SERIOUSLY, YOU CAN DO     COOL THINGS:Getting Advanced with the Text Layout Framework               by Huyen Tue Dao
ABOUT ME• Name ≈ “Hwin Tweh Dow”• Computer/Electrical Engineering @  University of Maryland• Flex developer since 2006; al...
WHAT ARE WE GOING TO          TALK ABOUT?•   Overview of Text Layout Framework and Flash Text Engine•   Using the Text Lay...
Stage                                                               TextLineTextBlock                                     ...
My Title                                            Here’s some text.                                            Here’s so...
interactionManager:ISelectionManager                         changes to TextFlow          passing input and user events   ...
OVERVIEW OF TLF AND FTE•   TLF utilizes FTE for advanced text rendering    •   Adds in MVC framework, automated/advanced l...
USING THE TLF IN MANUAL•   “Manual?”    •   Set up text flow, containers, controllers, and interaction        manager by ha...
USING THE TLF IN MANUAL•   “Automatic”: family of Spark components utilize TLF    •   Base TLF Spark components: RichText,...
USING THE TLF IN MANUAL•   “Semi-automatic”    •   TextContainerManager, class that handles a single-container TLF        ...
USING THE TLF IN MANUAL•   Basic classes involved    •   TextFlow and classes for importing/exporting a TextFlow:        •...
USING THE TLF IN MANUAL•   IFlowComposer: currently only StandardFlowComposer    implementation and TextFlow automatically...
Container layout in TextFlowLines                                                      Stage                              ...
USING THE TLF IN MANUAL•   ContainerController: connects TextFlow and a container, tracks    width and height of text area...
USING THE TLF IN MANUAL•   Basic setup:    •   Import/create TextFlow    •   Create one or more containers (Sprites)    • ...
USING THE TLF IN MANUAL•   Basic setup:    •   Import/create TextFlow    •   Create one or more containers (Sprites)    • ...
USING THE TLF IN MANUAL•   So what can we do in “manual?”•   Play with containers:    •   Use multiple, linked containers:...
USING THE TLF IN MANUAL•   States of a text container in TLF:    •   Damaged: when model or layout changes, IFlowComposer ...
USING THE TLF IN MANUAL•   Useful/Import TextFlow events:    •   DamageEvent.DAMAGE: dispatched whenever changes are      ...
USING THE TLF IN MANUAL•   Implementing pagination in TLF: check if the last container added    renders the end of the tex...
USING THE TLF IN MANUAL•   When do we perform this check?    •   Need to wait for the last page added to compose and displ...
USING THE TLF IN MANUAL•   Playing with containers: Useful TLF stuff    •   addController/removeController    •   DamageEv...
EXTENDING THE TLF•   Extending the Text Layout Framework    •   Can be difficult: some classes are marked final (that you wi...
EXTENDING THE TLF•   FlowOperations: family of objects utilized by IEditManager to    encapsulate changes to TextFlow and ...
EXTENDING THE TLF•   Creating your own operations:    •   FlowTextOperation: subclass of for transforming text    •   Crea...
EXTENDING THE TLF•   undo():SelectionState, contains logic for reversing changes,    return value is the selection state d...
EXTENDING THE TLF•   Things to keep in mind    •   You can use other operations within your operation        •   Take adva...
EXTENDING THE TLF•   Stay away from using FlowElement references in your    operation    •   When using copy/cut/paste or ...
LEVERAGING THE FTE•   Understanding underlying FTE parts of TLF can help you:    •   Decorate/enhance TLF-rendered text wi...
LEVERAGING THE FTE•   StandardFlowComposer: methods for grabbing TextFlowLines    •   findLineAtPosition/findLineIndexAtPosi...
LEVERAGING THE FTE•   TextLine: methods for getting position, index information for    individual characters    •   getAto...
COMBINING WITH OTHER        FLEX COMPONENTS•   Ideally, we would love to be to create custom FlowElements that    provide ...
COMBINING WITH OTHER      FLEX COMPONENTS•   Need to assign id to differentiate our placeholder    InlineGraphicElements f...
COMBINING WITH OTHER  FLEX COMPONENTS•   Can even import/export these components    •   Use XML: export as whatever tag re...
CONCLUSION•   Before even getting into TLF, make sure it’s the right solution.•   Most flexible, powerful way to user TLF i...
CREDIT WHERE CREDIT IS             DUE• Drawing highlights on TextLines technique from the HighlightAdornment example incl...
QUESTIONS?Thanks for coming!                       Huyen Tue Dao                     daotueh@gmail.com           queencode...
