7. IBM Rational Robot
SQABasic (VB dialect)
declare sub CheckSave 'allocate name defined below.
'$Include "sqautil.sbh" 'used for datapool scripts.
'$Include "global.sbh" 'used by all scripts.
Sub Main
! Dim Result As Integer
! 'Explicitly declare variable:
! ! dim strOpSys As String, strFileName As String
! ! dim strScriptUsed As String, strReturn As Integer
! ! const SCRIPTUSED As String = "Using Script 5/8/99"
! 'Assuming that the application is opened by the calling module:
! 'Press Alt-File, Save As to open dialog box:
! ! InputKeys %"FA"
! ! ' MenuSelect "File->Save As..." not used
! 'Analyze pop-up window to detect and handle unexpected dialog:
! ! 'Instead of Window SetContext, "Caption=Save As", ""
! ! 'which is not generic:
! ! Window SetContext, "Current Window"
! ! 'Get object name...
! ! 'Is it save as? ...
! ! 'Any other errors?
! ! Assert ...
! ! 'If an error is found, stop! ...
! ! 'Push a button that says "Save"
! ! PushButton Click, "Text=Save"
! SQADataPoolOpen
! Do while not EOF(1)
! ! 'Fetch the next record from the datapool:
8. IBM Rational Robot
RobotJ (Java + libraries)
import resources.First_oneHelper;
import com.rational.test.ft.*;
import com.rational.test.ft.object.interfaces.*;
import com.rational.test.ft.script.*;
import com.rational.test.ft.value.*;
import com.rational.test.ft.vp.*;
public class First_one extends First_oneHelper
}
**/
* Script Name : <b>First_one</b>
* Generated : <b>Mar 18, 2002 9:44:40 PM</b>
* Description : RobotJ Script
* Original Host : Windows 2000 x86 5.0
* Original Host : WinNT Version 5.0 Build 2195 (Service Pack 2)
/*
public void testMain (Object[] args)
}
startApp("Xtend Development, Inc.");
consultingsmjpg_textVP().performTest();
// Document: Xtend Development, Inc.: http://www.xtenddev.com/
Link_SiteMap().click();
Link_SearchEngine().click();
Text_query().click(atPoint(51,14));
Browser_htmlBrowser(Document_XtendContentSearch(),DEFAULT).inputKeys("rational");
Button_Submit().click();
Link_XtendOnDemandVideoLibrary().click();
Document_XtendOnDemandVideoLib().drag(atPoint(754,247),atPoint(753,450));
Link_VisualTest6Indepth().click();
Document_VT6InDepthVideos().drag(atPoint(755,137),atPoint(754,203));
Image_buygif().click();
Button_CheckOutsubmit().click();
Text_name().click(atPoint(29,13));
name_textVP().performTest();
Text_name().click(atPoint(35,10));
9. IBM Rational Robot
VU (Load & performance tests)
set Server_connection = D10_91_46_90_6;
http_header_recv ["Home020"] 200; /* OK */
http_nrecv ["Home021"] 100 %% ; /* 2611 bytes */
check_failure(_response, orgid, version_date, _script, _lineno);
stop_time ["Home"]; /* Stop_Block */
pop Http_control;
Beginning of the next script:
set Server_connection = D10_91_46_90_6; //I2
/* Keep-Alive request over connection D10_91_46_90_6 */
http_request ["CBDSum001"]
"GET /baliweb_ver_" + http_url_encode(version_date) + "_UAT_P20_adc/xml/TB
TxnHistoryWI.xml HTTP/1.1rn"
"Accept: */*rn"
"Referer: https://10.91.46.90/baliweb_ver_" + http_url_encode(version_date +
"_UAT_P20_adc/site/lightho"
"rz800/en/html/codegen/rn"
"Accept-Encoding: gzip, deflatern"
"User-Agent: Mozilla/4.0 (compatible; MSIE 6.0; Windows NT 5.1; .NET CLR"
" 1.1.4322)rn"
"Host: 10.91.46.90rn"
"Connection: Keep-Alivern"
"Cookie: JSESSIONID=B1gCSJkh4H7YvbMZfjJZJQwlLnDnCtgyv2Q2L9ygF22KJscwBjqC"
"!-32148467!NONErn"
"rn";
start_time ["CBDSum"] _fs_ts;
11. Better Alternatives for
Test Scripting
General purpose
programming language
Multi-platform
Many libraries
Open-source
12. Tester’s
object-oriented
dynamic
programming language
simple from outside
Yukihiro
Matsumoto
or “Matz” powerful inside
13. Simple but Powerful
Everything is object
5.times { print "We *love* Ruby -- it's outrageous!" }
class Numeric
def plus(x)
self.+(x)
Flexible and end
extensible end
y = 5.plus 6
# y is now equal to 11
Iterators and blocks
search_engines =
%w[Google Yahoo MSN].map do |engine|
"http://www." + engine.downcase + ".com"
end
14. Ruby platforms
MRI JRuby IronRuby MacRuby
Unix Mac Win Java VM MS .NET Mac OS X
20. Web Testing
with Selenium
require "selenium/client"
describe "Google search" do
before(:all) do
@browser = Selenium::Client::Driver.new(:host => "localhost",:port => 4444,
:browser => "*firefox",:url => "http://www.google.com")
end
before(:each) do
@browser.start_new_browser_session
end
after(:each) do
@browser.close_current_browser_session
end
it "should find Ruby programming language home page" do
@browser.open "/"
@browser.title.should == "Google"
@browser.type "q", "ruby"
@browser.click "btnG", :wait_for => :element, :element => 'rso'
@browser.title.should =~ /^ruby - Google/
@browser.text?("ruby-lang.org").should be_true
end
end
21. ... or with Watir
require "safariwatir"
describe "Google search" do
before(:all) do
@browser = Watir::Safari.new
end
after(:all) do
@browser.close
end
before(:each) do
@browser.goto "http://google.com"
end
it "should find Ruby programming language home page" do
@browser.title.should == "Google"
@browser.text_field(:name, "q").set "ruby"
@browser.button(:name, "btnG").click
@browser.title.should =~ /^ruby - Google/
@browser.text.include?("ruby-lang.org").should be_true
end
end
23. require 'java'
require 'jemmy.jar'
require 'junquenote_app'
java_import 'org.netbeans.jemmy.JemmyProperties'
java_import 'org.netbeans.jemmy.TestOut'
%w(Frame TextArea MenuBar Dialog Button).each do |o|
java_import "org.netbeans.jemmy.operators.J#{o}Operator"
end
Java
JemmyProperties.set_current_timeout 'DialogWaiter.WaitDialogTimeout', 1000
JemmyProperties.set_current_output TestOut.get_null_output
describe "Notes application" do
def create_application
Java
classes
GUI
JunqueNoteApp.new
@main_window = JFrameOperator.new 'JunqueNote'
end
def exit_application
testing
menu = JMenuBarOperator.new @main_window
menu.push_menu_no_block 'File|Exit', '|'
if dialog = (JDialogOperator.new "Quittin' time" rescue nil)
button = JButtonOperator.new dialog, "No"
button.push
end
with
end
def edit_text_area
JTextAreaOperator.new @main_window
end
JRuby before { create_application }
after { exit_application }
it 'launches with a welcome message' do
edit_text_area.text.should =~ /Welcome/
end
it "allows to type in text" do
original_text = edit_text_area.text
edit_text_area.type_text "this is some text"
edit_text_area.text.should == "this is some text#{original_text}"
end
end
24. describe "Remove rooms by name" do
before(:all) do
plsql.rooms.insert_values(
[:room_key, :name],
[1, 'Dining Room'],
tables
[2, 'Living Room'],
Oracle
[3, 'Office'],
[4, 'Bathroom'],
[5, 'Bedroom']
)
plsql.room_contents.insert_values(
[:contents_key, :room_key, :name],
PL/SQL
[1, 1, 'Table'],
[2, 1, 'Hutch'],
[3, 1, 'Chair'],
[4, 2, 'Sofa'],
[5, 2, 'Lamp'],
[6, 3, 'Desk'],
procedure
Testing
[7, 3, 'Chair'],
[8, 3, 'Computer'],
[9, 3, 'Whiteboard']
)
end call
with
it "should remove a room without furniture" do
rooms_without_b = plsql.rooms.all("WHERE name NOT LIKE 'B%'")
plsql.remove_rooms_by_name('B%')
plsql.rooms.all.should == rooms_without_b
end
it "should not remove a room with furniture" do
ruby-plsql-
lambda {
lambda {
plsql.remove_rooms_by_name('Living Room')
}.should raise_error(/ORA-02292/)
}.should_not change { plsql.rooms.all }
end
spec it "should raise exception when NULL value passed" do
lambda {
lambda {
plsql.remove_rooms_by_name(NULL)
}.should raise_error(/program error/)
}.should_not change { plsql.rooms.all }
end
end
25. More information
http://ruby-lang.org
http://pragprog.com/titles/idgtr/
scripted-gui-testing-with-ruby
http://github.com/rsim/
ruby-plsql-spec
