As I was ﬁlling up my car with gas, I
began taking pictures of the signage and
messages on the pump with my phone. As
I began to look a them closer, I realized
there was a lot to see on a gas pump, some
of which ties to Lean. I have attempted to
label and describe what I saw and draw a
few lessons. Take a look and enjoy. I
would be pleased to learn of applications
you see that I have missed.
13. Identiﬁcation Label
1. Safety Warnings
2. Cost Display 14. Pump Number
3. Late Differentiated Inspection label
15. Mistake Mitigation Label
4. Unit Display
5. Interaction Display 16. Visual Standard Work
6. Call Button
7. Direction 17. Direction
8. Preventive Warning
9. Color coded Key pad
10. Customized Directions
11. Visual Standard Work 21. Labeled Buttons
22. Visual Cue (Colored)
12. Safety Guidelines
23. Mistake Mitigation Nozzle
24. Safety Warnings
Visual Guide to a Gas Pump
Lean Lessons of the Pump
• Too much signage can reduce its
• Visual Standard Work is a good way to
get a message across
• Colors can be used for Visual Effect
• We can always try to mistake proof
• We can use tools in combination to
• There are Lean aspects around us if we
will look for them
• 1, 8, 12, 13, & 23-Safety Guidelines/
Warnings-We would expect such to be
posted based on regulatory
requirements. I was surprised by how
many there were.
• 2, 4, & 19-Measurement Displays-
Theses tell us how much. They
become more important if we are
limited by budget or ﬁlling capacity
(think 2 gallon small can).
• 3-Inspection Label-This does a couple
of things: one, records the last time
the Government inspected the
accuracy of the Pump, and two, serves
as a visual that it has been inspected.
I like that it allows late differentiation.
The month of the inspection punched
so the same labels can be used for a
• 5-Interactive Display-Allows question
• 6-Call Button-Allows user to ask for
help or report an issue. Visual green
• 7, 10, 17, & 20-Directions-Word
driven items to be done at the pump.
10 is a Kaizen to help the ﬂow of the
• 9 & 22 Color Coding- The key pad has
visually coded buttons using green,
red, blue, and gray. Grade selection is
yellow to stand out verses the black.
• 11 & 16-Visual Standard Work-11
Shows how to work the pump. It is
large and easy to follow. It helps to
make sure that someone new to this
style pump can use it without issue.
16 Shows how to swipe a card in the
card reader. Both are good examples
of simple and effect standard work.
• 14, 18, 19, & 21-Labels-Help us
• 15 & 23-Mistake Mitigation-15
Attempts to reduce non payment and
23 the nozzle is a different size than
the diesel nozzle so that diesel cannot
be put in the unleaded tank.
• All pictures taken by Tom Curtis May 2010
• Blog: www.onimproving.blogspot.com
• Other Presentations: Onimproving on
