  Ardustat: A case studyin Open Source Hardware in Academic Engineering Dan Steingart Printed/Electrochemical Engineering Lab City College of New York Department of Chemical Engineering City University of New York Energy Institute Open Source Hardware Summit, September 23rd 2010
• 2.
  Why is thisso hard?
• 3.
  It’s Not • Everyoneused to make their own potentiostat/galvanostats • Companies formed to streamline and standardize such units • People “forgot” how to make their own • or rather, the institutional knowledge was not passed on
• 4.
  Commercial Devices Arbin ~$1000/channel Gamry Maccor ~$10000/channel ~$1500/channel PAR Autolab ~$13000/ ~$15000/ channel channel
• 5.
  These Devices • Areall very good at what they’re designed to do • Are sold by folks that are knowledgable and can abstract internal functionality sufficiently for the modern material scientist/chemist/electrochemist • Are complete black boxes
• 6.
  “The Things YouOwn End Up Owning You” • The abstraction, cost and inflexibility of these devices define the experiment, which defines the experimentalist • The experimentalist needs to have access to tools that allow her to define the experiment
• 7.
  But • Time isso short • There is so much science to learn • Circuit engineering is the realm of EE/CS
• 8.
  The Ardustat • Arduinobased Galvanostat/Potentiostat • A first crack at creating something that those interested in hacking can improve, and those interested in science can exploit • The hope is (eventually): • Shared knowledge reduce the learning curve • Companies sell units for a “fair price”
• 9.
  The Ardustat
• 10.
  Comparison Ardustat Commercial Current Range 100 nA to 10 mA 1 fA to 10 A Potential Range ±5V ± 10 V Resolution 10 Bit 16 Bit CV Yes Yes EIS Not Yet Yes Cost $60/channel $1000+/channel Hackable Yes No
• 11.
  Cost and HackabilityAre Key • Screening • Training • Defining
• 12.
  Screen • Many combinationsin a parallel fashion
• 13.
  rrently four undergraduatestudents, including one underrepresented minority, are performing researc ated to the printer. Two chemical engineering undergraduates are examining the use of the IJ Fisna Train nter along with a Universal Laser Systems Versalaser 6.60 to rapid prototype batteries into flexibl bstrates. Two mechanical engineering undergraduates are improving the IJ Fisnar system, addin mputer vision for automated alignment of multiple layers. Both of these projects are in anticipation o ther work to be carried out as described in section 2. The work of the chemical engineering students i cused on qualitative studies of adhesion strength and delamination of printed structures on flexibl • Students on robust, low cost equipment bstrate, assisting the PI in determining quantitative parameters. The computer vision work i eliminary to the complementary fiber woodpile structures discussed in section 2.3. One high schoo dent is preparing ZnI2 cells using the IJ Fisnar printer and the laser cutter. gure 12) High school student (left) and undergraduate student (right) preparing various aspects of a printed batter 3. Rapid Prototyping of Electrochemical Systems with Stuyvesant High School encourage young students to explore engineering, the PI is collaborating with Stuyvesant High Schoo
• 14.
  Define • New ExperimentalTechniques
• 15.
  Why Not Labview/NI •Labview allows modification, but not reinvention • In my humble experience, folks learned in lab view are walled off from just about all other hardware solutions
• 16.
  What’s Needed • Not GCC • Not Labview • The Arduino is a great start • Sciduino Anyone?
