1. MySQL EXPLAIN Explained
Quick and Easy Query Optimisation
Adrian Hardy <talks@fuzzee.co.uk>

2. Before we begin...
What you need to know
How and why we add indexes to tables
●
The benefits of correct field typing
●
Understanding of the ideals of 3NF
●
Basic understanding of SQL JOINs
●
This presentation
Very quick introduction to EXPLAIN
●
Improve understanding of MySQL and indexing
●
Simplified examples / results
●

3. Introduction - Using MySQL EXPLAIN
Prefix a SELECT query with EXPLAIN
MySQL won't actually execute the query, just analyse it
●
EXPLAIN helps us understand how and when MySQL
●
will use indexes
EXPLAIN returns a table of data from which you identify
●
potential improvements
Optimise queries in three ways
●
Modify or create indexes
●
Modify query structure
●
Modify data structure
●
Optimised queries = faster results, lower server load...
●

4. Introduction - Review of Indexing
Fast, compact structure for identifying row locations
●
Keep indexes in memory by trimming the fat:
●
Can I reduce the characters in that VARCHAR index?
●
Can I use a TINYINT instead of a BIGINT?
●
Can I use an INTEGER to describe a status or flag (rather
●
than a textual description)?
Chop down your result set as quickly as possible
●
MySQL will only use one index per query/table – it cannot
●
combine two separate indexes to make a useful one *
Understanding and preparation brings about Indexing Strategy
* Not strictly true - look up “Index Merge” operations

5. Booking application schema
attendees
attendee_id surname conference_id registration_status
INTEGER (PK) VARCHAR INTEGER (FK) TINYINT
conferences
conference_id location_id topic_id date
INTEGER (PK) INTEGER (FK) INTEGER (FK) DATE

6. EXPLAIN – Worked Example
EXPLAIN SELECT * FROM attendees WHERE
conference_id = 123 AND registration_status > 0
table possible_keys key rows
attendees NULL NULL 14052
The three most important columns returned by EXPLAIN
1)Possible keys
All the possible indexes which MySQL could have used
●
Based on a series of very quick lookups and
●
calculations
2)Chosen key
3)Rows scanned
Indication of effort required to identify your result set
●

7. EXPLAIN – Worked Example
EXPLAIN SELECT * FROM attendees WHERE
conference_id = 123 AND registration_status > 0
table possible_keys key rows
attendees NULL NULL 14052
Interpreting the results
No suitable indexes for this query
●
MySQL had to do a full table scan
●
Full table scans are almost always the slowest query
●
Full table scans, while not always bad, are usually an
●
indication that an index is required

8. EXPLAIN – Worked Example
ALTER TABLE ADD INDEX conf (conference_id);
ALTER TABLE ADD INDEX reg (registration_status);
EXPLAIN SELECT * FROM attendees WHERE conference_id
= 123 AND registration_status > 1;
table possible_keys key rows
attendees conf, reg conf 331
MySQL had two indexes to choose from, but discarded “reg”
●
“reg” isn't sufficiently unique
●
The spread of values can also be a factor (e.g when 99% of
●
rows contain the same value)
Index “uniqueness” is called cardinality
●
There is scope for some performance increase...
●
Lower server load, quicker response
●

9. EXPLAIN – Worked Example
ALTER TABLE ADD INDEX reg_conf_index
(registration_status, conference_id);
EXPLAIN SELECT * FROM attendees WHERE conference_id =
123 AND registration_status > 1;
table possible_keys key rows
reg, conf,
attendees reg_conf_index 204
reg_conf_index
reg_conf_index is a much better choice
●
Note that the other two keys are still available, just
●
not as effective
Our query is now served well by the new index
●

10. EXPLAIN – Worked Example
DELETE INDEX conf; DELETE INDEX reg;
EXPLAIN SELECT * FROM attendees WHERE conference_id = 123
table possible_keys key rows
attendees NULL NULL 14052
Without the “conf” index, we're back to square one
●
The order in which fields were defined in a composite index
●
affects whether it is available for use in a query
● Remember, we defined our index : (registration_status,
conference_id)
Potential workaround:
EXPLAIN SELECT * FROM attendees WHERE conference_id = 123
AND registration_status >= -1
table possible_keys key rows
attendees reg_conf_index reg_conf_index 204

11. EXPLAIN – Example 2
EXPLAIN SELECT * FROM attendees WHERE surname LIKE 'har%';
table possible_keys key rows
attendees surname surname 234
MySQL uses an index on surname – which is good.
EXPLAIN SELECT * FROM attendees WHERE surname LIKE '%har%';
table possible_keys key rows
attendees NULL NULL 14052
MySQL doesn't even try to use an index!

12. EXPLAIN – Example 3
EXPLAIN SELECT * FROM conferences WHERE location_id = 2 OR
topic_id IN (4,6,1)
table possible_keys key rows
location_id,
conferences NULL 5043
topic_id
MySQL doesn't use an index, because of the OR
ALTER TABLE ADD INDEX location_topic (location_id,
topic_id);
EXPLAIN SELECT * FROM conferences WHERE location_id = 2
OR topic_id IN (4,6,1)
table possible_keys key rows
location_id,
conferences location_topic 15
topic_id,
location_topic
Full table scan avoided – could also use UNION (ALL) trick

13. EXPLAIN – Example 4
EXPLAIN SELECT * FROM attendees WHERE MD5(conference_id) =
MD5(123)
table possible_keys key rows
attendees NULL NULL 14052
Understandably, MySQL has to do a full table scan
A more realistic example?
EXPLAIN SELECT * FROM conferences WHERE
DATE_FORMAT(date,'%a') = 'Sat'
table possible_keys key rows
conferences NULL NULL 5043
A good candidate for Optimisation #3 – Modify Data Structure

14. JOINs
JOINing together large data sets (>= 100,000) is really
●
where EXPLAIN becomes useful
Each JOIN in a query gets its own row in EXPLAIN
●
Make sure each JOIN condition is FAST
●
Make sure each joined table is getting to its result set
●
as quickly as possible
● The benefits compound if each join requires less
effort

15. JOINs – Simple Example
EXPLAIN SELECT * FROM
conferences INNER JOIN attendees USING (conference_id)
WHERE conferences.location_id = 2 AND
conferences.topic_id IN (4,6,1) AND
attendees.registration_status > 1
table type possible_keys key rows
conferences ref conference_topic conference_topic 15
attendees ALL NULL NULL 14052
Looks like I need an index on attendees.conference_id
There are 13 different values for “type”
● Another indication of effort, aside from rows scanned
● Here, “ALL” is bad – we should be aiming for “ref”
● Common values are “const”, “ref”, and “all”
● http://dev.mysql.com/doc/refman/5.0/en/using-explain.html

16. The “extra” column
With every EXPLAIN, you get an “extra” column, which
shows additional operations invoked to get your result set.
table possible_keys key rows extra
Using where
attendees conf conf 331
Using filesort
Some example “extra” values:
Using where
●
Using temporary table
●
Using filesort
●
Using index
●
There are many more “extra” values which are discussed in
the MySQL manual.

17. “Using filesort”
Avoid, because:
● Doesn't use an index
● Involves a full scan of your result set
● Employs a generic (i.e. one size fits all)
algorithm
● Uses the filesystem (eeek)
● Will get slower with more data
It's not all bad...
Perfectly acceptable provided you get to your
●
result set as quickly as possible, and keep it
predictably small
Sometimes unavoidable - ORDER BY RAND()
●
ORDER BY operations can use indexes to do the
●
sorting!

18. “Using filesort” – Example
EXPLAIN SELECT * FROM attendees WHERE conference_id = 123
ORDER BY surname
table possible_keys key rows Extra
attendees conference_id conference_id 331 Using filesort
MySQL is using an index, but it's sorting the results slowly
ALTER TABLE attendees ADD INDEX conf_surname (conference_id,
surname);
EXPLAIN SELECT * FROM attendees WHERE conference_id = 123
ORDER BY surname
table possible_keys key rows Extra
conference_id,
attendees conf_surname 331
conf_surname
We've avoided a filesort

19. “Using index”
Celebrate, because:
MySQL got your results just by consulting the index,
●
● Which could well have been sat in memory
●MySQL didn't need to even look at the table to get you your
results
● Opening a table can be an expensive operation.
●MySQL can answer the next query more quickly
●The fastest way for you to get your data?
Particularly useful...
When you're just interested in a single date or an id
●
●Or the COUNT(), SUM(), AVG() etc. of a field

20. “Using index” – Example
EXPLAIN SELECT AVG(age) FROM attendees WHERE conference_id
= 123
table possible_keys key rows Extra
attendees conference_id conference_id 331
Nothing is actually wrong with this query – it could just be quicker!
ALTER TABLE attendees ADD INDEX conf_age (conference_id,
age);
EXPLAIN SELECT AVG(age) FROM attendees WHERE conference_id
= 123
table possible_keys key rows Extra
conference_id,
attendees conf_surname 331 Using index
conf_surname
Outside of caching, the fastest way to get your data *
*Not a guarantee

21. Moving forward...
Just because your queries are fast now, doesn't mean that they will stay
that way forever
Enable MySQL's Slow Query Log
● --log-slow-queries=/var/lib/mysql/slow-query.log
● Defaults to logging queries which take more than 10 seconds
● --long_query_time=1
● Use Percona's “microslow” patch for values < 1 second
● Find the query in the log, EXPLAIN it, improve it, rinse and repeat

22. Moving forward...
Use the command line to identify more general problems
● mysqladmin -u dbuser -p -r -i 10 extended-status
● Figures are relative, updated every 10 seconds
● Slow_queries = number of slow queries in last period
● Select_Scan = full table scans
● Select_full_join = full scans to complete join operations
● Created_tmp_disk_tables = filesorts
● Key_read_requests/Key_write_requests
● Determine write/read weighting of our application and alter your
indexes accordingly

23. MySQL Resources
http://dev.mysql.com/doc/refman/5.0/en/using-explain.html
●
High Performance MySQL - Baron Schwartz
●
ISBN 0596101716
–
£20 (Money well spent)
–
http://www.mysqlperformanceblog.com
●
Regular posts
–
