  1. 1. Trisha Gee & Michael Barker / LMAX The Disruptor - A Beginners Guide to Hardcore ConcurrencySunday, 13 November 11
  2. 2. Why is Concurrency So Difficult ?Sunday, 13 November 11
  3. 3. Program Order: Execution Order (maybe): int w = 10; int x = 20; int x = 20; int y = 30; int y = 30; int b = x * y; int z = 40; int w = 10; int a = w + z; int z = 40; int b = x * y; int a = w + z;Sunday, 13 November 11
  4. 4. Sunday, 13 November 11
  5. 5. Why Should We Care About the Details ?Sunday, 13 November 11
  6. 6. static long foo = 0; private static void increment() { for (long l = 0; l < 500000000L; l++) { foo++; } }Sunday, 13 November 11
  7. 7. public static long foo = 0; public static Lock lock = new Lock(); private static void increment() { for (long l = 0; l < 500000000L; l++){ lock.lock(); try { foo++; } finally { lock.unlock(); } } }Sunday, 13 November 11
  8. 8. static AtomicLong foo = new AtomicLong(0); private static void increment() { for (long l = 0; l < 500000000L; l++) { foo.getAndIncrement(); } }Sunday, 13 November 11
  9. 9. Cost of Contention Increment a counter 500 000 000 times. • One Thread : 300 msSunday, 13 November 11
  10. 10. Cost of Contention Increment a counter 500 000 000 times. • One Thread : 300 ms • One Thread (volatile): 4 700 ms (15x)Sunday, 13 November 11
  11. 11. Cost of Contention Increment a counter 500 000 000 times. • One Thread : 300 ms • One Thread (volatile): 4 700 ms (15x) • One Thread (Atomic) : 5 700 ms (19x)Sunday, 13 November 11
  12. 12. Cost of Contention Increment a counter 500 000 000 times. • One Thread : 300 ms • One Thread (volatile): 4 700 ms (15x) • One Thread (Atomic) : 5 700 ms (19x) • One Thread (Lock) : 10 000 ms (33x)Sunday, 13 November 11
  13. 13. Cost of Contention Increment a counter 500 000 000 times. • One Thread : 300 ms • One Thread (volatile): 4 700 ms (15x) • One Thread (Atomic) : 5 700 ms (19x) • One Thread (Lock) : 10 000 ms (33x) • Two Threads (Atomic) : 30 000 ms (100x)Sunday, 13 November 11
  14. 14. Cost of Contention Increment a counter 500 000 000 times. • One Thread : 300 ms • One Thread (volatile): 4 700 ms (15x) • One Thread (Atomic) : 5 700 ms (19x) • One Thread (Lock) : 10 000 ms (33x) • Two Threads (Atomic) : 30 000 ms (100x) • Two Threads (Lock) : 224 000 ms (746x) ^^^^^^^^ ~4 minutes!!!Sunday, 13 November 11
  15. 15. Parallel v. Serial - String Split Guy Steele @ Strangle Loop: http://www.infoq.com/presentations/Thinking-Parallel- Programming Scala Implementation and Brute Force version in Java: https://github.com/mikeb01/folklore/ 15Sunday, 13 November 11
  16. 16. Parallel (Scala) Serial (Java) 2000.0 1500.0 1000.0 500.0 0 String Split (ops/sec) higher is betterSunday, 13 November 11
  17. 17. CPUs Are Getting Faster 17Sunday, 13 November 11
  18. 18. Ya Rly! P8600 (Core 2 Duo) E5620 (Nehalem EP) i7 2667M (Sandy Bridge ULV) i7 2720QM (Sandy Bride) 3000.0 2250.0 1500.0 750.0 0 String Split 18Sunday, 13 November 11
  19. 19. What Problem Were Trying To Solve ?Sunday, 13 November 11
  20. 20. 20Sunday, 13 November 11
  21. 21. 21Sunday, 13 November 11
  22. 22. Why Queues Suck - Array Backed 22Sunday, 13 November 11
  23. 23. Why Queues Suck - Linked List 23Sunday, 13 November 11
  24. 24. Why Queues Suck - Linked List 24Sunday, 13 November 11
  25. 25. Contention Free Design 25Sunday, 13 November 11
  26. 26. 26Sunday, 13 November 11
  27. 27. How Fast Is It - Throughput ABQ Disruptor 30000000.0 22500000.0 15000000.0 7500000.0 0 Unicast Diamond 27Sunday, 13 November 11
  28. 28. How Fast Is It - Latency ABQ Disruptor Min 145 29 Mean 32,757 52 99 Percentile 2,097,152 128 99.99 Percentile 4,194,304 8,192 Max 5,069,086 175,567 28Sunday, 13 November 11
  29. 29. How Does It Work ?Sunday, 13 November 11
  30. 30. Ordering and Visibility private static final int SIZE = 32; private final Object[] data = new Object[SIZE]; private volatile long sequence = -1; private long nextValue = -1; public void publish(Object value) { long index = ++nextValue; data[(int)(index % SIZE)] = value; sequence = index; } public Object get(long index) { if (index <= sequence) { return data[(int)(index % SIZE)]; } return null; } 30Sunday, 13 November 11
  31. 31. Ordering and Visibility - Store mov $0x1,%ecx add 0x18(%rsi),%rcx ;*ladd ;... lea (%r12,%r8,8),%r11 ;*getfield data ;... mov %r12b,(%r11,%r10,1) mov %rcx,0x10(%rsi) lock addl $0x0,(%rsp) ;*ladd 31Sunday, 13 November 11
  32. 32. Ordering and Visibility - Load mov %eax,-0x6000(%rsp) push %rbp sub $0x20,%rsp ;*synchronization entry ; - RingBuffer::get@-1 mov 0x10(%rsi),%r10 ;*getfield sequence ; - RingBuffer::get@2 cmp %r10,%rdx jl 0x00007ff92505f22d ;*iflt ; - RingBuffer::get@6 mov %edx,%r11d ;*l2i ; - RingBuffer::get@14 32Sunday, 13 November 11
  33. 33. Look Ma’ No Memory Barrier AtomicLong sequence = new AtomicLong(-1); public void publish(Object value) { long index = ++nextValue; data[(int)(index % SIZE)] = value; sequence.lazySet(index); } 33Sunday, 13 November 11
  34. 34. False Sharing - Hidden Contention 34Sunday, 13 November 11
  35. 35. Cache Line Padding public class PaddedAtomicLong extends AtomicLong { public volatile long p1, p2, p3, p4, p5, p6 = 7L; //... lines omitted public long sumPaddingToPreventOptimisation() { return p1 + p2 + p3 + p4 + p5 + p6; } } 35Sunday, 13 November 11
  36. 36. Summary • Concurrency is a tool • Ordering and visibility are the key challenges • For performance the details matter • Dont believe everything you read o Come up with your own theories and test them! 36Sunday, 13 November 11
  37. 37. Q&A recruitment@lmax.comSunday, 13 November 11

×
