Information Retrieval      Lecture 6
-   Some crawlers were stuck in loops.-   Issues with storage-   MSU’s site has about 60,00+ URLs    including subdomains.
- 37.5% of grade based on Crawler- 37.5% on presentation- 25% Attendance- Paper topics handed out next week
- Information retrieval (IR) is finding material(usually documents) of an unstructured nature(usually text) that satisfies a...
   Three reasons to use multiple computers for    crawling     Helps to put the crawler closer to the sites it      craw...
 Linear Scan of Documents is called  “grepping”’ In order to perform “ranked retrieval” we  need the best answer among m...
 Ex: The works of Shakespeare. Record whether each book contains a word  out of all the words (~32,000) Create binary-t...
   Suppose we want to answer the Brutus AND    Ceaser and NOT Calpurnia. We operate on    the row vectors (NOT(Calpurnia)...
 Collection of Documents: Corpus To asses the effectiveness of an IR system     Precision: What fraction returned docum...
 Last example, incidence matrix, too large. A  500k x 1M matrix has ½ trillion 0’s and 1’s.  And too sparse. 99.8% of mat...
   Text is stored in hundreds of incompatible file    formats.. Bytes on a web server.     e.g., raw text, RTF, HTML, XM...
   A character encoding is a mapping    between bits and glyphs     i.e., getting from bits in a file to characters on  ...
   Other languages can have many more    glyphs     e.g., Chinese has more than 40,000     characters, with over 3,000 i...
 ASCII: Was able to rep. all of English  characters use numbers 32-127. (Unix and C  being invented) IBM started using t...
 A different way of thinking about character  representation Question is A different than A? In some  languages even the...
 UTF-8 -> Identical to ASCII codes. Coding  bits to Glyphs. You have to know what Encoding is being  used!
 Single mapping from numbers to glyphs  that attempts to include all glyphs in  common use in all known languages Unicod...
 e.g., Greek letter pi (π) is Unicode symbol  number 960 In binary, 00000011 11000000 (3C0 in  hexadecimal) Final encod...
   Web Site use:    <html>    <head>   <meta http-equiv="Content-Type"    content="text/html; charset=UTF-8" />
   Requirements for document storage system:     Random access      ○ request the content of a document based on its    ...
 Text is highly redundant (or predictable) Compression techniques exploit this  redundancy to make files smaller without...
   Google’s document storage system (Chang    et al., 2006)     Customized for storing, finding, and updating web      p...
   No query language, no complex queries to    optimize   Only row-level transactions   Tablets are stored in a replica...
 Logically organized into rows A row stores data for a single web page Combination of a row key, a column key, and  a t...
   BigTable can have a huge number of    columns per row     all rows have the same column groups     not all rows have...
   Duplicate and near-duplicate documents    occur in many situations     Copies, versions, plagiarism, spam, mirror    ...
 Exact duplicate detection is relatively easy Checksum techniques     A checksum is a value that is computed based on t...
   More challenging task     Are web pages with same text context but     different advertising or format near-duplicate...
 Many web pages contain text, links, and  pictures that are not directly related to the  main content of the page This a...
 Many web pages contain text, links, and  pictures that are not directly related to the  main content of the page This a...
   Other approaches    use DOM    structure and    visual (layout)    features
   Cumulative distribution of tags in the example    web page     Main text content of the page corresponds to the      ...
   R. Song et al., 2004. “Learning Block    Importance Models for Web Pages”
Information Retrieval, Encoding, Indexing, Big Table. Lecture 6  - Indexing
Information Retrieval, Encoding, Indexing, Big Table. Lecture 6  - Indexing
Information Retrieval, Encoding, Indexing, Big Table. Lecture 6  - Indexing
