1.
NullMQ
ZEROMQ SEMANTICS IN THE BROWSER
Jeff Lindsay Bulat Shakirzyanov
@progrium @avalanche123

2.
libzmq

3.
High-level patterns
libzmq

4.
Philosophy
High-level patterns
libzmq

5.
Philosophy
High-level patterns
libzmq

6.
Philosophy
High-level patterns
API / Semantics
libzmq

7.
Toolkit for building messaging systems...

8.
Toolkit for building messaging systems...
...behind your firewall

9.
Toolkit for building messaging systems...
...behind your firewall
...not for customers

10.
Toolkit for building messaging systems...
...behind your firewall
...not for customers
...certainly not with the browser

11.
WITH VOICE
MAKE & RECEIVE
PHONE CALLS
SEND & RECEIVE
TEXT MESSAGES
INSTANTLY BUY
PHONE NUMBERS
ADD VOICE TO
WEB & MOBILE APPS

12.
Browser Browser

13.
ZeroMQ in the
browser?

14.
ZeroMQ in the
browser?
• libzmq is a C++ library

15.
ZeroMQ in the
browser?
• libzmq is a C++ library
• Browser extension not viable

16.
ZeroMQ in the
browser?
• libzmq is a C++ library
• Browser extension not viable
• ZMTP is not valuable by itself

17.
Let’s say we did...

18.
Let’s say we did...
• Security?

19.
Let’s say we did...
• Security?
• Skip existing auth infrastructure

20.
Let’s say we did...
• Security?
• Skip existing auth infrastructure
• Need to make something up

21.
Let’s say we did...
• Security?
• Skip existing auth infrastructure
• Need to make something up
• Direct connections?

22.
Let’s say we did...
• Security?
• Skip existing auth infrastructure
• Need to make something up
• Direct connections?
• Lots of open connections, open ports

23.
Let’s say we did...
• Security?
• Skip existing auth infrastructure
• Need to make something up
• Direct connections?
• Lots of open connections, open ports
• Just not “web friendly”

24.
Philosophy
High-level patterns
API / Semantics
libzmq

25.
Philosophy
High-level patterns
API / Semantics
libzmq

26.
What do we want?

27.
What do we want?
• Near feature/semantic parity with ZeroMQ

28.
What do we want?
• Near feature/semantic parity with ZeroMQ
• Throughput performance not as important

29.
What do we want?
• Near feature/semantic parity with ZeroMQ
• Throughput performance not as important
• Embrace nature of the web in design

30.
What do we want?
• Near feature/semantic parity with ZeroMQ
• Throughput performance not as important
• Embrace nature of the web in design
• Single connection, service multiplexing

31.
What do we want?
• Near feature/semantic parity with ZeroMQ
• Throughput performance not as important
• Embrace nature of the web in design
• Single connection, service multiplexing
• Use existing transports, protocols, etc

32.
NullMQ
What do we want?
• Near feature/semantic parity with ZeroMQ
• Throughput performance not as important
• Embrace nature of the web in design
• Single connection, service multiplexing
• Use existing transports, protocols, etc

33.
What do we have?

34.
WebSocket

35.
WebSocket
• ZMTP over WebSocket?

36.
WebSocket
• ZMTP over WebSocket?
• Connection inefficient

37.
WebSocket
• ZMTP over WebSocket?
• Connection inefficient
• Not extensible

38.
WebSocket
• ZMTP over WebSocket?
• Connection inefficient
• Not extensible
• No easy parsers

39.
WebSocket

40.
WebSocket
• STOMP over WebSocket?

41.
WebSocket
• STOMP over WebSocket?
• Existing parsers, easy to write

42.
WebSocket
• STOMP over WebSocket?
• Existing parsers, easy to write
• Very much like HTTP

43.
WebSocket
• STOMP over WebSocket?
• Existing parsers, easy to write
• Very much like HTTP
• Used primarily to multiplex

44.
NullMQ

45.
var url = "ws://hostname/gateway";
var ctx = new nullmq.Context(url);
socket = ctx.socket(nullmq.REP);
socket.bind("nullmq://echo");
socket.recvall(function(request) {
socket.send("Got: "+request);
});

46.
var url = "ws://hostname/gateway";
var ctx = new nullmq.Context(url);
socket = ctx.socket(nullmq.REQ);
socket.connect("nullmq://echo");
socket.send("Hello world!");
socket.recv(function(reply) {
console.log(reply);
// "Got: Hello world!"
});

47.
Browser Server
Application Application
NullMQ NullMQ
STOMP STOMP
WebSocket WebSocket

48.
Browser Gateway Backend
Application Bridge ZMQ Socket
NullMQ NullMQ ZMQ Socket
STOMP STOMP ZMQ Socket
WebSocket WebSocket

49.
Presence Demo

50.
NullMQ
http://github.com/progrium/nullmq
http://groups.google.com/group/nullmq
@progrium
@avalanche123

51.
STOMP

52.
STOMP
• Simple and human-readable like HTTP

53.
STOMP
• Simple and human-readable like HTTP
• Extensible via headers

54.
STOMP
• Simple and human-readable like HTTP
• Extensible via headers
• Library and server support

55.
STOMP
• Simple and human-readable like HTTP
• Extensible via headers
• Library and server support
• An easy WebSocket subprotocol

56.
STOMP
• Simple and human-readable like HTTP
• Extensible via headers
• Library and server support
• An easy WebSocket subprotocol
• Can be used to model “virtual connections”

57.
STOMP
• Simple and human-readable like HTTP
• Extensible via headers
• Library and server support
• An easy WebSocket subprotocol
• Can be used to model “virtual connections”
• Transactions for multipart messages

58.
STOMP “Extensions”
1. Frames include socket type header
2. Header for “connect” or “bind” in SUBSCRIBE
3. Req-Rep messages use “reply-to” header
