Lync Mobility Deployment

  1. 1. Lync Mobility Deployment Tom Arbuthnot Justin Morris Consultant, Modality Systems and Lync MVP Consultant, Modality Systems @tomarbuthnot @jm_deluxe http://www.lyncdup.com http://www.justin-morris.net tom.arbuthnot@modalitysystems.com justin.morris@modalitysystems.com
  2. 2. Agenda • Step by Step Deployment Guide – Prerequisites, DNS, Certificates – Reverse Proxy, Push Notifications • The Lync Mobile Sign-In Process • Top 5 Issues • Do I need lyncdiscoverinternal? • Monitoring Performance of Mobility • Questions 19/01/2012 Microsoft Unified Communications User Group London (MUCUGL) 2
  3. 3. Mobility Service Deployment in 7 slides • Cumulative Update 4 on all Servers • Mobility DNS Requirements • New FE listening ports and IIS changes • Install the MCX Service • Certificate Updates • Reverse Proxy Rule Update • Add Lync Online Federation for Push Notifications 20/01/2012 Microsoft Unified Communications User Group London (MUCUGL) 3
  4. 4. Cumulative Update 4 First • CU4 on all servers • CU4 DB Update • Install-CsDatabase -Update - ConfiguredDatabases -SqlServerFqdn <EEBE.Fqdn> -UseDefaultSqlPaths 20/01/2012 Microsoft Unified Communications User Group London (MUCUGL) 4
  5. 5. DNS Requirements • Lync Mobile uses two DNS records to discover the server to register to, lyncdiscover and lyncdiscoverinternal • CNAME and Host (A) records are supported • Internal DNS: Lyncdiscoverinteral.domain.com points to Lync pool/Director DNS record • External DNS: Lyncdisover.domain.com, external (and reachable internal), points to External Reverse Proxy • Lync discover returns proxy FQDN. This needs to be resolvable internally 20/01/2012 Microsoft Unified Communications User Group London (MUCUGL) 5
  6. 6. New FE Listening Ports and IIS changes • Set-CsWebServer -Identity lync.domain.com - McxSipPrimaryListeningPort 5086 • Set-CsWebServer -Identity lync.domain.com - McxSipExternalListeningPort 5087 • Re enable the topology to enact these IIS changes – Enable-CsTopology • There is also an additional IIS feature Requirement – Import-Module ServerManager Add-WindowsFeature Web-Server, Web-Dyn- Compression 20/01/2012 Microsoft Unified Communications User Group London (MUCUGL) 6
  7. 7. Install the MCX Service • Download the McxStandalone.msi installation package and save it into the following existing directory on each Lync server where it will be installed. • C:ProgramDataMicrosoftLync ServerDeploymentcache4.0.7577.0setup • C:Program FilesMicrosoft Lync Server 2010DeploymentBootstrapper.exe 20/01/2012 Microsoft Unified Communications User Group London (MUCUGL) 7
  8. 8. Certificate Updates – Internal and External • Internal FE certs – Set-CsCertificate –Type Default,WebServicesInternal,WebServicesExternal – Thumbprint <Certificate Thumbprint> – This will add the lyncdiscover and lyncdiscoverinternal names to the FE cert • Externally, discovery can be done http(80) or https(443), if using https the external cert requires lyncdiscover.domain.com SAN name • Both required for each supported SIP domain on the system 20/01/2012 Microsoft Unified Communications User Group London (MUCUGL) 8
  9. 9. New Reverse Proxy Rule • To allow access from the outside for the mobile clients • It can be added to your existing reverse proxy rule set for Lync • Full Reverse Proxy setup steps on Adam’s imaucblog.com • Port 80 required for http discovery 20/01/2012 Microsoft Unified Communications User Group London (MUCUGL) 9
  10. 10. Federation to Lync Online for Push • New-CsHostingProvider –Identity "LyncOnline" –Enabled $true – ProxyFqdn "sipfed.online.lync.com" –VerificationLevel UseSourceVerification • New-CsAllowedDomain –Identity push.lync.com –Comment “Mobile Push Notifications” • Set-CsPushNotificationConfiguration –EnableApplePushNotificationService $true –EnableMicrosoftPushNotificationService $true 20/01/2012 Microsoft Unified Communications User Group London (MUCUGL) 10
  11. 11. Summary: Mobility Service Deployment • Cumulative Update 4 on all Servers • Mobility DNS Requirements • New FE listening ports and IIS changes • Install the MCX Service • Certificate Updates • Reverse Proxy Rule Update • Add Lync Online Federation for Push Notifications 20/01/2012 Microsoft Unified Communications User Group London (MUCUGL) 11
  12. 12. Handover to Justin 20/01/2012 Microsoft Unified Communications User Group London (MUCUGL) 12
  13. 13. Lync Mobile Sign-In Process Internal 1. Mobile device locates lyncdiscoverinternal.<SIP FQDN> record via internal DNS 2. External MCX URL is returned 3. Lync Mobile client communicates with external web service (4443 MCX virtual directory) by hair- pinning the reverse proxy 19/01/2012 Microsoft Unified Communications User Group London (MUCUGL) 13
  14. 14. Lync Mobile Sign-In Process External 1. Mobile device locates lyncdiscover.<SIPFQDN> record via external DNS 2. External MCX URL is returned 3. Lync Mobile client communicates with external web service (4443 MCX virtual directory) via the reverse proxy 19/01/2012 Microsoft Unified Communications User Group London (MUCUGL) 14
  15. 15. Lync Mobile Sign-In Process Authentication and In-Band Provisioning 1. Web ticket request is made for a client certificate for authentication. 2. SIP REGISTER packet comes from the Lync Front End on the listening port e.g. 5087. 3. Do I have a mobility policy granted to me? 4. In-band provisioning occurs: – Voicemail URI, ABS URL, dial plan, voice policy. 5. Contact list and contact cards are retrieved. 19/01/2012 Microsoft Unified Communications User Group London (MUCUGL) 15
  16. 16. Top Mobile Client Issues • Account details (domainusername) required if UPN is different to SIP URI e.g. UPN - justin.morris@contoso.int SIP URI – justin.morris@contoso.com • Check EWS connectivity – requires same as desktop client. • URL filtering in IM breaks push notifications. • McxStandalone.msi must be run using Bootstrapper. 19/01/2012 Microsoft Unified Communications User Group London (MUCUGL) 16
  17. 17. Do I need lyncdiscoverinternal? • Mobile clients won’t trust your internal CA, who has a public certificate on their FEs? • Deploying root CA certificate to all mobile devices is unlikely to happen. • Solution: route all internal lyncdiscover.sipdomain traffic to the external interface of the Reverse Proxy. 19/01/2012 Microsoft Unified Communications User Group London (MUCUGL) 17
  18. 18. Monitoring Performance of Mobility • Why do we do this? – Ensuring we have the capacity to support users. – Predicting when extra capacity is required. • How do we do this? – Can be monitored from within IIS -> Worker Processes. – CsIntMcxAppPool and CxExtMcxAppPool CPU% should be under 15% 19/01/2012 Microsoft Unified Communications User Group London (MUCUGL) 18
  19. 19. Questions? Sources: Brendan Carius - http://blog.kloud.com.au/2011/12/12/lync-2010-mobility-do-i-need-lyncdiscoverinternal/ http://blog.kloud.com.au/2011/12/12/lync-2010-mobility-sign-in-internals/ 19/01/2012 Microsoft Unified Communications User Group London (MUCUGL) 19
