STANFORD UNIVERSITY LIBRARIES
Annotations as Linked Data
with Fedora4 and Triannon
(A Real Use Case for RDF!)
C O D E 4 L I B 2015
PO R T L A N D , OR
FE B R U A R Y 11
Rob Sanderson / azaroth@stanford.edu / @azaroth42
Naomi Dushay / ndushay@stanford.edu
STANFORD UNIVERSITY LIBRARIES
Annotations as Linked Data
with Fedora4 and Triannon
(A Real Use Case for RDF!)
C O D E 4 L I B 2015
PO R T L A N D , OR
FE B R U A R Y 11
Rob Sanderson / azaroth@stanford.edu / @azaroth42
Naomi Dushay / ndushay@stanford.edu
Where are the Dragons?
:(
Triannon:
Putting the Dragons Back in Portland
since sometime last week
Requirements:
•  Create and manage tags/annotations in any client or environment
•  Retrieve tags/annotations to display in any client
•  With the identifiers of Works, not of catalog views
Need:
•  A model for annotations
•  A format to serialize them into
•  A protocol to transfer the serializations between systems
•  Implementations!
JSON Annotation Format
{!
"@context": "http://www.w3.org/ns/oa-context-20130208.json",!
"@id": "http://www.example.org/annotations/1",!
"@type": "oa:Annotation”,!
"motivatedBy":"oa:commenting",!
"hasBody": {!
"@type": "cnt:ContentAsText",!
"chars": "Portland is somewhere here. Also Dragons",!
"format": "text/plain"!
},!
"hasTarget": "http://purl.stanford.edu/bd136jk4522#xywh=..."!
} !
JSON-LD Annotation Format
{!
"@context": "http://www.w3.org/ns/oa-context-20130208.json",!
"@id": "http://www.example.org/annotations/1",!
"@type": "oa:Annotation”,!
"motivatedBy":"oa:commenting",!
"hasBody": {!
"@type": "cnt:ContentAsText",!
"chars": "Portland is somewhere here. Also Dragons",!
"format": "text/plain"!
},!
"hasTarget": "http://purl.stanford.edu/bd136jk4522#xywh=..."!
} !
JSON-LD Annotation Format
{!
"@context": "http://www.w3.org/ns/oa-context-20130208.json",!
"@id": "http://www.example.org/annotations/1",!
"@type": "oa:Annotation”,!
"motivatedBy":"oa:commenting",!
"hasBody": {!
"@type": "cnt:ContentAsText",!
"chars": "Portland is somewhere here. Also Dragons",!
"format": "text/plain"!
},!
"hasTarget": "http://purl.stanford.edu/bd136jk4522#xywh=..."!
} !
Dirty not-so-secret time...
RDF Annotation Format
{!
"@context": "http://www.w3.org/ns/oa-context-20130208.json",!
"@id": "http://www.example.org/annotations/1",!
"@type": "oa:Annotation”,!
"motivatedBy":"oa:commenting",!
"hasBody": {!
"@type": "cnt:ContentAsText",!
"chars": "Portland is somewhere here. Also Dragons",!
"format": "text/plain"!
},!
"hasTarget": "http://purl.stanford.edu/bd136jk4522#xywh=..."!
} !
It's actually RDF, following the Open Annotation model
Open Annotation
http://www.openannotation.org/spec/core/
http://www.w3.org/TR/annotation-model/ (beta)
Annotation Management: LDP
Reality is More Complex
In Reality ...
•  Multiple resources to manage, each requires a POST
•  Binary or external resources with descriptions tricky
•  Multiple JSON-LD contexts complex (IIIF, OA, ...)
Want:
•  Ease of use/implementation for annotation client
•  Ability to swap back-end to other LDP system
•  Integration with Rails environment
•  Search with Solr (easy) not SPARQL (less easy)
Triannon
Triannon plus Solr
Triannon: Implementation Goals
•  Rapid Development
•  Modular
•  Re-Usable
•  Deployable
•  Maintainable
Triannon: Rails Engine Gem
REST over HTTP
Create POST jsonld, turtle, rdfxml
Read GET "
Update PUT/PATCH "
Delete DELETE (id)
Model ActiveRecord ActiveModel LDP
View (for apps and developers) jsonld, turtle, rdfxml
Controller
http://github.com/sul-dlss/triannon
It’s the Graph, Baby!
Rails App (SearchWorks)
ActiveTriples
ld4l-open_annotation_rdf
triple store
(in memory)
RDF
SearchWorks: Create, Update, Delete
Triannon
id
html
form
jsonld from
RDF::Graph
Client App: Search and Display
Triannon SolrClient App
http://triannon-solr/by_target?url=purl.stanford.edu/bd136jk4522
'response'=>{'numFound'=>3,'start'=>0,'maxScore'=>1.0,'docs'=>[
{
'id'=>'98206ec8-4def-44b8-b190-648d8224ce1c’,
'anno_jsonld'=>'{"@context":"http://www.w3.org/ns/oa.jsonld","@graph":
[{"@id":"_:g70038924372700","@type":["dctypes:Text","cnt:ContentAsText"], "format":"text/plain”,
"chars":"Portland is somewhere here. Also Dragons”},{"@id":"https://
triannon-dev.stanford.edu/annotations/98206ec8-4def-44b8-
b190-648d8224ce1c","@type":"oa:Annotation","hasBody":"_:g70038924372700","hasTarget":"http://
purl.stanford.edu/bd136jk4522","motivatedBy":"oa:commenting"}]}',
...},
{
'id'=>'f691b921-6f54-415b-9dfb-0d017f0d8ada',
...
Rails App (SearchWorks)
ActiveTriples
ld4l-open_annotation_rdf
triple store
(in memory)
RDF
SearchWorks: Read and Display
•  Easy Access to Relevant Info from jsonld
•  Rapid Development
•  Modular
•  Maintainable
Triannon Solr
jsonld as
RDF::Graph
Search for
annos
LDP API
Fedora 4Solr
CRUD
Search /
Read
CRUDCUD
Client
Application
Client
Application
Client Application
Triannon
STANFORD UNIVERSITY LIBRARIES
Thank You!
February 11th, 2015
azaroth@stanford.edu
ndushay@stanford.edu
