The DynamoRIODynamic Tool PlatformDerek Bruening
Typical Modern Application: IIS                                  2
Runtime Interposition Layer                  running application                     DynamoRIO:             manipulate eve...
OutlineSystem OverviewExample Tools• Security• DebuggingOpen Source Project                      4
Direct Code Modification e9 37 6f 48 92   jmp <callout>         Kernel32!TerminateProcess:         7d4d1028 7c 05         ...
Entry Point Complications e9 37 6f 48 92   jmp <callout>         Kernel32!TerminateProcess:         7d4d1028 7c 05        ...
Basic Interpreter   application code    foo()        bar()         A                                 interpreter     B    ...
Improvement #1: Basic Block Cache   application code                 software                                      code   ...
Improvement # 2: Linking Direct Branches   application code                        software                               ...
Improvement # 3: Linking Indirect Branches   application code                             software                        ...
Improvement # 4: Building Traces   application code                             software                                  ...
Tool Platform   application code                             software                                                  cod...
TransparencyDo not want to interfere with the semantics of the programDangerous to make any assumptions about:• Register u...
Painful, But NecessaryDifficult and costly to handle corner casesMany applications will not notice……but some will!• Micros...
Avoid Resource Conflicts         Linux             Windows                                     15
DynamoRIO DemoInserts counters into every basic blockCounters are visible via shared memory                               ...
OutlineSystem OverviewExample Tools• Security• DebuggingOpen Source Project                      17
Anatomy of an Attack                                                 network                     ENTER                  CO...
Critical Data: Control Flow IndirectionSubroutine calls• Return address and activation records on visible stackDynamic lib...
Critical Data: Control Flow ExploitsReturn address overwrite• Classic buffer overflowGOT overwriteObject pointer overwrite...
Preventing Data Corruption Is DifficultStored program addresses legitimately manipulated bymany different entities• Dynami...
Insight: Hijack Violates Execution Model                              Hardware                              Interface     ...
Goal: Shrink Hardware Interface                                 Constrained                              Hardware Interfac...
Program ShepherdingMonitor all control-flow transfers during program execution• DynamoRIO is in perfect position to do thi...
OutlineSystem OverviewExample Tools• Security• DebuggingOpen Source Project                      25
Memory BugsMemory bugs are challenging to detect and fix• Memory corruption, reading uninitialized memory, memory leaksObs...
Dr. MemoryDetects unaddressable memoryaccesses• Wild access to invalid address• Use-after-free• Buffer and array overflow ...
Implementation StrategyTrack the state of application memory using shadowmemory• Track whether allocated and whether defin...
Shadow MetadataShadow each byte of memory with one of 3 states:                     allocate: mmap, calloc             all...
Shadow Memory          Shadow Stack             Shadow Heap  Stack                   Heap            defined      header  ...
Performance Comparison     Valgrind failed     Valgrind failed31
OutlineSystem OverviewExample Tools• Security• DebuggingOpen Source Project                      32
DynamoRIO History       Dynamo             Dynamo      @HP Labs            @HP Labs      on PA-RISC           on x86      ...
DynamoRIO History Cont’d                                          VMware          Google  DynamoRIO        Determina      ...
DynamoRIO Team                                           Google DynamoRIO     Determina        VMware    sponsors   @MIT  ...
DynamoRIO Open Source ProjectGoogle Code• BSD license• Subversion repository     300 KLOC     Mostly C, some assembly• I...
Dr. Memory Open Source ProjectGoogle Code• http://code.google.com/p/drmemory• LGPL 2.1 license• Subversion repository    ...
Potential ProjectsBuild a New Tool• Code coverage• Fuzzer• Profiler: basic block, edge, function, etc.• Malware sandbox• R...
Potential Projects Cont’dBuild a Tool Library• Control flow, call graph, data dependence analysis• Symbol table accessCont...
