Partner Webcast – Oracle NoSQL key-value database

1. Stay Connected BLOGS.ORACLE.COM/IMC TWITTER.COM/ORACLEIMC YOUTUBE.COM/ORACLEIMCTEAM FACEBOOK.COM/ORACLEIMC

3. Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | Agenda A bit of history and what is NoSQL Data Model Architecture Consistency When to use Community Edition vs Enterprise Edition What’s new in release 3.0

4. Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | Reasons for creating NoSQL technology The appearance in the early 2000s: •Google - web search engine •Facebook – social network •Amazon - online retailer Common features of these systems: •Constantly changing structure •Unpredictable data growth •A huge number of users

5. Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | What is NoSQL? NoSQL = Not only SQL. Do not have a structured scheme -Frequently the data is stored in the scheme of key-value -The structure of the database schema is created by the application Allow almost infinite horizontal scale -The data is stored in the copies on different servers -Node failure does not result in data loss -Reading is done from the master or a copies Working with data through a simple operations (no SQL) -CREATE -RETRIEVE -UPDATE -DELETE

7. Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | Oracle NoSQL Database Horizontally Scaled, Key-Value Database for Web Services and Cloud •Simple Data model Based on Key-value scheme with two parts key – major + minor Simple operations read/insert/update/delete •Scalability Optimized data access Smart division and distribution of data •High Availability & No-Single Point of Failure single-master, multi-replica database replication automated fail-over election •Transparent Load Balancing Read from master or/and replicas Network topology and latency-aware Storage Nodes Data Center A Storage Nodes Data Center B Application NoSQL DB Driver Application NoSQL DB Driver

8. Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | Key – Value pair Oracle NoSQL Database hashes keys to provide good distribution over a collection of computers that provide storage for the database. A key is the concatenation of a Major Key Path and a Minor Key Path, both of which are specified by the application. A minor component does not affect the distribution and can be empty. Key

9. Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | Key – Value pair Oracle NoSQL Database stores value as byte array. Mapping of the byte arrays to data structures is done by application. There are no restrictions on the size or structure of the value field. Value

10. Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | Logical representation of Oracle NoSQL Database Key Value Key 1 Value 1 Key 2 Value 2 Key 3 Value 3 Key 4 Value 4 Key 5 Value 5 Key 6 Value 6 Index Key 1 – Value 1 Key 5 – Value 5 Key 4 – Value 4 Key 2 – Value 2 Key 3 – Value 3 Key 6 – Value 6

11. Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | Physical representation of Oracle NoSQL Database Key 1 – Value 1 Key 5 – Value 5 Key 4 – Value 4 Key 2 – Value 2 Key 3 – Value 3 Key 6 – Value 6 server rack 1 server rack 2 Key 1 – Value 1 Key 1 – Value 1 Key 4 – Value 4 Key 4 – Value 4 Key 2 – Value 2 Key 2 – Value 2 Key 5 – Value 5 Key 5 – Value 5 Key 3 – Value 3 Key 3 – Value 3 Key 6 – Value 6 Key 6 – Value 6

12. Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | Physical representation of Oracle NoSQL Database server rack 1 server rack 2 Key 1 – Value 1 Key 1 – Value 1 Key 4 – Value 4 Key 4 – Value 4 Key 2 – Value 2 Key 2 – Value 2 Key 5 – Value 5 Key 5 – Value 5 Key 3 – Value 3 Key 3 – Value 3 Key 6 – Value 6 Key 6 – Value 6

13. Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | server rack 1 server rack 2 Key 1 – Value 1 Key 1 – Value 1 Key 4 – Value 4 Key 4 – Value 4 Key 2 – Value 2 Key 2 – Value 2 Key 5 – Value 5 Key 5 – Value 5 Key 3 – Value 3 Key 3 – Value 3 Key 6 – Value 6 Key 6 – Value 6 Storage architecture Shard 1 (Replication Group 1) Shard 2 (Replication Group 2) Shard 3 (Replication Group 3) Master Master Master Slave Slave Slave

14. Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | Storage architecture Key 1 – Value 1 Key 4 – Value 4 Oracle NoSQL Database Storage Node Key 1 – Value 1 Key 1 – Value 1 Key 4 – Value 4 Key 4 – Value 4 Key 2 – Value 2 Key 2 – Value 2 Key 5 – Value 5 Key 5 – Value 5 Key 3 – Value 3 Key 3 – Value 3 Key 6 – Value 6 Key 6 – Value 6 Master Master Master Slave Slave Slave

17. Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | Consistency of data BASE Basically Available Soft state Eventual consistency ACID Atomicity Atomicity requires that each transaction is "all or nothing": if one part of the transaction fails, the entire transaction fails, and the database state is left unchanged. Consistency The consistency property ensures that any transaction will bring the database from one valid state to another. Isolation The isolation property ensures that the concurrent execution of transactions results in a system state that would be obtained if transactions were executed serially, i.e. one after the other. Durability Durability means that once a transaction has been committed, it will remain so, even in the event of power loss, crashes, or errors.

18. Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | Consistency of data Oracle NoSQL Database – ACID or BASE system? Can be configured for the whole system and for a particular operation!

19. Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | In which case you should use Oracle NoSQL Database?  Terabytes or petabytes of data  The application should not have a single point of failure  The use of multiple low-cost servers  Short response time of simple queries  Unstructured or semi-structured data model

20. Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | Potential systems for Oracle NoSQL Database  LDAP like systems Why? It’s fast! User personalization Why? No clear data model and constant addition of new features! Collection of different types of data from the sensors Why? A lot of concurrent sessions! Logging of Internet traffic (CDR GPRS, web logs) Why? Huge amount of data! File storage (like Dropbox, Google disk) Why? Cheap store of large amounts of unstructured data!

21. Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | Oracle NoSQL Database Community VS Enterprise Edition Oracle NoSQL Database Community Edition. Open Source. GPLv2 or AGPL license. Oracle NoSQL Database Enterprise Edition. Closed Source. Standard Oracle License. List price: $10K/CPU.

22. Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | Oracle NoSQL Database benefits Community Edition 1.Java and C APIs 2.Store billions of records and multi-terabytes of data 3.No-Single Point of failure 4.Designed to scale out to thousands of nodes 5.Streaming Large Object Support 6.Easy online administration 7.Online rolling upgrade 8.Efficient Multi-Zone support 9.Integrated with Apache Hadoop

23. Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | Oracle NoSQL Database Enterprise Edition includes all features available in Community Edition, plus these additional features: Simple Network Management Protocol (SNMP) adapter for monitoring Oracle Database Integration via External Tables: Access data through SQL queries Integration with Oracle Event Processing (OEP) engine using NoSQL database cartridge: Access data through CQL queries Integration with Oracle Coherence to permit Oracle NoSQL Database to be used as a cache for Oracle Coherence applications and to allow applications to directly access cached data from Oracle NoSQL Database. A Java-based interface to store and query semantic data through support for the Resource Description Framework (RDF), SPARQL query language, and a subset of the Web Ontology Language (OWL) are now supported. Enterprise Grade Support (24x7) for Enterprise Edition (EE). Oracle NoSQL Database benefits Enterprise Edition

24. Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | Table data model support –Simplifies data modeling & leverages existing “table” expertise Secondary indexing –Allow indexing on any component of the record –Huge performance benefit due to parallel, indexed data access Data centers –Metro-area zones for disaster recovery and business continuity –Secondary zones for read-only workloads Security –Authentication and network-level encryption Oracle NoSQL DB Release 3.0

25. Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | Lower barrier to adoption, shorter time to market Simplified application modeling –Uses familiar table concepts –Introduces strongly typed fields –Easy to/from JSON with full type support and AVRO serialization –Allows secondary indexing of non-key data Sets foundation for SQL query access from Oracle DB Previous Key/Value and JSON schema APIs still supported Oracle NoSQL DB Release 3.0 Table model benefits

26. Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | Oracle NoSQL DB Release 3.0 Secondary Index support Broader low latency use case support –Primary and Secondary Indexes –Indexes automatically maintained –Provides sorted results Low resource cost with high performance –Low cardinality matching, guaranteed consistent –Shard-local indexing, low latency record access –B-trees locally ordered, scanned in parallel, merged result set –Improved index cache eviction

27. Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | Oracle NoSQL DB Release 3.0 Secondary Index Get() API specifies index Equality or range searches Low order multi-value indexes –Composite index on values –Parallel Index ScanA –Ordered results –Indexable single element arrays  Equality search on lname + fname  Equality search on lname and range on fname  Range or Equality search on lname by itself  Can’t search on just fname Index on (lname, fname) UserId fname lname email Table Users

28. Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | Oracle NoSQL DB Release 3.0 Zones Metro-Local Quorum –Low latency writes, HA 2nd’ary Read-Only Zones –Analytic workloads –Report generation –Asynchronous replication New Read Consistency: No Master Topology Aware Client Driver Provides business continuity and distributed workload management DC1 DC2 DC3 Metropolitan Zones Reports Batch Analytics

29. Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | Oracle NoSQL DB Release 3.0 Security Overview Protected Access to Data –Enforcement is configurable Authentication –OS independent, password based user access –Internal cluster components self authenticate (HA password distribution) –Oracle Wallet integrated –Admin utility to generate self-signed certificates Wire level data encryption –All client-server, server-server channels SSL encrypted

30. Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | •Free test of Oracle NoSQL database is available here: http://www.oracle.com/technetwork/database/database- technologies/nosqldb/overview/index.html •Try Oracle Big Data Lite Virtual Machine: http://www.oracle.com/technetwork/database/bigdata-appliance/oracle- bigdatalite-2104726.html 32 Try it yourself!

31. Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | Q&A 33 Andrey Rivkin FORS Distribution Big Data Specialist Andre.Rivkin@fors.ru ISV Migration Center blog: http://blogs.oracle.com/imc ISV Migration Center email: partner.imc@beehiveonline.oracle.com

32. Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | •Oracle.com Partner Hub oracle.com/partners/goto/hub-ecemea •Migration Center Team Blog blogs.oracle.com/imc feeds.feedburner.com/oracleIMC •Partner Webcast Recordings youtube.com/OracleIMCteam •Partner Webcast Presentations slideshare.net:/Oracle_IMC_team •Partner.IMC@beehiveonline.oracle.com Oracle Partner Hub ISV Migration Center •twitter.com/OracleIMC •plus.google.com/+OracleIMC •facebook.com/OracleIMC •linkedin.com/groups/Oracle-Partner-Hub-Migration- Center-4535240
