TutorialAccounting for uncertainty in species delineation during the analysis of environmental DNA sequence data<br />Jeff...
DNA-based taxonomic approaches and biodiversity estimation<br /><ul><li>The current biodiversity crisis has lead some to a...
Therefore, a major imperative in bioinformatics is the development of theoretical and practical approaches for generating ...
This is especially true for taxa that are relatively understudied from a taxonomic perspective (particularly microorganism...
A promising approach utilizes a mixed model that differentiates speciation events from population coalescent events based ...
Probabilistic diversity estimation with uncertain species boundaries <br />(using GMYC and model averaging)<br />Extension...
<ul><li>R is available at http://cran.r-project.org/.
The commands to enter are preceded by ‘> ‘, modify these as appropriate for your data; notes are entered after the ‘#’ sym...
‘Powell_supplemental_script.R’ contains functions for GMYC model averaging and most of the code used here; is available at...
Can open the source file with a text editor (e.g. Notepad, TextEdit)<br /><ul><li>These R packages (and their dependencies...
 Downloads and installs ‘igraph’ package<br /> Downloads and installs ‘vegan’ package<br /> Downloads and installs ‘gto...
‘ape’ and ‘paran’ are also required by the ‘splits’ package<br />‘splits’ needs to be installed from source, use the follo...
Read functions into R from source file in the working directory; calls to load required packages are also in source file<b...
Read tree into R; normally would read tree from file in working directory:<br />Newick format: “read.tree(‘treefile.phylo’...
Plot tree; needs to be ultrametric, meaning the distance from root to each tip is the same<br /> Can check with ‘is.ultra...
Plot the accumulation of branches (N) though time; GMYC model used to detect abrupt changes in this accumulation rate<br />
Fit the GMYC model to the tree using the single-threshold method (“method=‘s’”)<br /><ul><li>Results are stored in object ...
The model is fit using each node (first column) as the threshold, from the second to the last branching event (age in seco...
The last three columns are for diagnostic purposes (convergence warnings, number of iterations, and number of clusters), n...
<ul><li>Less than one minute to run single-threshold procedure
Time required increases with tree size</li></li></ul><li>Summary of results<br /> Comparison of the ML model (five paramet...
Fit the GMYC model to the tree using the multiple-thresholds method (“method=‘m’”)<br /><ul><li>Results are stored in obje...
Procedure starts by placing single threshold at a fixed point in the tree, then introducing additional thresholds closer t...
Model likelihood is printed to screen when improvement is observed
Procedure finished when improvements over null model or earlier GMYC models are no longer found</li></li></ul><li><ul><li>...
Increases (approximately exponentially) with tree size, decreases if multiple thresholds not detected</li></li></ul><li>Su...
Calculate AICc scores for GMYC models using different thresholds<br /> Specify object(s) containing GMYC model output fit ...
Generate some summary output: specify object contain model scores calculations; specify cutoff for maximum delta AICc to p...
Generate some summary output, continued:<br />Output:<br /> Models ranked by increasing delta AICc; last column (spilled o...
Generate some summary output, continued:<br />Output:<br /> Model-averaged parameter estimates  (this output does not acco...
Estimate number of clusters, entities (clusters + singletons), Shannon diversity; also estimate variance associated with t...
Calculate pairwise probabilities that tips co-occur within GMYC clusters<br /> Specify object containing model scores calc...
Visual representation of cluster sizes, uncertainty; probabilities range from white (1) to red (0); x- and y-axis labels a...
Plot tree, numbers above branches represent probabilities that all tips nested within node exist in a single GMYC cluster ...
Plot to file, specify dimensions (in inches) to plot over larger area<br /> Open connection<br /> Plot to file<br /> Close...
File found in working directory; numbers above branches represent probabilities that all tips nested within node exist in ...
Finish session:<br /> Show all objects in the workspace<br /> Quit R; specifying ‘y’ to save image will result in this wor...
Reload session to demonstrate sample-specific diversity estimates:<br /> Show working directory (started here)<br /> Show ...
