Lighting Calculation
Using DIALux 4.13
Presented By :
Swaroop Krishna
Contents
1 Introduction to DIALux 4.13
2 Key Concepts in Lighting Calculation
3 Project Setup & Room Definition
4 Luminaire Selection & Placement
5 Running Calculations & Analysis
6 Sample Problem
7 Best Practices
1
Introduction to DIALux 4.13
 DIALux is the world's leading free software for professional lighting
design.
 Version 4.13 supports indoor, outdoor, and road lighting
calculations.
 Used by architects, electrical engineers, and lighting designers
globally.
 Provides accurate photometric calculations using IES/LDT
luminaire data.
 Generates comprehensive PDF reports with illuminance values and
false-color maps.
Why DIALux 4.13?
Free
No license cost
Accurate
CIE compliant
Versatile
Indoor & Outdoor
Trusted
Used in 190+ countries
2
Key Concepts in Lighting Calculation
Lux (lx)
Unit of illuminance. 1 lux = 1 lumen per m²
Lumen (lm)
Total luminous flux emitted by a light source
Candela (cd)
Luminous intensity in a specific direction
Luminous Efficacy
Ratio of lumens to watts (lm/W)
Uniformity (U₀)
Ratio of minimum to average illuminance (Emin/Eavg)
Maintenance Factor
Accounts for lamp depreciation and dirt accumulation
3
Project Setup & Room Definition
1 New Project
File → New Project. Enter project name, address and
designer details.
2 Interior Scene
Select 'Interior' mode. DIALux opens the room editor
workspace.
3 Define Room Geometry
Set room length, width & height. Use the geometry editor
or enter exact dimensions (m).
4 Surface Reflectance
Assign reflectance values: Ceiling (70–80%), Walls (50–
60%), Floor (20–30%).
5 Calculation Plane
Set the reference calculation plane height (typically
0.85m for work plane).
6 Maintenance Factor
Input MF from 0.6–0.8 depending on environment type
and cleaning schedule.
4
Luminaire Selection & Placement
 Import Photometric File
Use File → Luminaire Catalogue. Import IES or LDT files from
manufacturer.
 Luminaire Properties
Verify wattage, lumen output, color temperature (CCT) and CRI from
datasheet.
 Placement Method
Use Arrange → Field or Single placement. Specify rows, columns and
spacing.
 Mounting Height
Set luminaire mounting height. Ensure adequate Spacing-to-Height
(S/MH) ratio.
 Tilt & Orientation
Adjust tilt angle if using directional fixtures for accent or task lighting.
Typical Spacing Ratios
Direct S/MH ≤ 1.5
Semi-direct S/MH ≤ 1.3
Indirect S/MH ≤ 1.2
Downlight S/MH ≤ 1.0
Linear LED S/MH ≤ 1.8
5
Running Calculations & Analysis
Calculation Setup
Go to Calculation → Settings. Choose calculation type: standard
(radiosity) or simplified. Set grid size (0.25m–1.0m). Smaller grid =
higher accuracy but longer compute time.
Calculation Surfaces
Add horizontal, vertical, or tilted calculation planes. Mark work plane
at 0.85m above floor for office environments.
Start & Monitor
Press F5 or Calculation → Start. Progress bar shows computation
status. Complex scenes may take several minutes.
Result Visualization
View illuminance as: numeric grid, false-color map, isolux curves, or
3D rendering. Toggle between maintained and initial values.
6
Sample problem 7
A small assembly shop 15 m long, 9 m wide, and 3 m up to trusses is to be illuminated to a level of 200 lux. The
coefficient of utilization is 0.75 maintenance factor is 0.8. Calculate the number of lamps required to illuminate
the whole area if the lumen output of the lamp selected is 3000 lumens.
Lumen Formula:
Number of lamps,
Where:
E = Illuminance level (lux) = 200 lux
A = Area of the room (m²) = 15 m × 9 m = 135 m²
Ln = Lumen output of one lamp = 3000 lumens
CU = Coefficient of Utilisation = 0.75
MF = Maintenance factor= 0.8
Sample problem (Cont.…) 8
Substitute values:
15 lamps are required to achieve 200 lux uniformly over the entire area.
m
Since SHR<1.5, the design is acceptable.
Calculation using Dialux 4.13 9
Floor Plan 3D-View
Summary 10
Best Practices
Use Manufacturer Data
Always import actual IES/LDT photometric files from the
luminaire manufacturer, not generic models.
Correct Maintenance Factor
Apply MF per EN 12665. Typical values: clean
environment 0.80, normal 0.72, dirty 0.67.
Validate Against Standards
Compare Em, U₀, and UGR against EN 12464-1 or
project-specific specifications.
Document Assumptions
Record all inputs (lamp data, MF, reflectance) in the
report notes for audit trail.
11
Thank You
