EEDC                          34330ExecutionEnvironments for                   Scientific ProgrammingDistributed          ...
OutlineScientific Programming Models  – Part 1: Introduction  – Part 2: Reference parallel programming models  – Part 3: N...
Introduction Scientific applications:   –   Solve complex problems   –   Usually long run applications   –   Implemented ...
Introduction             In time terms…Scientific applications can’t be no more     considered in sequential way!!!       ...
Introduction      We need solutions based on distribute and               parallelize the work.                        5
Introduction: MPI1980s - early 1990s: Distributed memory & parallel computing startedas a bunch of incompatible software t...
Introduction: OpenMPIn the early 90s: Vendors of shared-memory machines supplied similar,directive-based for Fortran progr...
Reference PM: OpenMPProgramming model: Computation is done by threads. Fork-join model: Threads are dynamically created ...
Reference PM: OpenMP Example of sequential PI calculation                           9
Reference PM: OpenMP Example of OpenMP PI calculation                         10
Reference PM: OpenMPStrong Points:   –   Keeps the sequential version.   –   Communication is implicit.   –   Easy to prog...
Reference PM: MPIProgramming model: Computation is done by several processes that execute the same program. Communicates...
Reference PM: MPI Example of MPI PI calculation                          13
Reference PM: MPIStrong Points:  –   Any parallel algorithm can be expressed in terms of the MPI paradigm.  –   Data place...
Reference PM: The best of both worlds Hybrid (MPI + OpenMP):  – MPI is most effective for problems with “course-grained” ...
Reference PM: Hybrid (MPI + OpenMP) Example of MPI + OpenMP PI calculation                         16
Reference PM: New reference approaches Heterogeneous parallel-computing:  – CUDA (From NVIDIA)  – OpenCL (Open Compute La...
Novel PMs Workflows:  –   Based on processes  –   Requires planning and scheduling  –   Needs flow control  –   In-transi...
Microsoft Dryad The Dryad Project is investigating programming model  for writing parallel and distributed programs to sc...
Microsoft DryadGraphBuilder Xset = moduleX^N;GraphBuilder Dset = moduleD^N;GraphBuilder Mset = moduleM^(N*4);GraphBuilder ...
MapReduce Programmer only defines 2 functions   – Map(KInput,VInput) list(Ktemp,Vtemp)   – Reduce(Ktemp, list(Vtemp))li...
MapReduce Weaknesses  – Specific programming.  – Not easy to find key value pairs. Strong points  – Efficiency.  – Simpl...
The COMP Superscalar (COMPSs)                23
COMPSs overview - Objective Reduce the development complexity of  Grid/Cluster/Cloud applications to the minimum   – As e...
COMPSs overview - Main idea                                                                                               ...
Programming model - Sample application  Main program  public void main(){          Integer sum=0;          double pi      ...
Programming Model - Task Selection                                                Task selection interfacepublic interface...
Programming Model – Main code   public static void main(String[] args) {            Integer sum=0;            double pi   ...
Programming Model – Real ExampleHMMER    Protein Database              Aminoacid Sequence                                 ...
Programming Model – Real ExampleAminoacidsequence                     30
Programming Model – Real ExampleString[] outputs = new String[numDBFrags];//Processfor (String dbFrag : dbFrags) {     out...
Programming Model – Real Examplepublic interface HMMPfamItf {    @Method(declaringClass = "worker.hmmerobj.HMMPfamImpl")  ...
Programming Model – Real Example                   33
Programming Model – Real Example                   34
COMPSs Strong points  –   Sequential programming approach  –   Parallelization at task level  –   Transparent data manage...
Tutorial Sample & Development Virtual Appliance   – http://bscgrid06.bsc.es/~lezzi/vms/COMPSs_Tutorial.ova Tutorial   – ...
Manjrasoft Aneka .NET based Platform-as-a-Service Allows the usage of:   – Private Clouds.   – Public Clouds: Amazon EC2...
Microsoft Azure .NET based Platform-as-a-Service Computing services  – Web Role: Web Service frontend.  – Worker Role: B...
Conclusions Scientific problems are usually complex. Current reference PMs are usually unsuitable. New novel & flexible...
Questions            40
