2008 Trends in the Back-end Rajiv Roy
<ul><li>Rudolph tools for back-end </li></ul><ul><li>Use of inspection for automotive semiconductor </li></ul><ul><ul><ul>...
Rudolph - Where We Play – Tools for Back-End Inspection Metrology Analysis Global Support August - NSX RVSI  -  WS API - P...
Use of Inspection for Automotive Semiconductor Investment in 100% Outgoing inspection – Zero Defects
Zero Defects and Automotive Semiconductor Industry Şafak Keçeci Infineon Regensburg June 12, 2007 Regensburg - Rudolph‘s E...
Key Enablers of Zero Defects Program <ul><li>Inspection </li></ul><ul><li>Automated over manual </li></ul><ul><li>Upstream...
Zero Defect as Key for Infineon Future  Customer Return Rate  Status April 2006 Products with 0 ppm:  Increase to … %
Inspections in the Back-end for Automotive Typical Products Available Q2 ‘09 Available today NSX with ultra-thin wafer han...
Use of Inspection for Automotive Semiconductor PMI (Probe Mark Inspection) Tool Correlation Certification wafer
<ul><li>T2T correlation and repeatability study was performed using PMI metrology data at customer site </li></ul><ul><ul>...
<ul><ul><li>Spec components tighter–camera, lenses, illumination </li></ul></ul><ul><ul><li>Illumination matching, flat-fi...
Sample Plan Bondpad 1 Bondpad 2 Bondpad 3 Bondpad 4 Bondpad 5 Bondpad 6 Bondpad 7 Bondpad 8
Left Edge Proximity ( µm ) Results
Average Left Edge Proximity ( µm ) Results Average correlation between two tools running the same wafer >96% for bond pad ...
Probe Mark Area ( µm ²) Results
Average Probe Mark Area ( µm ²) Results Average correlation between two tools running the same wafer >93% for probe mark a...
<ul><li>Automotive industry requires a metrology approach to inspection </li></ul><ul><li>Tools have to be designed ground...
Test Floor Avoiding Damage to Probe Cards Detecting Tall Particles
<ul><li>Laser Dark-field  on NSX was used to detect particles </li></ul><ul><li>Customer Supplied Rudolph Technologies wit...
<ul><li>Laser Dark-field </li></ul><ul><ul><li>With Laser Dark-field, the laser light hits the surface at an oblique angle...
<ul><li>Images at 10X, Brightfield used only for image capture </li></ul><ul><li>Red in images is laser reflecting off  fe...
Defect Height Estimates 1 2 3 4 5 6 7 <ul><li>Measure defect height with focus – focus on wafer surface and then focus on ...
Defect Height Estimates 8 9 10 11
Defect Height Estimates 12 13 14 15
<ul><li>The use of laser dark-field will adequately detect tall particles </li></ul><ul><li>The throughput will be effecte...
Inspection of CMOS Sensors & TSV
<ul><li>Inspect glue dimensions of bubbles after adhesion </li></ul><ul><li>Glass is pressed onto the silicon and the bubb...
<ul><li>5x inspection mag used to inspect bottom side of the wafer and pixel area in one pass through the glass </li></ul>...
<ul><li>The NSX is used at 3 different stages of the CMOS sensor assembly </li></ul><ul><li>Customer is performing 100% in...
Micro Bump Through Silicon Stacking Interconnect Flip-chip
<ul><li>Pillar Bumps come in various shapes and sizes </li></ul><ul><li>Height can vary from 5um to over 100um and diamete...
<ul><li>Typical height is 20-30um </li></ul><ul><li>Typical Pitch is 50um </li></ul><ul><li>Due to small size of the bump ...
Critical Issues and Inspection Requirements  Bump Dimensions / Bump Defects Bump Height Coplanarity: Best Fit Plane Method...
Critical Issues and Inspection Requirements Macro Defects <ul><li>Macro Defects can found the Surface of the wafer, Traces...
<ul><li>Copper Pillar Bumps </li></ul><ul><ul><li>Large Bump height variation requires sensor technology to be able to han...
Rudolph’s Approach to Micro Bump Inspection and Metrology
<ul><li>For 2D Inspection - TDI Line Scan Camera </li></ul><ul><li>Surface Defect Inspection </li></ul><ul><li>2D Bump Met...
<ul><li>Rudolph’s 3D Line Scan Laser with Micromap Technology </li></ul><ul><li>4 MHz scanning rate </li></ul><ul><li>1.2m...
Sample Inspection Case Studies
3D Scan of Copper Pillar Bumps Raw 3D Data
3D Scan of Copper Pillar Bumps Raw 3D Data <ul><li>Cross section of some bumps on a die </li></ul><ul><li>Dark is lower pi...
Sample Wafer Height Variation Across the Wafer Avg. Dia.= 26.6um Min. Dia.= 21.6um Max. Dia.= 35um Sigma = 2.8um Avg. Heig...
Copper Pillar Bump  Repeatability Results   WS Mean (15 Runs at 5 runs/Day)  WS STDV (15 Runs at 5 runs/Day)  Bump Height ...
3D scan of a Die with  Micro Solder Bumps Raw 3D Data Bump Height
Micro Solder Bump  Repeatability Results Measurement Avg. (um) Min. (um) (col., row) Max. (um) (Col, row) 3 Sigma (um) Tru...
Sample Captured Macro Defects
Throughputs <ul><li>Case 1  </li></ul><ul><ul><li>Throughput with handling based on 25 wafers/slot with 2.5X lens (2.8um p...
Conclusion of Microbump Inspection and Metrology <ul><li>Copper Pillar bumps and Micro bumps require high precision sensor...
Conclusions and Observations of Trends <ul><li>Use of Inspection for Automotive Semiconductor is increasing – it is essent...
Thank you!
