DevOps for PHP

  1. 1. DevOps for PHP Florian Anderiasch I October 28, 2011 © Mayflower GmbH 2010
  2. 2. Developer Ex-Admin DevOp? „I rant a lot“ @anderiasch stay in touch! Mayflower GmbH I 2
  3. 3. Do you know DevOps? Mayflower GmbH I 3
  4. 4. „These are cool tools!“ => „I'm doing DevOps now!“ Mayflower GmbH I 4
  5. 5. It's not about the tools! Mayflower GmbH I 5
  6. 6. It's about the culture! Mayflower GmbH I 6
  7. 7. Mayflower GmbH I 7
  8. 8. Coming from WebOps We often don't have much operations personnel. LAMP stack is our home Mayflower GmbH I 8
  9. 9. Learn from each other! Work together! Mayflower GmbH I 9
  10. 10. From ops to dev: repeatability change management monitoring provisioning Mayflower GmbH I 10
  11. 11. From dev to ops: unit tests version control agile methods Mayflower GmbH I 11
  12. 12. Why DevOps? Mayflower GmbH I 12
  13. 13. How many releases per year? Mayflower GmbH I 13
  14. 14. Some people do up to 60 per day Mayflower GmbH I 14
  15. 15. We're striving for one per day. For now. Mayflower GmbH I 15
  16. 16. We've come a long way Mayflower GmbH I 16
  17. 17. Development in the dark ages Mayflower GmbH I 17
  18. 18. Golden Image VMware/KVM Mayflower GmbH I 18
  19. 19. Copying files over FTP to a shared host Mayflower GmbH I 19
  20. 20. rsync /vcs checkout Mayflower GmbH I 20
  21. 21. Mayflower GmbH I 21
  22. 22. Hardware = Software = Configuration Mayflower GmbH I 22
  23. 23. OK, tools are important. Mayflower GmbH I 23
  24. 24. Bad news: they love ruby Mayflower GmbH I 24
  25. 25. Good news: There are DSLs Mayflower GmbH I 25
  26. 26. But in the end: It works Mayflower GmbH I 26
  27. 27. Going from: do X or Y Towards: I want state Z Mayflower GmbH I 27
  28. 28. Don't reinvent the wheel. Mayflower GmbH I 28
  29. 29. puppet modules apache, nginx, varnish php, ruby, tomcat mysql, pgsql, memcache Mayflower GmbH I 29
  30. 30. Monitoring Mayflower GmbH I 30
  31. 31. http://www.puppetlabs.com/puppet/related-projects/dashboard/ Mayflower GmbH I 31
  32. 32. Mayflower GmbH I 32
  33. 33. Vagrant I know how I want my servers to look like Let's replicate that for development as close as possible Mayflower GmbH I 33
  34. 34. Vagrant Based on VirtualBox automatically create VMs puppet or chef included Mayflower GmbH I 34
  35. 35. Vagrant Fully versioned configs On-Demand creation Developer Self Service Mayflower GmbH I 35
  36. 36. Getting started in 3 easy steps Mayflower GmbH I 36
  37. 37. Manage your setup with Vagrant and VeeWee (needs VirtualBox and Ruby) Mayflower GmbH I 37
  38. 38. $ gem install vagrant $ gem install veewee $ vagrant basebox templates $ vagrant basebox define 'natty' 'ubuntu-11.04-server-amd64' $ vagrant basebox build 'natty' $ vagrant basebox export natty $ vagrant box add 'natty' 'natty.box' Mayflower GmbH I 38
  39. 39. http://vagrantbox.es Mayflower GmbH I 39
  40. 40. $ gem install vagrant $ vagrant box add maverick64 http://mathie- vagrant-boxes.s3.amazonaws.com/maverick64.box $ mkdir maverick_demo $ cd maverick_demo $ vagrant init maverick64 $ vagrant up $ vagrant ssh vagrant@maverick64:~$ Mayflower GmbH I 40
  41. 41. Manage your configuration Mayflower GmbH I 41
  42. 42. Mayflower GmbH I 42
  43. 43. Chef or Puppet Mayflower GmbH I 43
  44. 44. - Configuration as Code - Client-only or Client-Server setup - backed by companies - officially supported by Amazon - tried and tested - good documentation - good, vibrant communities Mayflower GmbH I 44
  45. 45. - Chef is ruby code, puppet has a DSL - puppet has the bigger community - puppet has more documentation - but chef is catching up - puppet: europe, chef: USA - chef is more flexible - if you puppet, you don't know ruby and vice versa Mayflower GmbH I 45
  46. 46. - both know current configuration - you define your nodes (servers) - lots of community cookbooks/modules - easy to extend - templates - providers as platform abstractions (e.g. apt-get/ports/yum) Mayflower GmbH I 46
  47. 47. There's no „better“ tool. But we prefer puppet. Less Ruby ;) Mayflower GmbH I 47
  48. 48. user { 'florian': ensure => present, uid => '507', gid => 'admin', shell => '/bin/bash', home => '/home/florian', managehome => true, } Mayflower GmbH I 48
  49. 49. user „florian“ do username „florian“ password „$1$P$WXmqrQEVj88fVTHevErxq.“ shell „/bin/bash“ system true supports :manage_home => true end Mayflower GmbH I 49
  50. 50. Back to Vagrant Mayflower GmbH I 50
  51. 51. Vagrant::Config.run do |config| config.vm.box = „natty“ end Mayflower GmbH I 51
  52. 52. $ cat Vagrantfile Vagrant::Config.run do |config| config.vm.provision :puppet, :module_path => „modules“ do |puppet| puppet.manifests_path = „manifests“ puppet.manifest_file = „development.pp“ end config.vm.define :web do |web_config| web_config.vm.box = „natty“ web_config.vm.host_name = „webserver01“ web_config.vm.network „33.33.33.10“ web_config.vm.forward_port „http“,80,8080 web_config.vm.port „ssh“,22,2222 web_config.vm.share_folder „v- data“,“/srv/www“,“../silex-demo“ end end Mayflower GmbH I 52
  53. 53. $ cat manifests/development.pp import „classes/*“ node „webserver01“ { include web } node „dbserver01“ { include db } node „ciserver01“ { include ci } Mayflower GmbH I 53
  54. 54. $ cat manifests/classes/web.pp class web inherits basenode { include apache include apache::php apache::vhost { 'silex-demo.local': port => '80', docroot => '/srv/www/docroot', } package { ['mysql-client','php5-cli',...]: ensure => present, } } Mayflower GmbH I 54
  55. 55. $ cat manifests/classes/ci.pp class ci inherits basenode { include apache include apache::php exec { 'pear-autodiscover': command => '/usr/bin/pear config-set auto_discover 1', } package{ ['pear.phpunit.de/PHP_CodeBrowser',...]: ensure => latest, provider => 'pear', require => Exec['pear-autodiscover'], } } Mayflower GmbH I 55
  56. 56. Make the configuration part of your source code Mayflower GmbH I 56
  57. 57. . |-- application |-- data |-- docs |-- library |-- public |-- scripts | |-- jobs | |-- build | -- configuration | |-- Vagrantfile | |-- manifests | -- modules |-- temp -- tests Mayflower GmbH I 57
  58. 58. Why did I do that? Mayflower GmbH I 58
  59. 59. Simple Failsafe Fast Setup Repeatable Consistent Self-Service Mayflower GmbH I 59
  60. 60. No more golden images! Mayflower GmbH I 60
  61. 61. No more USB sticks! Mayflower GmbH I 61
  62. 62. Just one directory in your vcs Mayflower GmbH I 62
  63. 63. Machine Life Cycle Management: Foreman Mayflower GmbH I 63
  64. 64. A frontend for puppet Shows the system inventory Create new machines Provisioning Mayflower GmbH I 64
  65. 65. Mayflower GmbH I 65
  66. 66. Mayflower GmbH I 66
  67. 67. I want more! Like 20+ Mayflower GmbH I 67
  68. 68. McCloud wrapper around Vagrant and Fog transparent local & cloud usage Mayflower GmbH I 68
  69. 69. I want more! Like 500... Mayflower GmbH I 69
  70. 70. mCollective ssh-for-loop on steroids fast management for loads of servers uses puppet/facter, MQ-based Mayflower GmbH I 70
  71. 71. $ mc-package -W "architecture=x86" status apache * [ ==================================> ] 10 / 10 host01.example.com version = apache-2.2.9-7 host02.example.com version = apache-2.2.9-7 host03.example.com version = apache-2.2.9-7 host04.example.com version = apache-2.2.9-7 host05.example.com version = apache-2.2.9-7 host06.example.com version = apache-2.2.9-7 host07.example.com version = apache-2.2.9-7 host08.example.com version = apache-2.2.9-7 host09.example.com version = apache-2.2.9-7 host10.example.com version = apache-2.2.9-7 ---- package agent summary ---- Nodes: 10 / 10 Versions: 10 * 0.25.5-1.el5 Elapsed Time: 1.03 s Mayflower GmbH I 71
  72. 72. DevOps @Mayflower Mayflower GmbH I 72
  73. 73. 1-2 „admins“ per team Mayflower GmbH I 73
  74. 74. Operations and Development Mayflower GmbH I 74
  75. 75. Working hand in hand with company admins Mayflower GmbH I 75
  76. 76. Got root? Yes. Mayflower GmbH I 76
  77. 77. 1+n puppetmaster 1 central n teams Mayflower GmbH I 77
  78. 78. Example setup: puppetmaster 10 developer VMs Jenkins 4x Staging (eucalyptus) 4x Live (Amazon) Mayflower GmbH I 78
  79. 79. More tools: gitorious eucalyptus cloud proxmox Mayflower GmbH I 79
  80. 80. In the works: Vagrant Scrum => Kanban Puppet + Nagios Mayflower GmbH I 80
  81. 81. Questions? Mayflower GmbH I 81
  82. 82. Thanks for listening! Contact Florian Anderiasch florian.anderiasch@mayflower.de +49 89 242054 1134 @anderiasch Mayflower GmbH Mannhardtstrasse 6 29.10.11 80538 München Mayflower GmbH 82
  83. 83. Images Domo-Kun(5) http://www.hawaiikawaii.net/2011/domo-kun-wallpaper-on-my-desktop/ Domo-Kun(6), Nina Helmer, CC-BY-NC-ND http://www.flickr.com/photos/origami_potato/3242174542/ Clouds (21), John Mueller, CC-BY-NC-ND http://www.flickr.com/photos/johnmueller/52621490/ Domo-Kun (23) http://i572.photobucket.com/albums/ss163/xxLoveorDie54xx/OMG-Its-Domo-kun.jpg puppet-dashboard (31) http://puppetlabs.com/puppet/related-projects/dashboard/ Mayflower GmbH I 83
