Stateful SOAP Webservices with Java and PHP
International PHP Conference 2008 – Spring Edition
Thorsten Rinne
Introduction

❙ Thorsten Rinne
❙ 31 years old
❙ Graduated in computer science
❙ Project manager at Mayflower GmbH, Munich
...
Summary

❙ Introduction
❙ SOAP and PHP
❙ Stateful SOAP Webservices
❙ Implemention
❙ Real world example
❙ Questions and ans...
What is SOAP?

❙ SOAP is a protocol for exchanging XML-based messages
  over computer networks
❙ It uses HTTP, HTTPS or SM...
A simple SOAP message

❙ Simple structure of a SOAP message

 <?xml version=quot;1.0quot;?>
 <s:Envelope
  xmlns:s=quot;ht...
Using SOAP with PHP

❙ ext/soap can be used to write SOAP servers and clients
❙ Support of subsets of SOAP 1.1, SOAP 1.2 a...
Stateful SOAP Webservices

❙ By default, SOAP webservices are stateless
❙ A stateful SOAP webservice is a webservice that ...
Implementation

Apache Axis2 example:

<wsa:ReplyTo>
   <wsa:Address>
      http://www.w3.org/2005/08/addressing/anonymous...
PHP implementation

❙ ext/soap doesn‘t support SOAP sessions
❙ Would be possible with WSO2 Web Services
  Framework/PHP (W...
PHP implementation (I)

class MyProject_SOAPClient extends SoapClient
{
    public function __doRequest($request, $locatio...
PHP implementation (II)

class OurService {
    /* … */
    $axis2session = $this->_getSoapSession($this->soapClient->__ge...
Welcome to the real world

❙ Various applications based on
   ❙ Java (main application)
   ❙ Excel with a included DLL wri...
Welcome to the real world!
      Old architecture

                                     Microsoft Office Client PC

      ...
Welcome to the real world!
  Current architecture
             J2EE Cluster (Calculation engine)
                         ...
Questions and answers




                        Stateful SOAP Webservices
                         © MAYFLOWER GmbH 2008 15
Thank you very much!

Thorsten Rinne, Dipl.-Inf. (FH)
Mayflower GmbH
Mannhardtstraße 6
D-80538 München
Germany
+49 (89) 24...
Upcoming SlideShare
Loading in …5
×

Stateful SOAP Webservices

14,731 views

Published on

Published in: Technology
0 Comments
2 Likes
Statistics
Notes
  • Be the first to comment

No Downloads
Views
Total views
14,731
On SlideShare
0
From Embeds
0
Number of Embeds
439
Actions
Shares
0
Downloads
192
Comments
0
Likes
2
Embeds 0
No embeds

No notes for slide

Stateful SOAP Webservices

  1. 1. Stateful SOAP Webservices with Java and PHP International PHP Conference 2008 – Spring Edition Thorsten Rinne
  2. 2. Introduction ❙ Thorsten Rinne ❙ 31 years old ❙ Graduated in computer science ❙ Project manager at Mayflower GmbH, Munich ❙ Reporting applications ❙ Critical bank applications ❙ PHP Consulting ❙ PHP software development since 1999 ❙ Founder and main developer of Open Source FAQ- management software phpMyFAQ since 2001 ❙ Zend Certified Engineer (PHP 5) Stateful SOAP Webservices © MAYFLOWER GmbH 2008 2
  3. 3. Summary ❙ Introduction ❙ SOAP and PHP ❙ Stateful SOAP Webservices ❙ Implemention ❙ Real world example ❙ Questions and answers Stateful SOAP Webservices © MAYFLOWER GmbH 2008 3
  4. 4. What is SOAP? ❙ SOAP is a protocol for exchanging XML-based messages over computer networks ❙ It uses HTTP, HTTPS or SMTP ❙ SOAP is the successor of XML-RPC ❙ Advantages ❙ using SOAP over HTTP allows for easier communication through proxies and firewalls ❙ platform independent ❙ language independent ❙ Disadvantages ❙ Slower than technologies like CORBA ❙ Bad performance with binary data Stateful SOAP Webservices © MAYFLOWER GmbH 2008 4
  5. 5. A simple SOAP message ❙ Simple structure of a SOAP message <?xml version=quot;1.0quot;?> <s:Envelope xmlns:s=quot;http://www.w3.org/2001/12/soap-envelopequot;> <s:Header> </s:Header> <s:Body> </s:Body> </s:Envelope> Stateful SOAP Webservices © MAYFLOWER GmbH 2008 5
  6. 6. Using SOAP with PHP ❙ ext/soap can be used to write SOAP servers and clients ❙ Support of subsets of SOAP 1.1, SOAP 1.2 and WSDL 1.1 specifications ❙ No built-in support for WS-Addressing! ❙ SOAP server $server = new SoapServer('some.wsdl', array('soap_version' => SOAP_1_2)); ❙ SOAP client $client = new SoapClient('some.wsdl', array('soap_version' => SOAP_1_2)); Stateful SOAP Webservices © MAYFLOWER GmbH 2008 6
  7. 7. Stateful SOAP Webservices ❙ By default, SOAP webservices are stateless ❙ A stateful SOAP webservice is a webservice that maintains state information between message calls ❙ Session ID is stored in the SOAP header with WS-Addressing (WS-A) ❙ How do stateful SOAP webservices work? ❙ Request by SOAP client CS ❙ SOAP session will be created by SOAP server ❙ Response from SOAP server to SOAP client with Session ID CS ❙ More interaction between client and server ❙ Used in mulit-user environments with multiple requests/responses Stateful SOAP Webservices © MAYFLOWER GmbH 2008 7
  8. 8. Implementation Apache Axis2 example: <wsa:ReplyTo> <wsa:Address> http://www.w3.org/2005/08/addressing/anonymous </wsa:Address> <wsa:ReferenceParameters> <axis2:ServiceGroupId xmlns:axis2= quot;http://ws.apache.org/namespaces/axis2quot;> urn:uuid:65E9C56F702A398A8B11513011677354 </axis2:ServiceGroupId> </wsa:ReferenceParameters> </wsa:ReplyTo> Stateful SOAP Webservices © MAYFLOWER GmbH 2008 8
  9. 9. PHP implementation ❙ ext/soap doesn‘t support SOAP sessions ❙ Would be possible with WSO2 Web Services Framework/PHP (WSO2 WSF/PHP) extension ❙ We have to overwrite the SoapClient::__doRequest() method from PHP to implement WS-Addressing support ❙ First, we have to add a WS-A class written by Rob Richards (http://www.cdatazone.org/files/soap-wsa.phps) ❙ Parses to the SOAP XML header ❙ Sets the session ID ❙ Also support for WS-Security (WS-S) if needed Stateful SOAP Webservices © MAYFLOWER GmbH 2008 9
  10. 10. PHP implementation (I) class MyProject_SOAPClient extends SoapClient { public function __doRequest($request, $location, $saction, $version) { $dom = new DOMDocument(); $dom->loadXML($request); $wsasoap = new WSASoap($dom); $wsasoap->addAction($saction); $wsasoap->addTo($location); $wsasoap->addMessageID(); // Sets the session ID $wsasoap->addReplyTo(); $request = $wsasoap->saveXML(); return parent::__doRequest($request, $location, $saction, $version); } } Stateful SOAP Webservices © MAYFLOWER GmbH 2008 10
  11. 11. PHP implementation (II) class OurService { /* … */ $axis2session = $this->_getSoapSession($this->soapClient->__getLastResponse()); $soapHeader = new SoapHeader('http://ws.apache.org/namespaces/axis2', 'ServiceGroupId',$axis2session); $this->soapClient->__soapCall('getData', array(), null, $soapHeader); /* … */ private function _getSoapSession($response) { $soapsession = ''; $xml = new XMLReader(); $xml->XML($response); while ($xml->read()) { if (strpos($xml->name, 'axis2:ServiceGroupId') !== false) { $xml->read(); $soapsession = $xml->value; $xml->read(); } } return $soapsession; } Stateful SOAP Webservices } © MAYFLOWER GmbH 2008 11
  12. 12. Welcome to the real world ❙ Various applications based on ❙ Java (main application) ❙ Excel with a included DLL written in C++ ❙ Access/Visual Basic ❙ Web application in PHP (our project) ❙ All applications were using the same calculation logic but implemented in different programming language ❙ Big problems when the logic changes ❙ Solution ❙ Migration of the Access tool into the PHP application ❙ Build a SOAP service on top of the Java classes ❙ Replace the C++ written library and our PHP based library with the SOAP webservice Stateful SOAP Webservices © MAYFLOWER GmbH 2008 12
  13. 13. Welcome to the real world! Old architecture Microsoft Office Client PC Microsoft Access and Excel mod_php MySQL Apache 2.0 Linux J2EE Cluster (Calculation engine) Stateful SOAP Webservices © MAYFLOWER GmbH 2008 13
  14. 14. Welcome to the real world! Current architecture J2EE Cluster (Calculation engine) Microsoft Office Client PC Transfer by SFTP SOAP over HTTPS SOAP SOAP mod_php Axis2 java.class MySQL Apache 2.0 Tomcat 5.5 Linux Stateful SOAP Webservices © MAYFLOWER GmbH 2008 14
  15. 15. Questions and answers Stateful SOAP Webservices © MAYFLOWER GmbH 2008 15
  16. 16. Thank you very much! Thorsten Rinne, Dipl.-Inf. (FH) Mayflower GmbH Mannhardtstraße 6 D-80538 München Germany +49 (89) 24 20 54 – 31 thorsten.rinne@mayflower.de

×
