DRAWING AND CHARTING                              Brendan Coughran, Sencha                                      @whereisth...
DrawWednesday, November 2, 2011
Surface                         SVG Engine   VML Engine   Canvas Engine                                        SpriteWedne...
Surface                              SVG Engine                               VML Engine                              Canv...
SurfaceWednesday, November 2, 2011
Surface                              Vector Primitives                                    Text                            ...
SpriteWednesday, November 2, 2011
Sprite                       Abstracted drawing elements             Normalizes differences between engine API syntax     ...
DrawComponent       Extends Component       Contains surface       Layout participation       <replace-with class=com.senc...
DrawComponent Example              DrawComponent component = new DrawComponent();              PathSprite path = new PathS...
Wednesday, November 2, 2011
Wednesday, November 2, 2011
Wednesday, November 2, 2011
Wednesday, November 2, 2011
ChartsWednesday, November 2, 2011
Chart Example              ListStore<Data> store = new ListStore<Data>(dataAccess.nameKey());              store.addAll(Te...
Scatter Example              NumericAxis<Data> axis = new NumericAxis<Data>();              axis.setPosition(Position.LEFT...
Wednesday, November 2, 2011
Wednesday, November 2, 2011
Bar Example              CategoryAxis<Data, String> catAxis = new CategoryAxis<Data, String>();              catAxis.setPo...
Wednesday, November 2, 2011
Wednesday, November 2, 2011
Line Example              Legend<Data> legend = new Legend<Data>();              legend.setPosition(Position.RIGHT);      ...
Wednesday, November 2, 2011
Wednesday, November 2, 2011
Area Example              AreaSeries<Data> series = new AreaSeries<Data>();              series.setYAxisPosition(Position....
Wednesday, November 2, 2011
Wednesday, November 2, 2011
Gauge Example              GaugeAxis<Data> axis = new GaugeAxis<Data>();              axis.setMargin(10);              axi...
Wednesday, November 2, 2011
Wednesday, November 2, 2011
Radar Example              RadialAxis<Data, String> axis = new RadialAxis<Data, String>();              axis.setCategoryFi...
Wednesday, November 2, 2011
Wednesday, November 2, 2011
Pie Example           PieSeries<Data> series = new PieSeries<Data>();           series.setAngleField(dataAccess.data1()); ...
Wednesday, November 2, 2011
Wednesday, November 2, 2011
Customization                                   and                               InteractivityWednesday, November 2, 2011
Events           series.addSeriesSelectionHandler(new SeriesSelectionHandler() {             @Override             public ...
Wednesday, November 2, 2011
Wednesday, November 2, 2011
Mixed Example             BarSeries<Data> bar = new BarSeries<Data>();             bar.setYAxisPosition(Position.LEFT);   ...
Wednesday, November 2, 2011
Wednesday, November 2, 2011
Renderer Example           column.setRenderer(new SeriesRenderer<Data>() {             @Override             public Sprite...
Wednesday, November 2, 2011
Wednesday, November 2, 2011
Tooltip Example           private LabelProvider<Number> million = new LabelProvider<Number>() {             @Override     ...
Wednesday, November 2, 2011
Wednesday, November 2, 2011
Label Example             PieSeries<Data> series = new PieSeries<Data>();             series.setAngleField(dataAccess.data...
Wednesday, November 2, 2011
Wednesday, November 2, 2011
Live Example              line.setMarkerIndex(1);              TimeAxis<Site> time = new TimeAxis<Site>();              ti...
Wednesday, November 2, 2011
Wednesday, November 2, 2011
Animation Example           private Animator createRadiusAnimator(final CircleSprite sprite, double           radius) {   ...
Wednesday, November 2, 2011
Wednesday, November 2, 2011
Questions?Wednesday, November 2, 2011
