SharePoint 2010  - Administration 101<br />SharePoint Saturday the ConferenceAugust 2011Chris McNulty<br />
SharePoint SpeedMetal [Admin 101](S5A-104)Admin – 200<br />Chris McNulty<br />KMA<br />Welcome to SharePoint Saturday—The ...
Welcome to SharePoint Saturday—The Conference<br />Thank you for being a part of the first SharePoint Saturday conference<...
About KMA<br />Founded 1995<br />29 employees<br />4 partners, including 2 co-founders<br /><ul><li>Principal lines of bus...
Working with SharePoint technologies since 2000/2001
20 years consulting and financial services technology (Santander, John Hancock, GMO, State Street)
MBA in Investment Management from Boston College Carroll School of Management
Write and speak often on Microsoft IW technologies (blogs & books)
Microsoft MCSE/MCTS/MSA/MVTSP
Hiking, cooking, playing guitar, colonial history, photography
My family: Hayley, three kids (16, 7, 4) and my dog Stan</li></li></ul><li>
Out Of Scope<br />Deep Dives (e.g. PowerShell, BI, Upgrade, SQL DBA)<br />Development<br />Customization<br />Design & Arc...
The dilemma<br />Architecture, Design & Planning<br />Installation and Upgrade<br />Post Installation Best Practices<br />...
<ul><li>You’re the new SharePoint Administrator!!!
But…
You’re still responsible for:
Exchange
Active Directory
SQL
Desktop
Help Desk
Network/Firewall
Cooking & Cleaning
Etc.</li></ul>Congratulations!<br />
<ul><li>SharePoint administration is often an ‘add-on’ for other IT professionals (SQL DBAs, AD Admins, Exchange Engineers)
Time and focus are scarce resources!
Common pain points include
Upgrades are complex and hard to monitor
Dispersed workforce, little control of browsers and Office versions
Hard to understand and troubleshoot “behind the scenes” performance and capacity planning
Best practices not always understood or compared to system health
“All or nothing” administration means IT must be engaged for all admin responsibilities, even search</li></ul>The Dilemma<...
Microsoft SharePoint Server 2010 … the bright frontier<br />Eastern Long Island, July 4, 2010<br />
Microsoft SharePoint 2010<br />Ribbon UI<br />SharePoint Workspace<br />SharePoint Mobile<br />Office Client and Office We...
Architecture and Design<br />
<ul><li>Typical Roles:
http services
Search query
Scaling
Add servers to load balanced cluster
Performance Optimization
RAM
Easily virtualized</li></ul>Server Farm – Web Front End<br />14<br />
<ul><li>Typical Roles:
Search index/crawl
Excel calculation
User profiles
Managed Metadata
Scaling
Add search servers and partitions
Move shared services to dedicated servers
Performance Optimization
CPU</li></ul>Server Farm - Application Server<br />15<br />
<ul><li>Typical Roles:
Data storage
SQL Reporting
Scaling
Add storage capacity
Performance Optimization
Disk I/O</li></ul>Server Farm - Database<br />16<br />
<ul><li>Typical Roles:
Small teams
Small pools of documents
Considerations
Performance & fault tolerance less of a concern
SQL & Web on same system
Search not a core function</li></ul>Sizing - Single Server<br />
<ul><li>Typical Roles:
100-10,000 users
10,000 – 1MM documents
Scenarios
Enterprise portal
Upcoming SlideShare
Loading in …5
×

SPSPTCDC - SharePoint Admin 101 - SpeedMetal - PowerUser to Admin in 75 Minutes

1,734 views

Published on

A recap of Chris McNulty's SharePoint presentation at SharePoint Saturday the Conference in August 2011.

Published in: Technology
  • Be the first to comment

SPSPTCDC - SharePoint Admin 101 - SpeedMetal - PowerUser to Admin in 75 Minutes

  1. 1. SharePoint 2010 - Administration 101<br />SharePoint Saturday the ConferenceAugust 2011Chris McNulty<br />
  2. 2. SharePoint SpeedMetal [Admin 101](S5A-104)Admin – 200<br />Chris McNulty<br />KMA<br />Welcome to SharePoint Saturday—The Conference<br />
  3. 3. Welcome to SharePoint Saturday—The Conference<br />Thank you for being a part of the first SharePoint Saturday conference<br />Please turn off all electronic devices or set them to vibrate.<br />If you must take a phone call, please do so in the hall so as not to disturb others.<br />Open wireless access is available at SSID: SPSTC2011<br />Feel free to “tweet and blog” during the session<br />Thanks to our Diamond and Platinum Sponsors:<br />
  4. 4. About KMA<br />Founded 1995<br />29 employees<br />4 partners, including 2 co-founders<br /><ul><li>Principal lines of business:</li></ul>Professional Services<br />SharePoint Consulting<br />SharePoint Managed Services<br />Custom Application Development<br />Software Product<br />Mekko Graphics advanced charting software<br /><ul><li>Roots in academia (MIT, Harvard, BU)</li></li></ul><li>Chris McNulty<br /><ul><li>KMA SharePoint Practice Lead/Manager
  5. 5. Working with SharePoint technologies since 2000/2001
  6. 6. 20 years consulting and financial services technology (Santander, John Hancock, GMO, State Street)
  7. 7. MBA in Investment Management from Boston College Carroll School of Management
  8. 8. Write and speak often on Microsoft IW technologies (blogs & books)
  9. 9. Microsoft MCSE/MCTS/MSA/MVTSP
  10. 10. Hiking, cooking, playing guitar, colonial history, photography
  11. 11. My family: Hayley, three kids (16, 7, 4) and my dog Stan</li></li></ul><li>
  12. 12. Out Of Scope<br />Deep Dives (e.g. PowerShell, BI, Upgrade, SQL DBA)<br />Development<br />Customization<br />Design & Architecture<br />Power User (e.g. Library Customization, Designer Workflows, etc.)<br />Office 365<br />Rules<br />Move fast, PowerPoint is shared<br />Questions – time permitting during session<br />Any time after session – email etc.<br />Objectives<br />
  13. 13. The dilemma<br />Architecture, Design & Planning<br />Installation and Upgrade<br />Post Installation Best Practices<br />Service/Feature Placement<br />Support<br />Monitoring and Optimization<br />Backup<br />PowerShell<br />Development Functions<br />Optimization<br />Patching<br />SQL Maintenance<br />Best Practices<br />Agenda<br />
  14. 14. <ul><li>You’re the new SharePoint Administrator!!!
  15. 15. But…
  16. 16. You’re still responsible for:
  17. 17. Exchange
  18. 18. Active Directory
  19. 19. SQL
  20. 20. Desktop
  21. 21. Help Desk
  22. 22. Network/Firewall
  23. 23. Cooking & Cleaning
  24. 24. Etc.</li></ul>Congratulations!<br />
  25. 25. <ul><li>SharePoint administration is often an ‘add-on’ for other IT professionals (SQL DBAs, AD Admins, Exchange Engineers)
  26. 26. Time and focus are scarce resources!
  27. 27. Common pain points include
  28. 28. Upgrades are complex and hard to monitor
  29. 29. Dispersed workforce, little control of browsers and Office versions
  30. 30. Hard to understand and troubleshoot “behind the scenes” performance and capacity planning
  31. 31. Best practices not always understood or compared to system health
  32. 32. “All or nothing” administration means IT must be engaged for all admin responsibilities, even search</li></ul>The Dilemma<br />
  33. 33. Microsoft SharePoint Server 2010 … the bright frontier<br />Eastern Long Island, July 4, 2010<br />
  34. 34. Microsoft SharePoint 2010<br />Ribbon UI<br />SharePoint Workspace<br />SharePoint Mobile<br />Office Client and Office Web App Integration<br />Standards Support<br />Business Connectivity Services<br />InfoPath Form Services<br />External Lists<br />Workflow<br />SharePoint Designer<br />Visual Studio<br />API Enhancements<br />REST/ATOM/RSS<br />Sites<br />Tagging, Tag Cloud, Ratings<br />Social Bookmarking<br />Blogs and Wikis<br />My Sites<br />Activity Feeds<br />Profiles and Expertise<br />Org Browser<br />Communities<br />Composites<br />PerformancePoint Services<br />Excel Services<br />Chart Web Part<br />Visio Services<br />Web Analytics<br />SQL Server Integration<br />PowerPivot<br />Content<br />Insights<br />Enterprise Content Types<br />Metadata and Navigation<br />Document Sets<br />Multi-stage Disposition<br />Audio and Video Content Types<br />Remote Blob Storage<br />List Enhancements<br />Search<br />Social Relevance<br />Phonetic Search<br />Navigation<br />FAST Integration<br />Enhanced Pipeline<br />
  35. 35. Architecture and Design<br />
  36. 36. <ul><li>Typical Roles:
  37. 37. http services
  38. 38. Search query
  39. 39. Scaling
  40. 40. Add servers to load balanced cluster
  41. 41. Performance Optimization
  42. 42. RAM
  43. 43. Easily virtualized</li></ul>Server Farm – Web Front End<br />14<br />
  44. 44. <ul><li>Typical Roles:
  45. 45. Search index/crawl
  46. 46. Excel calculation
  47. 47. User profiles
  48. 48. Managed Metadata
  49. 49. Scaling
  50. 50. Add search servers and partitions
  51. 51. Move shared services to dedicated servers
  52. 52. Performance Optimization
  53. 53. CPU</li></ul>Server Farm - Application Server<br />15<br />
  54. 54. <ul><li>Typical Roles:
  55. 55. Data storage
  56. 56. SQL Reporting
  57. 57. Scaling
  58. 58. Add storage capacity
  59. 59. Performance Optimization
  60. 60. Disk I/O</li></ul>Server Farm - Database<br />16<br />
  61. 61. <ul><li>Typical Roles:
  62. 62. Small teams
  63. 63. Small pools of documents
  64. 64. Considerations
  65. 65. Performance & fault tolerance less of a concern
  66. 66. SQL & Web on same system
  67. 67. Search not a core function</li></ul>Sizing - Single Server<br />
  68. 68. <ul><li>Typical Roles:
  69. 69. 100-10,000 users
  70. 70. 10,000 – 1MM documents
  71. 71. Scenarios
  72. 72. Enterprise portal
  73. 73. Large scale collaboration
  74. 74. Broader applications platform
  75. 75. Larger external search pool
  76. 76. Mix and match internal external front end servers on common content databases</li></ul>Sizing - Medium Farm<br />
  77. 77. <ul><li>Typical Roles:
  78. 78. Large distributed enterprise users (10000+)
  79. 79. Large pools of documents (>1MM)</li></ul>Sizing - Large Farm<br />
