CPU Caches
Jamie Allen
@jamie_allen
http://github.com/jamie-allen
JavaZone 2012
Agenda
• Goal
• Definitions
• Architectures
• Development Tips
• The Future
Goal
Provide you with the information you need
about CPU caches so that you can improve the
performance of your applications
Why?
• Increased virtualization
– Runtime (JVM, RVM)
– Platforms/Environments (cloud)
• Disruptor, 2011
Definitions
SMP
• Symmetric Multiprocessor (SMP) Architecture
• Shared main memory controlled by single OS
• No more Northbridge
NUMA
• Non-Uniform Memory Access
• The organization of processors reflect the time
to access data in RAM, called the “NUMA
factor”
• Shared memory space (as opposed to multiple
commodity machines)
Data Locality
• The most critical factor in performance
• Not guaranteed by a JVM
• Spatial - reused over and over in a loop, data
accessed in small regions
• Temporal - high probability it will be reused
before long
Memory Controller
• Manages communication of reads/writes
between the CPU and RAM
• Integrated Memory Controller on die
Cache Lines
• 32-256 contiguous bytes, most commonly 64
• Beware “false sharing”
• Use padding to ensure unshared lines
• Transferred in 64-bit blocks (8x for 64 byte
lines), arriving every ~4 cycles
• Position in the line of the “critical word”
matters, but not if pre-fetched
• @Contended annotation coming to JVM?
Cache Associativity
• Fully Associative: Put it anywhere
• Somewhere in the middle: n-way set-
associative, 2-way skewed-associative
• Direct Mapped: Each entry can only go in one
specific place
Cache Eviction Strategies
• Least Recently Used (LRU)
• Pseudo-LRU (PLRU): for large associativity
caches
• 2-Way Set Associative
• Direct Mapped
• Others
Cache Write Strategies
• Write through: changed cache line
immediately goes back to main memory
• Write back: cache line is marked when dirty,
eviction sends back to main memory
• Write combining: grouped writes of cache
lines back to main memory
• Uncacheable: dynamic values that can change
without warning
Exclusive versus Inclusive
• Only relevant below L3
• AMD is exclusive
– Progressively more costly due to eviction
– Can hold more data
– Bulldozer uses "write through" from L1d back to L2
• Intel is inclusive
– Can be better for inter-processor memory sharing
– More expensive as lines in L1 are also in L2 & L3
– If evicted in a higher level cache, must be evicted
below as well
Inter-Socket Communication
• GT/s – gigatransfers per second
• Quick Path Interconnect (QPI, Intel) – 8GT/s
• HyperTransport (HTX, AMD) – 6.4GT/s (?)
• Both transfer 16 bits per transmission in
practice, but Sandy Bridge is really 32
MESI+F Cache Coherency Protocol
• Specific to data cache lines
• Request for Ownership (RFO), when a processor tries to write to
a cache line
• Modified, the local processor has changed the cache line,
implies only one who has it
• Exclusive, one processor is using the cache line, not modified
• Shared, multiple processors are using the cache line, not
modified
• Invalid, the cache line is invalid, must be re-fetched
• Forward, designate to respond to requests for a cache line
• All processors MUST acknowledge a message for it to be valid
Static RAM (SRAM)
• Requires 6-8 pieces of circuitry per datum
• Cycle rate access, not quite measurable in
time
• Uses a relatively large amount of power for
what it does
• Data does not fade or leak, does not need to
be refreshed/recharged
Dynamic RAM (DRAM)
• Requires 2 pieces of circuitry per datum
• “Leaks” charge, but not sooner than 64ms
• Reads deplete the charge, requiring
subsequent recharge
• Takes 240 cycles (~100ns) to access
• Intel's Nehalem architecture - each CPU socket
controls a portion of RAM, no other socket has
direct access to it
Architectures
Current Processors
• Intel
– Nehalem/Westmere
– Sandy Bridge
– Ivy Bridge
• AMD
– Bulldozer
• Oracle
– UltraSPARC isn't dead
CPU Caches
“Latency Numbers Everyone Should Know”
L1 cache reference ......................... 0.5 ns
Branch mispredict ............................ 5 ns
L2 cache reference ........................... 7 ns
Mutex lock/unlock ........................... 25 ns
Main memory reference ...................... 100 ns
Compress 1K bytes with Zippy ............. 3,000 ns = 3 µs
Send 2K bytes over 1 Gbps network ....... 20,000 ns = 20 µs
SSD random read ........................ 150,000 ns = 150 µs
Read 1 MB sequentially from memory ..... 250,000 ns = 250 µs
Round trip within same datacenter ...... 500,000 ns = 0.5 ms
Read 1 MB sequentially from SSD* ..... 1,000,000 ns = 1 ms
Disk seek ........................... 10,000,000 ns = 10 ms
Read 1 MB sequentially from disk .... 20,000,000 ns = 20 ms
Send packet CA->Netherlands->CA .... 150,000,000 ns = 150 ms
• Shamelessly cribbed from this gist: https://gist.github.com/2843375, originally by Peter Norvig and amended by Jeff Dean
Measured Cache Latencies
Sandy Bridge-E L1d L2 L3 Main
=======================================================================
Sequential Access ..... 3 clk 11 clk 14 clk 6ns
Full Random Access .... 3 clk 11 clk 38 clk 65.8ns
SI Software's benchmarks: http://www.sisoftware.net/?d=qa&f=ben_mem_latency
Registers
• On-core for instructions being executed and
their operands
• Can be accessed in a single cycle
• There are many different types
• A 64-bit Intel Nehalem CPU had 128 Integer &
128 floating point registers
Store Buffers
• Hold data for Out of Order (OoO) execution
• Fully associative
• Prevent “stalls” in execution on a thread when
the cache line is not local to a core on a write
• ~1 cycle
Level Zero (L0)
• New to Sandy Bridge
• A cache of the last 1536 uops decoded
• Well-suited for hot loops
• Not the same as the older "trace" cache
Level One (L1)
• Divided into data and instructions
• 32K data (L1d), 32K instructions (L1i) per core
on a Sandy Bridge
• Sandy Bridge loads data at 256 bits per cycle,
double that of Nehalem
• 3-4 cycles to access L1d
Level Two (L2)
• 256K per core on a Sandy Bridge
• 2MB per “module” on AMD's Bulldozer
architecture
• ~11 cycles to access
• Unified data and instruction caches from here
up
• If the working set size is larger than L2, misses
grow
Level Three (L3)
• Was a “unified” cache up until Sandy Bridge,
shared between cores
• Varies in size with different processors and
versions of an architecture
• 14-38 cycles to access
Programming Tips
Striding & Pre-fetching
• Predictable memory access is really important
• Hardware pre-fetcher on the core looks for
patterns of memory access
• Can be counter-productive if the access
pattern is not predictable
• Martin Thompson blog post: “Memory Access
Patterns are Important”
• Shows the importance of locality and striding
Cache Misses
• Cost hundreds of cycles
• Keep your code simple
• Instruction read misses are most expensive
• Data read miss are less so, but still hurt performance
• Write misses are okay unless using Write Through
• Miss types:
– Compulsory
– Capacity
– Conflict
Programming Optimizations
• Stack allocated data is cheap
• Pointer interaction - you have to retrieve data
being pointed to, even in registers
• Avoid locking and resultant kernel arbitration
• CAS is better and occurs on-thread, but
algorithms become more complex
• Match workload to the size of the last level
cache (LLC, L3)
What about Functional Programming?
• Have to allocate more and more space for
your data structures, leads to eviction
• When you cycle back around, you get cache
misses
• Choose immutability by default, profile to find
poor performance
• Use mutable data in targeted locations
Hyperthreading
• Great for I/O-bound applications
• If you have lots of cache misses
• Doesn't do much for CPU-bound applications
• You have half of the cache resources per core
Data Structures
• BAD: Linked list structures and tree structures
• BAD: Java's HashMap uses chained buckets
• BAD: Standard Java collections generate lots of
garbage
• GOOD: Array-based and contiguous in memory is
much faster
• GOOD: Write your own that are lock-free and
contiguous
• GOOD: Fastutil library, but note that it's additive
Application Memory Wall & GC
• Tremendous amounts of RAM at low cost
• GC will kill you with compaction
• Use pauseless GC
– IBM's Metronome, very predictable
– Azul's C4, very performant
Using GPUs
• Remember, locality matters!
• Need to be able to export a task with data
that does not need to update
The Future
ManyCore
• David Ungar says > 24 cores, generally many
10s of cores
• Really gets interesting above 1000 cores
• Cache coherency won't be possible
• Non-deterministic
Memristor
• Non-volatile, static RAM, same write
endurance as Flash
• 200-300 MB on chip
• Sub-nanosecond writes
• Able to perform processing?
• Multistate, not binary
Phase Change Memory (PRAM)
• Higher performance than today's DRAM
• Intel seems more fascinated by this, just
released its "neuromorphic" chip design
• Not able to perform processing
• Write degradation is supposedly much slower
• Was considered susceptible to unintentional
change, maybe fixed?
Thanks!
Credits!
• What Every Programmer Should Know About Memory, Ulrich Drepper of
RedHat, 2007
• Java Performance, Charlie Hunt
• Wikipedia/Wikimedia Commons
• AnandTech
• The Microarchitecture of AMD, Intel and VIA CPUs
• Everything You Need to Know about the Quick Path Interconnect, Gabriel
Torres/Hardware Secrets
• Inside the Sandy Bridge Architecture, Gabriel Torres/Hardware Secrets
• Martin Thompson's Mechanical Sympathy blog and Disruptor
presentations
• The Application Memory Wall, Gil Tene, CTO of Azul Systems
• AMD Bulldozer/Intel Sandy Bridge Comparison, Gionatan Danti
• SI Software's Memory Latency Benchmarks
• Martin Thompson and Cliff Click provided feedback &additional content

More Related Content

What's hot

OS - Ch1
OS - Ch1OS - Ch1
OS - Ch1
sphs

CS4109 Computer System Architecture
CS4109 Computer System ArchitectureCS4109 Computer System Architecture
CS4109 Computer System Architecture
ktosri

Cache memory
Cache  memoryCache  memory
Cache memory
Prasenjit Dey

Multicore processor by Ankit Raj and Akash Prajapati
Multicore processor by Ankit Raj and Akash PrajapatiMulticore processor by Ankit Raj and Akash Prajapati
Multicore processor by Ankit Raj and Akash Prajapati
Ankit Raj

Computer architecture virtual memory
Computer architecture virtual memoryComputer architecture virtual memory
Computer architecture virtual memory
Mazin Alwaaly

Kompüterin Aparat Təminatı
Kompüterin Aparat TəminatıKompüterin Aparat Təminatı
Kompüterin Aparat Təminatı
fermanquliyev

OS Structure
OS StructureOS Structure
OS Structure
Ajay Singh Rana

0 introduction to computer architecture
0 introduction to computer architecture0 introduction to computer architecture
0 introduction to computer architecture
aamc1100

03_03_Implementing_PCIe_ATS_in_ARM-based_SoCs_Final
03_03_Implementing_PCIe_ATS_in_ARM-based_SoCs_Final03_03_Implementing_PCIe_ATS_in_ARM-based_SoCs_Final
03_03_Implementing_PCIe_ATS_in_ARM-based_SoCs_Final
Gopi Krishnamurthy

Real Time OS For Embedded Systems
Real Time OS For Embedded SystemsReal Time OS For Embedded Systems
Real Time OS For Embedded Systems
Himanshu Ghetia

Memórias
MemóriasMemórias
Memórias
André Lopes

Computer architecture multi core processor
Computer architecture multi core processorComputer architecture multi core processor
Computer architecture multi core processor
Mazin Alwaaly

Reliability, Availability, and Serviceability (RAS) on ARM64 status - SAN19-118
Reliability, Availability, and Serviceability (RAS) on ARM64 status - SAN19-118Reliability, Availability, and Serviceability (RAS) on ARM64 status - SAN19-118
Reliability, Availability, and Serviceability (RAS) on ARM64 status - SAN19-118
Wei Fu

Ch4 memory management
Ch4 memory managementCh4 memory management
Ch4 memory management
Bullz Musetsho

cache memory
 cache memory cache memory
cache memory
NAHID HASAN

BCS 100: Introduction to Computer Science Lesson 3
BCS 100: Introduction to Computer Science Lesson 3BCS 100: Introduction to Computer Science Lesson 3
BCS 100: Introduction to Computer Science Lesson 3
Ndubi Amos

GPU Computing
GPU ComputingGPU Computing
GPU Computing
Khan Mostafa

Cache memory
Cache memoryCache memory
Cache memory
Muhammad Imran

Introduction to Computer Architecture
Introduction to Computer ArchitectureIntroduction to Computer Architecture
Introduction to Computer Architecture
KSundarAPIICSE

Cache coherence
Cache coherenceCache coherence
Cache coherence
Employee


What's hot (20)

OS - Ch1
OS - Ch1OS - Ch1
OS - Ch1

CS4109 Computer System Architecture
CS4109 Computer System ArchitectureCS4109 Computer System Architecture
CS4109 Computer System Architecture

Cache memory
Cache  memoryCache  memory
Cache memory

Multicore processor by Ankit Raj and Akash Prajapati
Multicore processor by Ankit Raj and Akash PrajapatiMulticore processor by Ankit Raj and Akash Prajapati
Multicore processor by Ankit Raj and Akash Prajapati

Computer architecture virtual memory
Computer architecture virtual memoryComputer architecture virtual memory
Computer architecture virtual memory

Kompüterin Aparat Təminatı
Kompüterin Aparat TəminatıKompüterin Aparat Təminatı
Kompüterin Aparat Təminatı

OS Structure
OS StructureOS Structure
OS Structure

0 introduction to computer architecture
0 introduction to computer architecture0 introduction to computer architecture
0 introduction to computer architecture

03_03_Implementing_PCIe_ATS_in_ARM-based_SoCs_Final
03_03_Implementing_PCIe_ATS_in_ARM-based_SoCs_Final03_03_Implementing_PCIe_ATS_in_ARM-based_SoCs_Final
03_03_Implementing_PCIe_ATS_in_ARM-based_SoCs_Final

Real Time OS For Embedded Systems
Real Time OS For Embedded SystemsReal Time OS For Embedded Systems
Real Time OS For Embedded Systems

Memórias
MemóriasMemórias
Memórias

Computer architecture multi core processor
Computer architecture multi core processorComputer architecture multi core processor
Computer architecture multi core processor

Reliability, Availability, and Serviceability (RAS) on ARM64 status - SAN19-118
Reliability, Availability, and Serviceability (RAS) on ARM64 status - SAN19-118Reliability, Availability, and Serviceability (RAS) on ARM64 status - SAN19-118
Reliability, Availability, and Serviceability (RAS) on ARM64 status - SAN19-118

Ch4 memory management
Ch4 memory managementCh4 memory management
Ch4 memory management

cache memory
 cache memory cache memory
cache memory

BCS 100: Introduction to Computer Science Lesson 3
BCS 100: Introduction to Computer Science Lesson 3BCS 100: Introduction to Computer Science Lesson 3
BCS 100: Introduction to Computer Science Lesson 3

GPU Computing
GPU ComputingGPU Computing
GPU Computing

Cache memory
Cache memoryCache memory
Cache memory

Introduction to Computer Architecture
Introduction to Computer ArchitectureIntroduction to Computer Architecture
Introduction to Computer Architecture

Cache coherence
Cache coherenceCache coherence
Cache coherence


Viewers also liked

Cat @ scale
Cat @ scaleCat @ scale
Cat @ scale
Rohit Jnagal

VHPC'12: Pre-Copy and Post-Copy VM Live Migration for Memory Intensive Applic...
VHPC'12: Pre-Copy and Post-Copy VM Live Migration for Memory Intensive Applic...VHPC'12: Pre-Copy and Post-Copy VM Live Migration for Memory Intensive Applic...
VHPC'12: Pre-Copy and Post-Copy VM Live Migration for Memory Intensive Applic...
aidanshribman

Leveraging memory in sql server
Leveraging memory in sql serverLeveraging memory in sql server
Leveraging memory in sql server
Chris Adkin

SLES Performance Enhancements for Large NUMA Systems
SLES Performance Enhancements for Large NUMA SystemsSLES Performance Enhancements for Large NUMA Systems
SLES Performance Enhancements for Large NUMA Systems
Davidlohr Bueso

美团技术沙龙04 - 高性能服务器架构设计和调优
美团技术沙龙04 - 高性能服务器架构设计和调优美团技术沙龙04 - 高性能服务器架构设计和调优
美团技术沙龙04 - 高性能服务器架构设计和调优
美团点评技术团队

Tuning Linux for Databases.
Tuning Linux for Databases.Tuning Linux for Databases.
Tuning Linux for Databases.
Alexey Lesovsky

Summit2014 riel chegu_w_0340_automatic_numa_balancing_0
Summit2014 riel chegu_w_0340_automatic_numa_balancing_0Summit2014 riel chegu_w_0340_automatic_numa_balancing_0
Summit2014 riel chegu_w_0340_automatic_numa_balancing_0
sprdd

Aca 2
Aca 2Aca 2
Technical update KVM and Red Hat Enterprise Virtualization (RHEV) by syedmshaaf
Technical update KVM and Red Hat Enterprise Virtualization (RHEV) by syedmshaafTechnical update KVM and Red Hat Enterprise Virtualization (RHEV) by syedmshaaf
Technical update KVM and Red Hat Enterprise Virtualization (RHEV) by syedmshaaf
Syed Shaaf

Cache & CPU performance
Cache & CPU performanceCache & CPU performance
Cache & CPU performance
so61pi

Linux NUMA & Databases: Perils and Opportunities
Linux NUMA & Databases: Perils and OpportunitiesLinux NUMA & Databases: Perils and Opportunities
Linux NUMA & Databases: Perils and Opportunities
Raghavendra Prabhu

QEMU Disk IO Which performs Better: Native or threads?
QEMU Disk IO Which performs Better: Native or threads?QEMU Disk IO Which performs Better: Native or threads?
QEMU Disk IO Which performs Better: Native or threads?
Pradeep Kumar

NUMA overview
NUMA overviewNUMA overview
NUMA overview
Abed Maatalla

Notes on NUMA architecture
Notes on NUMA architectureNotes on NUMA architecture
Notes on NUMA architecture
Intel Software Brasil

Kvm performance optimization for ubuntu
Kvm performance optimization for ubuntuKvm performance optimization for ubuntu
Kvm performance optimization for ubuntu
Sim Janghoon

Multiprocessor architecture
Multiprocessor architectureMultiprocessor architecture
Multiprocessor architecture
Arpan Baishya

Multiple processor (ppt 2010)
Multiple processor (ppt 2010)Multiple processor (ppt 2010)
Multiple processor (ppt 2010)
Arth Ramada

Multi-Physics Methods, Modeling, Simulation & Analysis
Multi-Physics Methods, Modeling, Simulation & AnalysisMulti-Physics Methods, Modeling, Simulation & Analysis
Multi-Physics Methods, Modeling, Simulation & Analysis
inside-BigData.com

Virtualization Architecture & KVM
Virtualization Architecture & KVMVirtualization Architecture & KVM
Virtualization Architecture & KVM
Pradeep Kumar


Viewers also liked (20)

Cat @ scale
Cat @ scaleCat @ scale
Cat @ scale

VHPC'12: Pre-Copy and Post-Copy VM Live Migration for Memory Intensive Applic...
VHPC'12: Pre-Copy and Post-Copy VM Live Migration for Memory Intensive Applic...VHPC'12: Pre-Copy and Post-Copy VM Live Migration for Memory Intensive Applic...
VHPC'12: Pre-Copy and Post-Copy VM Live Migration for Memory Intensive Applic...

Leveraging memory in sql server
Leveraging memory in sql serverLeveraging memory in sql server
Leveraging memory in sql server

SLES Performance Enhancements for Large NUMA Systems
SLES Performance Enhancements for Large NUMA SystemsSLES Performance Enhancements for Large NUMA Systems
SLES Performance Enhancements for Large NUMA Systems

美团技术沙龙04 - 高性能服务器架构设计和调优
美团技术沙龙04 - 高性能服务器架构设计和调优美团技术沙龙04 - 高性能服务器架构设计和调优
美团技术沙龙04 - 高性能服务器架构设计和调优

Tuning Linux for Databases.
Tuning Linux for Databases.Tuning Linux for Databases.
Tuning Linux for Databases.

Summit2014 riel chegu_w_0340_automatic_numa_balancing_0
Summit2014 riel chegu_w_0340_automatic_numa_balancing_0Summit2014 riel chegu_w_0340_automatic_numa_balancing_0
Summit2014 riel chegu_w_0340_automatic_numa_balancing_0

Aca 2
Aca 2Aca 2
Aca 2

Technical update KVM and Red Hat Enterprise Virtualization (RHEV) by syedmshaaf
Technical update KVM and Red Hat Enterprise Virtualization (RHEV) by syedmshaafTechnical update KVM and Red Hat Enterprise Virtualization (RHEV) by syedmshaaf
Technical update KVM and Red Hat Enterprise Virtualization (RHEV) by syedmshaaf

Cache & CPU performance
Cache & CPU performanceCache & CPU performance
Cache & CPU performance

Linux NUMA & Databases: Perils and Opportunities
Linux NUMA & Databases: Perils and OpportunitiesLinux NUMA & Databases: Perils and Opportunities
Linux NUMA & Databases: Perils and Opportunities

美团技术团队 - KVM性能优化
美团技术团队 - KVM性能优化美团技术团队 - KVM性能优化
美团技术团队 - KVM性能优化

QEMU Disk IO Which performs Better: Native or threads?
QEMU Disk IO Which performs Better: Native or threads?QEMU Disk IO Which performs Better: Native or threads?
QEMU Disk IO Which performs Better: Native or threads?

NUMA overview
NUMA overviewNUMA overview
NUMA overview

Notes on NUMA architecture
Notes on NUMA architectureNotes on NUMA architecture
Notes on NUMA architecture

Kvm performance optimization for ubuntu
Kvm performance optimization for ubuntuKvm performance optimization for ubuntu
Kvm performance optimization for ubuntu

Multiprocessor architecture
Multiprocessor architectureMultiprocessor architecture
Multiprocessor architecture

Multiple processor (ppt 2010)
Multiple processor (ppt 2010)Multiple processor (ppt 2010)
Multiple processor (ppt 2010)

Multi-Physics Methods, Modeling, Simulation & Analysis
Multi-Physics Methods, Modeling, Simulation & AnalysisMulti-Physics Methods, Modeling, Simulation & Analysis
Multi-Physics Methods, Modeling, Simulation & Analysis

Virtualization Architecture & KVM
Virtualization Architecture & KVMVirtualization Architecture & KVM
Virtualization Architecture & KVM


Similar to CPU Caches

CPU Caches - Jamie Allen
CPU Caches - Jamie AllenCPU Caches - Jamie Allen
CPU Caches - Jamie Allen
jaxconf

Cpu Caches
Cpu CachesCpu Caches
Cpu Caches
shinolajla

Motivation for multithreaded architectures
Motivation for multithreaded architecturesMotivation for multithreaded architectures
Motivation for multithreaded architectures
Young Alista

Multicore computers
Multicore computersMulticore computers
Multicore computers
Syed Zaid Irshad

chap 18 multicore computers
chap 18 multicore computers chap 18 multicore computers
chap 18 multicore computers
Sher Shah Merkhel

network ram parallel computing
network ram parallel computingnetwork ram parallel computing
network ram parallel computing
Niranjana Ambadi

LMAX Disruptor - High Performance Inter-Thread Messaging Library
LMAX Disruptor - High Performance Inter-Thread Messaging LibraryLMAX Disruptor - High Performance Inter-Thread Messaging Library
LMAX Disruptor - High Performance Inter-Thread Messaging Library
Sebastian Andrasoni

Memory
MemoryMemory
Basic Computer Architecture
Basic Computer ArchitectureBasic Computer Architecture
Basic Computer Architecture
Yong Heui Cho

Coa presentation3
Coa presentation3Coa presentation3
Coa presentation3
rickypatel151

A Closer Look at Apache Kudu
A Closer Look at Apache KuduA Closer Look at Apache Kudu
A Closer Look at Apache Kudu
Andriy Zabavskyy

cachegrand: A Take on High Performance Caching
cachegrand: A Take on High Performance Cachingcachegrand: A Take on High Performance Caching
cachegrand: A Take on High Performance Caching
ScyllaDB

5_Embedded Systems مختصر.pdf
5_Embedded Systems  مختصر.pdf5_Embedded Systems  مختصر.pdf
5_Embedded Systems مختصر.pdf
aliamjd

In-memory Data Management Trends & Techniques
In-memory Data Management Trends & TechniquesIn-memory Data Management Trends & Techniques
In-memory Data Management Trends & Techniques
Hazelcast

Tuning Linux for your database FLOSSUK 2016
Tuning Linux for your database FLOSSUK 2016Tuning Linux for your database FLOSSUK 2016
Tuning Linux for your database FLOSSUK 2016
Colin Charles

Cassandra Core Concepts
Cassandra Core ConceptsCassandra Core Concepts
Cassandra Core Concepts
DataStax Academy

Taming Non-blocking Caches to Improve Isolation in Multicore Real-Time Systems
Taming Non-blocking Caches to Improve Isolation in Multicore Real-Time SystemsTaming Non-blocking Caches to Improve Isolation in Multicore Real-Time Systems
Taming Non-blocking Caches to Improve Isolation in Multicore Real-Time Systems
Heechul Yun

Jay Kreps on Project Voldemort Scaling Simple Storage At LinkedIn
Jay Kreps on Project Voldemort Scaling Simple Storage At LinkedInJay Kreps on Project Voldemort Scaling Simple Storage At LinkedIn
Jay Kreps on Project Voldemort Scaling Simple Storage At LinkedIn
LinkedIn

INFORMATION TECHNOLOGY HARDWARE LESSON GRD 12.pptx
INFORMATION TECHNOLOGY HARDWARE LESSON GRD 12.pptxINFORMATION TECHNOLOGY HARDWARE LESSON GRD 12.pptx
INFORMATION TECHNOLOGY HARDWARE LESSON GRD 12.pptx
disoloaneglenda

Modeling, estimating, and predicting Ceph (Linux Foundation - Vault 2015)
Modeling, estimating, and predicting Ceph (Linux Foundation - Vault 2015)Modeling, estimating, and predicting Ceph (Linux Foundation - Vault 2015)
Modeling, estimating, and predicting Ceph (Linux Foundation - Vault 2015)
Lars Marowsky-Brée


Similar to CPU Caches (20)

CPU Caches - Jamie Allen
CPU Caches - Jamie AllenCPU Caches - Jamie Allen
CPU Caches - Jamie Allen

Cpu Caches
Cpu CachesCpu Caches
Cpu Caches

Motivation for multithreaded architectures
Motivation for multithreaded architecturesMotivation for multithreaded architectures
Motivation for multithreaded architectures

Multicore computers
Multicore computersMulticore computers
Multicore computers

chap 18 multicore computers
chap 18 multicore computers chap 18 multicore computers
chap 18 multicore computers

network ram parallel computing
network ram parallel computingnetwork ram parallel computing
network ram parallel computing

LMAX Disruptor - High Performance Inter-Thread Messaging Library
LMAX Disruptor - High Performance Inter-Thread Messaging LibraryLMAX Disruptor - High Performance Inter-Thread Messaging Library
LMAX Disruptor - High Performance Inter-Thread Messaging Library

Memory
MemoryMemory
Memory

Basic Computer Architecture
Basic Computer ArchitectureBasic Computer Architecture
Basic Computer Architecture

Coa presentation3
Coa presentation3Coa presentation3
Coa presentation3

A Closer Look at Apache Kudu
A Closer Look at Apache KuduA Closer Look at Apache Kudu
A Closer Look at Apache Kudu

cachegrand: A Take on High Performance Caching
cachegrand: A Take on High Performance Cachingcachegrand: A Take on High Performance Caching
cachegrand: A Take on High Performance Caching

5_Embedded Systems مختصر.pdf
5_Embedded Systems  مختصر.pdf5_Embedded Systems  مختصر.pdf
5_Embedded Systems مختصر.pdf

In-memory Data Management Trends & Techniques
In-memory Data Management Trends & TechniquesIn-memory Data Management Trends & Techniques
In-memory Data Management Trends & Techniques

Tuning Linux for your database FLOSSUK 2016
Tuning Linux for your database FLOSSUK 2016Tuning Linux for your database FLOSSUK 2016
Tuning Linux for your database FLOSSUK 2016

Cassandra Core Concepts
Cassandra Core ConceptsCassandra Core Concepts
Cassandra Core Concepts

Taming Non-blocking Caches to Improve Isolation in Multicore Real-Time Systems
Taming Non-blocking Caches to Improve Isolation in Multicore Real-Time SystemsTaming Non-blocking Caches to Improve Isolation in Multicore Real-Time Systems
Taming Non-blocking Caches to Improve Isolation in Multicore Real-Time Systems

Jay Kreps on Project Voldemort Scaling Simple Storage At LinkedIn
Jay Kreps on Project Voldemort Scaling Simple Storage At LinkedInJay Kreps on Project Voldemort Scaling Simple Storage At LinkedIn
Jay Kreps on Project Voldemort Scaling Simple Storage At LinkedIn

INFORMATION TECHNOLOGY HARDWARE LESSON GRD 12.pptx
INFORMATION TECHNOLOGY HARDWARE LESSON GRD 12.pptxINFORMATION TECHNOLOGY HARDWARE LESSON GRD 12.pptx
INFORMATION TECHNOLOGY HARDWARE LESSON GRD 12.pptx

Modeling, estimating, and predicting Ceph (Linux Foundation - Vault 2015)
Modeling, estimating, and predicting Ceph (Linux Foundation - Vault 2015)Modeling, estimating, and predicting Ceph (Linux Foundation - Vault 2015)
Modeling, estimating, and predicting Ceph (Linux Foundation - Vault 2015)


More from shinolajla

20180416 reactive is_a_product_rs
20180416 reactive is_a_product_rs20180416 reactive is_a_product_rs
20180416 reactive is_a_product_rs
shinolajla

20180416 reactive is_a_product
20180416 reactive is_a_product20180416 reactive is_a_product
20180416 reactive is_a_product
shinolajla

20161027 scala io_keynote
20161027 scala io_keynote20161027 scala io_keynote
20161027 scala io_keynote
shinolajla

20160609 nike techtalks reactive applications tools of the trade
20160609 nike techtalks reactive applications   tools of the trade20160609 nike techtalks reactive applications   tools of the trade
20160609 nike techtalks reactive applications tools of the trade
shinolajla

20160524 ibm fast data meetup
20160524 ibm fast data meetup20160524 ibm fast data meetup
20160524 ibm fast data meetup
shinolajla

20160520 The Future of Services
20160520 The Future of Services20160520 The Future of Services
20160520 The Future of Services
shinolajla

20160520 what youneedtoknowaboutlambdas
20160520 what youneedtoknowaboutlambdas20160520 what youneedtoknowaboutlambdas
20160520 what youneedtoknowaboutlambdas
shinolajla

20160317 lagom sf scala
20160317 lagom sf scala20160317 lagom sf scala
20160317 lagom sf scala
shinolajla

Effective Akka v2
Effective Akka v2Effective Akka v2
Effective Akka v2
shinolajla

20150411 mutability matrix of pain scala
20150411 mutability matrix of pain scala20150411 mutability matrix of pain scala
20150411 mutability matrix of pain scala
shinolajla

Reactive applications tools of the trade huff po
Reactive applications   tools of the trade huff poReactive applications   tools of the trade huff po
Reactive applications tools of the trade huff po
shinolajla

20140228 fp and_performance
20140228 fp and_performance20140228 fp and_performance
20140228 fp and_performance
shinolajla

Effective akka scalaio
Effective akka scalaioEffective akka scalaio
Effective akka scalaio
shinolajla

Real world akka recepies v3
Real world akka recepies v3Real world akka recepies v3
Real world akka recepies v3
shinolajla

Effective actors japanesesub
Effective actors japanesesubEffective actors japanesesub
Effective actors japanesesub
shinolajla

Effective Actors
Effective ActorsEffective Actors
Effective Actors
shinolajla

Taxonomy of Scala
Taxonomy of ScalaTaxonomy of Scala
Taxonomy of Scala
shinolajla


More from shinolajla (17)

20180416 reactive is_a_product_rs
20180416 reactive is_a_product_rs20180416 reactive is_a_product_rs
20180416 reactive is_a_product_rs

20180416 reactive is_a_product
20180416 reactive is_a_product20180416 reactive is_a_product
20180416 reactive is_a_product

20161027 scala io_keynote
20161027 scala io_keynote20161027 scala io_keynote
20161027 scala io_keynote

20160609 nike techtalks reactive applications tools of the trade
20160609 nike techtalks reactive applications   tools of the trade20160609 nike techtalks reactive applications   tools of the trade
20160609 nike techtalks reactive applications tools of the trade

20160524 ibm fast data meetup
20160524 ibm fast data meetup20160524 ibm fast data meetup
20160524 ibm fast data meetup

20160520 The Future of Services
20160520 The Future of Services20160520 The Future of Services
20160520 The Future of Services

20160520 what youneedtoknowaboutlambdas
20160520 what youneedtoknowaboutlambdas20160520 what youneedtoknowaboutlambdas
20160520 what youneedtoknowaboutlambdas

20160317 lagom sf scala
20160317 lagom sf scala20160317 lagom sf scala
20160317 lagom sf scala

Effective Akka v2
Effective Akka v2Effective Akka v2
Effective Akka v2

20150411 mutability matrix of pain scala
20150411 mutability matrix of pain scala20150411 mutability matrix of pain scala
20150411 mutability matrix of pain scala

Reactive applications tools of the trade huff po
Reactive applications   tools of the trade huff poReactive applications   tools of the trade huff po
Reactive applications tools of the trade huff po

20140228 fp and_performance
20140228 fp and_performance20140228 fp and_performance
20140228 fp and_performance

Effective akka scalaio
Effective akka scalaioEffective akka scalaio
Effective akka scalaio

Real world akka recepies v3
Real world akka recepies v3Real world akka recepies v3
Real world akka recepies v3

Effective actors japanesesub
Effective actors japanesesubEffective actors japanesesub
Effective actors japanesesub

Effective Actors
Effective ActorsEffective Actors
Effective Actors

Taxonomy of Scala
Taxonomy of ScalaTaxonomy of Scala
Taxonomy of Scala


Recently uploaded

Acumatica vs. Sage Intacct _Construction_July (1).pptx
Acumatica vs. Sage Intacct _Construction_July (1).pptxAcumatica vs. Sage Intacct _Construction_July (1).pptx
Acumatica vs. Sage Intacct _Construction_July (1).pptx
BrainSell Technologies

Generative AI Reasoning Tech Talk - July 2024
Generative AI Reasoning Tech Talk - July 2024Generative AI Reasoning Tech Talk - July 2024
Generative AI Reasoning Tech Talk - July 2024
siddu769252

Keynote : AI & Future Of Offensive Security
Keynote : AI & Future Of Offensive SecurityKeynote : AI & Future Of Offensive Security
Keynote : AI & Future Of Offensive Security
Priyanka Aash

Finetuning GenAI For Hacking and Defending
Finetuning GenAI For Hacking and DefendingFinetuning GenAI For Hacking and Defending
Finetuning GenAI For Hacking and Defending
Priyanka Aash

Discovery Series - Zero to Hero - Task Mining Session 1
Discovery Series - Zero to Hero - Task Mining Session 1Discovery Series - Zero to Hero - Task Mining Session 1
Discovery Series - Zero to Hero - Task Mining Session 1
DianaGray10

How UiPath Discovery Suite supports identification of Agentic Process Automat...
How UiPath Discovery Suite supports identification of Agentic Process Automat...How UiPath Discovery Suite supports identification of Agentic Process Automat...
How UiPath Discovery Suite supports identification of Agentic Process Automat...
DianaGray10

Welcome to Cyberbiosecurity. Because regular cybersecurity wasn't complicated...
Welcome to Cyberbiosecurity. Because regular cybersecurity wasn't complicated...Welcome to Cyberbiosecurity. Because regular cybersecurity wasn't complicated...
Welcome to Cyberbiosecurity. Because regular cybersecurity wasn't complicated...
Snarky Security

Intel Unveils Core Ultra 200V Lunar chip .pdf
Intel Unveils Core Ultra 200V Lunar chip .pdfIntel Unveils Core Ultra 200V Lunar chip .pdf
Intel Unveils Core Ultra 200V Lunar chip .pdf
Tech Guru

Choosing the Best Outlook OST to PST Converter: Key Features and Considerations
Choosing the Best Outlook OST to PST Converter: Key Features and ConsiderationsChoosing the Best Outlook OST to PST Converter: Key Features and Considerations
Choosing the Best Outlook OST to PST Converter: Key Features and Considerations
webbyacad software

Demystifying Neural Networks And Building Cybersecurity Applications
Demystifying Neural Networks And Building Cybersecurity ApplicationsDemystifying Neural Networks And Building Cybersecurity Applications
Demystifying Neural Networks And Building Cybersecurity Applications
Priyanka Aash

Semantic-Aware Code Model: Elevating the Future of Software Development
Semantic-Aware Code Model: Elevating the Future of Software DevelopmentSemantic-Aware Code Model: Elevating the Future of Software Development
Semantic-Aware Code Model: Elevating the Future of Software Development
Baishakhi Ray

Mastering OnlyFans Clone App Development: Key Strategies for Success
Mastering OnlyFans Clone App Development: Key Strategies for SuccessMastering OnlyFans Clone App Development: Key Strategies for Success
Mastering OnlyFans Clone App Development: Key Strategies for Success
David Wilson

Computer HARDWARE presenattion by CWD students class 10
Computer HARDWARE presenattion by CWD students class 10Computer HARDWARE presenattion by CWD students class 10
Computer HARDWARE presenattion by CWD students class 10
ankush9927

COVID-19 and the Level of Cloud Computing Adoption: A Study of Sri Lankan Inf...
COVID-19 and the Level of Cloud Computing Adoption: A Study of Sri Lankan Inf...COVID-19 and the Level of Cloud Computing Adoption: A Study of Sri Lankan Inf...
COVID-19 and the Level of Cloud Computing Adoption: A Study of Sri Lankan Inf...
AimanAthambawa1

UX Webinar Series: Aligning Authentication Experiences with Business Goals
UX Webinar Series: Aligning Authentication Experiences with Business GoalsUX Webinar Series: Aligning Authentication Experiences with Business Goals
UX Webinar Series: Aligning Authentication Experiences with Business Goals
FIDO Alliance

Keynote : Presentation on SASE Technology
Keynote : Presentation on SASE TechnologyKeynote : Presentation on SASE Technology
Keynote : Presentation on SASE Technology
Priyanka Aash

Camunda Chapter NY Meetup July 2024.pptx
Camunda Chapter NY Meetup July 2024.pptxCamunda Chapter NY Meetup July 2024.pptx
Camunda Chapter NY Meetup July 2024.pptx
ZachWylie3

UX Webinar Series: Essentials for Adopting Passkeys as the Foundation of your...
UX Webinar Series: Essentials for Adopting Passkeys as the Foundation of your...UX Webinar Series: Essentials for Adopting Passkeys as the Foundation of your...
UX Webinar Series: Essentials for Adopting Passkeys as the Foundation of your...
FIDO Alliance

Accelerating Migrations = Recommendations
Accelerating Migrations = RecommendationsAccelerating Migrations = Recommendations
Accelerating Migrations = Recommendations
isBullShit

Vulnerability Management: A Comprehensive Overview
Vulnerability Management: A Comprehensive OverviewVulnerability Management: A Comprehensive Overview
Vulnerability Management: A Comprehensive Overview
Steven Carlson


Recently uploaded (20)

Acumatica vs. Sage Intacct _Construction_July (1).pptx
Acumatica vs. Sage Intacct _Construction_July (1).pptxAcumatica vs. Sage Intacct _Construction_July (1).pptx
Acumatica vs. Sage Intacct _Construction_July (1).pptx

Generative AI Reasoning Tech Talk - July 2024
Generative AI Reasoning Tech Talk - July 2024Generative AI Reasoning Tech Talk - July 2024
Generative AI Reasoning Tech Talk - July 2024

Keynote : AI & Future Of Offensive Security
Keynote : AI & Future Of Offensive SecurityKeynote : AI & Future Of Offensive Security
Keynote : AI & Future Of Offensive Security

Finetuning GenAI For Hacking and Defending
Finetuning GenAI For Hacking and DefendingFinetuning GenAI For Hacking and Defending
Finetuning GenAI For Hacking and Defending

Discovery Series - Zero to Hero - Task Mining Session 1
Discovery Series - Zero to Hero - Task Mining Session 1Discovery Series - Zero to Hero - Task Mining Session 1
Discovery Series - Zero to Hero - Task Mining Session 1

How UiPath Discovery Suite supports identification of Agentic Process Automat...
How UiPath Discovery Suite supports identification of Agentic Process Automat...How UiPath Discovery Suite supports identification of Agentic Process Automat...
How UiPath Discovery Suite supports identification of Agentic Process Automat...

Welcome to Cyberbiosecurity. Because regular cybersecurity wasn't complicated...
Welcome to Cyberbiosecurity. Because regular cybersecurity wasn't complicated...Welcome to Cyberbiosecurity. Because regular cybersecurity wasn't complicated...
Welcome to Cyberbiosecurity. Because regular cybersecurity wasn't complicated...

Intel Unveils Core Ultra 200V Lunar chip .pdf
Intel Unveils Core Ultra 200V Lunar chip .pdfIntel Unveils Core Ultra 200V Lunar chip .pdf
Intel Unveils Core Ultra 200V Lunar chip .pdf

Choosing the Best Outlook OST to PST Converter: Key Features and Considerations
Choosing the Best Outlook OST to PST Converter: Key Features and ConsiderationsChoosing the Best Outlook OST to PST Converter: Key Features and Considerations
Choosing the Best Outlook OST to PST Converter: Key Features and Considerations

Demystifying Neural Networks And Building Cybersecurity Applications
Demystifying Neural Networks And Building Cybersecurity ApplicationsDemystifying Neural Networks And Building Cybersecurity Applications
Demystifying Neural Networks And Building Cybersecurity Applications

Semantic-Aware Code Model: Elevating the Future of Software Development
Semantic-Aware Code Model: Elevating the Future of Software DevelopmentSemantic-Aware Code Model: Elevating the Future of Software Development
Semantic-Aware Code Model: Elevating the Future of Software Development

Mastering OnlyFans Clone App Development: Key Strategies for Success
Mastering OnlyFans Clone App Development: Key Strategies for SuccessMastering OnlyFans Clone App Development: Key Strategies for Success
Mastering OnlyFans Clone App Development: Key Strategies for Success

Computer HARDWARE presenattion by CWD students class 10
Computer HARDWARE presenattion by CWD students class 10Computer HARDWARE presenattion by CWD students class 10
Computer HARDWARE presenattion by CWD students class 10

COVID-19 and the Level of Cloud Computing Adoption: A Study of Sri Lankan Inf...
COVID-19 and the Level of Cloud Computing Adoption: A Study of Sri Lankan Inf...COVID-19 and the Level of Cloud Computing Adoption: A Study of Sri Lankan Inf...
COVID-19 and the Level of Cloud Computing Adoption: A Study of Sri Lankan Inf...

UX Webinar Series: Aligning Authentication Experiences with Business Goals
UX Webinar Series: Aligning Authentication Experiences with Business GoalsUX Webinar Series: Aligning Authentication Experiences with Business Goals
UX Webinar Series: Aligning Authentication Experiences with Business Goals

Keynote : Presentation on SASE Technology
Keynote : Presentation on SASE TechnologyKeynote : Presentation on SASE Technology
Keynote : Presentation on SASE Technology

Camunda Chapter NY Meetup July 2024.pptx
Camunda Chapter NY Meetup July 2024.pptxCamunda Chapter NY Meetup July 2024.pptx
Camunda Chapter NY Meetup July 2024.pptx

UX Webinar Series: Essentials for Adopting Passkeys as the Foundation of your...
UX Webinar Series: Essentials for Adopting Passkeys as the Foundation of your...UX Webinar Series: Essentials for Adopting Passkeys as the Foundation of your...
UX Webinar Series: Essentials for Adopting Passkeys as the Foundation of your...

Accelerating Migrations = Recommendations
Accelerating Migrations = RecommendationsAccelerating Migrations = Recommendations
Accelerating Migrations = Recommendations

Vulnerability Management: A Comprehensive Overview
Vulnerability Management: A Comprehensive OverviewVulnerability Management: A Comprehensive Overview
Vulnerability Management: A Comprehensive Overview


CPU Caches

  • 2. Agenda • Goal • Definitions • Architectures • Development Tips • The Future
  • 3. Goal Provide you with the information you need about CPU caches so that you can improve the performance of your applications
  • 4. Why? • Increased virtualization – Runtime (JVM, RVM) – Platforms/Environments (cloud) • Disruptor, 2011
  • 6. SMP • Symmetric Multiprocessor (SMP) Architecture • Shared main memory controlled by single OS • No more Northbridge
  • 7. NUMA • Non-Uniform Memory Access • The organization of processors reflect the time to access data in RAM, called the “NUMA factor” • Shared memory space (as opposed to multiple commodity machines)
  • 8. Data Locality • The most critical factor in performance • Not guaranteed by a JVM • Spatial - reused over and over in a loop, data accessed in small regions • Temporal - high probability it will be reused before long
  • 9. Memory Controller • Manages communication of reads/writes between the CPU and RAM • Integrated Memory Controller on die
  • 10. Cache Lines • 32-256 contiguous bytes, most commonly 64 • Beware “false sharing” • Use padding to ensure unshared lines • Transferred in 64-bit blocks (8x for 64 byte lines), arriving every ~4 cycles • Position in the line of the “critical word” matters, but not if pre-fetched • @Contended annotation coming to JVM?
  • 11. Cache Associativity • Fully Associative: Put it anywhere • Somewhere in the middle: n-way set- associative, 2-way skewed-associative • Direct Mapped: Each entry can only go in one specific place
  • 12. Cache Eviction Strategies • Least Recently Used (LRU) • Pseudo-LRU (PLRU): for large associativity caches • 2-Way Set Associative • Direct Mapped • Others
  • 13. Cache Write Strategies • Write through: changed cache line immediately goes back to main memory • Write back: cache line is marked when dirty, eviction sends back to main memory • Write combining: grouped writes of cache lines back to main memory • Uncacheable: dynamic values that can change without warning
  • 14. Exclusive versus Inclusive • Only relevant below L3 • AMD is exclusive – Progressively more costly due to eviction – Can hold more data – Bulldozer uses "write through" from L1d back to L2 • Intel is inclusive – Can be better for inter-processor memory sharing – More expensive as lines in L1 are also in L2 & L3 – If evicted in a higher level cache, must be evicted below as well
  • 15. Inter-Socket Communication • GT/s – gigatransfers per second • Quick Path Interconnect (QPI, Intel) – 8GT/s • HyperTransport (HTX, AMD) – 6.4GT/s (?) • Both transfer 16 bits per transmission in practice, but Sandy Bridge is really 32
  • 16. MESI+F Cache Coherency Protocol • Specific to data cache lines • Request for Ownership (RFO), when a processor tries to write to a cache line • Modified, the local processor has changed the cache line, implies only one who has it • Exclusive, one processor is using the cache line, not modified • Shared, multiple processors are using the cache line, not modified • Invalid, the cache line is invalid, must be re-fetched • Forward, designate to respond to requests for a cache line • All processors MUST acknowledge a message for it to be valid
  • 17. Static RAM (SRAM) • Requires 6-8 pieces of circuitry per datum • Cycle rate access, not quite measurable in time • Uses a relatively large amount of power for what it does • Data does not fade or leak, does not need to be refreshed/recharged
  • 18. Dynamic RAM (DRAM) • Requires 2 pieces of circuitry per datum • “Leaks” charge, but not sooner than 64ms • Reads deplete the charge, requiring subsequent recharge • Takes 240 cycles (~100ns) to access • Intel's Nehalem architecture - each CPU socket controls a portion of RAM, no other socket has direct access to it
  • 20. Current Processors • Intel – Nehalem/Westmere – Sandy Bridge – Ivy Bridge • AMD – Bulldozer • Oracle – UltraSPARC isn't dead
  • 22. “Latency Numbers Everyone Should Know” L1 cache reference ......................... 0.5 ns Branch mispredict ............................ 5 ns L2 cache reference ........................... 7 ns Mutex lock/unlock ........................... 25 ns Main memory reference ...................... 100 ns Compress 1K bytes with Zippy ............. 3,000 ns = 3 µs Send 2K bytes over 1 Gbps network ....... 20,000 ns = 20 µs SSD random read ........................ 150,000 ns = 150 µs Read 1 MB sequentially from memory ..... 250,000 ns = 250 µs Round trip within same datacenter ...... 500,000 ns = 0.5 ms Read 1 MB sequentially from SSD* ..... 1,000,000 ns = 1 ms Disk seek ........................... 10,000,000 ns = 10 ms Read 1 MB sequentially from disk .... 20,000,000 ns = 20 ms Send packet CA->Netherlands->CA .... 150,000,000 ns = 150 ms • Shamelessly cribbed from this gist: https://gist.github.com/2843375, originally by Peter Norvig and amended by Jeff Dean
  • 23. Measured Cache Latencies Sandy Bridge-E L1d L2 L3 Main ======================================================================= Sequential Access ..... 3 clk 11 clk 14 clk 6ns Full Random Access .... 3 clk 11 clk 38 clk 65.8ns SI Software's benchmarks: http://www.sisoftware.net/?d=qa&f=ben_mem_latency
  • 24. Registers • On-core for instructions being executed and their operands • Can be accessed in a single cycle • There are many different types • A 64-bit Intel Nehalem CPU had 128 Integer & 128 floating point registers
  • 25. Store Buffers • Hold data for Out of Order (OoO) execution • Fully associative • Prevent “stalls” in execution on a thread when the cache line is not local to a core on a write • ~1 cycle
  • 26. Level Zero (L0) • New to Sandy Bridge • A cache of the last 1536 uops decoded • Well-suited for hot loops • Not the same as the older "trace" cache
  • 27. Level One (L1) • Divided into data and instructions • 32K data (L1d), 32K instructions (L1i) per core on a Sandy Bridge • Sandy Bridge loads data at 256 bits per cycle, double that of Nehalem • 3-4 cycles to access L1d
  • 28. Level Two (L2) • 256K per core on a Sandy Bridge • 2MB per “module” on AMD's Bulldozer architecture • ~11 cycles to access • Unified data and instruction caches from here up • If the working set size is larger than L2, misses grow
  • 29. Level Three (L3) • Was a “unified” cache up until Sandy Bridge, shared between cores • Varies in size with different processors and versions of an architecture • 14-38 cycles to access
  • 31. Striding & Pre-fetching • Predictable memory access is really important • Hardware pre-fetcher on the core looks for patterns of memory access • Can be counter-productive if the access pattern is not predictable • Martin Thompson blog post: “Memory Access Patterns are Important” • Shows the importance of locality and striding
  • 32. Cache Misses • Cost hundreds of cycles • Keep your code simple • Instruction read misses are most expensive • Data read miss are less so, but still hurt performance • Write misses are okay unless using Write Through • Miss types: – Compulsory – Capacity – Conflict
  • 33. Programming Optimizations • Stack allocated data is cheap • Pointer interaction - you have to retrieve data being pointed to, even in registers • Avoid locking and resultant kernel arbitration • CAS is better and occurs on-thread, but algorithms become more complex • Match workload to the size of the last level cache (LLC, L3)
  • 34. What about Functional Programming? • Have to allocate more and more space for your data structures, leads to eviction • When you cycle back around, you get cache misses • Choose immutability by default, profile to find poor performance • Use mutable data in targeted locations
  • 35. Hyperthreading • Great for I/O-bound applications • If you have lots of cache misses • Doesn't do much for CPU-bound applications • You have half of the cache resources per core
  • 36. Data Structures • BAD: Linked list structures and tree structures • BAD: Java's HashMap uses chained buckets • BAD: Standard Java collections generate lots of garbage • GOOD: Array-based and contiguous in memory is much faster • GOOD: Write your own that are lock-free and contiguous • GOOD: Fastutil library, but note that it's additive
  • 37. Application Memory Wall & GC • Tremendous amounts of RAM at low cost • GC will kill you with compaction • Use pauseless GC – IBM's Metronome, very predictable – Azul's C4, very performant
  • 38. Using GPUs • Remember, locality matters! • Need to be able to export a task with data that does not need to update
  • 40. ManyCore • David Ungar says > 24 cores, generally many 10s of cores • Really gets interesting above 1000 cores • Cache coherency won't be possible • Non-deterministic
  • 41. Memristor • Non-volatile, static RAM, same write endurance as Flash • 200-300 MB on chip • Sub-nanosecond writes • Able to perform processing? • Multistate, not binary
  • 42. Phase Change Memory (PRAM) • Higher performance than today's DRAM • Intel seems more fascinated by this, just released its "neuromorphic" chip design • Not able to perform processing • Write degradation is supposedly much slower • Was considered susceptible to unintentional change, maybe fixed?
  • 44. Credits! • What Every Programmer Should Know About Memory, Ulrich Drepper of RedHat, 2007 • Java Performance, Charlie Hunt • Wikipedia/Wikimedia Commons • AnandTech • The Microarchitecture of AMD, Intel and VIA CPUs • Everything You Need to Know about the Quick Path Interconnect, Gabriel Torres/Hardware Secrets • Inside the Sandy Bridge Architecture, Gabriel Torres/Hardware Secrets • Martin Thompson's Mechanical Sympathy blog and Disruptor presentations • The Application Memory Wall, Gil Tene, CTO of Azul Systems • AMD Bulldozer/Intel Sandy Bridge Comparison, Gionatan Danti • SI Software's Memory Latency Benchmarks • Martin Thompson and Cliff Click provided feedback &additional content

Editor's Notes

  1. To improve performance, we need to understand the impact of our decisions in the physical world My goal is help everyone understand how each physical level of caching within a CPU works Capped the talk below virtual memory (memory management for multitasking kernels), as that is specific to the operating system running on the machine Not enough time to cover all of the levels of caching that exist on CPUs
  2. 2011 Sandy Bridge and AMD Fusion integrated Northbridge functions into CPUs, along with processor cores, memory controller and graphics processing unit Gil Tene of Azul claims the Vega architecture is a true SMP compared to those of AMD/Intel – circular architecture with linkages between every core
  3. NUMA architectures have more trouble migrating processes across sockets because L3 isn’t warmed Initially, it has to look for a core with the same speed accessing memory resources and enough resources for the process; if none are found, it then allows for degradation
  4. All algorithms are dominated by that - you have to send data somewhere to have an operation performed on it, and then you have to send it back to where it can be used
  5. Memory controllers were moved onto the processor die on AMD64 and Nehalem
  6. Be careful about what's on them, because if a line holds multiple variables and the state of one changes, coherency must be maintained, killing performance for parallel threads on an SMP machine If the critical word in the line is in the last block, takes 30 cycles or more to arrive after the first word. However, the memory controller is free to request the blocks in a different order. The processor can specify the "critical word", and the block that word resides in can be retrieved first for the cache line by the memory controller. The program has the data it needs and can continue while the rest of the line is retrieved and the cache is not yet in a consistent state, called "Critical Word First & Early Restart” Note that with pre-fetching, the critical word is not known - if the core requests the cache line while the pre-fetching is in transit, it will not be able to influence the block ordering and will have to wait until the critical word arrives in order; position in the cache line matters, faster to be at the front than the rear
  7. Replacement policy determines where in the cache an entry of main memory will go Tradeoff - if data can be mapped to multiple places, all of those places have to be checked to see if the data is there, costing power and possibly time; but more associativity means less cache misses Set associative has a fixed number of places and can be 2-16-way; skewed does as well, but uses a hash to place the second cache line in the group, only up to 2-way that I know of
  8. LRU can be expensive, tracks each cache line with “age bits” - each time a cache line is used, all others have to be updated PLRU is used where LRU is prohibitively expensive – “almost always” discards one of the most LRU lines and no guarantee it was the absolutely LEAST recently used is sufficient 2WSA for caches where even PLRU is too slow – address of an item is used to put it in one of two positions, and the LRU of those two is discarded Direct mapped evicts whatever was in that position before it, regardless of when it was last used
  9. Write through caching: slow, but predictable, resulting in lots of FSB traffic Write back caching: mark flag bit as dirty, when evicted the processor notes and sends cache line back to main memory, instead of just dropping it; have to be careful of false sharing and cache coherency Write combining caching: used by graphics cards, groups writes to main memory for speed Uncacheable: dynamic memory values that can change without warning, used for commodity hardware
  10. In an exclusive cache (AMD), when the processor needs data it is loaded by cache line into L1d, which evicts a line to L2, which evicts a line to L3, which evicts a line to main memory; each eviction is progressively more expensive Exclusive is necessary if the L2 is less than 4-8x the size of L1, otherwise duplication of data affects L2’s local hit rate In an inclusive cache (Intel), eviction is much faster - if another processor wants to delete data, it only has to check L2 because it knows L1 will have it as well; exclusive will have to check both, which is more expensive; good for snooping
  11. For intra-socket communication, Sandy Bridge has a 4-ring architecture linking cores, LLC and GPU; prior to Sandy Bridge, required direct linkages GT/s - how many times signals are sent per second Not a bus, but a point to point interface for connections between sockets in a NUMA platform, or from processors to I/O and peripheral controllers DDR = double data rate, two data transferred per clock cycle, Processors "snoop" on each other, and certain actions are announced on external pins to make changes visible to others; the address of the cache line is visible through the address bus Sandy Bridge can transfer on both the rise & fall of the clock cycle and is full duplex HTX could theoretically be up to 32 bits per transmission, but hasn't been done yet that I know of
  12. Request for Ownership (RFO): a cache line is held exclusively for read by one processor, but another requests for write; cache line is sent, but not marked shared by the original holder - it is marked Invalid and the other cache becomes Exclusive. This marking happens in the memory controller. Performing this operation in the last level cache is expensive, as is the I->M transition. If a Shared cache line is modified, all other views of it must be marked invalid via an announcement RFO message. If Exclusive, no need to announce. Processors will try to keep cache lines in an exclusive state, as the E to M transition is much faster than S to M. RFOs occur when a thread is migrated to another processor and the cache lines have to be moved once, or when two threads absolutely must share a line; the costs are a bit smaller when shared across two cores on the same processor. Collisions on the bus can happen, latency can be high with NUMA systems, sheer traffic can slow things down - all reasons to minimize traffic. Since code almost never changes, instruction caches do not use MESI but rather just a SI protocol. If code does change, a lot of pessimistic assumptions have to be made by the controller.
  13. The number of circuits per datum means that SRAM can never be dense.
  14. One transistor, one capacitor Reading contiguous memory is faster than random access due to how you read - you get one write combining buffer at a time from each of the memory banks, 33% slower. 240 cycles to get data from here E7-8870 (Westmere) can hold 4TB of RAM, E5-2600 Sandy Bridge "only" 1TB DDR3-SDRAM: Double Data Rate, Synchronous Dynamic Has a high-bandwidth three-channel interface Reduces power consumption 30% over DDR2 Data is transferred on the rising and falling edges of a 400-1066 MHz I/O clock of the system DDR4 and 5 are coming, or are here with GPGPUs. DDR3L is for lower energy usage
  15. Westmere was the 32nm die shrink of Nehalem from 45nm. Ivy Bridge uses 22nm, but the Sandy Bridge architecture I'm ignoring Oracle SPARC here, but note that Oracle is supposedly building a 16K core UltraSPARC 64 Current Intel top of the line is Xeon E7-8870 (8 cores per socket, 32MB L3, 4TB RAM), but it's a Westmere-based microarchitecture and doesn’t have the Sandy Bridge improvements The E5-2600 Romley is the top shelf new Sandy Bridge offering - it's specs don't sound as mighty (8 cores per socket, max 30MB L3, 1TB RAM). Don't be fooled, the Direct Data IO makes up for it as disks network cards can do DMA (Direct Memory Access) from L3, not RAM, decreasing latency by ~18%. Also has two memory read ports, whereas previous architectures only had one and were a bottleneck for math-intensive applications Sandy Bridge is 4-30MB (8MB is currently max for mobile platforms, even with Ivy Bridge), includes the processor graphics
  16. The problem with these numbers is that while they're not far off, the lowest level cache interactions (registers, store buffers, L0, L1) are truly measured in cycles, not time Clock cycles are also known as Fetch and Execute or Fetch-Decode-Execute Cycle (FDX), retrieve instruction from memory, determine actions required and carry them out; ~1/3 of a nanosecond
  17. Sandy Bridge has 2 load/store operations for each memory channel Low values are because the pre-fetcher is hiding real latency in these tests when “striding” memory
  18. Types of registers include: instruction data (floating point, integer, chars, small bit arrays, etc) address conditional constant etc.
  19. Store buffers disambiguate memory access and manage dependencies for instructions occurring out of program order If CPU 1 needs to write to cache line A but doesn't have the line in its L1, it can drop the write in the store buffer while the memory controller fetches it to avoid a stall; if line is already in L1 it can store directly to it (and bypass store buffer), possibly causing invalidate requests to be sent out
  20. Macro ops have to be decoded into micro ops to be handled by the CPU Nehalem used L1i for macro ops decoding and had a copy of every operand required, but Sandy Bridge caches the uops (Micro-operations), boosting performance in tight code (small, highly profiled and optimized, can be secure, testable, easy to migrate) Not the same as the older "trace" cache, which stored uops in the order in which they were executed, which meant lots of potential duplication; no duplication in the L0, storing only unique decode instructions Hot loops (where the program spends the majority of its time) should be sized to fit here
  21. Instructions are generated by the compiler, which knows rules for good code generation Code has predictable patterns and CPUs are good at recognizing them, which helps pre-fetching Spatial and temporal locality is good Nehalem could load 128 bits per cycle, but Sandy Bridge can load double that because load and store address units can be interchanged - thus using 2 128-bit units per cycle instead of one
  22. When the working set size random access is greater than the L2 size, cache misses start to grow Caches from L2 up are "unified", having both instructions and data (not in terms of shared across cores)
  23. Sandy Bridge allows only exclusive access per core Last Level Cache (LLC)
  24. Doesn't have to be contiguous in an array, you can be jumping in 2K chunks without a performance hit As long as it's predictable, it will fetch the memory before you need it and have it staged Pre-fetching happens with L1d, can happen for L2 in systems with long pipelines Hardware prefetching cannot cross page boundaries, which slows it down as the working set size increases. If it did and the page wasn't there or is invalid, the OS would have to get involved and the program would experience a page fault it didn't initiate itself Temporally relevant data may be evicted fetching a line that will not be used
  25. The pre-fetcher will bring data into L1d for you. The simpler your code, the better it can do this If your code is complex, it will do it wrong, costing a cache miss and forcing it to lose the value of pre-fetching and having to go out to an outer layer to get that instruction again Compulsory/Capacity/Conflict are miss types
  26. Short lived data is not cheap, but variables scoped within a method running on the JVM are stack allocated and very fast Think about the affect of contending locking. You've got a warmed cache with all of the data you need, and because of contention (arbitrated at the kernel level), the thread will be put to sleep and your cached data is sitting until you can gain the lock from the arbitrator. Due to LRU, it could be evicted. The kernel is general purpose, may decide to do some housekeeping like defragging some memory, futher polluting your cache. When your thread finally does gain the lock, it may end up running on an entirely different core and will have to rewarm its cache. Everything you do will be a cache miss until its warm again. CAS is better, checking the value before you replace it with a new value. If it's different, re-read and try again. Happens in user space, not at the kernel, all on thread Algos get a lot harder, though - state machines with many more steps and complexity. And there is still a non-negligible cost. Remember the cycle time diffs for different cache sizes; if the workload can be tailored to the size of the last level cache, performance can be dramatically improved Note that for large data sets, you may have to be oblivious to caching
  27. Eventually, caches have to evict, cache misses cost hundreds of cycles
  28. Hyperthreading shares all CPU resources except the register set Intel CPUs limit to two threads per core, allows one hyper thread to access resources (like the arithmetic logic unit) while another hyper thread is delayed, usually by memory access. Only more efficient if the combined runtime is lower than a single thread, possible by overlapping wait times for different memory access that would ordinarily be sequential. The only variable is the number of cache hits Note that the effectively shared L1d & L2 reduce the available caches and bandwidth for each thread to 50% when executing two completely different threads of execution (questionable unless the caches are very large), inducing more cache misses, therefore hyper threading is only useful in a limited set of situations. Can be good for debugging with SMT (simultaneous multi-threading) Contrast this with Bulldozer's "modules" (akin to two cores), which has dedicated schedulers and integer units for each thread in a single processor
  29. If n is not very large, an array will beat it for performance Linked lists and trees have pointer chasing which are bad for striding across 2K cache pre-fetching Java's hashmap uses chained buckets, where each hash's bucket is a linked list Clojure/Scala vectors are good, because they have groupings of contiguous memory in use, but do not require all data to be contiguous like Java's ArrayList Cliff Click has his lock-free library, Boundary has added with their own implementations Fastutil is additive, no removal, but that's not necessarily a bad thing with proper tombstoning and data cleanup
  30. We can have as much RAM/heap space as we want now. And requirements for RAM grow at about 100x per decade. But are we now bound by GC? You can get 100GB of heap, but how long do you pause for marking/remarking phases and compaction? Even on a 2-4 GB heap, you're going to get multi-second pauses - when and how often? IBM Metronome collector is very predictable. Azul around one millisecond for lots of garbage with C4.
  31. Graphics card processing (OpenCL) is great for specific kinds of operations, like floating point arithmetic. But they don't perform well for all operations, and you have to get the data to them.
  32. Number of cores is large enough that traditional multi-processor techniques are no longer efficient[citation needed] — largely because of issues with congestion in supplying instructions and data to the many processors. Network-on-chip technology may be advantageous above this threshold
  33. From HP, due to come out this year or next, may change memory fundamentally. If the data and the function are together, you get the highest throughput and lowest latency possible. Could replace DRAM and disk entirely. When current flows in one direction through the device, the electrical resistance increases; and when current flows in the opposite direction, the resistance decreases. When the current is stopped, the component retains the last resistance that it had, and when the flow of charge starts again, the resistance of the circuit will be what it was when it was last active. Is write endurance good enough for anything but storage?
  34. Thermally-driven phase change, not an electronic process. Faster because it doesn't need to erase a block of cells before writing. Flash degrades at 5000 writes per sector, where PRAM lasts 100 million writes. Some argue that PRAM should be considered a memristor as well.
