BPF Performance Tools
chapter 4 - bcc
Viller Hsiao
Feb. 17, 2020
What’s in Chapter 4
BPF Compiler Collection (BCC)
BCC is a toolkit for creating efficient kernel tracing and manipulation programs, and
includes several useful tools and examples. It makes use of extended BPF (Berkeley
Packet Filters), formally known as eBPF, a new feature that was first added to Linux 3.15.
Much of what BCC uses requires Linux 4.1 and above. (4.9 and up is better)
Overview (1/3)
● Use bcc
○ How to install bcc
■ with man page
■ example files
○ Tools overview
● Develop bcc program
○ bcc internals
○ debugging bcc
Overview (2/3)
● Use bcc
○ How to install bcc
○ Tools overview
● Develop bcc program
○ bcc internals
○ debugging bcc
Overview (3/3)
● Use bcc
○ How to install bcc
○ Tools overview
● Develop bcc program
○ bcc internals
○ debugging bcc
Example
bcc/examples/tracing/task_switch.py
task_switch.py
[/path/to/bcc/examples/tracing]% sudo python task_switch.py
task_switch[ 0-> 2520]=10
task_switch[14980-> 0]=1
task_switch[ 1096-> 0]=1
task_switch[19347->14055]=1
task_switch[14423-> 0]=1
task_switch[ 0-> 53]=1
task_switch[ 0->28879]=60
At First Glance
https://vignette.wikia.nocookie.net/pttpedia/images/4/48/File
_52cb83b426b60.jpg/revision/latest/scale-to-width-down/34
0?cb=20180122134757&path-prefix=zh
Main Parts
1. BPF program to run in
kernel
2. Kernel tracing tool to use
3. Retrieve data and
do some post processing
What’s the Program Do?
Translation
When kernel run to <target>,
use <tracing mechanism> to execute <handler>.
The handler record some <statistics> or do <something>.
(Like a function decorator in Python)
Actions
When kernel run to finish_task_switch,
use kprobe to execute cond_sched.
The handler store counts of task switch as hash map,
which is indexed by (prev_pid, curr_pid) pairs.
static struct rq * finish_task_switch(struct task_struct *prev)
BPF helper
Recorded Data Manipulation
When kernel run to finish_task_switch,
use kprobe to execute cond_sched.
The handler store counts of task switch as hash map,
which is indexed by (prev_pid, curr_pid) pairs.
翻訳コンニャク
When kernel run to finish_task_switch,
use kprobe to execute cond_sched.
The handler store counts of task switch as hash map,
which is indexed by (prev_pid, curr_pid) pairs.
Resources for bcc Programming
● bcc Reference Guide
○ BPF C
○ bcc Python
● bpftrace -l
Other resources
● If it’s hard to use bpftrace on your machine ...
● /sys/kernel/tracing
○ available_events
■ tracepoint
○ tracepoint format
■ /sys/kernel/tracing/<type>/<event>/format
■ e.g. events/irq/softirq_entry/format
○ available_filter_functions
■ kprobe on function entry
● “perf list”
○ pmu events
Alternative Tools
Alternative Profiling Tools
● bpftrace
● ftrace / perf
○ perf-tools, by Brendan Gregg, before bcc
○ iosnoop vs biosnoop-bpfcc
● Other frontends
○ systemtap, LTTng and so on
Q & A
