Data Collection

Demand forecasting
Demand forecastingDemand forecasting
Demand forecasting

The Fashion Channel - A case Analysis
The Fashion Channel - A case AnalysisThe Fashion Channel - A case Analysis
The Fashion Channel - A case Analysis

Distributed System Management
Distributed System ManagementDistributed System Management
Distributed System Management

Fixed Income Trading System Architecture
Fixed Income Trading System ArchitectureFixed Income Trading System Architecture
Fixed Income Trading System Architecture

Procurement Plan
Procurement PlanProcurement Plan
Procurement Plan

Digital Engagement Strategies
Digital Engagement StrategiesDigital Engagement Strategies
Digital Engagement Strategies

Enterprise Architecture Frameworks
Enterprise Architecture FrameworksEnterprise Architecture Frameworks
Enterprise Architecture Frameworks

Developingan Export Strategy Marketing Plan (1)
Developingan Export Strategy Marketing Plan (1)Developingan Export Strategy Marketing Plan (1)
Developingan Export Strategy Marketing Plan (1)

Mga isyu at problema sa pilipinas bunga ng mga pagbabago sa asya
Mga isyu at problema sa pilipinas bunga ng mga pagbabago sa asyaMga isyu at problema sa pilipinas bunga ng mga pagbabago sa asya
Mga isyu at problema sa pilipinas bunga ng mga pagbabago sa asya

Mobile Money Business Models
Mobile Money Business ModelsMobile Money Business Models
Mobile Money Business Models

A project report on evaluation of financial performance based on ratio analysis
A project report on  evaluation of financial performance based on ratio analysisA project report on  evaluation of financial performance based on ratio analysis
A project report on evaluation of financial performance based on ratio analysis

Introduction to fixed partial denture
Introduction to fixed partial dentureIntroduction to fixed partial denture
Introduction to fixed partial denture

内容组织
内容组织内容组织
内容组织


Similar to Extending the Platform with Spring Boot and Cloud Foundry

Cloud Native Java with Spring Cloud Services
Cloud Native Java with Spring Cloud ServicesCloud Native Java with Spring Cloud Services
Cloud Native Java with Spring Cloud Services
VMware Tanzu

Consumer Driven Contracts and Your Microservice Architecture
Consumer Driven Contracts and Your Microservice ArchitectureConsumer Driven Contracts and Your Microservice Architecture
Consumer Driven Contracts and Your Microservice Architecture
Marcin Grzejszczak

Lattice: A Cloud-Native Platform for Your Spring Applications
Lattice: A Cloud-Native Platform for Your Spring ApplicationsLattice: A Cloud-Native Platform for Your Spring Applications
Lattice: A Cloud-Native Platform for Your Spring Applications
Matt Stine

Zuul @ Netflix SpringOne Platform
Zuul @ Netflix SpringOne PlatformZuul @ Netflix SpringOne Platform
Zuul @ Netflix SpringOne Platform
Mikey Cohen - Hiring Amazing Engineers

Managing the Complexity of Microservices Deployments
Managing the Complexity of Microservices DeploymentsManaging the Complexity of Microservices Deployments
Managing the Complexity of Microservices Deployments
VMware Tanzu

Continuous Delivery for Microservice Architectures with Concourse & Cloud Fou...
Continuous Delivery for Microservice Architectures with Concourse & Cloud Fou...Continuous Delivery for Microservice Architectures with Concourse & Cloud Fou...
Continuous Delivery for Microservice Architectures with Concourse & Cloud Fou...
VMware Tanzu

Marcin Grzejszczak - Contract Tests in the Enterprise
Marcin Grzejszczak - Contract Tests in the EnterpriseMarcin Grzejszczak - Contract Tests in the Enterprise
Marcin Grzejszczak - Contract Tests in the Enterprise
SegFaultConf

Experience + Education = Empowerment
Experience + Education = EmpowermentExperience + Education = Empowerment
Experience + Education = Empowerment
VMware Tanzu

Cloud Configuration Ecosystem at Intuit
Cloud Configuration Ecosystem at IntuitCloud Configuration Ecosystem at Intuit
Cloud Configuration Ecosystem at Intuit
VMware Tanzu

Consumer Driven Contracts and Your Microservice Architecture
Consumer Driven Contracts and Your Microservice ArchitectureConsumer Driven Contracts and Your Microservice Architecture
Consumer Driven Contracts and Your Microservice Architecture
Marcin Grzejszczak

Fast 5 Things You Can Do Now to Get Ready for the Cloud
Fast 5 Things You Can Do Now to Get Ready for the CloudFast 5 Things You Can Do Now to Get Ready for the Cloud
Fast 5 Things You Can Do Now to Get Ready for the Cloud
VMware Tanzu

Containers Were Never Your End State
Containers Were Never Your End StateContainers Were Never Your End State
Containers Were Never Your End State
VMware Tanzu

How to Build More Secure Service Brokers
How to Build More Secure Service BrokersHow to Build More Secure Service Brokers
How to Build More Secure Service Brokers
VMware Tanzu

Building .NET Microservices
Building .NET MicroservicesBuilding .NET Microservices
Building .NET Microservices
VMware Tanzu

Consumer Driven Contracts and Your Microservice Architecture
Consumer Driven Contracts and Your Microservice ArchitectureConsumer Driven Contracts and Your Microservice Architecture
Consumer Driven Contracts and Your Microservice Architecture
VMware Tanzu

So You're Up to Your Eyes in Foundations
So You're Up to Your Eyes in FoundationsSo You're Up to Your Eyes in Foundations
So You're Up to Your Eyes in Foundations
VMware Tanzu

12 Factor, or Cloud Native Apps - What EXACTLY Does that Mean for Spring Deve...
12 Factor, or Cloud Native Apps - What EXACTLY Does that Mean for Spring Deve...12 Factor, or Cloud Native Apps - What EXACTLY Does that Mean for Spring Deve...
12 Factor, or Cloud Native Apps - What EXACTLY Does that Mean for Spring Deve...
VMware Tanzu

Cloud-Native Streaming Platform: Running Apache Kafka on PKS (Pivotal Contain...
Cloud-Native Streaming Platform: Running Apache Kafka on PKS (Pivotal Contain...Cloud-Native Streaming Platform: Running Apache Kafka on PKS (Pivotal Contain...
Cloud-Native Streaming Platform: Running Apache Kafka on PKS (Pivotal Contain...
VMware Tanzu

Crossing the CI/CD/DevOps Chasm
Crossing the CI/CD/DevOps ChasmCrossing the CI/CD/DevOps Chasm
Crossing the CI/CD/DevOps Chasm
VMware Tanzu

Implementing microservices tracing with spring cloud and zipkin (spring one)
Implementing microservices tracing with spring cloud and zipkin (spring one)Implementing microservices tracing with spring cloud and zipkin (spring one)
Implementing microservices tracing with spring cloud and zipkin (spring one)
Reshmi Krishna


Similar to Extending the Platform with Spring Boot and Cloud Foundry (20)

Cloud Native Java with Spring Cloud Services
Cloud Native Java with Spring Cloud ServicesCloud Native Java with Spring Cloud Services
Cloud Native Java with Spring Cloud Services

Consumer Driven Contracts and Your Microservice Architecture
Consumer Driven Contracts and Your Microservice ArchitectureConsumer Driven Contracts and Your Microservice Architecture
Consumer Driven Contracts and Your Microservice Architecture

Lattice: A Cloud-Native Platform for Your Spring Applications
Lattice: A Cloud-Native Platform for Your Spring ApplicationsLattice: A Cloud-Native Platform for Your Spring Applications
Lattice: A Cloud-Native Platform for Your Spring Applications

Zuul @ Netflix SpringOne Platform
Zuul @ Netflix SpringOne PlatformZuul @ Netflix SpringOne Platform
Zuul @ Netflix SpringOne Platform

Managing the Complexity of Microservices Deployments
Managing the Complexity of Microservices DeploymentsManaging the Complexity of Microservices Deployments
Managing the Complexity of Microservices Deployments

Continuous Delivery for Microservice Architectures with Concourse & Cloud Fou...
Continuous Delivery for Microservice Architectures with Concourse & Cloud Fou...Continuous Delivery for Microservice Architectures with Concourse & Cloud Fou...
Continuous Delivery for Microservice Architectures with Concourse & Cloud Fou...

Marcin Grzejszczak - Contract Tests in the Enterprise
Marcin Grzejszczak - Contract Tests in the EnterpriseMarcin Grzejszczak - Contract Tests in the Enterprise
Marcin Grzejszczak - Contract Tests in the Enterprise

Experience + Education = Empowerment
Experience + Education = EmpowermentExperience + Education = Empowerment
Experience + Education = Empowerment

Cloud Configuration Ecosystem at Intuit
Cloud Configuration Ecosystem at IntuitCloud Configuration Ecosystem at Intuit
Cloud Configuration Ecosystem at Intuit

Consumer Driven Contracts and Your Microservice Architecture
Consumer Driven Contracts and Your Microservice ArchitectureConsumer Driven Contracts and Your Microservice Architecture
Consumer Driven Contracts and Your Microservice Architecture

Fast 5 Things You Can Do Now to Get Ready for the Cloud
Fast 5 Things You Can Do Now to Get Ready for the CloudFast 5 Things You Can Do Now to Get Ready for the Cloud
Fast 5 Things You Can Do Now to Get Ready for the Cloud

Containers Were Never Your End State
Containers Were Never Your End StateContainers Were Never Your End State
Containers Were Never Your End State

How to Build More Secure Service Brokers
How to Build More Secure Service BrokersHow to Build More Secure Service Brokers
How to Build More Secure Service Brokers

Building .NET Microservices
Building .NET MicroservicesBuilding .NET Microservices
Building .NET Microservices

Consumer Driven Contracts and Your Microservice Architecture
Consumer Driven Contracts and Your Microservice ArchitectureConsumer Driven Contracts and Your Microservice Architecture
Consumer Driven Contracts and Your Microservice Architecture

So You're Up to Your Eyes in Foundations
So You're Up to Your Eyes in FoundationsSo You're Up to Your Eyes in Foundations
So You're Up to Your Eyes in Foundations

12 Factor, or Cloud Native Apps - What EXACTLY Does that Mean for Spring Deve...
12 Factor, or Cloud Native Apps - What EXACTLY Does that Mean for Spring Deve...12 Factor, or Cloud Native Apps - What EXACTLY Does that Mean for Spring Deve...
12 Factor, or Cloud Native Apps - What EXACTLY Does that Mean for Spring Deve...

Cloud-Native Streaming Platform: Running Apache Kafka on PKS (Pivotal Contain...
Cloud-Native Streaming Platform: Running Apache Kafka on PKS (Pivotal Contain...Cloud-Native Streaming Platform: Running Apache Kafka on PKS (Pivotal Contain...
Cloud-Native Streaming Platform: Running Apache Kafka on PKS (Pivotal Contain...

Crossing the CI/CD/DevOps Chasm
Crossing the CI/CD/DevOps ChasmCrossing the CI/CD/DevOps Chasm
Crossing the CI/CD/DevOps Chasm

Implementing microservices tracing with spring cloud and zipkin (spring one)
Implementing microservices tracing with spring cloud and zipkin (spring one)Implementing microservices tracing with spring cloud and zipkin (spring one)
Implementing microservices tracing with spring cloud and zipkin (spring one)


More from Kenny Bastani

Open Source Big Graph Analytics on Neo4j with Apache Spark
Open Source Big Graph Analytics on Neo4j with Apache SparkOpen Source Big Graph Analytics on Neo4j with Apache Spark
Open Source Big Graph Analytics on Neo4j with Apache Spark
Kenny Bastani

Big Graph Analytics on Neo4j with Apache Spark
Big Graph Analytics on Neo4j with Apache SparkBig Graph Analytics on Neo4j with Apache Spark
Big Graph Analytics on Neo4j with Apache Spark
Kenny Bastani

Document Classification with Neo4j
Document Classification with Neo4jDocument Classification with Neo4j
Document Classification with Neo4j
Kenny Bastani

Neo4j Graph Data Modeling
Neo4j Graph Data ModelingNeo4j Graph Data Modeling
Neo4j Graph Data Modeling
Kenny Bastani

Building a Graph-based Analytics Platform
Building a Graph-based Analytics PlatformBuilding a Graph-based Analytics Platform
Building a Graph-based Analytics Platform
Kenny Bastani

Building Killer Apps with Neo4j 2.0
Building Killer Apps with Neo4j 2.0Building Killer Apps with Neo4j 2.0
Building Killer Apps with Neo4j 2.0
Kenny Bastani

Natural Language Processing with Neo4j
Natural Language Processing with Neo4jNatural Language Processing with Neo4j
Natural Language Processing with Neo4j
Kenny Bastani

Natural language search using Neo4j
Natural language search using Neo4jNatural language search using Neo4j
Natural language search using Neo4j
Kenny Bastani


More from Kenny Bastani (8)

Open Source Big Graph Analytics on Neo4j with Apache Spark
Open Source Big Graph Analytics on Neo4j with Apache SparkOpen Source Big Graph Analytics on Neo4j with Apache Spark
Open Source Big Graph Analytics on Neo4j with Apache Spark

Big Graph Analytics on Neo4j with Apache Spark
Big Graph Analytics on Neo4j with Apache SparkBig Graph Analytics on Neo4j with Apache Spark
Big Graph Analytics on Neo4j with Apache Spark

Document Classification with Neo4j
Document Classification with Neo4jDocument Classification with Neo4j
Document Classification with Neo4j

Neo4j Graph Data Modeling
Neo4j Graph Data ModelingNeo4j Graph Data Modeling
Neo4j Graph Data Modeling

Building a Graph-based Analytics Platform
Building a Graph-based Analytics PlatformBuilding a Graph-based Analytics Platform
Building a Graph-based Analytics Platform

Building Killer Apps with Neo4j 2.0
Building Killer Apps with Neo4j 2.0Building Killer Apps with Neo4j 2.0
Building Killer Apps with Neo4j 2.0

Natural Language Processing with Neo4j
Natural Language Processing with Neo4jNatural Language Processing with Neo4j
Natural Language Processing with Neo4j

Natural language search using Neo4j
Natural language search using Neo4jNatural language search using Neo4j
Natural language search using Neo4j


Recently uploaded

Mobile App Development Company in Noida - Drona Infotech.
Mobile App Development Company in Noida - Drona Infotech.Mobile App Development Company in Noida - Drona Infotech.
Mobile App Development Company in Noida - Drona Infotech.
Mobile App Development Company in Noida - Drona Infotech

AWS DevOps-Tutorial CHANAKYA SRIYAN DUKKA.
AWS DevOps-Tutorial CHANAKYA SRIYAN DUKKA.AWS DevOps-Tutorial CHANAKYA SRIYAN DUKKA.
AWS DevOps-Tutorial CHANAKYA SRIYAN DUKKA.
Srinivas Dukka

Folding Cheat Sheet #7 - seventh in a series
Folding Cheat Sheet #7 - seventh in a seriesFolding Cheat Sheet #7 - seventh in a series
Folding Cheat Sheet #7 - seventh in a series
Philip Schwarz

Introduction to Cloud computing for Internet of Things
Introduction to Cloud computing for Internet of ThingsIntroduction to Cloud computing for Internet of Things
Introduction to Cloud computing for Internet of Things
NachuSubramanian1

Unleashing the Future: Building a Scalable and Up-to-Date GenAI Chatbot with ...
Unleashing the Future: Building a Scalable and Up-to-Date GenAI Chatbot with ...Unleashing the Future: Building a Scalable and Up-to-Date GenAI Chatbot with ...
Unleashing the Future: Building a Scalable and Up-to-Date GenAI Chatbot with ...
confluent

Artificial intelligence in customer services or chatbots
Artificial intelligence  in customer services or chatbotsArtificial intelligence  in customer services or chatbots
Artificial intelligence in customer services or chatbots
kayash1656

HIRE A HACKER FOR CHEATING HUSBAND/WIFE)
HIRE A HACKER FOR CHEATING HUSBAND/WIFE)HIRE A HACKER FOR CHEATING HUSBAND/WIFE)
HIRE A HACKER FOR CHEATING HUSBAND/WIFE)
josephinedrea942

Maximizing Efficiency and Profitability: Optimizing Data Systems, Enhancing C...
Maximizing Efficiency and Profitability: Optimizing Data Systems, Enhancing C...Maximizing Efficiency and Profitability: Optimizing Data Systems, Enhancing C...
Maximizing Efficiency and Profitability: Optimizing Data Systems, Enhancing C...
OnePlan Solutions

11 Top Cross Browser Testing Tools to Know About.pdf
11 Top Cross Browser Testing Tools to Know About.pdf11 Top Cross Browser Testing Tools to Know About.pdf
11 Top Cross Browser Testing Tools to Know About.pdf
kalichargn70th171

Celebrity Girls Call Mumbai 9920725232 Unlimited Short Providing Girls Servic...
Celebrity Girls Call Mumbai 9920725232 Unlimited Short Providing Girls Servic...Celebrity Girls Call Mumbai 9920725232 Unlimited Short Providing Girls Servic...
Celebrity Girls Call Mumbai 9920725232 Unlimited Short Providing Girls Servic...
45unexpected

welcome to presentation on Google Apps
welcome to   presentation on Google Appswelcome to   presentation on Google Apps
welcome to presentation on Google Apps
AsifKarimJim

Russian Girls Call Mumbai 🎈🔥9930687706 🔥💋🎈 Provide Best And Top Girl Service ...
Russian Girls Call Mumbai 🎈🔥9930687706 🔥💋🎈 Provide Best And Top Girl Service ...Russian Girls Call Mumbai 🎈🔥9930687706 🔥💋🎈 Provide Best And Top Girl Service ...
Russian Girls Call Mumbai 🎈🔥9930687706 🔥💋🎈 Provide Best And Top Girl Service ...
shanihomely

Independent Girls call Service Pune 000XX00000 Provide Best And Top Girl Serv...
Independent Girls call Service Pune 000XX00000 Provide Best And Top Girl Serv...Independent Girls call Service Pune 000XX00000 Provide Best And Top Girl Serv...
Independent Girls call Service Pune 000XX00000 Provide Best And Top Girl Serv...
bhumivarma35300

To Avoid Mistakes When Using Online Attendance Sheets
To Avoid Mistakes When Using Online Attendance SheetsTo Avoid Mistakes When Using Online Attendance Sheets
To Avoid Mistakes When Using Online Attendance Sheets
Task Tracker

Vip Girls Call ServiCe Hyderabad 0000000000 Pooja Best High Class Hyderabad A...
Vip Girls Call ServiCe Hyderabad 0000000000 Pooja Best High Class Hyderabad A...Vip Girls Call ServiCe Hyderabad 0000000000 Pooja Best High Class Hyderabad A...
Vip Girls Call ServiCe Hyderabad 0000000000 Pooja Best High Class Hyderabad A...
ashiklo9823

The Ultimate Guide to Phone Spy Apps: Everything You Need to Know
The Ultimate Guide to Phone Spy Apps: Everything You Need to KnowThe Ultimate Guide to Phone Spy Apps: Everything You Need to Know
The Ultimate Guide to Phone Spy Apps: Everything You Need to Know
onemonitarsoftware

Prada Group Reports Strong Growth in First Quarter …
Prada Group Reports Strong Growth in First Quarter …Prada Group Reports Strong Growth in First Quarter …
Prada Group Reports Strong Growth in First Quarter …
908dutch

React Native vs Flutter - SSTech System
React Native vs Flutter  - SSTech SystemReact Native vs Flutter  - SSTech System
React Native vs Flutter - SSTech System
SSTech System

Mumbai Girls Call Mumbai 🎈🔥9930687706 🔥💋🎈 Provide Best And Top Girl Service A...
Mumbai Girls Call Mumbai 🎈🔥9930687706 🔥💋🎈 Provide Best And Top Girl Service A...Mumbai Girls Call Mumbai 🎈🔥9930687706 🔥💋🎈 Provide Best And Top Girl Service A...
Mumbai Girls Call Mumbai 🎈🔥9930687706 🔥💋🎈 Provide Best And Top Girl Service A...
3610stuck

Software development... for all? (keynote at ICSOFT'2024)
Software development... for all? (keynote at ICSOFT'2024)Software development... for all? (keynote at ICSOFT'2024)
Software development... for all? (keynote at ICSOFT'2024)
miso_uam


Recently uploaded (20)

Mobile App Development Company in Noida - Drona Infotech.
Mobile App Development Company in Noida - Drona Infotech.Mobile App Development Company in Noida - Drona Infotech.
Mobile App Development Company in Noida - Drona Infotech.

AWS DevOps-Tutorial CHANAKYA SRIYAN DUKKA.
AWS DevOps-Tutorial CHANAKYA SRIYAN DUKKA.AWS DevOps-Tutorial CHANAKYA SRIYAN DUKKA.
AWS DevOps-Tutorial CHANAKYA SRIYAN DUKKA.

Folding Cheat Sheet #7 - seventh in a series
Folding Cheat Sheet #7 - seventh in a seriesFolding Cheat Sheet #7 - seventh in a series
Folding Cheat Sheet #7 - seventh in a series

Introduction to Cloud computing for Internet of Things
Introduction to Cloud computing for Internet of ThingsIntroduction to Cloud computing for Internet of Things
Introduction to Cloud computing for Internet of Things

Unleashing the Future: Building a Scalable and Up-to-Date GenAI Chatbot with ...
Unleashing the Future: Building a Scalable and Up-to-Date GenAI Chatbot with ...Unleashing the Future: Building a Scalable and Up-to-Date GenAI Chatbot with ...
Unleashing the Future: Building a Scalable and Up-to-Date GenAI Chatbot with ...

Artificial intelligence in customer services or chatbots
Artificial intelligence  in customer services or chatbotsArtificial intelligence  in customer services or chatbots
Artificial intelligence in customer services or chatbots

HIRE A HACKER FOR CHEATING HUSBAND/WIFE)
HIRE A HACKER FOR CHEATING HUSBAND/WIFE)HIRE A HACKER FOR CHEATING HUSBAND/WIFE)
HIRE A HACKER FOR CHEATING HUSBAND/WIFE)

Maximizing Efficiency and Profitability: Optimizing Data Systems, Enhancing C...
Maximizing Efficiency and Profitability: Optimizing Data Systems, Enhancing C...Maximizing Efficiency and Profitability: Optimizing Data Systems, Enhancing C...
Maximizing Efficiency and Profitability: Optimizing Data Systems, Enhancing C...

11 Top Cross Browser Testing Tools to Know About.pdf
11 Top Cross Browser Testing Tools to Know About.pdf11 Top Cross Browser Testing Tools to Know About.pdf
11 Top Cross Browser Testing Tools to Know About.pdf

Celebrity Girls Call Mumbai 9920725232 Unlimited Short Providing Girls Servic...
Celebrity Girls Call Mumbai 9920725232 Unlimited Short Providing Girls Servic...Celebrity Girls Call Mumbai 9920725232 Unlimited Short Providing Girls Servic...
Celebrity Girls Call Mumbai 9920725232 Unlimited Short Providing Girls Servic...

welcome to presentation on Google Apps
welcome to   presentation on Google Appswelcome to   presentation on Google Apps
welcome to presentation on Google Apps

Russian Girls Call Mumbai 🎈🔥9930687706 🔥💋🎈 Provide Best And Top Girl Service ...
Russian Girls Call Mumbai 🎈🔥9930687706 🔥💋🎈 Provide Best And Top Girl Service ...Russian Girls Call Mumbai 🎈🔥9930687706 🔥💋🎈 Provide Best And Top Girl Service ...
Russian Girls Call Mumbai 🎈🔥9930687706 🔥💋🎈 Provide Best And Top Girl Service ...

Independent Girls call Service Pune 000XX00000 Provide Best And Top Girl Serv...
Independent Girls call Service Pune 000XX00000 Provide Best And Top Girl Serv...Independent Girls call Service Pune 000XX00000 Provide Best And Top Girl Serv...
Independent Girls call Service Pune 000XX00000 Provide Best And Top Girl Serv...

To Avoid Mistakes When Using Online Attendance Sheets
To Avoid Mistakes When Using Online Attendance SheetsTo Avoid Mistakes When Using Online Attendance Sheets
To Avoid Mistakes When Using Online Attendance Sheets

Vip Girls Call ServiCe Hyderabad 0000000000 Pooja Best High Class Hyderabad A...
Vip Girls Call ServiCe Hyderabad 0000000000 Pooja Best High Class Hyderabad A...Vip Girls Call ServiCe Hyderabad 0000000000 Pooja Best High Class Hyderabad A...
Vip Girls Call ServiCe Hyderabad 0000000000 Pooja Best High Class Hyderabad A...

The Ultimate Guide to Phone Spy Apps: Everything You Need to Know
The Ultimate Guide to Phone Spy Apps: Everything You Need to KnowThe Ultimate Guide to Phone Spy Apps: Everything You Need to Know
The Ultimate Guide to Phone Spy Apps: Everything You Need to Know

Prada Group Reports Strong Growth in First Quarter …
Prada Group Reports Strong Growth in First Quarter …Prada Group Reports Strong Growth in First Quarter …
Prada Group Reports Strong Growth in First Quarter …

React Native vs Flutter - SSTech System
React Native vs Flutter  - SSTech SystemReact Native vs Flutter  - SSTech System
React Native vs Flutter - SSTech System

Mumbai Girls Call Mumbai 🎈🔥9930687706 🔥💋🎈 Provide Best And Top Girl Service A...
Mumbai Girls Call Mumbai 🎈🔥9930687706 🔥💋🎈 Provide Best And Top Girl Service A...Mumbai Girls Call Mumbai 🎈🔥9930687706 🔥💋🎈 Provide Best And Top Girl Service A...
Mumbai Girls Call Mumbai 🎈🔥9930687706 🔥💋🎈 Provide Best And Top Girl Service A...

Software development... for all? (keynote at ICSOFT'2024)
Software development... for all? (keynote at ICSOFT'2024)Software development... for all? (keynote at ICSOFT'2024)
Software development... for all? (keynote at ICSOFT'2024)


Extending the Platform with Spring Boot and Cloud Foundry

  • 1. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ Extending the Platform Kenny Bastani @kennybastani
  • 2. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ 2 @kennybastani Spring Developer Advocate
  • 3. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ What makes an application legacy? 3
  • 4. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ What makes an application legacy? • How fast can you make changes to the application and deliver it into production? • How much work is it to upgrade the application framework? 4
  • 5. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ Legacy is an architecture problem 5
  • 6. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ Monolith 6
  • 7. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ 7 Microservices…
  • 8. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ If we're creating 10x the number of apps, we're creating 10x the technical debt 8
  • 9. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ What does your microservice architecture look like in 10 years? 9
  • 10. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ If you have to implement the same thing in every application, it should be provided by the platform as a service 10
  • 11. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ Do this successfully, and the only thing is left is the valuable business logic 11
  • 12. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ The two road blocks of cloud native • Legacy applications • Legacy culture 12
  • 15. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ How do we do better? 15
  • 16. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ Platform Engineering 16
  • 17. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ Platform Engineering • Everything that sits around your applications is vital to supporting the health of your applications • Unfortunately, anything that is not business logic is going to make it harder to upgrade your application later • Platform engineering is the art of automating standards in an application architecture by reducing redundancy across applications 17
  • 18. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ Redundancy in code creates technical debt. In microservices, multiply that debt by the number of apps 18
  • 19. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ Spring Boot + Cloud Foundry Service Brokers 19
  • 20. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ Backing services 20
  • 21. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ Online Store Example 21
  • 24. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ Spring Boot 24
  • 25. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ Platform engineers can take an opinionated view on how application developers will consume services 25
  • 26. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ Cloud Foundry Service Brokers • The Cloud Foundry marketplace is similar to the idea of starter projects in Spring Boot • Services can be offered on Cloud Foundry and bound to your application deployments • These marketplace services can be seen as backing services for your applications 26
  • 27. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ 27 Microservices…
  • 29. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ Amazon S3 Service Broker • The demo for this presentation is going to create an Amazon S3 service broker • We’ll release the broker to PCF Dev • Extend Spring Boot to automatically consume service instances from the broker • Deploy Spring Boot S3 browser that uses a starter project to connect to Amazon S3 29
  • 30. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ Cloud Controller • The Cloud Controller is the contract that Cloud Foundry exposes over HTTP as a REST API • We can create service brokers that implement expectations from this contract to allow CF and other broker applications to talk to each other 30
  • 33. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ Spring Boot Service Broker Template • The Spring team maintains an example project that provides the boiler plate for creating custom service brokers using Spring Boot • https://github.com/spring-cloud/spring-cloud-cloudfoundry-service-broker 33
  • 34. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ Implementing the service contracts • Service Catalog • Service Instances • Service Bindings 34
  • 35. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ Service Catalog 35
  • 38. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ Service Instances • Each method in the interface represents the implementation of a repository pattern • Controls the lifecycle of resources on AWS that provide exclusive access to a S3 bucket • The two resources that we will manage are: • S3 buckets • IAM users 38
  • 45. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ Service Bindings • The goal of the Amazon S3 Broker is to create S3 buckets that can be automatically bound to an application • Further, we want to make the service as easy to consume in a cloud native environment using Spring Boot starter projects to auto-configure the connection • The result of this is that a service binding will attach to a Cloud Foundry deployment and inject the environment variables into the application’s container • Our Spring Boot application will look for those environment variables at runtime and automatically configure an S3 connection 45
  • 48. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ Releasing the Service Broker • There are multiple options for releasing service brokers • Deploy as a CF app • Release with BOSH 48
  • 49. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ Why should we use BOSH to release a service broker instead of deploying the application with Cloud Foundry? 49
  • 50. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ It depends on the virtualized compute resources you intend to manage with your custom broker 50
  • 51. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ When to use BOSH • When you need to orchestrate resources with the IaaS provider that your CF deployment uses • Virtual machines • Network resources • BOSH provides a director API you can use to manage IaaS resources • Portable with different IaaS providers that have a BOSH CPI 51
  • 52. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ When not to use BOSH • When you do not need to manage resources using the IaaS • Example: • Amazon S3 • Basically any AWS service that has an SDK • Sometimes we just want to wrap another cloud service in a service broker, and that is OK 52
  • 53. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ Releasing with Cloud Foundry • Let’s jump into code and release the S3 service broker as a CF deployment 53
  • 54. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ Release steps • Create MySQL database as a service binding for the S3 broker • Build and push the S3 broker app • Bind Amazon AWS credentials as environment variables • Restage the S3 broker • Create service broker using CF CLI • Enable marketplace access to S3 broker • Create new service instance named s3-service 54
  • 55. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ Extending Spring Boot • We can create a starter project that includes an Amazon S3 template for consuming S3 service instances • All we need to do is to include the Amazon S3 starter project as a dependency 55
  • 56. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ Custom Spring Boot starter projects • We need to create two project modules • Auto-configuration project with the client libraries to consume a service instance (Amazon S3 Template) • Basic starter dependency project that includes the auto-configuration project using Maven 56
  • 57. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ Conclusion 57
  • 58. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ Platforms are forever 58
  • 59. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ Build value into the platform and reduce redundancies early in microservice architectures 59
  • 60. Unless otherwise indicated, these slides are © 2013-2016 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/ Learn More. Stay Connected. Thanks! @kennybastani on Twitter @springcentral spring.io/blog @pivotal pivotal.io/blog @pivotalcf http://engineering.pivotal.io
