Microsoft Lync 2010 Call Flows Explained            Justin Morris            Consultant, Modality Systems                 ...
Agenda• The foundations:      – What is SIP, SDP, RTP, RTCP?      – What is ICE and MRAS?• How is a call established?• Loo...
What is SIP and SDP?• The signalling component of the call – sets up the session.• SIP – Session Initiation Protocol. The ...
What is RTP and RTCP?• The actual media (voice or video) component of  the call.• RTP – Realtime Transport Protocol      –...
What is ICE and MRAS?• ICE – Interactive Connectivity Establishment      – STUN - Session Traversal Utilities for NAT (use...
How is a call established?•   Address Discovery•   Address Exchange (SIP INVITE 183, 200 OK)•   Connectivity Checks•   Can...
Address Discovery• Combinations of available IPv4 addresses and randomly allocated  TCP/UDP ports within the configured po...
Address Exchange• SIP INVITE is sent with SDP and candidate list.• Both endpoints send candidate list to each  other.19/04...
Connectivity Checks• STUN binding requests - pings on media ports.  Wont see these in Snooper, only in Wireshark.• Priorit...
Candidate Promotion• Once path is validated, another SIP INVITE is  sent containing the validated remote  candidate in the...
Media Flow Connectivity has been checked. Candidate has been determined (IP address, port and  transport type). Codec h...
SIP traces - Lync P2P internal call19/04/2012   Microsoft Unified Communications User Group London (MUCUGL)   12
SIP traces - Escalating from P2P toa Conference19/04/2012   Microsoft Unified Communications User Group London (MUCUGL)   13
SIP traces - Lync internal user toPSTN call19/04/2012   Microsoft Unified Communications User Group London (MUCUGL)   14
SIP traces - Internal user toRemote User call19/04/2012   Microsoft Unified Communications User Group London (MUCUGL)   15
SIP traces - Internal user toFederated User call19/04/2012   Microsoft Unified Communications User Group London (MUCUGL)  ...
Troubleshooting• Logging Tool      – Comes with Lync Server 2010.      – Trace S4 and SIPStack.• Snooper      – Displays a...
Questions?19/04/2012   Microsoft Unified Communications User Group London (MUCUGL)   18
Upcoming SlideShare
Loading in …5
×

Microsoft Lync 2010 Call Flows Explained

33,914 views

Published on

Justin Morris runs through a deep-dive session on internal and external Lync Call Flows.

Published in: Technology
  • i can't see the sip traces also
       Reply
    Are you sure you want to  Yes  No
    Your message goes here
  • Hi, the SIP traces all seem to be missing, was that intentional?
       Reply
    Are you sure you want to  Yes  No
    Your message goes here

Microsoft Lync 2010 Call Flows Explained

  1. 1. Microsoft Lync 2010 Call Flows Explained Justin Morris Consultant, Modality Systems @justimorris http://www.justin-morris.net justin.morris@modalitysystems.com
  2. 2. Agenda• The foundations: – What is SIP, SDP, RTP, RTCP? – What is ICE and MRAS?• How is a call established?• Looking at real Call Flow SIP traces: – Lync P2P Internal Call – Escalating from P2P to a Conference – Internal to PSTN Call – Internal to Remote User Call – Internal to Federated User Call• Troubleshooting Calls• Questions19/04/2012 Microsoft Unified Communications User Group London (MUCUGL) 2
  3. 3. What is SIP and SDP?• The signalling component of the call – sets up the session.• SIP – Session Initiation Protocol. The backbone of Lync. – INVITE – REGISTER – INFO • Presence and IMs are sent and received in these messages – SIMPLE. – BYE – 200 OK• SDP - Session Description Protocol – Sent in SIP INVITE and 200 OK messages. – Allows endpoints to negotiate how their media session will take place. – Works out IP address to connect on, what media codec to use, etc.19/04/2012 Microsoft Unified Communications User Group London (MUCUGL) 3
  4. 4. What is RTP and RTCP?• The actual media (voice or video) component of the call.• RTP – Realtime Transport Protocol – Carries the audio and/or video stream in IP packets. – Can be RTP (unencrypted) or SRTP (encrypted). – Almost always UDP.• RTCP – Realtime Transport Control Protocol – Monitors RTP. RTAudio uses this to negotiate narrowband or wideband based on network conditions.19/04/2012 Microsoft Unified Communications User Group London (MUCUGL) 4
  5. 5. What is ICE and MRAS?• ICE – Interactive Connectivity Establishment – STUN - Session Traversal Utilities for NAT (used to be called Simple Traversal of UDP through NAT). – TURN – Traversal of UDP via Relay NAT. – The secret sauce of the Edge Server.• MRAS – Media Relay Authentication Service – Runs on internal interface of Edge Servers. – Users request MRAS creds on sign-in. – MCUs also request credentials on service start.19/04/2012 Microsoft Unified Communications User Group London (MUCUGL) 5
  6. 6. How is a call established?• Address Discovery• Address Exchange (SIP INVITE 183, 200 OK)• Connectivity Checks• Candidate Promotion• Media Flow19/04/2012 Microsoft Unified Communications User Group London (MUCUGL) 6
  7. 7. Address Discovery• Combinations of available IPv4 addresses and randomly allocated TCP/UDP ports within the configured port ranges for the Lync client.• There are three types of candidates: – Internal IP address - IP of the NIC of the client computer. – Reflexive IP address - the public IP address of the internet router/NAT device. – Media relay IP address - public IP address of the A/V Edge service that is associated with the users internal Lync pool.• Before address exchange occurs, client must hit the A/V Edge and be allocated an IP address and port. Client sends username that was used when MRAS creds were received.• Although the edge server has just allocated those port to the user, it is ACLd and means that it is only accessible by that client IP and only with valid authentication info.• All of this is done before the SIP INVITE is sent.19/04/2012 Microsoft Unified Communications User Group London (MUCUGL) 7
  8. 8. Address Exchange• SIP INVITE is sent with SDP and candidate list.• Both endpoints send candidate list to each other.19/04/2012 Microsoft Unified Communications User Group London (MUCUGL) 8
  9. 9. Connectivity Checks• STUN binding requests - pings on media ports. Wont see these in Snooper, only in Wireshark.• Priority for media connectivity: – UDP direct – UDP NAT – UDP Relay (via an Edge Server) – TCP Relay (via an Edge Server - last resort)19/04/2012 Microsoft Unified Communications User Group London (MUCUGL) 9
  10. 10. Candidate Promotion• Once path is validated, another SIP INVITE is sent containing the validated remote candidate in the SDP.• Callee responds with 200 OK and a remote candidate similar to the candidate the caller presented.• For each pair, one is for RTP and the other is for RTCP.19/04/2012 Microsoft Unified Communications User Group London (MUCUGL) 10
  11. 11. Media Flow Connectivity has been checked. Candidate has been determined (IP address, port and transport type). Codec has been agreed. SIP messages stops and media then begins to flow between the two endpoints. • Once the call is complete, ports are closed and SIP BYE is sent.• If Monitoring Server is deployed, a SIP SERVICE message is sent to the FE and onto the Monitoring Server to log call data.19/04/2012 Microsoft Unified Communications User Group London (MUCUGL) 11
  12. 12. SIP traces - Lync P2P internal call19/04/2012 Microsoft Unified Communications User Group London (MUCUGL) 12
  13. 13. SIP traces - Escalating from P2P toa Conference19/04/2012 Microsoft Unified Communications User Group London (MUCUGL) 13
  14. 14. SIP traces - Lync internal user toPSTN call19/04/2012 Microsoft Unified Communications User Group London (MUCUGL) 14
  15. 15. SIP traces - Internal user toRemote User call19/04/2012 Microsoft Unified Communications User Group London (MUCUGL) 15
  16. 16. SIP traces - Internal user toFederated User call19/04/2012 Microsoft Unified Communications User Group London (MUCUGL) 16
  17. 17. Troubleshooting• Logging Tool – Comes with Lync Server 2010. – Trace S4 and SIPStack.• Snooper – Displays all UCCP logs and Logging Tool generated traces. – Separate install - Snooper comes with the Lync Server 2010 Resource Kit.• Wireshark – Can show everything that isn’t TLS encrypted: • Problems before TLS encryption occurs. • Inspect the RTP stream to determine audio codec being used. • SIP TCP signalling (e.g. with CSTA gateways, PSTN gateways, etc).19/04/2012 Microsoft Unified Communications User Group London (MUCUGL) 17
  18. 18. Questions?19/04/2012 Microsoft Unified Communications User Group London (MUCUGL) 18

×
