Video Conferencing Capabilities    within Lync Server 2013       Adam Jacobs       Polycom Global UCA, Lync MVP           ...
DisclaimerEverything within this presentation is basedupon capabilities within Lync Server 2013 PublicPreview, as this is ...
Agenda (all in 25mins) •   Lync 2010 video capability•   Lync 2013 a standards-based approach•   Lync 2013 video changes•...
First some Lync 2010 videohistory…• Lync Server 2010 AVMCU is limited to H.263 (P2P only) and  RTV video codecs• HD 720p i...
Lync 2013 a standards-basedapproach• Microsoft engaged in Unified Communications  Interoperability Forum (UCIF) for standa...
What’s new in Lync 2013conferencing?•   H.264 SVC/AVC support•   Up to 1080p HD multi-party and point-to-point video•   Su...
Face detection and smart framing(Demo)30/07/2012   Microsoft Unified Communications User Group London (MUCUGL)   7
Scalable Video Code (SVC)1. Temporal scalability                                                               Layer 0 : 7...
Scalable Video Code (SVC)2. Spatial scalability                                                                   Layer 0 ...
Scalable Video Code (SVC)1 + 2 = SVC                        Lync 2013     Lync 2010                                       ...
Video Interoperability• SVC Config Mode 0, 1 (Simulcast)      – Suggestion is Mode 0 for legacy video        (H.264 AVC or...
New CsConferencingPolicyCmdlets in Lync 2013 Preview                                                                      ...
Resources• Jeff Schertz’s Blog (fellow MVP and Polycom employee)  http://blog.schertz.name/2012/07/video-interoperability-...
Questions?26/07/2012   Microsoft Unified Communications User Group London (MUCUGL)   14
Upcoming SlideShare
Loading in …5
×

20120726 aj-mucugl-video-conferencing-capabilities-within-lync-2013

4,242 views

Published on

Lync Server 2013 Video Conferencing Capabilities delivered by Adam Jacobs at MUCUGL July 2012

Published in: Technology, Business
0 Comments
0 Likes
Statistics
Notes
  • Be the first to comment

  • Be the first to like this

No Downloads
Views
Total views
4,242
On SlideShare
0
From Embeds
0
Number of Embeds
2,129
Actions
Shares
0
Downloads
114
Comments
0
Likes
0
Embeds 0
No embeds

No notes for slide

20120726 aj-mucugl-video-conferencing-capabilities-within-lync-2013

  1. 1. Video Conferencing Capabilities within Lync Server 2013 Adam Jacobs Polycom Global UCA, Lync MVP @adamjacobs http://imaucblog.com adam@imaucblog.com
  2. 2. DisclaimerEverything within this presentation is basedupon capabilities within Lync Server 2013 PublicPreview, as this is a public beta release and notRTM, features could be subject to change.30/07/2012 Microsoft Unified Communications User Group London (MUCUGL) 2
  3. 3. Agenda (all in 25mins) • Lync 2010 video capability• Lync 2013 a standards-based approach• Lync 2013 video changes• Scalable Video Codec (SVC)• Video interoperability• Changes to video manageability in 2013• Questions30/07/2012 Microsoft Unified Communications User Group London (MUCUGL) 3
  4. 4. First some Lync 2010 videohistory…• Lync Server 2010 AVMCU is limited to H.263 (P2P only) and RTV video codecs• HD 720p is only possible with RTV and point-to-point (not AVMCU)• Lync Server 2010 needs to be enabled for HD – Set-CsMediaConfiguration –Identity Global - MaxVideoRateAllowed Hd720p15M• HD 720p receive requires either dual core (15fps) or quad core (30fps)• HD 720p both send/receive requires quad core• Interoperability with legacy video requires Microsoft SIP signalling capability and RTV video support (3rd party SW or native support)30/07/2012 Microsoft Unified Communications User Group London (MUCUGL) 4
  5. 5. Lync 2013 a standards-basedapproach• Microsoft engaged in Unified Communications Interoperability Forum (UCIF) for standardisation of video, transport and signalling• Lync 2013 H.264 bitstream is likely to confirm to UCIF interoperability spec, removing the need to perform media transcoding for other UCIF compliant H.264 systems• Lync 2013 video specifications disclosed publically• Capability to leverage H.264 hardware-based acceleration• Polycom H.264 SVC technology adopted• More on SVC later…30/07/2012 Microsoft Unified Communications User Group London (MUCUGL) 5
  6. 6. What’s new in Lync 2013conferencing?• H.264 SVC/AVC support• Up to 1080p HD multi-party and point-to-point video• Supporting desktop, mobile, and slate devices (including web)• Up to 5 users continuous presence (most active participants/pinning)• HD photos (delivered only via Exchange 2013)• Face detection and smart framing (demo)• Dynamic layouts – Gallery View shows all participants’ photos or videos – Speaker View shows the meeting content and only the presenter’s video or photo – Presentation View shows meeting content only – Compact View shows just the meeting controls26/07/2012 Microsoft Unified Communications User Group London (MUCUGL) 6
  7. 7. Face detection and smart framing(Demo)30/07/2012 Microsoft Unified Communications User Group London (MUCUGL) 7
  8. 8. Scalable Video Code (SVC)1. Temporal scalability Layer 0 : 720p 7.5fps Layer 1 : 720p 15fps 7.5 frames Layer 2 : 720p 30fps 7.5 frames 15 frames30/07/2012 Microsoft Unified Communications User Group London (MUCUGL) 8
  9. 9. Scalable Video Code (SVC)2. Spatial scalability Layer 0 : 180p Layer 1 : 360p 180p res. Layer 2 : 720p 180p res. 360p res.30/07/2012 Microsoft Unified Communications User Group London (MUCUGL) 9
  10. 10. Scalable Video Code (SVC)1 + 2 = SVC Lync 2013 Lync 2010 Polycom Slate Client Legacy Video Client Client Legacy Video (H.264 SVC (H.264 AVC (H.264 SVC (RTVideo 720p (RTVideo 720p 720p capable) 720p capable) 1080p capable) capable) capable) The combination of these two processes result in video appropriate to the requesting video endpoint. AVMCU routes/discards video modes that are unsuitable for the client based upon SDP discovery30/07/2012 Microsoft Unified Communications User Group London (MUCUGL) 10
  11. 11. Video Interoperability• SVC Config Mode 0, 1 (Simulcast) – Suggestion is Mode 0 for legacy video (H.264 AVC or RTVideo) – Mode 1 for H.264 SVC• Simultaneous streaming being a requirement for non-transcoding MCU• Lync 2010 and/or legacy video endpoints will result in gallery Source: MSDN 2.2.12.2 Video Source view and high resolution video Request (VSR) being unavailable• Video gateways still necessary to facilitate Microsoft SIP signalling• 3rd party bridges still a requirement for communication with standard SIP, H.323, ISDN, TIP, etc.30/07/2012 Microsoft Unified Communications User Group London (MUCUGL) 11
  12. 12. New CsConferencingPolicyCmdlets in Lync 2013 Preview Default inCmdlet Description PreviewAllowMultiView Enable multi-view by AVMCU : TrueDisablePowerPointAnnotations Allow annotations to PowerPoint slides, allowed by default : FalseAllowNonEnterpriseVoice Conference dial out for users that are not enabled forUsersToDialOut Enterprise Voice : False OneNote notebooks linked to a conference are automatically updated with information i.e. conference participants andAllowSharedNotes details about content shared during the conference : TrueAllowLargeMeetings Limits notifications to participants and roster size : False Only for Lync 2013 clients, specifies max allowed bitrate for all combined video streams received, except for panorama. E.g. if you specify 1500 kbps, then a client can receive up to 1500TotalReceiveVideoBitRate kbps of video, which may consist of multiple 180P videoKb streams or a single 540P video stream. : 6000EnableMultiViewJoin Enable multi-view by user : True30/07/2012 Microsoft Unified Communications User Group London (MUCUGL) 12
  13. 13. Resources• Jeff Schertz’s Blog (fellow MVP and Polycom employee) http://blog.schertz.name/2012/07/video-interoperability-in- lync-2013/• Microsoft’s H.264 AVC and SVC UCConfig specification http://bit.ly/MGw1rB• Polycom and Microsoft joint-announcement http://www.polycom.com/company/news_room/press_releas es/2010/20101108_2.html• UCI Forum http://www.ucif.org/• MSDN Video Source Request (VSR) reference http://msdn.microsoft.com/en-us/library/hh659630.aspx• My Blog (I’m a UC Blog) http://imaucblog.com30/07/2012 Microsoft Unified Communications User Group London (MUCUGL) 13
  14. 14. Questions?26/07/2012 Microsoft Unified Communications User Group London (MUCUGL) 14

×
