How Flipkart Scales PHP   Tips & Tricks
About Flipkart• Flipkart.com• India’s largest eCommerce website*• Millions of requests/day
About Me• Siddhartha Reddy• Tech Lead at Flipkart• Taking care of Search & Browse experience
Today• Flipkart.com’s Architecture   • How each component addresses scale
Flipkart.com’s           Architecture                                   Session                        Database           ...
What is Scaling?
What is Scaling?• Handle large amount of traffic• High availability• Good response times
How Flipkart Scales
How Flipkart Scales• Logging and measuring• Horizontal Scaling   • Load-balancing• High Availability setup• Web-server opt...
How Flipkart Scales
How Flipkart Scales• Logging and measuring• Horizontal Scaling   • Load-balancing• High Availability setup• Web-server opt...
Logging & Measuring
Logging & Measuring
How Flipkart Scales• Horizontal Scaling   • Load-balancing• High Availability setup• Web-server optimizations• Caching
Traffic
Servers: Chuck Norris Style
Servers: Spartan Style
Horizontal Scaling
Horizontal Scaling      Traffic   web-1       web-2   ...   web-n
Horizontal Scaling                    Load-      Traffic       balancer   web-1       web-2          ...   web-n
Horizontal Scaling                    Load-      Traffic       balancer   web-1       web-2          ...   web-n
Horizontal Scaling                    Load-      Traffic       balancer   web-1       web-2          ...   web-n
Horizontal Scaling                    Load-      Traffic       balancer   web-1       web-2          ...   web-n
Horizontal Scaling                    Load-      Traffic       balancer   web-1       web-2          ...   web-n
How Flipkart Scales• Horizontal Scaling   • Load-balancing• High Availability setup• Web-server optimizations• Caching
Load Balancer
Load Balancer• Internal binary services (Apache Thrift)• Internal web services (HTTP)• External web traffic (HTTP/HTTPS)
Load Balancer• Internal binary services (Apache Thrift)• Internal web services (HTTP)• External web traffic (HTTP/HTTPS)
Load Balancer• Internal binary services (Apache Thrift)   • Software: HAProxy   • Transport layer (TCP) load balancer   • ...
Load Balancer• Internal binary services (Apache Thrift)• Internal web services (HTTP)• External web traffic (HTTP/HTTPS)
Load Balancer• Internal binary services (Apache Thrift)• Internal web services (HTTP)    • Software: Varnish    • Applicat...
Load Balancer• Internal binary services (Apache Thrift)• Internal web services (HTTP)• External web traffic (HTTP/HTTPS)
Load Balancer• Internal binary services (Apache Thrift)• Internal web services (HTTP)• External web traffic (HTTP/HTTPS)   ...
Load Balancer:Session Affinity?               Load-              balancer                         ...   web-n  web-1   web-2
Load Balancer:Session Affinity?     SID: 123 (1)                         Load-                        balancer             ...
Load Balancer:Session Affinity?     SID: 123 (1)                         Load-                        balancer             ...
Load Balancer:Session Affinity?     SID: 123 (1)                         Load-                        balancer             ...
Load Balancer:Session Affinity?     SID: 123 (1)                         Load-     SID: 123 (2)       balancer             ...
Load Balancer:Session Affinity?     SID: 123 (1)                         Load-     SID: 123 (2)       balancer             ...
Load Balancer:Session Affinity?     SID: 123 (1)                           Load-     SID: 123 (2)         balancer         ...
HTTP Load Balancing:  Session Affinity
HTTP Load Balancing:    Session Affinity• (+) Sessions can be stored on the web server• (+) Different code on different web...
HTTP Load Balancer:Session Non-affinity
HTTP Load Balancer:   Session Non-affinity• Sessions stored in a common session-store• (+) Easy to manage -- all web server...
HTTP Load Balancer:Session Some-affinity
HTTP Load Balancer: Session Some-affinity• Sessions sticky to a subset (group) of machines• Use a common session-store
How Flipkart Scales• Horizontal Scaling   • Load-balancing• High Availability setup• Web-server optimizations• Caching
Load Balancer:  Hardware?
Load Balancer:            Hardware?• Expensive• Inflexible to manage• They run Linux anyway!
Flipkart’s Load-   Balancers
Flipkart’s Load-   Balancers
Flipkart’s Load-   Balancers
Flipkart’s Load-   Balancers
Flipkart’s Load-   Balancers
Flipkart’s Load-   Balancers
Flipkart’s Load-   Balancers
Flipkart’s Load-   Balancers
Flipkart’s Load-       balancers bond:1            bond:1(10.3.1.1)        (10.3.1.2) bond:0            bond:0(10.3.0.1)  ...
Flipkart’s Load-        balancers  bond:1            bond:1 (10.3.1.1)        (10.3.1.2)  bond:0            bond:0 (10.3.0...
Flipkart’s Load-        balancers  bond:1              bond:1 (10.3.1.1)          (10.3.1.2)  bond:0              bond:0 (...
Flipkart’s Load-        balancers  bond:1              bond:1 (10.3.1.1)          (10.3.1.2)  bond:0              bond:0 (...
Flipkart’s Load-        balancers  bond:1                       bond:1 (10.3.1.1)                   (10.3.1.2)  bond:0    ...
How Flipkart Scales• Horizontal Scaling   • Load-balancing• High Availability setup• Web-server optimizations• Caching
On the Web Servers
On the Web Servers• PHP5
On the Web Servers• PHP5• Apache/mod_php
On the Web Servers• PHP5• Apache/mod_php
On the Web Servers• PHP5• Apache/mod_php• Apache/mod_fcgid (FastCGI)
On the Web Servers• PHP5• Apache/mod_php• Apache/mod_fcgid (FastCGI)
On the Web Servers• PHP5• Apache/mod_php• Apache/mod_fcgid (FastCGI)• PHP-FPM
On the Web Servers• PHP5• Apache/mod_php• Apache/mod_fcgid (FastCGI)• PHP-FPM    • PHP FastCGI Process Manager    • Great ...
On the Web Server:   fk-w3-agent
On the Web Server:      fk-w3-agent• Simple Java “middleware” daemon
On the Web Server:      fk-w3-agent• Simple Java “middleware” daemon• Deployed on each web server
On the Web Server:      fk-w3-agent• Simple Java “middleware” daemon• Deployed on each web server• Communicates with PHP t...
On the Web Server:      fk-w3-agent• Simple Java “middleware” daemon• Deployed on each web server• Communicates with PHP t...
On the Web Server:      fk-w3-agent• Simple Java “middleware” daemon• Deployed on each web server• Communicates with PHP t...
fk-w3-agent: Why?
fk-w3-agent: Why?• “I wish PHP could ...”
fk-w3-agent: Why?• “I wish PHP could ...”• Logging
fk-w3-agent: Why?• “I wish PHP could ...”• Logging• Connection pools
fk-w3-agent: Why?• “I wish PHP could ...”• Logging• Connection pools• Parallelization
fk-w3-agent: Why?• “I wish PHP could ...”• Logging• Connection pools• Parallelization• Config & discovery
fk-w3-agent: Why?• “I wish PHP could ...”• Logging• Connection pools• Parallelization• Config & discovery• Running statistics
fk-w3-agent: Logging
fk-w3-agent: Logging• We like to log, a lot
fk-w3-agent: Logging• We like to log, a lot• Logs need to be flushed to disk
fk-w3-agent: Logging• We like to log, a lot• Logs need to be flushed to disk• PHP resources wasted    • waiting for disk I/...
fk-w3-agent: Logging
fk-w3-agent: Logging• PHP processes send logs to fk-w3-agent• fk-w3-agent writes logs to files
fk-w3-agent:Connection Pooling
fk-w3-agent:   Connection Pooling• Many service calls / request
fk-w3-agent:   Connection Pooling• Many service calls / request• Cost of recreating connections high
fk-w3-agent:   Connection Pooling• Many service calls / request• Cost of recreating connections high• PHP does not support...
fk-w3-agent:Connection Pooling
fk-w3-agent:   Connection Pooling• fk-w3-agent maintains persistent connection pools  to various services• PHP accesses se...
fk-w3-agent:Parallelization
fk-w3-agent:        Parallelization• Service calls can be parallelized
fk-w3-agent:        Parallelization• Service calls can be parallelized• Multi-threading in PHP is ...
fk-w3-agent:Parallelization
fk-w3-agent:        Parallelization• PHP sends request to fk-w3-agent• fk-w3-agent uses multiple threads to hit services i...
fk-w3-agent:Config & Discovery
fk-w3-agent:    Config & Discovery• Change config without deployment?
fk-w3-agent:    Config & Discovery• Change config without deployment?• Simple: store config in a database
fk-w3-agent:    Config & Discovery• Change config without deployment?• Simple: store config in a database• But: reloading con...
fk-w3-agent:Config & Discovery
fk-w3-agent:    Config & Discovery• fk-w3-agent loads config from database   • Caches it in memory   • Keeps it up-to-date• ...
fk-w3-agent:Running Statistics
fk-w3-agent:    Running Statistics• PHP sends basic stats to fk-w3-agent for every  request• fk-w3-agent aggregates these ...
How Flipkart Scales• Horizontal Scaling   • Load-balancing• Web-server optimizations• Caching
To Cache or not to     Cache?
To Cache or not to          Cache?• “There are only two hard things in Computer  Science: cache invalidation and naming th...
To Cache or not to          Cache?• “There are only two hard things in Computer  Science: cache invalidation and naming th...
Caches Invalidation
Caches Invalidation• Objects updated => Notification Message
Caches Invalidation• Objects updated => Notification Message• Remove updated objects from cache
Caches Invalidation• Objects updated => Notification Message• Remove updated objects from cache• Replace updated objects in...
Caches Invalidation• Objects updated => Notification Message• Remove updated objects from cache• Replace updated objects in...
Caches at Flipkart
Caches at Flipkart• Memcached -- in memory caching
Caches at Flipkart• Memcached -- in memory caching• Redis -- persistent store/cache
Caches at Flipkart• Memcached -- in memory caching• Redis -- persistent store/cache• Varnish -- HTTP caching
Caches at Flipkart• Memcached -- in memory caching• Redis -- persistent store/cache• Varnish -- HTTP caching• fk-w3-agent ...
Let’s continue the         discussion• @sids on Twitter• siddhartha@flipkart.com• #phpcloud on irc.freenode.net
