EUC3163VMware View Performanceand Best Practices<br />BanitAgrawal, VMware, Inc.<br />Rishi Bidarkar, VMware, Inc.<br />Su...

Disclaimer<br />This session may contain product features that are currently under development.<br />This session/overview...

What’s key for a good VDI solution?<br />Efficient display protocol<br />Having highly scalable virtualization platform<br...

VDI scope<br />Storage Optimizations<br />Hypervisor<br />Optimizations<br /> Enhancements<br />vCenter Enhancements<...

Enhancements<br />Storage Optimizations<br />Hypervisor Optimizations<br /> Enhancements<br />vCenter Enhancements<br...

vSphere 5.0 Release<br />What to expect from releases<br />Storage<br />Hypervisor<br />View improvements andbest practice...

Agenda<br />Highlights<br />VDI Benchmarking challenges<br />VMware View Planner<br />Platform enhancements and best prac...

vSphere 5.0 for VDI <br />CPU <br />Better out of the box CPU scheduling for VDI workloads<br />No special tuning require...

What’s new with the View<br />Protocol Enhancements<br />WAN Bandwidth optimizations<br />Lossless CODEC for text <br />Cl...

VDI benchmarking challenges<br />Goals<br />Capacity planning Consolidation ratio studies <br />QoS ...

VMware View Planner<br />Typical office user workload <br />Workload generator and sizing tool<br />Capacity planning<br /...

View Planner Features<br />View Planner 2.0<br />Ships as a virtual appliance<br />Support for Office 2003/2007<br />Autom...

Outline<br />Platform Enhancements <br />Platform Enhancements and Best Practices<br />

CPU and memory consolidation<br />vSphere 5.0 achieves more consolidation compared to vSphere 4.1<br />Scheduler optimizat...

CPU Scheduler improvements in ESX 5.0<br />Better out of the box CPU scheduling for VDI workloads<br />No need to tweak sc...

Memory improvements in ESX5.0<br />Virtual machine book keeping memory has been significantly reduced in ESX5.0<br />This ...

Further savings from page sharing and ballooning<br />Usually able to run more than the calculated number of VMs, up to 20...

So how far have we come in one year ?<br />HP BL460c blade<br />8 Nehalem cores<br />96GB RAM<br />1GB vRAM/desktop<br />L...

Storage Tiering<br />Persona<br />Disposable<br />OS Image<br />Persona VMDK<br />Disposable VMDK<br />Replica VMDK<br />C...

Tiering data distribution<br />“90/10” distribution of IOPS for a freshly created desktop pool<br />Maximize the SSD resou...

Best practices<br />CPU<br />Up to 14.5 Windows 7 VMs per core for light to moderate Office applications<br />What is good...

View Composer Provisioning Improvements<br />Increase provisioning concurrency<br />

Outline<br /> Enhancements<br /> Client / Protocol<br />

Experimental Setup: Single-VM run<br />32-bit WinXP SP3<br />1-VCPU, 768 MB<br />1152x864 resolution<br />32-bit Win7 de...

Performance Metrics<br />Useful metrics we all care about<br />CPU Usage<br />Bandwidth Usage<br />Response time<br />Me...

Performance Improvements in View 5.0<br /><ul><li> Response time in LAN/WAN in view 5.0 is slightly better

More noticeable difference in extreme WAN conditions</li></li></ul><li>Performance Improvements in View 5.0<br /><ul><li...

In View 5.0, less than 50 kbps usage per desktop on average</li></li></ul><li>Performance Improvements in View 5.0<br />...

better consolidation on the ESX host</li></li></ul><li>Experimental Setup – display protocols comparison<br />32-bit WinX...

Performance Comparison with Other Protocols<br /><ul><li> PCoIP provides better user experience in all network conditions

RDP7 doesn’t perform well in extreme WAN</li></li></ul><li>Performance Comparison with Other Protocols<br /><ul><li> PC...

RDP7 cripples the video and web-album – bandwidth could have been more</li></li></ul><li>Performance Comparison with Oth...

PCoIP is lower, RDP is lower in extreme WAN because of excessive crippling</li></li></ul><li>Gain insight for troublesho...

30+ statistics available in 4 categories

Supports WMI based tools</li></ul>Benefits<br /><ul><li>Enable performance monitoring

Proactively troubleshoot issues

Quick issue resolution

Easily integrates with existing tools</li></ul>Performance Monitoring<br />

Best Practices Recommendations<br />
