PRINCIPLES AND PATTERNS
OF
SOFTWARE DESIGN
June 29, 2015
Paulo Sousa
Singleton
Tight coupling
Untestable
Premature optimization
Indescriptive Naming
Duplication
Code smells
Signs that the code is rotten and should be refactored
2
Single Responsibility Principle
Open/Close
Liskov Substitution Principle
Interface Segregation
Dependency Inversion
Single Responsibility Principle
A class should have only one reason to change.
4
5
Single Responsibility Principle
6
changeName(first, last)
changeAddress(street, zip)
first: string
last:string
street: string
zip: string
email:string
Person
changeName(first, last)
changeAddress(address)
first: string
last:string
email:string
Person
changeAddress(street, zip)
street: string
zip: string
Address
The domain, SRP and Value Objects
Primitive types are not the best option to represent
domain concepts!
Favour imutability of your objects.
7
Person
«value»
Name
«value»
Address
«value»
NIF
«value»
PhoneNumber
1..*1
1 *
«value»
Email
*
Open/Close Principle
A module should be open for extension but closed for
modification.
8
What would you choose to protect yourself from the
sun?
• Brain surgery to implant sun-resisting hair and
skin, or
• Put on a hat?
9
Polymorphism
10
Template Method
Define an overall
algorithm structure while
allowing for certain
operations (steps) to be
tailored for concrete
cases
11
Strategy
Provide different implementations of the same
algorithm and allow the client to choose which one to
use.
source: Design Patterns: Elements of Reusable Object-Oriented Software
Decorator
Dynamically attach additional
responsibilities to an object.
Decorators provide a flexible
alternative to subclassing for
extending functionality.
source: Design Patterns: Elements of Reusable
Object-Oriented Software
Visitor
Separate the algorithm from
the data structure it operates
on by creating a visitor that
traverses the desired object.
Source: http://www.oodesign.com/visitor-pattern.html
Liskov Substitution Principle
Subclasses should be substitutable for their base
classes.
15
The implication is:
Subclasses must abide the
same contract and invariants
of the base class, without
semantic changes.
The circle/elipse dilemma
16
The circle/ellipse dilemma
17
Interface Seggregation Principle
Many client specific interfaces are better than one
general purpose interface.
18
Interface Seggregation Principle
19
Interface Seggregation Principle
20
Dependency Inversion Principle
Depend upon Abstractions. Do not depend upon
concretions.
21
Dependency Inversion Principle
22
Dependency Injection
Modules declare their dependencies but do not
create them explicitily
23
class Component {
NeededService svc;
Component() {
svc = new ServiceImplementation();
}
}
class Component {
NeededService svc;
Component(NeededService impl) {
svc = impl;
}
}
Separated Interface
Defines an interface in a
separate package from
its implementation.
source: Patterns of Enterprise Application Architecture
Closings
25
Key Principles
 Consider what should be variable in your design
 Program to an interface not an implementation
 Keep different responsibilities apart from each
other
 Favour composition instead of inheritance
References
Bibliography
• Robert C. Martin. Design Principles and Design
Patterns.
http://www.objectmentor.com/resources/articles/Princ
iples_and_Patterns.pdf
• William Durand. From STUPID to SOLID code!.
http://williamdurand.fr/2013/07/30/from-stupid-to-
solid-code/
• Allen Holub. Why extends is evil.
http://www.javaworld.com/javaworld/jw-08-2003/jw-
0801-toolbox.html
• Erich Gamma, Richard Helm, Ralph Johnson, John
Vissides. Design patterns : elements of reusable object-
oriented software. Adisson-Wesley.
