Z I P K I NA distributed tracing framework
Why Zipkin?
Google0.5 sec slower20% traffic drop                  @skr | @thisisfranklin   3
Google0.5 sec slower    1.5 sec faster20% traffic drop   CTR up 12%                               @skr | @thisisfranklin   3
Performance matters
Front end            @skr | @thisisfranklin   5
Front end   Back end                   @skr | @thisisfranklin   5
@skr | @thisisfranklin   6
@skr | @thisisfranklin   6
@skr | @thisisfranklin   7
@skr | @thisisfranklin   8Picture from http://www.flickr.com/photos/jpellgen
@skr | @thisisfranklin   9
• Collects traces from production requests• Low overhead• Minimum of extra work for developers                            ...
Finagle“Finagle is an asynchronous network stack for the JVM that you can use to buildasynchronous Remote Procedure Call (...
@skr | @thisisfranklin   11
Finagle Http service                       @skr | @thisisfranklin   11
Finagle Http service                       @skr | @thisisfranklin   11
Finagle Http serviceFinagle Thrift Service                                          @skr | @thisisfranklin   11
Finagle Http serviceFinagle Thrift Service                                          @skr | @thisisfranklin   11
Finagle Http serviceFinagle Thrift Service                                          @skr | @thisisfranklin   11
Finagle Http serviceFinagle Thrift Service                Service                                                @skr | @t...
Finagle Http serviceFinagle Thrift Service                Service                                                @skr | @t...
Finagle Http serviceFinagle Thrift Service                Service                                                @skr | @t...
Zipkin terminology‣   Annotation: string data associated with a particular timestamp, service, and    host                ...
‣   Span: represents one specific method call; made up of a set of annotations.    Has a name and an id.                  ...
‣   Span: represents one specific method call; made up of a set of annotations.    Has a name and an id.                  ...
‣   Span: represents one specific method call; made up of a set of annotations.    Has a name and an id.                  ...
‣   Span: represents one specific method call; made up of a set of annotations.    Has a name and an id.                  ...
‣   Span: represents one specific method call; made up of a set of annotations.    Has a name and an id.                  ...
‣   Span: represents one specific method call; made up of a set of annotations.    Has a name and an id.                  ...
Finagle httpservice          @skr | @thisisfranklin   14
• Generate a random i64 trace id                                   Finagle                                    http        ...
• Generate a random i64 trace id• Decide if we should sample thetrace or not                       Finagle                ...
• Generate a random i64 trace id• Decide if we should sample thetrace or not                       Finagle                ...
• Generate a random i64 trace id• Decide if we should sample thetrace or not                       Finagle                ...
• Generate a random i64 trace id• Decide if we should sample thetrace or not                       Finagle                ...
• Generate a random i64 trace id• Decide if we should sample thetrace or not                       Finagle                ...
• Generate a random i64 trace id• Decide if we should sample thetrace or not                            Finagle           ...
Finagle httpserviceFinagle thriftservice          @skr | @thisisfranklin   14
Finagle           http          serviceFinagle   Finagle thrift    thriftservice   service                    @skr | @this...
Finagle           http          serviceFinagle   Finagle thrift    thriftservice   service                    Finagle     ...
Finagle            http          service          SFinagle   Finagle thrift    thriftSservice   service          S        ...
Finagle            http          service          S                               Zipkin                              coll...
Finagle            http          service          S                               Zipkin                              coll...
Finagle ♥ Zipkin
Finagle Thrift server       ServerBuilder()        .bindTo(address)        .codec(ThriftServerFramedCodec())        .name(...
Finagle Thrift server       ServerBuilder()        .bindTo(address)        .codec(ThriftServerFramedCodec())        .name(...
Finagle Thrift server       ServerBuilder()        .bindTo(address)        .codec(ThriftServerFramedCodec())        .name(...
Finagle Thrift server       ServerBuilder()        .bindTo(address)        .codec(ThriftServerFramedCodec())        .name(...
Finagle Http server       ServerBuilder()        .bindTo(address)        .codec(Http())        .name("servicename")       ...
ServerBuilder() .bindTo(address) .codec(ThriftServerFramedCodec()) .name("servicename") .tracerFactory(ZipkinTracer()) .bu...
ClientBuilder() .cluster(hosts) .codec(ThriftServerFramedCodec()) .name("clientname") .tracerFactory(ZipkinTracer()) .buil...
Trace.record("doing stuff")                              @skr | @thisisfranklin   20
Trace.record("doing stuff")                              @skr | @thisisfranklin   20
Trace.record("doing stuff")   time: 2012-01-21 22:37:01   value: “doing stuff”   server: 135.34.53.2   service: “timelines...
Trace.recordBinary("key", data)                                  @skr | @thisisfranklin   21
Key           ValueTrace.recordBinary("key", data)   responsecode       500                                  cache:somekey...
Platform    Protocol   Client   Server Finagle     Thrift     Yes      Yes Finagle     HTTP       Yes      Yes Finagle    ...
Zipkin UI
@skr | @thisisfranklin   24
@skr | @thisisfranklin   24
@skr | @thisisfranklin   24
What did we find?
github.com/twitter/zipkin     @zipkinproject                            @skr | @thisisfranklin   27
Zipkin - Runtime open house
Zipkin - Runtime open house
Upcoming SlideShare
Loading in …5
×

Zipkin - Runtime open house

4,970 views

Published on

Zipkin is a distributed tracing system that helps us gather timing data for all the disparate services at Twitter, and manages collection and lookup of data through a Collector and a Query service.
With Zipkin, we can trace a subset of all requests made to the site, and collect detailed data about the path taken through our systems, as well as timings. Then, we can visualize and ultimately pinpoint where and possibly why a response took longer than expected.

Published in: Technology, Education
0 Comments
16 Likes
Statistics
Notes
  • Be the first to comment

No Downloads
Views
Total views
4,970
On SlideShare
0
From Embeds
0
Number of Embeds
134
Actions
Shares
0
Downloads
128
Comments
0
Likes
16
Embeds 0
No embeds

No notes for slide
  • Talk more about what tracing is. Compare in process profiling to distributed system?\n
  • Before we get into what Zipkin is: why we created it\n
  • Shit is slow, you lose users and money\n
  • \n
  • Simplify wildly, there are two parts to web performance\nFront end. The order assets are loaded, minifying and other tricsk\nBack end. How quickly can we generate and push out the HTML/JSON/whatever\n
  • For the front end we have these nice development tools. Shows us how the assets loaded, what it was waiting for and so on.\nWe want a fancy tool like this for the backend.\nPicked a page where server side was unusually bad, normally it’s mostly FE\n
  • For the back end we only had these graphs to look at per service.\nNothing that ties them together\n
  • Capture information about how services in a datacentre is working together to respond to a request. \n
  • Read this paper from Google called Dapper\n
  • Read this paper from Google called Dapper\n
  • \n
  • \n
  • \n
  • \n
  • \n
  • \n
  • \n
  • \n
  • \n
  • \n
  • \n
  • \n
  • \n
  • \n
  • \n
  • Mention that Cassandra and Scribe can both be replaced. Zookeeper coordination?\n
  • Mention that Cassandra and Scribe can both be replaced. Zookeeper coordination?\n
  • Mention that Cassandra and Scribe can both be replaced. Zookeeper coordination?\n
  • Mention that Cassandra and Scribe can both be replaced. Zookeeper coordination?\n
  • Mention that Cassandra and Scribe can both be replaced. Zookeeper coordination?\n
  • Mention that Cassandra and Scribe can both be replaced. Zookeeper coordination?\n
  • Mention that Cassandra and Scribe can both be replaced. Zookeeper coordination?\n
  • Mention that Cassandra and Scribe can both be replaced. Zookeeper coordination?\n
  • Mention that Cassandra and Scribe can both be replaced. Zookeeper coordination?\n
  • Mention that Cassandra and Scribe can both be replaced. Zookeeper coordination?\n
  • Mention that Cassandra and Scribe can both be replaced. Zookeeper coordination?\n
  • Mention that Cassandra and Scribe can both be replaced. Zookeeper coordination?\n
  • Mention that Cassandra and Scribe can both be replaced. Zookeeper coordination?\n
  • Mention that Cassandra and Scribe can both be replaced. Zookeeper coordination?\n
  • Mention that Cassandra and Scribe can both be replaced. Zookeeper coordination?\n
  • Mention that Cassandra and Scribe can both be replaced. Zookeeper coordination?\n
  • Mention that Cassandra and Scribe can both be replaced. Zookeeper coordination?\n
  • Mention that Cassandra and Scribe can both be replaced. Zookeeper coordination?\n
  • Mention that Cassandra and Scribe can both be replaced. Zookeeper coordination?\n
  • Mention that Cassandra and Scribe can both be replaced. Zookeeper coordination?\n
  • \n
  • Mention dependency on finagle-zipkin\n
  • Mention dependency on finagle-zipkin\n
  • Mention dependency on finagle-zipkin\n
  • Mention dependency on finagle-zipkin\n
  • Mention dependency on finagle-zipkin\n
  • \n
  • \n
  • \n
  • \n
  • \n
  • \n
  • \n
  • \n
  • \n
  • Trace view\nServices on the left. Time scale on top. Least impactful parts of trace collapsed automatically.\nMention bootstrap and dj\n
  • \n
  • It’s all open source, check it out now.\n
