+<br />-<br />HIGH  TENSION <br />GENERATOR<br />& <br />RECTIFICATION<br />SYSTEM  <br />1<br />MODERATOR<br />MR. S.C. B...
 INTRODUCTION:<br /><ul><li>An x-ray generator is a device that Supplies electrical power to x-ray tube.
It provides
high voltage between anode & cathode
filament voltage.
Controls exposure timing
Turns exposure on and off
High voltage switched on and off</li></ul>2<br />
Electricity & Current:   <br /><ul><li>Electricity is the flow of current.
Current is the flow of charge.
 It is measured in Amperes.
It is defined as the flow of 1C charge per unit time.</li></ul>		i.e.,        <br />			 I=Q/t<br />		where,<br />			I=curr...
Alternating Current<br /><ul><li>An  electric current in which amplitude and polarity of the current vary with time.
Its a sinusoidal wave which varies amplitude and periodic reversal of polarity.</li></ul>4<br />
Battery<br />DC<br />A<br />Switch<br />A<br />Time<br />Direct Current<br />	Electric current which flows in one directio...
What Is A.C Generator?<br /><ul><li>An electrical machine used to convert mechanical energy into electrical energy.
Construction:</li></ul>  1. Armature<br />  2. Strong field magnet<br />  3.Slip Rings<br />  4.Contact Brushes<br /><ul><...
EMINDUCTION<br /><ul><li>Changing magnetic field induces voltage in wire
Strength of magnetic field determines strength of induced voltage
Direction of magnetic field change determines the direction of electron flow
Process is reciprocal (B)
Magnitude of induced magnetic field α number of turns in coil</li></ul>7<br />
Three Ways To Create Motion Between Lines Of Force And A Conductor:<br /><ul><li>Move the conductor through magnetic  field
Move magnetic lines of force
Vary the magnetic flux
Faraday law regulate the strength of the induced current
Strength of the Magnet
Speed of the motion
Angle of the magnet
Number of turns on the conduction coil</li></ul>8<br />
Types Of Alternating Current<br />It is of two types<br />Single phase AC<br />Poly-phase AC<br /><ul><li>IN single phase ...
For 60Hz AC, pulse length = 1/120s = 8 ms
Tube current is nonlinear and drops off below 40 kV
Capacitors hold and release charge in a time delayed manner </li></ul>9<br />
In polyphase AC or three phase AC, 3 coils are made to rotate simultaneously by placing at equidistance from each other in...
Distribution Of Electricity<br />	The generated electricity is  distributed as follows:<br />	2 methods in which the windi...
STAR TYPE OR WYE TYPE CIRCUIT<br /><ul><li>Generally for each coil of three phase AC circuit two wires are required and in...
This type of method would result in a poor economy and great wastage. So alternative to this is by having 4 wires in place...
In this star connection coils L1, L2 and L3 are connected to a common point N known as neutral cable</li></ul>12<br />
Delta Type Configuration:<br /><ul><li>Another  configuration of the windings in the primary or secondary side of a three-...
Combinations of wye & delta configurations in the primary and secondary windings of a transformer will give rise to a phas...
Advantages & Disadvantages:<br /><ul><li>High x-ray output per Mass.Smaller range of x-ray energies.</li></ul>Adv. Of Wye ...
Less stress and liability to break down in regard to insulation.
Can supply two different voltage as per need of different types of user, e.g. single phase for domestic user and three pha...
High Tension Circuits<br /><ul><li>An x-ray equipment is just not directly connected to the source where electricity is ge...
Components of H.T. Circuit:</li></ul>		1.Transformer<br />			Step up transformer<br />			Step down transformer<br />			Aut...
TRANSFORMER<br /><ul><li>Definition: An electrical device that transforms the voltage of alternating current electricity f...
Principle : It is based on the principle of electromagnetic induction.</li></ul>16<br />
Types Of Transformer On The Basis Of Construction:<br />17<br />
Construction<br />Working:<br /> P. coil supplied with A.C.<br />As the current flows through it , a changing magnetic fie...
Law of transformers:<br /><ul><li> The voltage in the primary or secondary coil is directly Proportional to the number of ...
Efficiency Of Transformer<br /><ul><li>It is the ratio of output power in watts to the input power in watt expressed as %a...
Reason Behind This?<br />	The basic reason behind this is there is certain & small amount of definite energy losses which ...
<ul><li>Hysteresis losses: It is a heat loss caused by the magnetic properties of the core. When an core is in a magnetic ...
Copper Loss Due To Resistance:   <br /><ul><li>When current flows through a wire , the material of the wire offer resistan...
Types Of Transformer Used In X-ray Circuit:<br />In x-ray circuit , three type of transformer are used:<br />24<br /><ul><...
Step down transformer
Auto transformer</li></li></ul><li>Autotransformer<br /><ul><li>The autotransformer is designed to supply voltage of varyi...
It works on the principle of self induction .</li></ul>25<br />
contd.<br /><ul><li>Because there is only one winding, the primary and secondary circuits are in metallic (conductive) con...
In comparison with two-winding transformers, autotransformers are smaller in size, are economical of copper wire and cost ...
Diagram Of Autotransformer:<br />27<br />c<br />A<br />d<br />300V<br />450V<br />300V<br />2:2 TURN RATIO<br />2:2 TURN R...
Step Up Transformer Or High Tension Transformer:<br /><ul><li>Definition: Transformers that convert a low voltage into a h...
Step-up transformer
primary from autotransformer
secondary to rectifier circuit
mA monitored at center grounded point of secondary
Supplies high voltage for x-ray tube</li></ul>28<br />
<ul><li>Grounded metal box
filled with oil
 oil acts as electrical insulator
Function:
		Increases alternating voltage
		Also contains rectifier circuit
		changes alternating current into direct current</li></ul>Auto-<br />transformer<br />Rectifier<br />Circuit<br />mA<br /...
	Step Down Transformer<br /><ul><li>Also called filament transformer.
A step down transformer has less turns of wire on the secondary coil,which makes a smaller induced voltage in the secondar...
Placement : It is connected directly to the filament of x-ray tube.
Purpose: the filament of the x-ray tube needs to be heated up in order to emit the electrons (thermal electrons).
The Tube Current is controlled through a separate circuit called the filament circuit which is connected to filament trans...
Diagram of x-ray circuit showing filament transformer:<br />+<br />High Voltage Transformer<br />Rectifier Circuit<br />Ti...
RECTIFICATION<br /><ul><li>Process  by  which  alternating current is changed to pulsating  direct current
A device which converts AC into pulsating DC is called rectifier.
A rectifier can be valve type or vacuum type or it can be solid state/semiconductor/metallic type rectifier.
X-ray tube is a sort of valve type rectifier or diode rectifier as it has two electrodes and allows the current to flow in...
UNRECTIFIED A.C WAVE<br />NO RECTIFICATION<br />HALF-WAVE<br />FULL-WAVE<br />33<br />
Thermionic Diode Valves:<br /><ul><li>An evacuated tube with two electrodes in it is called a thermionic diode valve. Henc...
A glass envelope enclosing a vacuum.
Two electrodes within the glass envelope, one of which is a heated filament.
The filament of a valve is heated by a step down transformer and emits electrons which are drawn across to the anode when ...
Functioning of a Diode Valve:<br />			If the valve is connected in a complete circuit such that cathode is –ve with respec...
Solid State Rectifier<br />	As the name solid state implies, conduction takes place by electron travel through solid mater...
Bands Theory of Semiconductor:<br />37<br />electron<br />
Types Of Semiconductor <br /><ul><li>Pure semiconductor have little  conduction towards  electricity, so to enhance the co...
A/c to adding of impurities it is of two types:</li></ul>		1. P-Type semiconductor<br />		2. N-Type semiconductor<br />38<...
P-Type semiconductor:<br />	P-type semiconductor is obtained by adding a certain type of atoms to the semiconductor in ord...
