CITOOLKIT
Fishbone Diagram
The Role of Fishbone Diagram in Analyzing Cause and Effect

citoolkit.com
Definition
A fishbone diagram provides a structured way to identify and organize the
potential causes of a p...

citoolkit.com
Definition
It is called this way because of its visual representation that looks like the
skeleton of a fish...

citoolkit.com
Uses
Often used during brainstorming sessions to identify the causes of an
undesirable effect or a problem.
...

citoolkit.com
Uses
Often used in Lean Six Sigma and other quality improvement approaches
to narrow down the area of analys...

citoolkit.com
Uses
Used to identify the sources of variation within a process which causes a
problem to occur.
Fishbone Di...

citoolkit.com
Benefits
Provides clarity regarding the causes of an effect in any problematic scenario.
Fishbone Diagram 7
...

citoolkit.com
Benefits
Fishbone Diagram 8
Identifies the potential factors that
may cause an effect to prevent future
prob...

citoolkit.com
Structure
The first step in conducting a fishbone analysis is to clearly define the
effect.
Fishbone Diagram...

citoolkit.com
Structure
The effect will become the head of the fishbone.
Fishbone Diagram 10
Effect
• Should be brief.
• U...

citoolkit.com
Structure
The causes will be placed in the branches of the chart.
Fishbone Diagram 11
Each cause needs to be...

citoolkit.com
Structure
A fishbone diagram allows to identify the hierarchy of causes including the
possible root causes.
...

citoolkit.com
Structure
Combining the fishbone with the 5 whys gives the analysis an extra
dimension.
Fishbone Diagram 13
...

citoolkit.com
Grouping Potential Causes
Potential causes in a fishbone diagram are normally grouped into
categories for ea...

citoolkit.com
Grouping Potential Causes
There are different approaches of constructing a fishbone diagram
indicated by the...

citoolkit.com
Grouping Potential Causes – 4 Ms
One of the most basic forms to group the potential causes of a problem or
e...

citoolkit.com
Grouping Potential Causes – 6 Ms
The most common way to categorize potential causes of a problem or
effect.
...

citoolkit.com
Grouping Potential Causes – 6 Ms
Man – Anyone involved with the process and contributes to the effect
Includ...

citoolkit.com
Grouping Potential Causes – 6 Ms
Method – How the process is performed and the specific requirements for
doi...

citoolkit.com
Grouping Potential Causes – 6 Ms
Machine – The machinery, equipment and tools required to perform the
proces...

citoolkit.com
Grouping Potential Causes – 6 Ms
Material – All the materials needed to perform a process.
Fishbone Diagram ...

citoolkit.com
Grouping Potential Causes – 6 Ms
Environment – The conditions in which the process operates.
Fishbone Diagra...

citoolkit.com
Grouping Potential Causes – 6 Ms
Measurement – The data and metrics that are used to evaluate the
performanc...

citoolkit.com
Grouping Potential Causes – 6 Ms
Different names may be used for the same category depending on the
situatio...

citoolkit.com
Grouping Potential Causes – 8 Ms
Adds Management and Maintenance to the 6 M categories.
Fishbone Diagram 25
...

citoolkit.com
Grouping Potential Causes
When you are working on an affinity diagram, you can use the titles of the
affinit...

citoolkit.com
Grouping Potential Causes
When the effect results from a documented or mapped process, the
process steps can...

citoolkit.com
Grouping Potential Causes
You may also create subcategories of a main category and include it in new
branche...

citoolkit.com
Grouping Potential Causes
You may even rename or create your own branches that best suit your
project.
Fishb...

citoolkit.com
Grouping Potential Causes
Typical Categories for Manufacturing and Non-Manufacturing Processes.
Fishbone Dia...

citoolkit.com
Steps for Drawing a Fishbone Diagram
Fishbone Diagram 31
With your team, clearly define the effect that you ...

citoolkit.com
Steps for Drawing a Fishbone Diagram
Fishbone Diagram 32
Identify the cause categories using the 4Ms or any ...

citoolkit.com
Steps for Drawing a Fishbone Diagram
Fishbone Diagram 33
Use brainstorming to log all possible causes under ...

citoolkit.com
Steps for Drawing a Fishbone Diagram
Fishbone Diagram 34
Take time to ensure the appropriateness of the reco...

citoolkit.com
Steps for Drawing a Fishbone Diagram
Fishbone Diagram 35
Highlight or assign numbers near to the key causes ...

citoolkit.com
Steps for Drawing a Fishbone Diagram
Fishbone Diagram 36
If necessary, collect data to confirm key causes ar...

citoolkit.com
Example – Increased Invoice Errors
Fishbone Diagram 37
Increased
Invoice Errors
Cumbersome process
Manual da...

citoolkit.com
Example – Increased Coolant Consumption
Fishbone Diagram 38
High Coolant
Consumption
Man
Measure
Material
En...

citoolkit.com
Example – Coffee Flavor
Fishbone Diagram 39
Over roasting
Not fresh coffee beans
Unclean coffee maker
Low wa...

citoolkit.com
Further Information
Be aware of adding causes which are actually solutions.
Fishbone Diagram 40
The main ide...

citoolkit.com
Further Information
A cause-and-effect matrix can be used to prioritize the causes of the
problem.
Fishbone ...

citoolkit.com
Further Information
Another way of highlighting the structure of the possible causes is to use
the tree diag...

citoolkit.com
Further Information
The measure of success for a fishbone diagram is typically the quantity of
ideas generat...

citoolkit.com
Further Information
A fishbone diagram can also be used to structure the thoughts of a team.
Fishbone Diagra...

citoolkit.com
Further Information
Sometimes it is useful to brainstorm out the ideas first then organize them
by category ...

© Copyright Citoolkit.com. All Rights Reserved.
