Switching on My Ears<br />A case study: Designing a hand held device for bionic implant recipients<br />Matt Morphett<br /...
Rami 1 – Cochlear<br />		The extent 	of hearing 		loss<br />14 in 1,000 adults (>16 years) are severely to profoundly deaf...
Cochlear™<br />Original creators and developers of multichannel cochlear implant technology <br />Commitment to hearing in...
-  Bernard Coen – FOX News Presenter, 40 Years<br />
How does it work?<br />Nucleus CP810sound processor<br />Nucleus CI512cochlear implant<br />NEWNucleus CR110remote assista...
Limits to Growth? <br />Large install base<br />+<br />Projected growth<br />
Limits to Growth? <br />Before Implantation<br />After Implantation<br />Surgeon<br />CI Audiologist<br />CI Audiologist<b...
Limits to Growth? <br />Before Implantation<br />After Implantation<br />Home<br />Surgeon<br />CI Audiologist<br />CI Aud...
The Switch-On<br />http://youtu.be/YWe6iJmHKUE<br />
The Business Requirement<br />Existing Requirements<br />Suit Wide Range of Users / Hearing Configurations<br />Cater For ...
Minimise Change Management
Maintain Backwards  & Sideways Compatibility
Establish Extensible Platform – Start With Scalability Suite</li></ul>?<br />
Deliberately Unstructured Research<br />Recipient Appointments With Audiologists<br />Sat in on Clinical Trials With CI Re...
Followed Twitter Accounts for the Deaf Community
Downloaded iPhone Rehabilitation Apps
Wore the Cochlear Test Rig Around for a Day
Spoke to the Support-Line Manager
Looked Outside the Industry
Undertook Usability Testing
Taught Preschoolers About Cochlear Implants.</li></li></ul><li>Who Are Our Users?<br />Timid<br />Adventurous<br />Primary...
Carers</li></ul>Tertiary Personas<br /><ul><li>Clinicians</li></li></ul><li>What Do Users Need To Do? <br />Adjust their h...
Sound coming in
Identify / Troubleshoot Issues</li></ul>Establish their own hearing configuration<br />…. + Dozens of other things<br />
Taking Cues<br />Bespoke Mobile Device<br />Battery<br />Websites<br />Amazon, Xero, etc.<br />Screen<br />Comms<br />Best...
Early Device Mock-ups<br />Dedicated Buttons<br />Pros<br />Fastest, simplest access to features<br />Cons<br />Not easily...
The Main Navigation Paradigm<br />The Carousel<br />Benefits<br />Recognisable<br />Learnable / Logical<br />Efficient<br ...
Good Design…<br />Volume<br />Sensitivity<br />Detailed Hearing<br />Adjustments<br />Settings<br />Home /Environmnts<br /...
Volume<br />Sensitivity<br />Detailed Hearing<br />Adjustments<br />Settings<br />Home /Environmnts<br />Check Status<br /...
Lessons…<br />
Upcoming SlideShare
Loading in …5
×

“Switching on my ears” a case study: Designing a hand held device for bionic implant recipients

1,770 views

Published on

Designing a physical hand-held device presents a number of unique challenges. Designing that device predominantly for use by folks with impaired physical abilities introduces another layer of complexity. Ensuring that the experience is appropriate for an audience ranging from five year-old kids to ninety five year-old retirees while they control one of their primary senses is just downright difficult.

Matt & Shane recently worked with Australian innovator and international success story Cochlear in design of a new device to help bionic ear implant recipients monitor and control their hearing. The design represented an evolution to a simpler more usable second-generation device.

Matt & Shane are joined by Cochlear Technical Product Lead (and some time “User Fairy”) Rami Banna as they walk through key aspects of this project.

Particular attention is given to:

Design artefacts including wireframes and screen mock-ups illustrating the evolution from early design concepts through to refined user interface.
The full UX lifecycle including; ethnographic research, iterative interaction design cycles and usability testing with real Cochlear implant recipients.
The approach taken to coordinate a design exercise across multiple teams including; industrial design, ergonomics, electronics, software design, graphic design and small screen user interface design.
The delicate balance required when attempting to improve a user experience without completely confounding the expectations of a large and vocal existing user-base.
The objective of this case study is to provide conference delegates with genuine insight into the design process by exposing the methods but also by showing the actual designs at various points of their development.

Along the way, we will detail the pitfalls encountered and outline the practical solutions that were applied. Processes and lessons learned are applicable across UX projects of all types, not just mobile and hand-held product design projects.

  • Be the first to comment

  • Be the first to like this

“Switching on my ears” a case study: Designing a hand held device for bionic implant recipients

  1. 1. Switching on My Ears<br />A case study: Designing a hand held device for bionic implant recipients<br />Matt Morphett<br />matt@amberdew.com.au<br />twitter: @mattmorphett<br />Shane Morris<br />shane@automaticstudio.com.au<br />twitter: @shanemo<br />Rami Banna<br />RBanna@cochlear.com<br />
  2. 2. Rami 1 – Cochlear<br /> The extent of hearing loss<br />14 in 1,000 adults (>16 years) are severely to profoundly deaf.<br /> 80 in 1,000 elderly adults (>70 years) are severely to profoundly deaf.<br />“We” have treated < 5% of prevalence<br />
  3. 3. Cochlear™<br />Original creators and developers of multichannel cochlear implant technology <br />Commitment to hearing innovation<br />Over 230,000 Cochlear and Baha recipients worldwide<br />Partner with researchers in 19 countries and more than 1000 clinics around the world<br />R&D investment – $AUD 100 million in 2009.<br />#1 choice of cochlear implant recipients1<br />Baha® successfully used for >30 years<br />1. Hearing Aid Market Report 2010 Koncept Analytics<br />
  4. 4. - Bernard Coen – FOX News Presenter, 40 Years<br />
  5. 5. How does it work?<br />Nucleus CP810sound processor<br />Nucleus CI512cochlear implant<br />NEWNucleus CR110remote assistant<br /> Custom Sound™ Suite 3.0<br />Cochlear™ Nucleus® 5 System<br />
  6. 6. Limits to Growth? <br />Large install base<br />+<br />Projected growth<br />
  7. 7. Limits to Growth? <br />Before Implantation<br />After Implantation<br />Surgeon<br />CI Audiologist<br />CI Audiologist<br />
  8. 8. Limits to Growth? <br />Before Implantation<br />After Implantation<br />Home<br />Surgeon<br />CI Audiologist<br />CI Audiologist<br />
  9. 9. The Switch-On<br />http://youtu.be/YWe6iJmHKUE<br />
  10. 10. The Business Requirement<br />Existing Requirements<br />Suit Wide Range of Users / Hearing Configurations<br />Cater For Many More Features Than There Are Buttons<br />Be Smaller Than a Mobile<br />More Useful Than a Credit Card Sized Remote<br />New Requirements<br /><ul><li>Demonstrably (testably) Better Than Existing UI
  11. 11. Minimise Change Management
  12. 12. Maintain Backwards & Sideways Compatibility
  13. 13. Establish Extensible Platform – Start With Scalability Suite</li></ul>?<br />
  14. 14. Deliberately Unstructured Research<br />Recipient Appointments With Audiologists<br />Sat in on Clinical Trials With CI Recipients<br /><ul><li>Cochlear Implant Forums & Blogs
  15. 15. Followed Twitter Accounts for the Deaf Community
  16. 16. Downloaded iPhone Rehabilitation Apps
  17. 17. Wore the Cochlear Test Rig Around for a Day
  18. 18. Spoke to the Support-Line Manager
  19. 19. Looked Outside the Industry
  20. 20. Undertook Usability Testing
  21. 21. Taught Preschoolers About Cochlear Implants.</li></li></ul><li>Who Are Our Users?<br />Timid<br />Adventurous<br />Primary Personas<br />Elderly<br />Adult<br />Young Person<br />Secondary Personas<br /><ul><li>Parents
  22. 22. Carers</li></ul>Tertiary Personas<br /><ul><li>Clinicians</li></li></ul><li>What Do Users Need To Do? <br />Adjust their hearing<br />Select a Program<br />Change Volume<br />Telecoil<br />Check that everything is OK<br /><ul><li>Battery levels
  23. 23. Sound coming in
  24. 24. Identify / Troubleshoot Issues</li></ul>Establish their own hearing configuration<br />…. + Dozens of other things<br />
  25. 25. Taking Cues<br />Bespoke Mobile Device<br />Battery<br />Websites<br />Amazon, Xero, etc.<br />Screen<br />Comms<br />Best Practice<br />Wroblewski, Nielsen, Tidwell<br />Butt.<br />Butt.<br />Web Standards<br />HTML / CSS<br />Dynamic Web<br />The Web UX Stack<br />W3C etc.<br />Fields, RBs, Dropdowns, etc.<br />Javascript, Flash, etc.<br />Butt.<br />Browser<br />Back, Next, Scrolling, etc.<br />Functions<br />Electronics<br />Butt.<br />Butt.<br />Butt.<br />OS<br />GUI Guidelines<br />Reqs.<br />Hardware<br />Butt.<br />Butt.<br />Mouse & Keyboard<br />Butt.<br />Butt.<br />Butt.<br />Connex<br />Connex<br />
  26. 26. Early Device Mock-ups<br />Dedicated Buttons<br />Pros<br />Fastest, simplest access to features<br />Cons<br />Not easily extended with new features<br />Some buttons not required by some users<br />Novel Vertical Carousel<br />Pros<br />Faster, flatter navigation<br />Easily extended with new features<br />Cons<br />Reliability / cost concerns<br />Carousel Navigation<br />Pros<br />Easily extended with new features<br />Consistent usable navigation<br />Cons<br />Reaching deep settings inefficient<br />Each button does multiple things<br />Existing<br />Device<br />
  27. 27. The Main Navigation Paradigm<br />The Carousel<br />Benefits<br />Recognisable<br />Learnable / Logical<br />Efficient<br />Staged access to features<br />Extensible<br />All main features available from main screen.<br />
  28. 28. Good Design…<br />Volume<br />Sensitivity<br />Detailed Hearing<br />Adjustments<br />Settings<br />Home /Environmnts<br />Check Status<br />Setting<br />Setting<br />Setting<br />Setting<br />Setting<br />Setting<br />Setting<br />Setting<br />…Reflects Behavior<br />Adjustments<br />Adjustments<br />Adjustments<br />Adjustments<br />Occasional<br />Tasks<br />Home<br />Daily Tasks<br />Rare Tasks<br />Adj.<br />Adj.<br />Adj.<br />Adj.<br />Adj.<br />Adj.<br />Adj.<br />Adj.<br />Adj.<br />Adj.<br />Adj.<br />
  29. 29. Volume<br />Sensitivity<br />Detailed Hearing<br />Adjustments<br />Settings<br />Home /Environmnts<br />Check Status<br />Setting<br />Setting<br />Setting<br />Setting<br />Setting<br />Setting<br />Setting<br />Setting<br />…Informs Behavior<br />Adjustments<br />Adjustments<br />Adjustments<br />Adjustments<br />Adj.<br />Adj.<br />Adj.<br />Adj.<br />Adj.<br />Adj.<br />Adj.<br />Sensitivity<br />Adj.<br />Adj.<br />Adj.<br />Adj.<br />Good Design…<br />
  30. 30. Lessons…<br />
  31. 31. IntuitivityVs Efficiency<br />
  32. 32. Innovation vs Change Management<br />Innovate<br />Increment<br />
  33. 33. Pattern Matching…<br />Causing Problems<br />Setting<br />Setting<br />Setting<br />Setting<br />Setting<br />Setting<br />Setting<br />Setting<br />Suggesting Solutions<br />Volume<br />Sensitivity<br />Detailed Hearing<br />Adjustments<br />Settings<br />Home /Environmnts<br />Check Status<br />Setting<br />Setting<br />Setting<br />Setting<br />Setting<br />Setting<br />Setting<br />Adj.<br />Adj.<br />Adj.<br />Adj.<br />Adjustment<br />Adjustment<br />Adjustment<br />Adjustment<br />Adj.<br />Adj.<br />Adj.<br />
  34. 34. Moving From UI to UX<br />Keys to success<br />The Right UI<br />Audiologist<br />Support<br />Materials<br />Users<br />+<br />
  35. 35. Training Audiologists as Testers<br />How<br />Wrote 1st Protocol & Materials<br />Conducted 1st Round Testing<br />Bought Steve Krug’s Book<br />Observed 2nd Round Testing<br />Mentored<br />Left them to rounds 3, 4 and 5<br />Were very responsive to results<br />Benefits<br /><ul><li>SMEs Become UX Evangelists
  36. 36. Impartial Validation
  37. 37. …yet still tight, respectful relationship</li></li></ul><li>The Healthcare UX Formula<br />Patient Outcome<br />=<br /> Efficacy x Compliance<br />
  38. 38. The Healthcare UX Formula<br />Compliance<br />=<br /> Efficacy x _________<br />A whole bunch of complex human factors<br />User Experience<br />
  39. 39. Presenting Mock-ups at Target Size<br />Don’t do this…<br />…do this<br />
  40. 40. Prototype, Prototype, Prototype!<br />Paper<br />Balsamiq<br />Flowella (on Nokia & HTC)<br />Keynote -> PDF on iPhone<br />Sketchflow and Balsamiq on Windows tablet<br />New code on existing Cochlear device<br />
  41. 41. Conclusion<br />It’s different<br />…but the same<br />Seek, understand, exploit patterns<br />Present at device size…on device…ideally prototype<br />Manage innovation and change<br />Balance intuitivity and efficiency<br />Test ideas (not just complete solutions) casually.<br />
  42. 42. Thanks<br />Matt Morphett<br />matt@amberdew.com.au<br />twitter: @mattmorphett<br />Shane Morris<br />shane@automaticstudio.com.au<br />twitter: @shanemo<br />Rami Banna<br />RBanna@cochlear.com<br />

×
