DirectAccess Technical Drilldown Part 1 IPv6 & Transition Technologies<br />John Craddock<br />Infrastructure & Security A...
DirectAccess – Simple?<br />Internet<br />Corporate intranet<br />When a DirectAccess client connects to the Internet it i...
A VPN on Steroids<br />Corporate Network<br />Pre log on<br />Patch management, health check and GPOs<br />Always On<br />...
No Gain Without Pain<br />Challenge 1<br />Uses end-to-end IPv6<br />Requires transition technologies for the Internet and...
Simple? May Be Not<br />Internet<br />Corporate intranet<br />Tunnelling technologies for the Internet and Intranet to sup...
Don’t Give Up Now<br />Part 1<br />IPv6 Intro<br />Transition Technologies<br />End-to-end connectivity<br />Part 2<br />I...
Demo Environment<br />EX1<br />DC1<br />DNS<br />DC, DNS,CA<br />WIN7<br />NAT1<br />DA1<br />Home<br />Corporate intranet...
IPv6<br />IPv6 natively supports many of the extensions that have been added to IPv4<br />IPSec<br />QoS<br />IPv6 adds<br...
Drawbacks<br />Requires a new routing infrastructure to support native IPv6<br />IPv6 can be used across IPv4 networks usi...
Layer 2<br />Link layer header<br />IPv6 header<br />Payload<br />Link layer trailer<br />IPv6 packet<br />Link layer fram...
Address Notation<br />2009:0adb:0001:56af:0321:000d:98fe:dbfe<br />Leading zeros can be removed<br />2009:adb:1:56af:321:d...
Compressing Zeros<br />2009:0000:0000:0000:0321:000d:98fe:dbfe<br />2009::0321:000d:98fe:dbfe<br />2009:0000:0000:0321:000...
IPv6 Prefix<br />/48<br />/64<br />2009:0adb:0001:56af:0321:000d:98fe:dbfe<br />The IPv6 prefix identifies the number of b...
IPv6 Addressing<br />Network Identifier<br />Host Identifier<br />64-bits<br />64-bits<br />The host component can be deri...
Link Local Address<br />Zone IDs eliminate ambiguity when more than one interface is connected to a network <br />Fe80::Ho...
Unicast Addresses<br />Unique Local address (Similar to IPv4 private address ranges)<br />FD hex<br />Routing betweenLANs ...
Host Configuration<br />Auto configure link-local address<br />DHCPv6<br />Manual configuration of otheraddresses possible...
Routing (simplified)<br />Advertise:<br />A ::/64 on link<br />::/0 next hop A:1<br />Network B<br />B:1<br />A:1<br />Adv...
IPv4<br />IPv6<br />Transition Technologies<br />IPv6 over IPv4<br />IPv6<br />Layer 7Applications<br />Router to router t...
Tunnelling <br />IPv4<br />IPv4<br />IPv6<br />IPv6<br />Tunnel<br />The tunnel end may be a single host or IPv6 network<b...
6to4 Network	<br />The 6to4 Network is an Internet based public IPv6 network<br />Addresses start with the 2002::/16 prefi...
Native IPv6 network and addressing<br />6to4 Components<br />6to4Router<br />6to4Relay<br />IPv4 Internet<br />Tunnel<br /...
6to4 Addressing<br />Host configured with a public IPv4 address <br />6to4 interface automatically enabled and assigned a ...
6to4 Host/Router to 6to4 Host<br />IPv4<br />6to4 tunnel <br />Use me to get to 2002::/16 on-link<br />IPv4 packet encapsu...
6to4 Host/Router to Native Host<br />IPv4<br />Use me to get to default gateway,  next hop 6to4 Relay<br />6to4 tunnel <br...
6to4 Configuration (reference)<br />6to4Host/Router<br />:: Set name of 6to4 relay<br />netsh interface 6to4 set relay cor...
Intra-Site Automatic Tunnel Addressing Protocol (ISATAP)<br />ISATAP is similar to 6to4 as it tunnels IPv6 within an IPv4 ...
ISATAP Components<br />NativeIPv6 Host<br />ISATAPHost<br />Native IPv6Intranet<br />ISATAP Router<br />IPv4 Intranet<br /...
ISATAP Host Configuration<br />0:5efe for a private IPv4 address<br />200:5efe for a public IPv4 address<br />The ISATAP i...
ISATAP Host Configuration<br />The host can either be configured with the address of the ISATAP router or it can resolve i...
ISATAP Host to ISATAP Host<br />IPv4<br />Use me to get to fd00:9999:0:1::/64<br />On link<br />ISATAP tunnel <br />Tunnel...
ISATAP Host to Native IPv6 Host<br />IPv4<br />Use me to get to ::/0Next hop ISATAP router<br />ISATAP tunnel <br />Tunnel...
ISATAP Configuration (reference)<br />ISATAPHost<br />No Client configuration, ISATAP interface automatically configured w...
Supporting IPv4 Only Hosts<br />For connections between IPv6 hosts and hosts that only support IPv4<br />NAT-PT and DNS-AL...
IPv4 Internet<br />IPv4 private<br />Teredo<br />NAT Device<br />Teredoserver & relay<br />TeredoHost<br />Private IPv4 ad...
Teredo Components<br />IPv6 Host<br />TeredoHost<br />NAT Device<br />IPv6Intranet<br />Tunnel<br />Teredoserver & relay<b...
IPv4 Outbound Packet translation<br />IPv4 Internet<br />IPv4 private<br />NAT Device<br />Teredoserver & relay<br />Tered...
Inbound traffic<br />IPv4 Internet<br />IPv4 private<br />NAT Device<br />Teredoserver & relay<br />TeredoHost<br />P200<b...
The Challenge	<br />NAT normally allows inbound traffic as a response to an outbound request<br />To allow any host to ini...
Initial Negotiation<br />The Teredo host connects to the Teredo server<br />The server performs tests to determine the typ...
Teredo Host Address<br />2001:0:9013:a:346b:a79:6fe6:37fe<br />IPv4 Internet<br />IPv4 private<br />NAT Device<br />Teredo...
Teredo Configuration (reference)<br />TeredoHost<br />::Enable client for Teredo<br />netsh interface ipv6 set teredoenter...
IPHTTPS<br />IPHTTPS can be used if a host behind NAT cannot tunnel using Teredo<br />Firewall blocking port 3544 <br />IP...
IPHTTPS Components<br />Web server with CRL<br />X<br />X<br />X<br />IPv6 Host<br />IPHTTPSserver<br />NAT Device<br />IP...
IPHTTPS Configuration (reference)<br />netsh interface httpstunnel add interface client <br />	https://DA1.example.com:443...
Don’t Like Netsh?<br />
Summary: Internet to Intranet <br />6to4Host/Router<br />6to4Relay<br />NAT Device<br />Teredoserver & relay<br />TeredoHo...
Summary: IPv6/IPv4 Intranet<br />IPv6<br />ISATAP Router<br />Native IPv6<br />IPv6<br />NAT-PTor NAT64<br />IPv4<br />IPv...
Don’t Give Up Now<br />Part 1<br />IPv6 Intro<br />Transition Technologies<br />End-to-end connectivity<br />Part 2<br />I...
Required Slide<br />Speakers, <br />TechEd 2009 is not producing <br />a DVD. Please announce that <br />attendees can acc...
Related Content<br />Required Slide<br />Speakers, <br />please list the Breakout Sessions, TLC Interactive Theaters and L...
My Sessions at TechEd<br />Required Slide<br />Speakers, <br />please list the Breakout Sessions, TLC Interactive Theaters...
Required Slide<br />Complete an evaluation on CommNet and enter to win an Xbox 360 Elite!<br />
Required Slide<br />© 2009 Microsoft Corporation. All rights reserved. Microsoft, Windows, Windows Vista and other product...
