4/14/10<br />©2010 SugarCRM Inc. All rights reserved.<br />1<br />
Best Practices for Creating Custom Apps in Sugar	<br />John Mertic<br />SugarCRM<br />4/14/10<br />©2010 SugarCRM Inc. All...
The golden rules of customizations<br />Use Module Builder/Studio for customizations if possible<br />Otherwise, put your ...
Why do this?<br />Module Builder/Studio changes are well supported and easier to manage<br />Customizations are separated ...
Exceptions to this…<br />New modules need to be under modules/ directory.<br />Bean class customizations to OOTB modules n...
Let’s see what we can do<br />4/14/10<br />©2010 SugarCRM Inc. All rights reserved.<br />6<br />
MVC Framework<br />MVC stands for Model View Controller<br />4/14/10<br />©2010 SugarCRM Inc. All rights reserved.<br />7<...
MVC Framework – The anatomy of a request<br />4/14/10<br />©2010 SugarCRM Inc. All rights reserved.<br />8<br />
MVC Framework – SugarApplication<br />Bootstraps the application<br />Loads many of the default application settings<br />...
MVC Framework - SugarController<br />Manages all the actions of a module<br />Contains logic for handling requests that do...
MVC Framework – SugarController API<br />4/14/10<br />©2010 SugarCRM Inc. All rights reserved.<br />11<br />
MVC Framework – Controller Example<br />4/14/10<br />©2010 SugarCRM Inc. All rights reserved.<br />12<br /><?php<br />clas...
MVC Framework – Controller-less mapping<br />If your module doesn’t need to have any controller logic, use action mapping ...
MVC Framework - SugarView<br />Contains the display logic for the action<br />Uses a metadata backend for Edit, Detail, Li...
MVC Framework – SugarView API<br />4/14/10<br />©2010 SugarCRM Inc. All rights reserved.<br />15<br />
MVC Framework – SugarView API<br />4/14/10<br />©2010 SugarCRM Inc. All rights reserved.<br />16<br />
MVC Framework – View Example<br />4/14/10<br />©2010 SugarCRM Inc. All rights reserved.<br />17<br /><?php<br />class View...
MVC Framework – ViewDetail Example<br />4/14/10<br />©2010 SugarCRM Inc. All rights reserved.<br />18<br /><?php<br />requ...
4/14/10<br />©2010 SugarCRM Inc. All rights reserved.<br />19<br />Where do I put my customizations?<br />Controllers<br /...
Metadata Layer<br />4/14/10<br />©2010 SugarCRM Inc. All rights reserved.<br />20<br />
Kinds of metadata<br />editviewdefs.php / detailviewdefs.php / quickcreatedefs.php<br />Wireless variants: wireless.editvi...
editviewdefs.php<br />4/14/10<br />©2010 SugarCRM Inc. All rights reserved.<br />22<br /><?php<br />$viewdefs[$module_name...
subpaneldefs.php<br />4/14/10<br />©2010 SugarCRM Inc. All rights reserved.<br />23<br /><?php<br />$layout_defs[$module_n...
searchdefs.php<br />4/14/10<br />©2010 SugarCRM Inc. All rights reserved.<br />24<br /><?php<br />$searchdefs[$module_name...
SearchFields.php<br />4/14/10<br />©2010 SugarCRM Inc. All rights reserved.<br />25<br /><?php<br />$searchFields[$module_...
popupdefs.php<br />4/14/10<br />©2010 SugarCRM Inc. All rights reserved.<br />26<br /><?php<br />global $mod_strings;<br /...
Where do I put my customizations?<br />Subpaneldefs<br />custom/Extension/modules/Modulename/Ext/Layoutdefs/NameWhateverYo...
Logic Hooks<br />4/14/10<br />©2010 SugarCRM Inc. All rights reserved.<br />28<br />
Logic Hook Types<br />4/14/10<br />©2010 SugarCRM Inc. All rights reserved.<br />29<br />
Logic Hook Types (cont)<br />4/14/10<br />©2010 SugarCRM Inc. All rights reserved.<br />30<br />
Logic Hook Types (new in 6.0)<br />4/14/10<br />©2010 SugarCRM Inc. All rights reserved.<br />31<br />
logic_hooks.php<br />4/14/10<br />©2010 SugarCRM Inc. All rights reserved.<br />32<br /><?php<br />$hook_version = 1; <br ...
AccountHooks.php<br />4/14/10<br />©2010 SugarCRM Inc. All rights reserved.<br />33<br /><?php<br />class AccountHooks<br ...
Where do I put my customizations?<br />Application Level Logic Hooks<br />/custom/modules/<br />Module Level Logic Hooks<b...
Themes<br />4/14/10<br />©2010 SugarCRM Inc. All rights reserved.<br />35<br />
Theme Directory Layout<br />css/ - contains all css files<br />images/ - contains all images<br />js/ - contains any js fi...
Themes can inherit from other themes<br />Theme Inheritance Model<br />12/30/08<br />©2009 SugarCRM Inc. All rights reserv...
Allow upgrade-safe modifications to themes<br />All themes can be modified by putting the replacement or overriding file i...
Resources<br />4/14/10<br />©2010 SugarCRM Inc. All rights reserved.<br />39<br />http://developers.sugarcrm.com<br />Buy ...
Thanks for coming!<br />4/14/10<br />©2010 SugarCRM Inc. All rights reserved.<br />40<br />
