Coping with IFC lists in the
ifcOWL ontology
Pieter Pauwels, Ghent University
Walter Terkaj, ITIA-CNR
Thomas Krijnen, Eindhoven University of Technology
Jakob Beetz, Eindhoven University of Technology
outline
background, context and purposes
possible conversion procedures
conclusion
thank you
2
example
3
BACKGROUND, CONTEXT AND
PURPOSES
4
http://www.bimforum.lv/communities/6/004/012/741/086//images/4611848847.jpg5
openBIM
6
Data exchange standard
buildingSMART specifications
7
Ifc2x_all_lf.exp
IFC2X2_ADD1.exp
IFC2X2_FINAL.exp
IFC2X2_PLATFORM.exp
IFC2X3_Final.exp
IFC2X3_TC1.exp
IFC4.exp
IFC4_ADD1.exp
not supported
not supported
not supported
not supported
IFC2X3_Final.owl / .ttl
IFC2X3_TC1.owl / .ttl
IFC4.owl / .ttl
IFC4_ADD1.owl / .ttl
http://www.linkedbuildingdata.net/resources/IFC2X3_Final.ttl
http://www.linkedbuildingdata.net/resources/IFC2X3_TC1.ttl
http://www.linkedbuildingdata.net/resources/IFC4.ttl
http://www.linkedbuildingdata.net/resources/IFC4_ADD1.ttl
EXPRESS to OWL conversion
IFC to RDF conversion
converting EXPRESS schema to OWL
IFC
Schema
Simple data type
Defined data type
Aggregation data type
SET data type --------
LIST & ARRAY data type --------
Constructed data type
SELECT data type --------
ENUMERATION data type --------
Entity data type
Attributes --------
Derive attr
WHERE rules
Functions
Rules
ifcOWL
Ontology
owl:class + owl:DatatypeProperty restriction
owl:class
owl:class
-------- owl:ObjectProperty restriction on
ifc:hasSet
-------- indirect subclass of ifc:List
owl:class
-------- owl:unionOf ( owl:classes )
-------- one of ( owl:NamedIndividuals )
owl:class
-------- object properties
-
-
-
-
P. Pauwels, D. Van Deursen, R. Verstraeten, J. De Roo, R. De Meyer, R. Van de Walle, J. Van Campenhout. A
semantic rule checking environment for building performance checking. Automation in Construction 20: 506-
518, 2011.
IFC as a graph (both Tbox and Abox)
SCOPE FOR THIS PRESENTATION
10
11
conversions done
first IFC graphs are there
12
Size multiplies with 10!!!!!!
file size is huge
triple count is too high
13
• 417.033 entity instances
• 45.085 are instances of IfcCartesianPoint (10,6%)
• Geometry typically occupies 70 to 80 percent of an IFC model
• The majority of geometric entities and properties is represented using LISTs
statistics for Book Tower sample model
1 ENTITY IfcCartesianPoint
2 SUBTYPE OF (IfcPoint);
3 Coordinates : LIST [1:3] OF IfcLengthMeasure;
4 DERIVE
5 Dim : IfcDimensionCount := HIINDEX(Coordinates);
6 WHERE
7 CP2Dor3D : HIINDEX(Coordinates) >= 2;
8 END_ENTITY;
14
IfcCartesianPoint defined in EXPRESS
1 #37=IFCCARTESIANPOINT((0.,0.,-350.));
15
IfcCartesianPoint in an IFC SPF
=> Near to impossible to be more efficient than this, in terms of file size
=> Impossible to be more efficient than this using RDF, in terms of file size
=> Let us please be as efficient as possible when aiming at benefits
associated with RDF graphs
:UMultiplicities.
:ColourIndex.
:ListPositions.
:KnotMultiplicities.
:VMultiplicities.
:RefLongitude.
:RefLatitude.
:WeightsData.
:DirectionRatios.
:MaterialLayers.
:Roles_of_IfcOrganization.
:Roles_of_IfcPersonAndOrganization.
:Roles_of_IfcPerson.
:Segments.
:Pixel.
:Vertices.
:DefinedValues.
:RowCells.
:EnumerationValues.
:ListValues_of_IfcIrregularTimeSeriesValue.
:EnumerationValues.
:DefiningValues.
:ListValues_of_IfcTimeSeriesValue.
:ListValues_of_IfcPropertyListValue.
:Polygon.
:Points.
:ControlPointsList_of_IfcBSplineCurve.
:UKnots.
:Knots.
:Coordinates_of_IfcTextureVertex.
:VKnots.
:ElectronicMailAddresses.
:AddressLines.
:SuffixTitles.
:FacsimileNumbers.
:PrefixTitles.
:MiddleNames.
:TelephoneNumbers.
:TexCoordsList.
:Normals.
:LuminousIntensity.
:BendingParameters_of_IfcReinforcingBarType.
:BendingParameters_of_IfcReinforcingMeshType.
:CostValues.
:Addresses_of_IfcOrganization.
:Addresses_of_IfcPerson.
:SecondaryPlaneAngle.
:OffsetDistances.
:Coordinates_of_IfcCartesianPoint.
:OffsetValues_of_IfcMaterialLayerWithOffsets.
:SurfaceReinforcement1.
:SurfaceReinforcement2.
:OffsetValues_of_IfcMaterialProfileWithOffsets.
:RelatedObjects_of_IfcRelNests.
:Representations.
:BaseCosts_of_IfcConstructionResource.
:Components.
:BaseCosts_of_IfcConstructionResourceType.
:Textures.
:Maps.
:DistributionData.
:CrossSections.
:RelatedPriorities.
:RelatingPriorities.
:EdgeList_of_IfcEdgeLoop.
:EdgeList_of_IfcPath.
:CrossSectionPositions.
:Rows.
:ControlPointsList_of_IfcBSplineSurface.
:WAxes.
:IntersectingAxes.
:UAxes.
:VAxes.
:TilingPattern.
:Values_of_IfcStructuralLoadConfiguration.
:ColourList.
:RepresentationMaps.
:Values_of_IfcRegularTimeSeries.
:Parameter_of_IfcTextureCoordinateGenerator.
:WeightsData.
:MessagingIDs.
:BenchmarkValues.
:ReinforcementSectionDefinitions.
:CoordList.
:Locations.
:MaterialProfiles.
:Columns.
:NormalIndex.
:TexCoordIndex.
:CoordIndex.
:SelfWeightCoefficients.
:PatternList.
:Values_of_IfcIrregularTimeSeries.
:ShapeRepresentations.
:FontFamily.
:ReferenceTokens.
:Parameter_of_IfcSurfaceTexture.
:CostQuantities.
:TimePeriods.
:Materials.
16
DIVERSE CONVERSION
PROCEDURES
17
1. Conversion to the regular rdf:List concept natively available
in RDF
2. Conversion to general purpose list concepts
3. Conversion to customised concepts
4. Conversion to customised concepts referring to portions of
Well-Known Text (WKT)
18
conversion procedures
1 @prefix rdf: <http://www.w3.org/1999/02/22-rdf-syntax-ns#> .
2 @prefix rdfs: <http://www.w3.org/2000/01/rdf-schema#> .
3 @prefix owl: <http://www.w3.org/2002/07/owl#> .
4 @prefix xsd: <http://www.w3.org/2001/XMLSchema#> .
5 @prefix ifcowl1: <http://www.buildingsmart-tech.org/ifcOWL1#> .
6 @prefix ifcowl2: <http://www.buildingsmart-tech.org/ifcOWL2#> .
7 @prefix ifcowl3: <http://www.buildingsmart-tech.org/ifcOWL3#> .
8 @prefix ifcowl4: <http://www.buildingsmart-tech.org/ifcOWL4#> .
9 @prefix ifcowl5: <http://www.buildingsmart-tech.org/ifcOWL5#> .
10 @prefix ifcinst: <http://www.lbd.net/20150504_ListInstances#> .
19
namespaces & prefixes used
1 ifcinst:IfcCartesianPoint_37
2 rdf:type ifcowl1:IfcCartesianPoint ;
3 ifcowl1:Coordinates_of_IfcCartesianPoint
ifcinst:IfcLengthMeasure_List_371 .
4 ifcinst:IfcLengthMeasure_List_371
5 rdf:type rdf:List ;
6 rdf:first ifcinst:IfcLengthMeasure_371inst ;
7 rdf:rest ifcinst:IfcLengthMeasure_List_372 .
8 ifcinst:IfcLengthMeasure_371inst
9 rdf:type ifcowl1:IfcLengthMeasure ;
10 ifcowl1:has_double “0.0”^^xsd:double .
11 ifcinst:IfcLengthMeasure_List_372
12 rdf:type rdf:List ;
13 rdf:first ifcinst:IfcLengthMeasure_372inst ;
14 rdf:rest ifcinst:IfcLengthMeasure_List_373 .
15 ifcinst:IfcLengthMeasure_372inst
16 rdf:type ifcowl1:IfcLengthMeasure ;
17 ifcowl1:has_double “0.0”^^xsd:double .
18 ifcinst:IfcLengthMeasure_List_373
19 rdf:type rdf:List ;
20 rdf:first ifcinst:IfcLengthMeasure_373inst;
21 rdf:rest rdf:nil .
22 ifcinst:IfcLengthMeasure_373inst
23 rdf:type ifcowl1:IfcLengthMeasure ;
24 ifcowl1:has_double “-350.0”^^xsd:double .
20
procedure 1: usage of regular rdf:List concept
+ rdf:List is standard.
- Not intuitive when using SPARQL or inference
engines
- Verbose in RDF/XML
21
procedure 1: pros and cons
1 ifcinst:IfcCartesianPoint_37
2 rdf:type ifcowl1:IfcCartesianPoint ;
3 ifcowl1:Coordinates_of_IfcCartesianPoint
(ifcinst:IfcLengthMeasure_371inst
ifcinst:IfcLengthMeasure_372inst
ifcinst:IfcLengthMeasure_373inst).
4 ifcinst:IfcLengthMeasure_371inst
5 rdf:type ifcowl1:IfcLengthMeasure ;
6 ifcowl1:has_double “0.0”^^xsd:double .
7 ifcinst:IfcLengthMeasure_372inst
8 rdf:type ifcowl1:IfcLengthMeasure ;
9 ifcowl1:has_double “0.0”^^xsd:double .
10 ifcinst:IfcLengthMeasure_373inst
11 rdf:type ifcowl1:IfcLengthMeasure ;
12 ifcowl1:has_double “-350.0”^^xsd:double .
22
side-remark: not so verbose in N3
1 ifcinst:IfcCartesianPoint_37
2 rdf:type ifcowl2:IfcCartesianPoint ;
3 ifcowl2:Coordinates_of_IfcCartesianPoint
ifcinst:IfcLengthMeasure_List_371 .
4 ifcinst:IfcLengthMeasure_List_371
5 rdf:type ifcowl2:List ;
6 ifcowl2:hasListContent inst:IfcLengthMeasure_371inst ;
7 ifcowl2:hasNext inst:IfcLengthMeasure_List_372 .
8 ifcinst:IfcLengthMeasure_371inst
9 rdf:type ifcowl2:IfcLengthMeasure ;
10 ifcowl2:has_double “0.0”^^xsd:double.
11 ifcinst:IfcLengthMeasure_List_372
12 rdf:type ifcowl2:List ;
13 ifcowl2:hasListContent ifcinst:IfcLengthMeasure_372inst ;
14 ifcowl2:hasNext ifcinst:IfcLengthMeasure_List_373 .
15 ifcinst:IfcLengthMeasure_372inst
16 rdf:type ifcowl2:IfcLengthMeasure ;
17 ifcowl2:has_double “0.0”^^xsd:double .
18 ifcinst:IfcLengthMeasure_List_373
19 rdf:type ifcowl2:List ;
20 ifcowl2:hasListContent ifcinst:IfcLengthMeasure_373inst;
21 ifcinst:IfcLengthMeasure_373inst
22 rdf:type ifcowl2:IfcLengthMeasure ;
23 ifcowl2:has_double “-350.0”^^xsd:double .
23
procedure 2: general purpose list concepts
• the OWLList by Drummond et al. (2006)
• the Ordered List Ontology (OLO) by Abdallah and
Ferris (2010)
• the approach followed in OntoSTEP by Krima et
al. (2009) and Barbau et al. (2012)
• the approach proposed in the ifcOWL ontology by
Pauwels and Terkaj (2015a, 2015b)
• the approach proposed in the ifcOWL ontology by
Seppo Törmä and Nam Vu Hoang (Aalto Univ.)
24
example implementations of procedure 2
+ regular RDF
- Not standard
- Not intuitive when using SPARQL or inference
engines
- Verbose in RDF/XML
25
procedure 2: pros and cons
1 ifcinst:IfcCartesianPoint_37
2 rdf:type ifcowl3:IfcCartesianPoint ;
3 ifcowl3:xCoordinate_of_IfcCartesianPoint
ifcinst:IfcLengthMeasure_371inst ;
4 ifcowl3:yCoordinate_of_IfcCartesianPoint
ifcinst:IfcLengthMeasure_372inst ;
5 ifcowl3:zCoordinate_of_IfcCartesianPoint
ifcinst:IfcLengthMeasure_373inst .
6 ifcinst:IfcLengthMeasure_371inst
7 rdf:type ifcowl3:IfcLengthMeasure ;
8 ifcowl3:has_double “0.0”^^xsd:double .
9 ifcinst:IfcLengthMeasure_372inst
10 rdf:type ifcowl3:IfcLengthMeasure ;
11 ifcowl3:has_double “0.0”^^xsd:double .
12 ifcinst:IfcLengthMeasure_373inst
13 rdf:type ifcowl3:IfcLengthMeasure ;
14 ifcowl3:has_double “-350.0”^^xsd:double .
26
procedure 3a: custom concepts
1 ifcinst:IfcCartesianPoint_37
2 rdf:type ifcowl:IfcCartesianPoint ;
3 ifcowl4:xCoordinate_of_IfcCartesianPoint
“0.0”^^ifcowl4:IfcLengthMeasure ;
4 ifcowl4:yCoordinate_of_IfcCartesianPoint
“0.0”^^ifcowl4:IfcLengthMeasure ;
5 ifcowl4:zCoordinate_of_IfcCartesianPoint
“-350.0”^^ifcowl4:IfcLengthMeasure.
27
procedure 3b: custom concepts
+ intuitive when using SPARQL or inference
engines
+ semantically more explicit (better formal
model)
+ significantly less verbose
- Not within the current IFC standard -> need to
rewrite and convert
28
procedure 3: pros and cons
1 ifcinst:IfcCartesianPoint_37
2 rdf:type ifcowl5:IfcCartesianPoint ;
3 ifcowl5:Coordinates_of_IfcCartesianPoint
“POINTZ(0.0 0.0 -350.0)”^^ifcowl5:wktLiteral
29
procedure 4: custom concepts referring to
portions of Well-Known Text (WKT)
+ intuitive when using SPARQL or inference
engines
+ significantly less verbose
- Semantically less explicit than current IFC and
ifcOWL
- Need to stick to agreements (WKT needs to
remain WK and agreed)
30
procedure 4: pros and cons
CONCLUSION
31
Number of triples and individuals needed to represent a 3-item list like in the
case of Cartesian coordinates.
32
comparison of procedures
Procedure #triples #individuals
#triples per
list item
#individuals
per list item
RDFlist 1 17 (21) 4 5 (6) 1
ifcOWL_1 2 16 (23) 7 6 (7) 2
XYZ_1 3a 10 (14) 4 3 (4) 1
XYZ_2 3b 4 (5) 1 1 0
WKT 4 2 (3) 1 1/3 0
In (brackets) the number of triples if each individual is explicitly typed as
owl:NamedIndividual
• trade-off needs to be made between semantic precision and
computational efficiency.
• The procedures that result in the semantically most precise
representations (Procedure 1 and 2) also result in lengthy and
overly complex representations, yet they are the closest equivalents
to the original EXPRESS schema.
• The procedures that result in computationally more efficient
representations (Procedure 3a, 3b, and 4), on the other hand, could
result in sloppier data representations, which could in turn result in
errors, flaws and mistakes in the applications relying on that data.
• Yet, as many have concluded in the geospatial domain, this might
be the only option to make the use of RDF graphs and OWL
ontologies feasible for the architectural design and construction
industry.
33
conclusion
Thank you
Pieter Pauwels
pipauwel.pauwels@ugent.be
Walter Terkaj
walter.terkaj@itia.cnr.it
Thomas Krijnen
T.F.Krijnen@tue.nl
Jakob Beetz
j.Beetz@tue.nl
34

More Related Content

Similar to EG-ICE 2015 - Coping with IFC lists in the ifcOWL ontology

Getting the best of Linked Data and Property Graphs: rdf2neo and the KnetMine...
Getting the best of Linked Data and Property Graphs: rdf2neo and the KnetMine...Getting the best of Linked Data and Property Graphs: rdf2neo and the KnetMine...
Getting the best of Linked Data and Property Graphs: rdf2neo and the KnetMine...
Rothamsted Research, UK

Compiler2016 by abcdabcd987
Compiler2016 by abcdabcd987Compiler2016 by abcdabcd987
Compiler2016 by abcdabcd987
乐群 陈

Force11 JDDCP workshop presentation, @ Force2015, Oxford
Force11 JDDCP workshop presentation, @ Force2015, OxfordForce11 JDDCP workshop presentation, @ Force2015, Oxford
Force11 JDDCP workshop presentation, @ Force2015, Oxford
Mark Wilkinson

Data FAIRport Skunkworks: Common Repository Access Via Meta-Metadata Descript...
Data FAIRport Skunkworks: Common Repository Access Via Meta-Metadata Descript...Data FAIRport Skunkworks: Common Repository Access Via Meta-Metadata Descript...
Data FAIRport Skunkworks: Common Repository Access Via Meta-Metadata Descript...
datascienceiqss

Bio2RDF@BH2010
Bio2RDF@BH2010Bio2RDF@BH2010
Bio2RDF@BH2010
François Belleau

Postgres в основе вашего дата-центра, Bruce Momjian (EnterpriseDB)
Postgres в основе вашего дата-центра, Bruce Momjian (EnterpriseDB)Postgres в основе вашего дата-центра, Bruce Momjian (EnterpriseDB)
Postgres в основе вашего дата-центра, Bruce Momjian (EnterpriseDB)
Ontico

Pragmatic Optimization in Modern Programming - Demystifying the Compiler
Pragmatic Optimization in Modern Programming - Demystifying the CompilerPragmatic Optimization in Modern Programming - Demystifying the Compiler
Pragmatic Optimization in Modern Programming - Demystifying the Compiler
Marina Kolpakova

Scala Meetup Hamburg - Spark
Scala Meetup Hamburg - SparkScala Meetup Hamburg - Spark
Scala Meetup Hamburg - Spark
Ivan Morozov

Algorithm
AlgorithmAlgorithm
Algorithm
Prajakta Bagal

Modern Association Rule Mining Methods
Modern Association Rule Mining MethodsModern Association Rule Mining Methods
Modern Association Rule Mining Methods
ijcsity

Training Large-scale Ad Ranking Models in Spark
Training Large-scale Ad Ranking Models in SparkTraining Large-scale Ad Ranking Models in Spark
Training Large-scale Ad Ranking Models in Spark
Patrick Pletscher

PyConLT19-No_more_struggles_with_Apache_Spark_(PySpark)_workloads_in_production
PyConLT19-No_more_struggles_with_Apache_Spark_(PySpark)_workloads_in_productionPyConLT19-No_more_struggles_with_Apache_Spark_(PySpark)_workloads_in_production
PyConLT19-No_more_struggles_with_Apache_Spark_(PySpark)_workloads_in_production
Chetan Khatri

Prometheus as exposition format for eBPF programs running on Kubernetes
Prometheus as exposition format for eBPF programs running on KubernetesPrometheus as exposition format for eBPF programs running on Kubernetes
Prometheus as exposition format for eBPF programs running on Kubernetes
Leonardo Di Donato

Project Hydrogen: State-of-the-Art Deep Learning on Apache Spark
Project Hydrogen: State-of-the-Art Deep Learning on Apache SparkProject Hydrogen: State-of-the-Art Deep Learning on Apache Spark
Project Hydrogen: State-of-the-Art Deep Learning on Apache Spark
Databricks

Performance #5 cpu and battery
Performance #5  cpu and batteryPerformance #5  cpu and battery
Performance #5 cpu and battery
Vitali Pekelis

IRJET- Hadoop based Frequent Closed Item-Sets for Association Rules form ...
IRJET-  	  Hadoop based Frequent Closed Item-Sets for Association Rules form ...IRJET-  	  Hadoop based Frequent Closed Item-Sets for Association Rules form ...
IRJET- Hadoop based Frequent Closed Item-Sets for Association Rules form ...
IRJET Journal

Visualize open data with Plone - eea.daviz PLOG 2013
Visualize open data with Plone - eea.daviz PLOG 2013Visualize open data with Plone - eea.daviz PLOG 2013
Visualize open data with Plone - eea.daviz PLOG 2013
Antonio De Marinis

Metadata Provenance
Metadata ProvenanceMetadata Provenance
Metadata Provenance
Kai Eckert

05 SPARQL queries over Open Land Use, Open Transport Net and Smart Points Of ...
05 SPARQL queries over Open Land Use, Open Transport Net and Smart Points Of ...05 SPARQL queries over Open Land Use, Open Transport Net and Smart Points Of ...
05 SPARQL queries over Open Land Use, Open Transport Net and Smart Points Of ...
plan4all

OKE2018 Challenge @ ESWC2018
OKE2018 Challenge @ ESWC2018OKE2018 Challenge @ ESWC2018
OKE2018 Challenge @ ESWC2018
Holistic Benchmarking of Big Linked Data


Similar to EG-ICE 2015 - Coping with IFC lists in the ifcOWL ontology (20)

Getting the best of Linked Data and Property Graphs: rdf2neo and the KnetMine...
Getting the best of Linked Data and Property Graphs: rdf2neo and the KnetMine...Getting the best of Linked Data and Property Graphs: rdf2neo and the KnetMine...
Getting the best of Linked Data and Property Graphs: rdf2neo and the KnetMine...

Compiler2016 by abcdabcd987
Compiler2016 by abcdabcd987Compiler2016 by abcdabcd987
Compiler2016 by abcdabcd987

Force11 JDDCP workshop presentation, @ Force2015, Oxford
Force11 JDDCP workshop presentation, @ Force2015, OxfordForce11 JDDCP workshop presentation, @ Force2015, Oxford
Force11 JDDCP workshop presentation, @ Force2015, Oxford

Data FAIRport Skunkworks: Common Repository Access Via Meta-Metadata Descript...
Data FAIRport Skunkworks: Common Repository Access Via Meta-Metadata Descript...Data FAIRport Skunkworks: Common Repository Access Via Meta-Metadata Descript...
Data FAIRport Skunkworks: Common Repository Access Via Meta-Metadata Descript...

Bio2RDF@BH2010
Bio2RDF@BH2010Bio2RDF@BH2010
Bio2RDF@BH2010

Postgres в основе вашего дата-центра, Bruce Momjian (EnterpriseDB)
Postgres в основе вашего дата-центра, Bruce Momjian (EnterpriseDB)Postgres в основе вашего дата-центра, Bruce Momjian (EnterpriseDB)
Postgres в основе вашего дата-центра, Bruce Momjian (EnterpriseDB)

Pragmatic Optimization in Modern Programming - Demystifying the Compiler
Pragmatic Optimization in Modern Programming - Demystifying the CompilerPragmatic Optimization in Modern Programming - Demystifying the Compiler
Pragmatic Optimization in Modern Programming - Demystifying the Compiler

Scala Meetup Hamburg - Spark
Scala Meetup Hamburg - SparkScala Meetup Hamburg - Spark
Scala Meetup Hamburg - Spark

Algorithm
AlgorithmAlgorithm
Algorithm

Modern Association Rule Mining Methods
Modern Association Rule Mining MethodsModern Association Rule Mining Methods
Modern Association Rule Mining Methods

Training Large-scale Ad Ranking Models in Spark
Training Large-scale Ad Ranking Models in SparkTraining Large-scale Ad Ranking Models in Spark
Training Large-scale Ad Ranking Models in Spark

PyConLT19-No_more_struggles_with_Apache_Spark_(PySpark)_workloads_in_production
PyConLT19-No_more_struggles_with_Apache_Spark_(PySpark)_workloads_in_productionPyConLT19-No_more_struggles_with_Apache_Spark_(PySpark)_workloads_in_production
PyConLT19-No_more_struggles_with_Apache_Spark_(PySpark)_workloads_in_production

Prometheus as exposition format for eBPF programs running on Kubernetes
Prometheus as exposition format for eBPF programs running on KubernetesPrometheus as exposition format for eBPF programs running on Kubernetes
Prometheus as exposition format for eBPF programs running on Kubernetes

Project Hydrogen: State-of-the-Art Deep Learning on Apache Spark
Project Hydrogen: State-of-the-Art Deep Learning on Apache SparkProject Hydrogen: State-of-the-Art Deep Learning on Apache Spark
Project Hydrogen: State-of-the-Art Deep Learning on Apache Spark

Performance #5 cpu and battery
Performance #5  cpu and batteryPerformance #5  cpu and battery
Performance #5 cpu and battery

IRJET- Hadoop based Frequent Closed Item-Sets for Association Rules form ...
IRJET-  	  Hadoop based Frequent Closed Item-Sets for Association Rules form ...IRJET-  	  Hadoop based Frequent Closed Item-Sets for Association Rules form ...
IRJET- Hadoop based Frequent Closed Item-Sets for Association Rules form ...

Visualize open data with Plone - eea.daviz PLOG 2013
Visualize open data with Plone - eea.daviz PLOG 2013Visualize open data with Plone - eea.daviz PLOG 2013
Visualize open data with Plone - eea.daviz PLOG 2013

Metadata Provenance
Metadata ProvenanceMetadata Provenance
Metadata Provenance

05 SPARQL queries over Open Land Use, Open Transport Net and Smart Points Of ...
05 SPARQL queries over Open Land Use, Open Transport Net and Smart Points Of ...05 SPARQL queries over Open Land Use, Open Transport Net and Smart Points Of ...
05 SPARQL queries over Open Land Use, Open Transport Net and Smart Points Of ...

OKE2018 Challenge @ ESWC2018
OKE2018 Challenge @ ESWC2018OKE2018 Challenge @ ESWC2018
OKE2018 Challenge @ ESWC2018


More from Pieter Pauwels

FOMI2017 - A method to generate a modular ifcOWL ontology
FOMI2017 - A method to generate a modular ifcOWL ontologyFOMI2017 - A method to generate a modular ifcOWL ontology
FOMI2017 - A method to generate a modular ifcOWL ontology
Pieter Pauwels

FOMI2017 - Reusing Domain Ontologies in Linked Building Data: the Case of Bui...
FOMI2017 - Reusing Domain Ontologies in Linked Building Data: the Case of Bui...FOMI2017 - Reusing Domain Ontologies in Linked Building Data: the Case of Bui...
FOMI2017 - Reusing Domain Ontologies in Linked Building Data: the Case of Bui...
Pieter Pauwels

LOA seminar 2017 - Product and 3D geometry ontologies at action in constructi...
LOA seminar 2017 - Product and 3D geometry ontologies at action in constructi...LOA seminar 2017 - Product and 3D geometry ontologies at action in constructi...
LOA seminar 2017 - Product and 3D geometry ontologies at action in constructi...
Pieter Pauwels

UGent Research Projects on Linked Data in Architecture and Construction
UGent Research Projects on Linked Data in Architecture and ConstructionUGent Research Projects on Linked Data in Architecture and Construction
UGent Research Projects on Linked Data in Architecture and Construction
Pieter Pauwels

ECPPM2016 - SimpleBIM: from full ifcOWL graphs to simplified building graphs
ECPPM2016 - SimpleBIM: from full ifcOWL graphs to simplified building graphsECPPM2016 - SimpleBIM: from full ifcOWL graphs to simplified building graphs
ECPPM2016 - SimpleBIM: from full ifcOWL graphs to simplified building graphs
Pieter Pauwels

ECPPM2016 - ifcOWL for Managing Product Data
ECPPM2016 - ifcOWL for Managing Product DataECPPM2016 - ifcOWL for Managing Product Data
ECPPM2016 - ifcOWL for Managing Product Data
Pieter Pauwels

ECPPM2016 - SemCat: Publishing and Accessing Building Product Information as ...
ECPPM2016 - SemCat: Publishing and Accessing Building Product Information as ...ECPPM2016 - SemCat: Publishing and Accessing Building Product Information as ...
ECPPM2016 - SemCat: Publishing and Accessing Building Product Information as ...
Pieter Pauwels

ACM SIGMOD SBD2016 - Querying and reasoning over large scale building dataset...
ACM SIGMOD SBD2016 - Querying and reasoning over large scale building dataset...ACM SIGMOD SBD2016 - Querying and reasoning over large scale building dataset...
ACM SIGMOD SBD2016 - Querying and reasoning over large scale building dataset...
Pieter Pauwels

LDAC Workshop 2016 - Linked Building Data Community Efforts
LDAC Workshop 2016 - Linked Building Data Community EffortsLDAC Workshop 2016 - Linked Building Data Community Efforts
LDAC Workshop 2016 - Linked Building Data Community Efforts
Pieter Pauwels

BabelNet Workshop 2016 - Making sense of building data and building product data
BabelNet Workshop 2016 - Making sense of building data and building product dataBabelNet Workshop 2016 - Making sense of building data and building product data
BabelNet Workshop 2016 - Making sense of building data and building product data
Pieter Pauwels

BIMMeeting 2016 - BIM-Infra-GIS: building bridges from single buildings to di...
BIMMeeting 2016 - BIM-Infra-GIS: building bridges from single buildings to di...BIMMeeting 2016 - BIM-Infra-GIS: building bridges from single buildings to di...
BIMMeeting 2016 - BIM-Infra-GIS: building bridges from single buildings to di...
Pieter Pauwels

BuildingSMART Standards Summit 2015 - JBeetz - Product Room - Use Cases for i...
BuildingSMART Standards Summit 2015 - JBeetz - Product Room - Use Cases for i...BuildingSMART Standards Summit 2015 - JBeetz - Product Room - Use Cases for i...
BuildingSMART Standards Summit 2015 - JBeetz - Product Room - Use Cases for i...
Pieter Pauwels

SustainablePlaces_ifcOWL_applications_2015-09-17
SustainablePlaces_ifcOWL_applications_2015-09-17SustainablePlaces_ifcOWL_applications_2015-09-17
SustainablePlaces_ifcOWL_applications_2015-09-17
Pieter Pauwels

CIB W78 2015 - Semantic Rule-checking for Regulation Compliance Checking
CIB W78 2015 - Semantic Rule-checking for Regulation Compliance CheckingCIB W78 2015 - Semantic Rule-checking for Regulation Compliance Checking
CIB W78 2015 - Semantic Rule-checking for Regulation Compliance Checking
Pieter Pauwels

CIB W78 2015 - Keynote "The Web of Construction Data:Pathways and Opportunities"
CIB W78 2015 - Keynote "The Web of Construction Data:Pathways and Opportunities"CIB W78 2015 - Keynote "The Web of Construction Data:Pathways and Opportunities"
CIB W78 2015 - Keynote "The Web of Construction Data:Pathways and Opportunities"
Pieter Pauwels

CIB W78 Accelerating BIM Workshop 2015 - IFC2RDF tools
CIB W78 Accelerating BIM Workshop 2015 - IFC2RDF toolsCIB W78 Accelerating BIM Workshop 2015 - IFC2RDF tools
CIB W78 Accelerating BIM Workshop 2015 - IFC2RDF tools
Pieter Pauwels

CAA NLFL 2015 - Semantics in the documentation of architectural heritage: BIM...
CAA NLFL 2015 - Semantics in the documentation of architectural heritage: BIM...CAA NLFL 2015 - Semantics in the documentation of architectural heritage: BIM...
CAA NLFL 2015 - Semantics in the documentation of architectural heritage: BIM...
Pieter Pauwels

BuildingSMART Standards Summit 2015 - Technical Room - Linked Data for Constr...
BuildingSMART Standards Summit 2015 - Technical Room - Linked Data for Constr...BuildingSMART Standards Summit 2015 - Technical Room - Linked Data for Constr...
BuildingSMART Standards Summit 2015 - Technical Room - Linked Data for Constr...
Pieter Pauwels

2_presFriday_ontologydevelopment
2_presFriday_ontologydevelopment2_presFriday_ontologydevelopment
2_presFriday_ontologydevelopment
Pieter Pauwels

CAADFutures 2015 - Shape grammars for architectural design: the need for refr...
CAADFutures 2015 - Shape grammars for architectural design: the need for refr...CAADFutures 2015 - Shape grammars for architectural design: the need for refr...
CAADFutures 2015 - Shape grammars for architectural design: the need for refr...
Pieter Pauwels


More from Pieter Pauwels (20)

FOMI2017 - A method to generate a modular ifcOWL ontology
FOMI2017 - A method to generate a modular ifcOWL ontologyFOMI2017 - A method to generate a modular ifcOWL ontology
FOMI2017 - A method to generate a modular ifcOWL ontology

FOMI2017 - Reusing Domain Ontologies in Linked Building Data: the Case of Bui...
FOMI2017 - Reusing Domain Ontologies in Linked Building Data: the Case of Bui...FOMI2017 - Reusing Domain Ontologies in Linked Building Data: the Case of Bui...
FOMI2017 - Reusing Domain Ontologies in Linked Building Data: the Case of Bui...

LOA seminar 2017 - Product and 3D geometry ontologies at action in constructi...
LOA seminar 2017 - Product and 3D geometry ontologies at action in constructi...LOA seminar 2017 - Product and 3D geometry ontologies at action in constructi...
LOA seminar 2017 - Product and 3D geometry ontologies at action in constructi...

UGent Research Projects on Linked Data in Architecture and Construction
UGent Research Projects on Linked Data in Architecture and ConstructionUGent Research Projects on Linked Data in Architecture and Construction
UGent Research Projects on Linked Data in Architecture and Construction

ECPPM2016 - SimpleBIM: from full ifcOWL graphs to simplified building graphs
ECPPM2016 - SimpleBIM: from full ifcOWL graphs to simplified building graphsECPPM2016 - SimpleBIM: from full ifcOWL graphs to simplified building graphs
ECPPM2016 - SimpleBIM: from full ifcOWL graphs to simplified building graphs

ECPPM2016 - ifcOWL for Managing Product Data
ECPPM2016 - ifcOWL for Managing Product DataECPPM2016 - ifcOWL for Managing Product Data
ECPPM2016 - ifcOWL for Managing Product Data

ECPPM2016 - SemCat: Publishing and Accessing Building Product Information as ...
ECPPM2016 - SemCat: Publishing and Accessing Building Product Information as ...ECPPM2016 - SemCat: Publishing and Accessing Building Product Information as ...
ECPPM2016 - SemCat: Publishing and Accessing Building Product Information as ...

ACM SIGMOD SBD2016 - Querying and reasoning over large scale building dataset...
ACM SIGMOD SBD2016 - Querying and reasoning over large scale building dataset...ACM SIGMOD SBD2016 - Querying and reasoning over large scale building dataset...
ACM SIGMOD SBD2016 - Querying and reasoning over large scale building dataset...

LDAC Workshop 2016 - Linked Building Data Community Efforts
LDAC Workshop 2016 - Linked Building Data Community EffortsLDAC Workshop 2016 - Linked Building Data Community Efforts
LDAC Workshop 2016 - Linked Building Data Community Efforts

BabelNet Workshop 2016 - Making sense of building data and building product data
BabelNet Workshop 2016 - Making sense of building data and building product dataBabelNet Workshop 2016 - Making sense of building data and building product data
BabelNet Workshop 2016 - Making sense of building data and building product data

BIMMeeting 2016 - BIM-Infra-GIS: building bridges from single buildings to di...
BIMMeeting 2016 - BIM-Infra-GIS: building bridges from single buildings to di...BIMMeeting 2016 - BIM-Infra-GIS: building bridges from single buildings to di...
BIMMeeting 2016 - BIM-Infra-GIS: building bridges from single buildings to di...

BuildingSMART Standards Summit 2015 - JBeetz - Product Room - Use Cases for i...
BuildingSMART Standards Summit 2015 - JBeetz - Product Room - Use Cases for i...BuildingSMART Standards Summit 2015 - JBeetz - Product Room - Use Cases for i...
BuildingSMART Standards Summit 2015 - JBeetz - Product Room - Use Cases for i...

SustainablePlaces_ifcOWL_applications_2015-09-17
SustainablePlaces_ifcOWL_applications_2015-09-17SustainablePlaces_ifcOWL_applications_2015-09-17
SustainablePlaces_ifcOWL_applications_2015-09-17

CIB W78 2015 - Semantic Rule-checking for Regulation Compliance Checking
CIB W78 2015 - Semantic Rule-checking for Regulation Compliance CheckingCIB W78 2015 - Semantic Rule-checking for Regulation Compliance Checking
CIB W78 2015 - Semantic Rule-checking for Regulation Compliance Checking

CIB W78 2015 - Keynote "The Web of Construction Data:Pathways and Opportunities"
CIB W78 2015 - Keynote "The Web of Construction Data:Pathways and Opportunities"CIB W78 2015 - Keynote "The Web of Construction Data:Pathways and Opportunities"
CIB W78 2015 - Keynote "The Web of Construction Data:Pathways and Opportunities"

CIB W78 Accelerating BIM Workshop 2015 - IFC2RDF tools
CIB W78 Accelerating BIM Workshop 2015 - IFC2RDF toolsCIB W78 Accelerating BIM Workshop 2015 - IFC2RDF tools
CIB W78 Accelerating BIM Workshop 2015 - IFC2RDF tools

CAA NLFL 2015 - Semantics in the documentation of architectural heritage: BIM...
CAA NLFL 2015 - Semantics in the documentation of architectural heritage: BIM...CAA NLFL 2015 - Semantics in the documentation of architectural heritage: BIM...
CAA NLFL 2015 - Semantics in the documentation of architectural heritage: BIM...

BuildingSMART Standards Summit 2015 - Technical Room - Linked Data for Constr...
BuildingSMART Standards Summit 2015 - Technical Room - Linked Data for Constr...BuildingSMART Standards Summit 2015 - Technical Room - Linked Data for Constr...
BuildingSMART Standards Summit 2015 - Technical Room - Linked Data for Constr...

2_presFriday_ontologydevelopment
2_presFriday_ontologydevelopment2_presFriday_ontologydevelopment
2_presFriday_ontologydevelopment

CAADFutures 2015 - Shape grammars for architectural design: the need for refr...
CAADFutures 2015 - Shape grammars for architectural design: the need for refr...CAADFutures 2015 - Shape grammars for architectural design: the need for refr...
CAADFutures 2015 - Shape grammars for architectural design: the need for refr...


EG-ICE 2015 - Coping with IFC lists in the ifcOWL ontology
