WHY WE CHOSE MONGODB TO PUT BIG-DATA ‘ON THE MAP’          JUNE 2012           @nknize        +Nicholas Knize
“The 3D UDOP allows near real time visibility of all SOUTHCOM Directorates information in onelocation…this capability allo...
• Expose enterprise data in a geo-temporal user defined  environment• Provide a flexible and scalable spatial indexing fra...
Desired Data Store Characteristic for ‘Big Data’• Horizontally scalable – Large volume / elastic• Vertically scalable – He...
Subset of Evaluated NoSQL Options           • Cassandra                 –   Nice Bring Your Own Index (BYOI) design       ...
Why MongoDB for Thermopylae?• Documents based on JSON – A GEOJSON match made in heaven!• C++ - No Garbage Collection Overh...
... The Spatial Indexer wasn’t quite right• MongoDB (like nearly all relational DBs) uses a b-Tree     – Data structure fo...
How does MongoDB solve the dimensionality problem?• Space Filling (Z) Curve     – A continuous line that       intersects ...
Issues with the Geohash b-Tree approach• Neighbors aren’t so  close!     – Neighboring points on the       Geoid may end u...
Mongo Multi-location Document Clipping Issues                         ($within search doesn’t always work w/ multi-locatio...
Potential Solutions • Constrain the system to single point searches       – Multi-dimension support will be exponentially ...
Thermopylae Custom Tuned MongoDB               for GeoTST Leverage’s Guttman’s 1984 Research in R/R* Trees• R-Trees organi...
Spatial Indexing at Scale with R-TreesSpatial data represented as minimum bounding rectangles (2-dimension),cubes (3-dimen...
mn o p    R*-Tree Spatial Index Example• Sample insertion result for 4th order  tree• Objectives:                         ...
Insert • Similar to insertion into B+-tree but may insert   into any leaf; leaf splits in case capacity exceeded.       – ...
Insert—Leaf Selection• Follow a path from root to leaf.• At each node move into subtree whose MBR area  increases least wi...
Insert—Leaf Selection• Insert into m.               m
Insert—Leaf Selection• Insert into n.                        n
Insert—Leaf Selection• Insert into o.                        o
Insert—Leaf Selection• Insert into p.                        p
mn o pQuery  • Start at root                     a b cd           e f            g h i   jk l  • Find all overlapping MBRs...
mn o pQuery                                 a b cd           e f            g h i   jk l• Search m.                       ...
R*-Tree Leverages B-Tree Base Data Structures (buckets) R*-TREE MONGODB IMPLEMENTATION ACCOMPLISHING THE IMPOSSIBLE
Geo-Sharding – (in work)     Scalable Distributed R* Tree (SD-r*Tree)“Balanced” binary tree, withnodes distributed on a se...
SD-r*Tree Data Structure Illustration                               a                                a                    ...
SD-r*Tree Structure Distribution                             a                                      c       GeoShard 2    ...
GeoSharding Alternative – 3D / 4D Hilbert Scanning Order  GEO-SHARDING ALTERNATIVE  ACCOMPLISHING THE IMPOSSIBLE
Next Steps: Beyond 4-Dimensions - X-Tree                                  (Berchtold, Keim, Kriegel – 1996)               ...
X-Tree Performance Results                               (Berchtold, Keim, Kriegel – 1996)X-TREE PERFORMANCEACCOMPLISHING ...
T-Sciences Custom Tuned Spatial Indexer• Optimized Spatial Search – Finds intersecting MBR and recurses into  those nodes•...
Example Use Case – OSINT (Foursquare Data)• Sample Foursquare  data set mashed with  Government Intel  Data (poly reports)...
Community Support• Thermopylae contributes fixes to the codebase      – http://github.com/mongodb• TST will work with 10ge...
THANK YOU                                 Questions?                                   Nicholas Knize                     ...
