The document describes the process of converting a non-deterministic finite automaton (NFA) to a deterministic finite automaton (DFA). It provides an example of an NFA with initial state q0 and shows the steps to obtain the transition function δ' and states of the equivalent DFA. The resulting DFA has states A, B, and C, with transitions between them labeled 0 or 1. It also provides the transition table for the equivalent DFA.

1. Conversion problem: PART-B
1. NFA- DFA
2. NFA - ε to NFA
3. NFA-ε to DFA
4. RE to NFA- ε
5. DFA to RE
6. Minimization of DFA

2. Convert the given NFA to DFA.
Initial State of given NFA is {q0 }
Since NFA is equivalent to DFA,
Let Initial State of DFA be [q0] ----- A

3. Now we will obtain δ' transition for state A.
δ’(A, 0)= δ’({q0}, 0) = {q0} =[q0] -------- A Transition table
δ’(A, 1)= δ’({q0}, 1) = {q1}=[q1] -------- B (new state generated)
The δ' transition for state B is obtained as:
δ’(B, 0)= δ’({q1}, 0) = {q1, q2} =[q1,q2] -------- C
δ’(B,1) = δ’({q1}, 1) = {q1}=[q1] -------- B
Now we will obtain δ' transition on C.
δ’(C, 0) =δ’({q1, q2}, 0)
= δ(q1, 0) ∪ δ(q2, 0)
= {q1, q2} ∪ {q2}
= [q1, q2] -------- C
δ’(C, 1) =δ’({q1, q2}, 1)
= δ(q1, 1) ∪ δ(q2, 1)
= {q1} ∪ {q1, q2}
= {q1, q2}
= [q1, q2] -------- C
0
1
→A A B
B C B
*C C C
DFA - Transition diagram
DFA - Transition table
Resultant DFA

4. Can also be denoted the states as it is,
without renaming as A,B,C
0
1
→[q0] [q0] [q1]
[q1] [q1, q2] [q1]
*[q1, q2] [q1, q2] [q1, q2]

5. Example 2: NFA to DFA
Note : use [ ] in DFA instead { }

6. Example 3: NFA to DFA
Resultant:
State / Alphabet 0 1
→q0 q0 {q1, q2}
State / Alphabet 0 1
→q0 q0 {q1, q2}
{q1, q2} {q0, q1, q2} {q1, q2}
State / Alphabet 0 1
→q0 q0 {q1, q2}
{q1, q2} {q0, q1, q2} {q1, q2}
{q0, q1, q2}
{q0, q1, q2}
{q1, q2}
State / Alphabet 0 1
→q0 [q0] [q1, q2]
*[q1, q2] [q0, q1, q2] [q1, q2]
*[q0, q1, q2]
[q0, q1, q2]
[q1, q2]
