Apps de consumo de APIs de Internet para mobile phones

1,252 views

Published on

Web Apps é um modo fácil e rápido de se construir aplicações para Série 40, entretanto existe o desafio de fazer uma App consumir APIs de Internet. Este webinar tem como objetivo mostrar métodos e boas práticas de consumo de APIs de Internet para a Web Apps Série 40.

Published in: Technology, Business

Apps de consumo de APIs de Internet para mobile phones

  1. 1. ECOSYSTEM1
  2. 2. Interação Nokia Developer http://www.developer.nokia.com Twitter: @nokiadev_brasil Grupo Devs S40 no Nokia Developer http://www.developer.nokia.com/Co mmunity/Discussion/group.php?grou pid=1142
  3. 3. Apps de consumo deAPIs de Internet paramobile phonesRaymundo JuniorDesenvolvedor – INdTEvangelista Nokia de Tecnologia3
  4. 4. Conteúdo• Device S40• Estrutura do Projeto• Main• Template• Lib• Service• JSON Viewer• View1• View2• View3• Estudo de Caso 4
  5. 5. Device S40Nokia Developer• http://www.developer.nokia.com/Devices/Device_sp ecifications/?filter1=s405
  6. 6. Estrutura do Projeto6
  7. 7. Mainvar main = {init : function(){view1.init();}};7
  8. 8. Templatevar template = {item_view1 : <div class="item-view1"onclick="mwl.switchClass(#content,view*,view2);view2.init({ID});">{TEXT}</div>,item_view2 : <divonclick="mwl.switchClass(#content,view*,view3);view3.init({ID});">{TEXT}</div>,item_view3 : <div>{TEXT}</div>};8
  9. 9. Libvar lib = {call: function(url, successCallback, errorCallback){var request = new XMLHttpRequest();try {request.open("GET", url, true);request.onreadystatechange = function(){if (request.readyState == 4) {if (request.status == 200) {successCallback(eval(( + request.responseText + )));} else {errorCallback("error status: " + request.status);}}};request.send(null);} catch (e) {errorCallback("error try: " + e);}}}; 9
  10. 10. Servicevar BASE_URL = http://justkaws.com/json/;10
  11. 11. Servicevar URLS = {plataformas : index.php?opcao=plataformas,devices : index.php?opcao=devices&id={ID},device : index.php?opcao=device&id={ID}};11
  12. 12. ServicegetView2 : function(id, success, error) {var url = service.getUrl(devices).replace("{ID}",id);lib.call(url, success, error);},getView3 : function(id, success, error) {var url = service.getUrl(device).replace("{ID}", id);lib.call(url, success, error);}12
  13. 13. Servicevar BASE_URL = http://justkaws.com/json/;var URLS = {plataformas : index.php?opcao=plataformas,devices : index.php?opcao=devices&id={ID},device : index.php?opcao=device&id={ID}};var service = { getUrl: function(id) { return BASE_URL + URLS[id]; }, getView1 : function(success, error) { var url = service.getUrl(plataformas); lib.call(url, success, error);},getView2 : function(id, success, error) {var url = service.getUrl(devices).replace("{ID}", id);lib.call(url, success, error);},getView3 : function(id, success, error) {var url = service.getUrl(device).replace("{ID}", id);lib.call(url, success, error);}}; 13
  14. 14. JSON Viewer LINK: http://jsonviewer.stack.hu/14
  15. 15. JSON Viewer LINK: http://jsonviewer.stack.hu/15
  16. 16. View1init : function(){document.getElementById(title-view1).innerHTML ="Plataformas NOKIA";service.getView1(function(data){view1.render(data);},function(data){document.getElementById(view-content1).innerHTML =data;});},16
  17. 17. View1render : function(data){var dados = data.json;var limit = dados.length; var itemTemplate = template.item_view1; var itens = "";for (var x = 0; x< limit; x++){var params = dados[x].platform + [!{#?#?#}!] + dados[x].id;itens += itemTemplate.replace("{TEXT}",dados[x].platform).replace("{ID}", params);}document.getElementById(view-content1).innerHTML = itens;}17
  18. 18. View1var view1 = {init : function(){document.getElementById(title-view1).innerHTML = "Plataformas NOKIA";service.getView1(function(data){view1.render(data);},function(data){document.getElementById(view-content1).innerHTML = data;});},render : function(data){var dados = data.json;var limit = dados.length; var itemTemplate = template.item_view1; var itens = "";for (var x = 0; x< limit; x++){var params = dados[x].platform + [!{#?#?#}!] + dados[x].id;itens += itemTemplate.replace("{TEXT}", dados[x].platform).replace("{ID}", params);}document.getElementById(view-content1).innerHTML = itens;}}; 18
  19. 19. View2init : function(args){var vetor = args.split([!{#?#?#}!]);document.getElementById(title-view2).innerHTML = vetor[0];service.getView2( vetor[1],function(data){view2.render(data);},function(data){document.getElementById(view-content2).innerHTML = data;});}, 19
  20. 20. View2render : function(data){var dados = data.json;var limit = dados.length;var itemTemplate = template.item_view2;var itens = "";for (var x = 0; x< limit; x++){var params = dados[x].name + [!{#?#?#}!] + dados[x].id;itens += itemTemplate.replace("{TEXT}",dados[x].name).replace("{ID}", params);}document.getElementById(view-content2).innerHTML = itens;}20
  21. 21. View2var view2 = {init : function(args){var vetor = args.split([!{#?#?#}!]);document.getElementById(title-view2).innerHTML = vetor[0];service.getView2( vetor[1],function(data){view2.render(data);},function(data){document.getElementById(view-content2).innerHTML = data;});},render : function(data){var dados = data.json;var limit = dados.length;var itemTemplate = template.item_view2;var itens = "";for (var x = 0; x< limit; x++){var params = dados[x].name + [!{#?#?#}!] + dados[x].id;itens += itemTemplate.replace("{TEXT}", dados[x].name).replace("{ID}", params);}document.getElementById(view-content2).innerHTML = itens;}}; 21
  22. 22. View3init : function(args){var vetor = args.split([!{#?#?#}!]);document.getElementById(title-view3).innerHTML = vetor[0];service.getView3( vetor[1],function(data){view3.render(data);},function(data){document.getElementById(view-content3).innerHTML = data;});}, 22
  23. 23. View3render : function(data){var dados = data.json;var limit = dados.length;var itemTemplate = template.item_view3;var itens = "";for (var x = 0; x< limit; x++){itens += itemTemplate.replace("{TEXT}", dados[x].label + ": "+ dados[x].value);}document.getElementById(view-content3).innerHTML =itens;}23
  24. 24. View3var view3 = {init : function(args){var vetor = args.split([!{#?#?#}!]);document.getElementById(title-view3).innerHTML = vetor[0];service.getView3( vetor[1],function(data){view3.render(data);},function(data){document.getElementById(view-content3).innerHTML = data;});},render : function(data){var dados = data.json;var limit = dados.length;var itemTemplate = template.item_view3;var itens = "";for (var x = 0; x< limit; x++){itens += itemTemplate.replace("{TEXT}", dados[x].label + ": " + dados[x].value);}document.getElementById(view-content3).innerHTML = itens;}}; 24
  25. 25. Estudo de Caso25
  26. 26. Obrigado!Raymundo JuniorDesenvolvedor – INdTEvangelista de TecnologiaE-mail: raymundo.ferreira-junior@indt.org.brTwitter: twitter.com/justkawsSite: justkaws.comBlog: blog.justkaws.com26

×
