  1. 1. XHTML Review Part 2 Instructor: Nancy Lee
  2. 2. Course Objectives <ul><li>To be able to create tables with rows and columns of data. </li></ul><ul><li>To be able to control table formatting </li></ul><ul><li>To be able to create and use forms </li></ul><ul><li>To be able to create and use image maps to aid in Web-page navigation </li></ul><ul><li>To be able to make Web pages accessible to search engines using <meta> tags </li></ul><ul><li>To be able to use the frameset element to display multiple Web pages in a single browser window. </li></ul>
  3. 3. Introduction <ul><li>Using tables to present information on web page </li></ul><ul><li>Forms to gather data </li></ul>
  4. 4. Basic XHTML Tables <ul><li>Used to organize data into rows and columns </li></ul><ul><li>table1.html </li></ul><ul><li>element <table> </table> </li></ul><ul><ul><li>defines a table </li></ul></ul><ul><ul><li>attributes </li></ul></ul><ul><ul><ul><li>border </li></ul></ul></ul><ul><ul><ul><ul><li>no border= “0” </li></ul></ul></ul></ul><ul><ul><ul><li>width </li></ul></ul></ul><ul><ul><ul><li>summary </li></ul></ul></ul><ul><ul><ul><ul><li>used by speech synthesizers </li></ul></ul></ul></ul>
  5. 5. Basic XHTML Tables <ul><li>element <caption> </caption> </li></ul><ul><ul><li>accessibility element in XHTML </li></ul></ul><ul><ul><li>describes table contents </li></ul></ul>
  6. 6. Basic XHTML Tables <ul><li>Table has three parts </li></ul><ul><ul><li>Head </li></ul></ul><ul><ul><li>Body </li></ul></ul><ul><ul><li>foot </li></ul></ul>
  7. 7. Basic XHTML Tables <ul><li>Table has three parts </li></ul><ul><ul><li>head </li></ul></ul><ul><ul><ul><li>column names </li></ul></ul></ul><ul><ul><ul><li><thead> </thead> element </li></ul></ul></ul><ul><ul><ul><li><tr></tr> element </li></ul></ul></ul><ul><ul><ul><ul><li>Defines rows </li></ul></ul></ul></ul><ul><ul><ul><li><th></th> </li></ul></ul></ul><ul><ul><ul><ul><li>Defines header column </li></ul></ul></ul></ul>
  8. 8. Basic XHTML Tables <ul><li>Table has three parts </li></ul><ul><ul><li>head </li></ul></ul><ul><ul><li>body </li></ul></ul><ul><ul><ul><li><tbody> </tbody> element </li></ul></ul></ul><ul><ul><ul><li><tr></tr> </li></ul></ul></ul><ul><ul><ul><ul><li>Rows </li></ul></ul></ul></ul><ul><ul><ul><li><td> </td> </li></ul></ul></ul><ul><ul><ul><ul><li>columns </li></ul></ul></ul></ul>
  9. 9. Basic XHTML Tables <ul><li>Table has three parts </li></ul><ul><ul><li>head </li></ul></ul><ul><ul><li>body </li></ul></ul><ul><ul><li>foot </li></ul></ul><ul><ul><ul><li>Contains totals and footnotes </li></ul></ul></ul><ul><ul><ul><li><tfoot></tfoot> </li></ul></ul></ul><ul><ul><ul><ul><li>Defines foot of table </li></ul></ul></ul></ul><ul><ul><ul><li><tr></tr> </li></ul></ul></ul><ul><ul><ul><li><th></th> element </li></ul></ul></ul>
  10. 10. Intermediate XHTML Tables and Formatting <ul><li>Elements required to build more complex tables </li></ul><ul><li>table2.html </li></ul><ul><li><colgroup> </colgroup> element </li></ul><ul><ul><li>Groups and formats columns </li></ul></ul><ul><ul><li><col> </col> element </li></ul></ul><ul><ul><ul><li>Attributes </li></ul></ul></ul><ul><ul><ul><ul><li>Align </li></ul></ul></ul></ul><ul><ul><ul><ul><li>Span </li></ul></ul></ul></ul><ul><ul><ul><ul><ul><li>Value how many columns the <col> formats </li></ul></ul></ul></ul></ul><ul><ul><ul><ul><li>colspan </li></ul></ul></ul></ul><ul><ul><ul><ul><li>rowspan </li></ul></ul></ul></ul><ul><ul><ul><ul><li>valign </li></ul></ul></ul></ul><ul><ul><ul><ul><ul><li>“ top” </li></ul></ul></ul></ul></ul><ul><ul><ul><ul><ul><li>“ middle” </li></ul></ul></ul></ul></ul><ul><ul><ul><ul><ul><li>“ bottom” </li></ul></ul></ul></ul></ul>
  11. 11. Basic XHTML Forms <ul><li>Used to collect data from user. </li></ul><ul><li>Used to collect data from user. </li></ul><ul><li>XHTML uses HTTP (Hypertext Transfer Protocol). </li></ul>
  12. 12. Basic XHTML Forms <ul><li>Used to collect data from user </li></ul><ul><li>XHTML uses HTTP (Hypertext Transfer Protocol) </li></ul><ul><li>Example program sends the form data to the Web Server which passes the form to a CGI (Common Gateway Interface) </li></ul><ul><ul><li>Written in Perl, C or some other language </li></ul></ul><ul><ul><li>Submit will cause error as server is not configured </li></ul></ul><ul><ul><ul><li>We will do that later in ASP.NET </li></ul></ul></ul>
  13. 13. Basic XHTML Forms <ul><li>Used to collect data from user </li></ul><ul><li>XHTML uses HTTP (Hypertext Transfer Protocol) </li></ul><ul><li>Example program sends the form data to the Web Server which passes the form to a CGI (Common Gateway Interface) </li></ul><ul><ul><li>Written in Perl, C or some other language </li></ul></ul><ul><ul><li>Submit will cause error as server is not configured </li></ul></ul><ul><ul><ul><li>We will do that later in ASP.NET </li></ul></ul></ul><ul><li>Forms can contain visual and non visual components </li></ul><ul><ul><li>Hidden inputs </li></ul></ul><ul><ul><ul><li>Store data in documents specified </li></ul></ul></ul>
  14. 14. Basic XHTML Forms <ul><li><form> </form> element </li></ul><ul><ul><li>Attributes </li></ul></ul><ul><ul><ul><li>method </li></ul></ul></ul><ul><ul><ul><ul><li>Specifies how form’s data is sent to the Web server </li></ul></ul></ul></ul><ul><ul><ul><ul><li>Value “post” appends form data to the browser request </li></ul></ul></ul></ul><ul><ul><ul><ul><ul><li>Contains the protocol </li></ul></ul></ul></ul></ul><ul><ul><ul><ul><ul><li>Requested sources URL </li></ul></ul></ul></ul></ul><ul><ul><ul><ul><ul><li>Scripts in the web server will process the data </li></ul></ul></ul></ul></ul><ul><ul><ul><ul><li>Value “get” appends for data directly to the end of the URL </li></ul></ul></ul></ul><ul><ul><ul><ul><li>We will discuss these in detail later </li></ul></ul></ul></ul><ul><ul><ul><li>action </li></ul></ul></ul><ul><ul><ul><ul><li>specifies the URL of a script on the Web server </li></ul></ul></ul></ul><ul><ul><ul><ul><li>Most ISPs have a formmail script </li></ul></ul></ul></ul>
  15. 15. Basic XHTML Forms <ul><li><input /> element </li></ul><ul><ul><li>Attributes </li></ul></ul><ul><ul><ul><li>type </li></ul></ul></ul><ul><ul><ul><ul><li>value </li></ul></ul></ul></ul><ul><ul><ul><ul><ul><li>“ hidden” used by web server script </li></ul></ul></ul></ul></ul><ul><ul><ul><ul><ul><li>“ text” </li></ul></ul></ul></ul></ul><ul><ul><ul><ul><ul><li>“ submit” button sends form to server </li></ul></ul></ul></ul></ul><ul><ul><ul><ul><ul><li>“ reset” resets all the components in form </li></ul></ul></ul></ul></ul><ul><ul><ul><li>name </li></ul></ul></ul><ul><ul><ul><ul><li>identifies element to script </li></ul></ul></ul></ul><ul><ul><ul><ul><li>value is used by server to process input </li></ul></ul></ul></ul><ul><ul><ul><li>size </li></ul></ul></ul><ul><ul><ul><ul><li>sets the length of the component </li></ul></ul></ul></ul><ul><ul><ul><li>maxlength </li></ul></ul></ul><ul><ul><ul><ul><li>sets the maximum number of characters </li></ul></ul></ul></ul>
  16. 16. Basic XHTML Forms <ul><li><label></label> element is used to label the form components. </li></ul>
  17. 17. More Complex XHTML Forms <ul><li>Add some components to the basic form to enhance it. </li></ul><ul><li>form2.html </li></ul><ul><li>adds some new components </li></ul><ul><ul><li><textarea> </textarea> </li></ul></ul><ul><ul><ul><li>Attributes </li></ul></ul></ul><ul><ul><ul><ul><li>rows </li></ul></ul></ul></ul><ul><ul><ul><ul><li>cols </li></ul></ul></ul></ul>
  18. 18. More Complex XHTML Forms <ul><ul><li><input /> </li></ul></ul><ul><ul><ul><li>type </li></ul></ul></ul><ul><ul><ul><ul><li>“password” fills text box with “*”, sends info to server </li></ul></ul></ul></ul><ul><ul><ul><ul><li>“checkbox” </li></ul></ul></ul></ul><ul><ul><ul><ul><ul><li>Assigned individually </li></ul></ul></ul></ul></ul><ul><ul><ul><ul><ul><li>Groups with same name </li></ul></ul></ul></ul></ul><ul><ul><ul><ul><ul><li>Must have different value so server can identify them. </li></ul></ul></ul></ul></ul>
  19. 19. More Complex XHTML Forms <ul><ul><li><input /> </li></ul></ul><ul><ul><ul><li>Form3.html </li></ul></ul></ul><ul><ul><ul><ul><ul><li>“radio” radio button </li></ul></ul></ul></ul></ul><ul><ul><ul><ul><ul><li>Only one in a group can be selected at a given time </li></ul></ul></ul></ul></ul><ul><ul><ul><ul><ul><li>Attribute checked=”checked” sets default selection </li></ul></ul></ul></ul></ul><ul><ul><ul><ul><ul><li>Name must be the same for all radio buttons in a group </li></ul></ul></ul></ul></ul>
  20. 20. More Complex XHTML Forms <ul><ul><ul><li><select> </select> element </li></ul></ul></ul><ul><ul><ul><ul><li>Dropdown list from which to select item </li></ul></ul></ul></ul><ul><ul><ul><ul><li>Attributes </li></ul></ul></ul></ul><ul><ul><ul><ul><ul><li>name </li></ul></ul></ul></ul></ul><ul><ul><ul><li><option></option> </li></ul></ul></ul><ul><ul><ul><ul><li>Attributes </li></ul></ul></ul></ul><ul><ul><ul><ul><ul><li>selected = “selected” sets the default option </li></ul></ul></ul></ul></ul>
  21. 21. Internal Linking <ul><li>Enables user to jump between locations in the same document. </li></ul><ul><li>Useful for long documents </li></ul><ul><li>Eliminates scrolling </li></ul><ul><li>links.html </li></ul><ul><li>use id = “name” in a text element to create hyperlink destination </li></ul><ul><li>Use <a href =”#linkname”>directions </a> </li></ul><ul><li>href = “filename.html#id” </li></ul><ul><ul><li>links to an anchor on another page </li></ul></ul>
  22. 22. Creating and Using Image Maps <ul><li>Image maps create hyperlink spots on an image called “hotspots.” </li></ul><ul><li>picture.html </li></ul><ul><li>current browsers do not support XHTML 1.1, so use XHTML 1.0 Transitional </li></ul><ul><ul><li>note <!DOCTYPE… </li></ul></ul>
  23. 23. Creating and Using Image Maps <ul><li>picture.html </li></ul><ul><ul><li><map> </map> element image map definition </li></ul></ul><ul><ul><ul><li>Attribute </li></ul></ul></ul><ul><ul><ul><ul><li>id = “mapname” </li></ul></ul></ul></ul>
  24. 24. Creating and Using Image Maps <ul><li>picture.html </li></ul><ul><ul><li><area /> element defines the hotspot </li></ul></ul><ul><ul><ul><li>Attributes </li></ul></ul></ul><ul><ul><ul><ul><li>href specifies hyperlink </li></ul></ul></ul></ul><ul><ul><ul><ul><li>shape specifies the shape </li></ul></ul></ul></ul><ul><ul><ul><ul><ul><li>rect rectangular shape </li></ul></ul></ul></ul></ul><ul><ul><ul><ul><ul><li>poly polygon shape </li></ul></ul></ul></ul></ul><ul><ul><ul><ul><ul><li>circle circle shape </li></ul></ul></ul></ul></ul><ul><ul><ul><ul><li>alt text to be displayed on mouseover </li></ul></ul></ul></ul><ul><ul><ul><ul><li>coords the coordinates in pixels </li></ul></ul></ul></ul>
  25. 25. Creating and Using Image Maps <ul><li>picture.html </li></ul><ul><ul><li><img /> element add attribute </li></ul></ul><ul><ul><ul><li>usemap = “mapname” </li></ul></ul></ul>

×
