Architectural Patterns for the Cloud

Maarten Balliauw
Maarten BalliauwDeveloper Advocate
APRIL 17, 2012 | SLIDE 1
Architectural Patterns for the Cloud
     Maarten Balliauw
     @maartenballiauw


APRIL 17, 2012 | SLIDE 2
Who am I?
      Maarten Balliauw
      Antwerp, Belgium
      www.realdolmen.com
      Focus on web
          ASP.NET MVC, Windows Azure, SignalR, ...
          MVP Windows Azure & ASPInsider
  http://blog.maartenballiauw.be
  @maartenballiauw
  Author: Pro NuGet - http://amzn.to/pronuget
APRIL 17, 2012 | SLIDE 4
Agenda
      Quick recap: Windows Azure
      What’s different in the cloud?
      Rethinking apps
      Conclusion


APRIL 17, 2012 | SLIDE 5
Quick recap
       Windows Azure
APRIL 17, 2012 | SLIDE 6
Windows Azure is a cloud platform
      On-demand
      Self-service
      Pay per use
      Highly automated


APRIL 17, 2012 | SLIDE 7
Windows Azure Components

               Compute                  Storage         SQL Azure      Service Bus   Connect




        BI            Marketplace                 CDN                   Caching       ACS


Application Services                Storage Services                Foundation Services



 APRIL 17, 2012 | SLIDE 8
What’s different
       in the cloud?
APRIL 17, 2012 | SLIDE 9
Differences with your infrastructure
      Uniform
      Automated
      Designed for failure
      Designed for scale
      It’s not in your datacenter

APRIL 17, 2012 | SLIDE 10
Uniform
  Every machine +/- the same
  No specialized hardware
  No specialized OS*




APRIL 17, 2012 | SLIDE 11
Demo
       Customizing the Windows Azure virtual machine
APRIL 17, 2012 | SLIDE 12
Automated
  Makes decisions on provisioning &
   updating
  Monitors health
  The platform knows what’s best
          Not necessarily for your app…


APRIL 17, 2012 | SLIDE 13
Designed for failure



UD 1


UD 2


  APRIL 17, 2012 | SLIDE 14
Designed for scale
  Scale out
  Stateless




APRIL 17, 2012 | SLIDE 15
It’s not in your datacenter
  Integration
  Authentication




APRIL 17, 2012 | SLIDE 16
Rethinking apps
       What do I have to think about?
APRIL 17, 2012 | SLIDE 17
Scenario: Newspaper website
      National & International
      Sudden spikes in usage
      Dynamic content
      Static content


APRIL 17, 2012 | SLIDE 18
Current architecture
  Will work on the cloud!
  Will fail on the cloud!




APRIL 17, 2012 | SLIDE 19
Design for failure
APRIL 17, 2012 | SLIDE 20
Assume everything will fail
      Automated service maintenance
      Compute node crash
      Storage throttling
      SQL Azure throttling
      Connectivity
      Your code
APRIL 17, 2012 | SLIDE 21
Retry everything
 SQL Azure Error 40501
 The service is currently busy. Retry the
 request after 10 seconds.

 Retry against anything that might be external
         SQL Azure, Windows Azure Storage, Service Bus, …

  http://windowsazurecat.com/2011/02/transient-fault-
  handling-framework/
APRIL 17, 2012 | SLIDE 22
The entire datacenter fails!
  Run in 2+ datacenters
  Keep data synchronized
          All data
          or limit scope



APRIL 17, 2012 | SLIDE 23
Refactoring the architecture




APRIL 17, 2012 | SLIDE 24
Windows Azure Data Centers

                                   100ms

                            50ms




APRIL 17, 2012 | SLIDE 25
Windows Azure Traffic Manager




APRIL 17, 2012 | SLIDE 26
Windows Azure Traffic Manager
  Strategies
          Round-robin
          Fail-over
          Performance (geo)
  Solves datacenter outage

APRIL 17, 2012 | SLIDE 27
Are we there yet?




APRIL 17, 2012 | SLIDE 28
Solutions to a SPOF being down
  Set a monitoring endpoint for TM
  Take the entire datacenter out of the loop

  Take the SPOF out of the story
  Degrade gracefully

APRIL 17, 2012 | SLIDE 29
Refactoring our architecture




APRIL 17, 2012 | SLIDE 30
Design for scale
       *and failure
APRIL 17, 2012 | SLIDE 31
Belgians are not used to snow


                            What will happen to our
                                architecture?



APRIL 17, 2012 | SLIDE 32
Here’s what will happen…




APRIL 17, 2012 | SLIDE 33
Solution: scale out!
  Add more VM’s!
  Autoscaling (WASABi)
          Windows Azure Autoscaling Application Block
          Enterprise Library
          http://entlib.codeplex.com/wikipage?title=WASABiBet
           aReleaseNotes&referringTitle=EntLib5Azure




APRIL 17, 2012 | SLIDE 34
Solution: scale out!
  Add more VM’s!
  Autoscaling (as-a-Service)
          www.opstera.com




APRIL 17, 2012 | SLIDE 35
Here’s what will happen…




APRIL 17, 2012 | SLIDE 36
SQL Azure
  Monitored by the platform
  The platform does not like high DB traffic
          Throttling & retries




APRIL 17, 2012 | SLIDE 37
Caching
  Most of our users are doing reads
  Cache content near where it’s needed

  Windows Azure Caching
  Blob Storage

APRIL 17, 2012 | SLIDE 38
Refactoring our architecture




APRIL 17, 2012 | SLIDE 39
Caching
  How do you populate it?
  When do you populate it?
  When do you invalidate it?




APRIL 17, 2012 | SLIDE 40
Work asynchrounously
  Read from cache
  Present? Use cache
  Not present? Ask to cache it & read from
   DB



APRIL 17, 2012 | SLIDE 41
Refactoring our architecture




APRIL 17, 2012 | SLIDE 42
A typical web request…
  1 request is dynamic
  493 requests are static*

  Get that static content out of your servers!
          Cache content near where it’s needed

APRIL 17, 2012 | SLIDE 43
Windows Azure CDN




APRIL 17, 2012 | SLIDE 44
Refactoring our architecture




APRIL 17, 2012 | SLIDE 45
Conclusion
APRIL 17, 2012 | SLIDE 46
Key takeaways
      Cloud is different
      Design for failure
      Design for scale
      Work asynchronously
      Cache close to where it’s needed
      Also think price vs. Allowed outage
APRIL 17, 2012 | SLIDE 47
One more… Learn from others!
      Amazon - http://slidesha.re/AlaHIG
      Trello - http://bit.ly/xO5G9e
      YouPorn - http://bit.ly/yUSanQ
      StackOverflow - http://bit.ly/xkLvH9
      InstaGram - http://bit.ly/xbWuzx
      … (highscalability.com)
APRIL 17, 2012 | SLIDE 48
http://blog.maartenballiauw.be
                                               @maartenballiauw




                                   http://amzn.to/pronuget
                            or Install-Package ProNuGet

THANK YOU!
APRIL 17, 2012 | SLIDE 49
