Things to be aware of when you are measuring the performance of your web sites (both synthetic testing and Real User Monitoring).

Related Books

Free with a 30 day trial from Scribd

See all

Measuring web performance

  1. 1. Measuring Web Performance Patrick Meenan pmeenan@webpagetest.org @patmeenan
  2. 2. Types of Measurement velocityconf.com/velocity2011/public/schedule/detail/18039
  3. 3. Measuring Web Performance SYNTHETIC TESTING
  4. 4. Active Testing • Consistent results – Good for detecting and diagnosing issues that are 100% repeatable and on pages you are monitoring • Lots of detail • Availability monitoring • Not representative of actual end-user performance – Usually tested from data centers – Sometimes co-located with CDN provider equipment
  5. 5. Bandwidth/Latency Impact (Fixed 60ms RTT) (Fixed 5Mbps Bandwidth) 5 www.belshe.com/2010/05/24/more-bandwidth-doesnt-matter-much/
  6. 6. US Broadband Latency WebPagetest DSL WebPagetest Cable WebPagetest FIOS Backbone 6 www.fcc.gov/document/measuring-broadband-america-report-consumer-broadband-performance-us
  7. 7. Actual Users Backbone Testing 7
  8. 8. DSL – Back-End: 17% Backbone – Back-End: 52% 8
  9. 9. Mac Traffic Shaping OS X Lion + Xcode 4.1 Cable, DSL, 3G, Edge, WiFi and Custom GUI for dummynet (which has been available for a while) osxdaily.com/2011/08/10/simulate-internet-connectivity-bandwidth-speeds-network-link-conditioner/
  10. 10. Synthetic Browsers • Know HOW your active testing is done – Some only test the base page – Synthetic browsers usually not reflective of real browser – Real browser testing – Connectivity (backbone, last-mile) • www.engadget.com – Synthetic Browser: 447 requests – IE 8: 241 requests
  11. 11. Measuring Web Performance REAL USER MONITORING (RUM)
  12. 12. Real User Monitoring (RUM) • Full coverage on all pages visited by users • Real performance information for end-user experience • No availability monitoring • No competitive reference • Limited detail – … but getting better
  13. 13. Navigation Timing window.performance.timing IE 9+ Chrome Firefox 9+ Android 4+ Front-End Back-End 13 dvcs.w3.org/hg/webperf/raw-file/tip/specs/NavigationTiming/Overview.html
  14. 14. Resource Timing (draft) Timing for every network-loaded resource w3c-test.org/webperf/specs/ResourceTiming/
  15. 15. Back-End Only
  16. 16. Access Logs • Overall Response Times - %D (Apache) • Custom variables (app-specific timings) • Logster + graphite = graphs • Lots of data-mining opportunities – Broken links/content (404’s with useful referer information) • Mike Brittain (Etsy) Presentation – http://www.slideshare.net/mikebrittain/web-performance-culture- and-tools-at-etsy-11159635
  17. 17. Measuring Web Performance THE METRICS
  18. 18. When is “Done”? Easy answer is onLoad But…
  19. 19. When is “Done”? Twitter onLoad (2.4s) Twitter end of activity (8.2s)
  20. 20. 2 Pages, Identical Performance …
  21. 21. http://youtu.be/Ipk1k_IobYg
  22. 22. Start Render Identical
  23. 23. Load Time Identical
  24. 24. Last Visual Change Identical
  25. 25. Visual “Completeness”
  26. 26. Measuring Web Performance INTRODUCING…
  27. 27. The Speed Index The user experience of A was 7.4 times faster than B sites.google.com/a/webpagetest.org/docs/using-webpagetest/metrics/speed-index
  28. 28. Amazon.com vs. Twitter …
  29. 29. Amazon vs. Twitter Amazon Twitter Speed Index 1501 6014 (+300%) onload 2.4 2.4 Fully Loaded 6.4 8.2 (+28%) www.webpagetest.org/video/view.php?id=120414_22f2206da973b41621c499e2be01d555cdac6ab0&bare=1
  30. 30. Measuring Web Performance WHAT’S NEW IN WEBPAGETEST
  31. 31. New Waterfall UI Nav Timing – domContentLoaded (Firefox/Chrome) Nav Timing – load event (Firefox/Chrome) Pop-up request details
  32. 32. Dependencies (Chrome) Line of code that Triggered request
  33. 33. Response Bodies
  34. 34. Dev Tools Timeline (Chrome)
  35. 35. Dev Tools Timeline (Chrome)
  36. 36. Creating Videos
  37. 37. Creating Videos (cont) Customize: - End Point/Times - Specific Run - First/Repeat View - Labels www.webpagetest.org/video/compare.php?tests=120416_QX_3ZKFP%2C120416_DR_3ZKFJ&bare=1
  38. 38. SPOF Demonstrating www.webpagetest.org/video/view.php?id=120416_d635d742a17d7eecf57df6282bcea87f5de2322c&bare=1
  39. 39. Custom viewport size Chrome/Firefox
  40. 40. EC2 AMIs IE 7 m1.small or IE 8 c1.medium IE 9, Chrome, Firefox (single image)
  41. 41. News/Updates • Twitter: @patmeenan • Google+ PatMeenan@gmail.com WebPagetest • WebPagetest Forums http://www.webpagetest.org/forums/
