How To Navigate And Extend The Flex Infrastructure

  1. 1. How to Navigate and Extend the Flex Infrastructure Michael Labriola Senior Consultant digital primates IT Consulting Group Adobe Certified Instructor – Flex Adobe Certified Expert – Flex Adobe Community Expert – Flex
  2. 2. Who am I? <ul><li>Senior Consultant @ digital primates IT </li></ul><ul><li>Consulting Group means: </li></ul><ul><ul><li>I spend the majority of my day crawling through the flex infrastructure so I can teach it to others </li></ul></ul><ul><ul><li>I mentor large development teams that need to learn Flex fast when management declares it as a new direction </li></ul></ul><ul><ul><li>I am responsible for writing code that will someday be cloned thousands of times with little regard to the initial context </li></ul></ul>
  3. 3. Who am I? <ul><li>Reverse Engineer </li></ul><ul><ul><li>Deciphering how someone else’s micro-controller was programmed with an oscilloscope and a lot of Mountain Dew ® </li></ul></ul><ul><ul><li>Reading and rewriting 68k opcodes in hex </li></ul></ul><ul><ul><li>Learning through pure induction, all day, every day </li></ul></ul>
  4. 4. What is Flex? <ul><li>Flex is a product developed by Adobe which allows developers to create rich Internet applications that run in the flash player. </li></ul><ul><ul><li>Flex solves some of the frustration traditional application developers encounter when trying to create applications in Flash </li></ul></ul><ul><ul><li>Flex is generally written using two languages </li></ul></ul><ul><ul><ul><li>MXML – An XML tag based language used to define the visual layout </li></ul></ul></ul><ul><ul><ul><li>ActionScript 3 – A newer generation of the actionscript language familiar to those with a flash background </li></ul></ul></ul>
  5. 5. What are we going to talk about? <ul><li>If you give a man a fish, he will have a single meal. If you teach him to fish, he will eat all his life. </li></ul><ul><ul><li>Sure, this saying is overused but the concept is important </li></ul></ul><ul><ul><li>I am not planning on teaching how to program a Flex component… I want to teach you how to figure it out on your own </li></ul></ul>
  6. 6. What are we going to talk about? <ul><li>Knowing how to solve a problem is more important than having the solution </li></ul><ul><ul><li>I think this applies to Flex… </li></ul></ul><ul><ul><li>Warning: Does not apply in every situation. Great example: lack of a parachute </li></ul></ul>
  7. 7. What are we going to talk about? <ul><li>The solutions already exist, you don’t know where to find them </li></ul><ul><ul><li>There is more information available in terms of code samples, design patterns and general Flex know-how in the framework *already* installed with Flex than any book, blog or doc in the world. </li></ul></ul><ul><ul><li>Why aren’t you using them? </li></ul></ul>
  8. 8. What can we expect? <ul><li>We aren’t going to write code. We are going to read code </li></ul><ul><ul><li>We will review, read and talk about code in the framework and code that I wrote for this session… </li></ul></ul><ul><ul><li>You don’t need to see me type it to make it valid </li></ul></ul><ul><ul><li>I am not going to provide a bunch of rules, I am going to show you where you should look to induce these generalities </li></ul></ul>
  9. 9. What can we expect? <ul><li>Questions </li></ul><ul><ul><li>Please ask when we are covering the topic. </li></ul></ul><ul><ul><li>In this session, depth is more important than breadth. I would rather drop slides off the end and ensure you understand what I do present </li></ul></ul>
  10. 10. Sounds fine, how do we get started? <ul><li>Source Code </li></ul><ul><ul><li>For those of you that don’t know, MXML tags, such as DataGrid and Button, are really just ActionScript classes </li></ul></ul><ul><ul><li>If you want to understand how to make a component that has nodes like the Tree control but moves panes like the Accordion, what better place to look but the source code for these components </li></ul></ul>
  11. 11. Where do we find the source? <ul><li>The Flex Framework </li></ul><ul><ul><li>Flex ships with (almost) all of the source code available for your review </li></ul></ul><ul><ul><li>You can find this code under the Flex Builder 3 installation folder at </li></ul></ul><ul><ul><li>sdks3.0.0frameworksprojectsframeworksrc </li></ul></ul>
  12. 12. How do we get to the source? <ul><li>Linked Folder </li></ul><ul><ul><li>If you feel like being a bit clever (lazy) you can setup a linked folder in your project to the source directory. Doing so will give you quick access to the source </li></ul></ul><ul><ul><li>You can also press </li></ul></ul><ul><ul><li>Control-Shift-T at any time to find a class </li></ul></ul>
  13. 13. How do we get to the source? <ul><li>Organization of Packages </li></ul><ul><ul><li>Flex packages follow a consistent setup </li></ul></ul><ul><ul><li>The majority of components extended by developers reside in controls and containers </li></ul></ul>
  14. 14. How do we know where the code resides? <ul><li>The Help Files </li></ul><ul><ul><li>The Flex help files contain the package information </li></ul></ul>
  15. 15. How do we read the code? <ul><li>Conventions </li></ul><ul><ul><li>Within the framework, coding conventions such as consistent method and variable names are routinely followed </li></ul></ul><ul><ul><li>Comments and compiler metadata are used to add dialogue to the code </li></ul></ul>
  16. 16. What are the conventions? <ul><li>Naming Conventions </li></ul><ul><ul><li>MyClassName – Classes are always mixed case starting with a capital letter </li></ul></ul><ul><ul><li>myMethodName() or myVariableName – Always start lower case </li></ul></ul><ul><ul><li>STATIC_OR_CONST – Always upper case, underscore separated </li></ul></ul>
  17. 17. What else do we need to read the code? <ul><li>Access Control </li></ul><ul><ul><li>internal - (default) Visible to references inside the same package </li></ul></ul><ul><ul><li>private – visible to references inside the same class </li></ul></ul><ul><ul><li>protected – visible to references in the same class and derived classes </li></ul></ul><ul><ul><li>public – visible to references everywhere </li></ul></ul><ul><ul><li>static – specifies that a properties belongs to a class, not an instance </li></ul></ul>
  18. 18. What else do we need to read the code? <ul><li>Namespaces </li></ul><ul><ul><li>Namespaces provide further granularity to the visibility of methods and properties </li></ul></ul><ul><ul><li>use namespace mx_internal; </li></ul></ul><ul><ul><li>mx_internal function columnItemRendererFactory() </li></ul></ul>
  19. 19. Got it. What Else? <ul><li>MetaData Tags </li></ul><ul><ul><li>Reading the metadata tags can often provide as much information as the remainder of the documentation </li></ul></ul>
  20. 20. What If we don’t see what we need? <ul><li>Following Inheritance </li></ul><ul><ul><li>Control+Click or F3 causes Flex Builder to find where a given property was defined </li></ul></ul><ul><ul><li>This is particularly helpful when the property or method was defined in a different class </li></ul></ul>
  21. 21. Is this inheritance documented? <ul><li>Just as the help files show the package name, they also show the inheritance chain and where a property was originally declared </li></ul>
  22. 22. How far does it go? <ul><li>While the majority of the source code is available for your review, event dispatching and some other low level items are not present as source code </li></ul>
  23. 23. That’s it? <ul><li>Viewing code without a concept of order is useless </li></ul><ul><ul><li>Flex Components startup and execute in a very specific order, often called the component instantiation lifecycle </li></ul></ul><ul><ul><li>This lifecycle consists of a series of methods that are called by the Flex framework, not directly by the developer </li></ul></ul>
  24. 24. What are these methods? <ul><li>The lifecycle methods consist mainly of: </li></ul><ul><ul><li>commitProperties() </li></ul></ul><ul><ul><li>createChildren() </li></ul></ul><ul><ul><li>measure() </li></ul></ul><ul><ul><li>updateDisplayList () </li></ul></ul>
  25. 25. What does commitProperties do? <ul><li>commitProperties commits changes to a component. It is useful for: </li></ul><ul><ul><li>Ensuring changes happen at the same time </li></ul></ul><ul><ul><li>Ensuring that properties are set in a specific order </li></ul></ul><ul><ul><li>Ensuring properties are not set on child objects until the exist </li></ul></ul><ul><ul><li>Reducing code duplication that can occur when dependencies between properties exist </li></ul></ul>
  26. 26. What does createChildren do? <ul><li>createChildren is used to make composite components. It is responsible for: </li></ul><ul><ul><li>instantiating any visual child objects within the component </li></ul></ul><ul><ul><li>createChildren only ensures these children are created, it does NOT deal with layout or sizing </li></ul></ul>
  27. 27. What does measure do? <ul><li>measure helps determine the size of a component </li></ul><ul><ul><li>Calculates the default size/default minimum size of a component. Parent objects have the ultimate say on sizing a component. Measure provides a ‘suggestion’ to the parent of this component </li></ul></ul><ul><ul><li>This method is only called if Flex needs to derive the size. It is not called if a explicit height and width are set </li></ul></ul>
  28. 28. What does updateDisplayList do? <ul><li>updateDisplayList is the workhorse of the Flex component </li></ul><ul><ul><li>Sizes and positions any items created in createChildren </li></ul></ul><ul><ul><li>Also responsible for drawing items like backgrounds or other graphical elements </li></ul></ul><ul><ul><li>When Flex calls updateDisplayList, it provides the width and height actually allocated for your component regardless of scaling </li></ul></ul>
  29. 29. Does that cover what I need to know? <ul><li>The order that these methods are called is still extremely important </li></ul><ul><ul><li>When a component is created either in MXML or ActionScript, the components constructor is always called </li></ul></ul><ul><ul><li><comp:MyComponent/> </li></ul></ul><ul><ul><li>OR </li></ul></ul><ul><ul><li>var comp:MyComponent = new MyComponent(); </li></ul></ul>
  30. 30. What about the rest of the methods? <ul><li>The lifecycle methods begin when a component is added to a container </li></ul><ul><ul><li>When using MXML to add a component, it is generally added to its parent container automatically </li></ul></ul><ul><ul><li>When using ActionScript, the developer manually calls the addChild method </li></ul></ul><ul><ul><li>var comp:MyComponent = new MyComponent(); </li></ul></ul><ul><ul><li>addChild( comp ); </li></ul></ul>
  31. 31. What about the rest of the methods? <ul><li>The lifecycle methods will then generally execute in this order </li></ul><ul><ul><li>commitProperties() </li></ul></ul><ul><ul><li>createChildren() </li></ul></ul><ul><ul><li>measure() </li></ul></ul><ul><ul><li>updateDisplayList() </li></ul></ul>
  32. 32. So these methods are only called once? <ul><li>createChildren() will only be called once, however, the developer can request that the other methods are called at specific times </li></ul><ul><ul><li>Calling invalidateProperties() asks Flex to call commitProperties() </li></ul></ul><ul><ul><li>Calling invalidateSize() asks Flex to call measure() </li></ul></ul><ul><ul><li>Calling invalidateDisplayList() asks Flex to call updateDisplayList() </li></ul></ul>
  33. 33. Why shouldn’t I just call the actual methods? <ul><li>Calling the invalidate* methods asks Flex to call the lifecycle methods at the appropriate time </li></ul><ul><ul><li>By using the invalidate* methods you allow Flex to effectively ‘schedule’ when these methods will be called </li></ul></ul><ul><ul><li>Doing so can increase the responsiveness of your application by decreasing the number of times a these methods are actually invoked </li></ul></ul>
  34. 34. Ok. That’s it, right? <ul><li>Yes, for now. </li></ul><ul><ul><li>Let’s take a tour of the framework and try to solve a real world problem using your newfound knowledge </li></ul></ul>
  35. 35. Review Time <ul><ul><li>The Flex framework has a tremendous amount of code available for review </li></ul></ul><ul><ul><li>It is, in my opinion, the single best way to learn Flex </li></ul></ul><ul><ul><li>Understanding where to look for these solutions means you have a virtually infinite resource of solid code and design patterns </li></ul></ul>
  36. 36. Where to go from here? <ul><ul><li>Read my blog ‘codeSlinger’… because I said so </li></ul></ul><ul><ul><ul><li> </li></ul></ul></ul><ul><ul><li>Everyone at digitalprimates </li></ul></ul><ul><ul><ul><li> </li></ul></ul></ul><ul><ul><li><michigan:FlexCamp/> on July 30 th and 31st </li></ul></ul><ul><ul><ul><li> </li></ul></ul></ul>
  37. 37. How to Navigate and Extend the Flex Infrastructure Michael Labriola Senior Consultant digital primates IT Consulting Group Adobe Certified Instructor – Flex Adobe Certified Expert – Flex Adobe Community Expert – Flex
