The Township of Langley 2008  Pavement Management System Study Prepared by EBA Engineering Consultants Ltd.
Contents <ul><li>Project Background </li></ul><ul><li>Data Collection  </li></ul><ul><li>Road Network Present Conditions i...
Project Background <ul><li>Township of Langley’s Pavement Management History </li></ul><ul><li>Pavement Management System ...
Pavement Inventory <ul><li>Township of Langley has approximately 930 centreline km of road </li></ul><ul><li>(813 centreli...
Township of Langley’s Road Network Road Network Classification Provincial Highways MRN Routes Arterial Routes Collector Ro...
All Cracked Area (ACA) as a Measure of Pavement Condition 100% 30% V Poor 30% 10% Poor 10% 5% Fair 5% 1% Good 1% 0% V Good...
Data Collection Cracking = 0 - 1 % Preventative Maintenance (crack sealing) $1.70 - $3.00/m 2 Cracking = 1 - 10 % Overlay,...
Data Collection Cracking = 10 - 30% (Overlay, Grind and Patch) $30 - $40/m 2 Cracking > 30% (Replace Asphalt) $40 - $65/m 2
Cracking (ACA) on Major Roads – 2007/08 0 – 1% (V Good)  =  133 km  40% 1 – 5% (Good)  =  98 km  30% 5 – 10% (Fair)  =  42...
Recommended Funding vs Actual (major roads) <ul><li>Average Cracking in 2000 = 5.2% </li></ul><ul><li>Average Cracking in ...
Comparison to Other Agencies How does this compare to elsewhere in terms of Cracking ?? Using the same data collection / i...
Cracking (ACA) on MRN Roads 2005 0 – 1% (V Good)  = 43 km 1 – 5% (Good)  = 14 km 5 – 10% (Fair)  =  2 km 10 – 30% (Poor)  ...
Cracking (ACA) on Local Roads - 2008 0 – 1% (V Good)  = 156 km 1 – 5% (Good)  = 125 km 5 – 10% (Fair)  =  38 km 10 – 30% (...
Analysis Inputs Example Pavement Strategies (combinations of treatments) 13 Years 10 Years 20 Years
Analysis Inputs Using Life Cycle Cost Analysis Evaluated Several Strategies for Each Pavement Segment <ul><li>Strategy is ...
Analysis Results – Major Roads Deterioration 9% 16% 4% 6% 20% Cracking (ACA) % $2.0mill $3.0 mill $3.5 mill $4.0 mill $1.5...
Analysis Results – Local Roads Deterioration 4% 11% 15% Cracking (ACA) % $3.0 mill $3.5 mill $4.0 mill $2.5 mill Recommend...
Cracking (ACA) on Major & Local Roads 2009 - 2025 Predicted condition in 2009 - 2025 Major:  $2.0 million/ year Local:  $2...
Cracking (ACA) on Major & Local Roads - 2009 0 – 1%  (V Good) 1 – 5%  (Good) 5 – 10%  (Fair) 10 – 30%  (Poor) 30 – 100%  (...
Cracking (ACA) on Major & Local Roads - 2010 0 – 1%  (V Good) 1 – 5%  (Good) 5 – 10%  (Fair) 10 – 30%  (Poor) 30 – 100%  (...
Cracking (ACA) on Major & Local Roads - 2011 0 – 1%  (V Good) 1 – 5%  (Good) 5 – 10%  (Fair) 10 – 30%  (Poor) 30 – 100%  (...
Cracking (ACA) on Major & Local Roads - 2012 0 – 1%  (V Good) 1 – 5%  (Good) 5 – 10%  (Fair) 10 – 30%  (Poor) 30 – 100%  (...
Cracking (ACA) on Major & Local Roads - 2013 0 – 1%  (V Good) 1 – 5%  (Good) 5 – 10%  (Fair) 10 – 30%  (Poor) 30 – 100%  (...
Cracking (ACA) on Major & Local Roads - 2014 0 – 1%  (V Good) 1 – 5%  (Good) 5 – 10%  (Fair) 10 – 30%  (Poor) 30 – 100%  (...
Cracking (ACA) on Major & Local Roads - 2015 0 – 1%  (V Good) 1 – 5%  (Good) 5 – 10%  (Fair) 10 – 30%  (Poor) 30 – 100%  (...
Cracking (ACA) on Major & Local Roads - 2016 0 – 1%  (V Good) 1 – 5%  (Good) 5 – 10%  (Fair) 10 – 30%  (Poor) 30 – 100%  (...
Cracking (ACA) on Major & Local Roads - 2017 0 – 1%  (V Good) 1 – 5%  (Good) 5 – 10%  (Fair) 10 – 30%  (Poor) 30 – 100%  (...
Cracking (ACA) on Major & Local Roads - 2018 0 – 1%  (V Good) 1 – 5%  (Good) 5 – 10%  (Fair) 10 – 30%  (Poor) 30 – 100%  (...
Cracking (ACA) on Major & Local Roads - 2019 0 – 1%  (V Good) 1 – 5%  (Good) 5 – 10%  (Fair) 10 – 30%  (Poor) 30 – 100%  (...
Cracking (ACA) on Major & Local Roads - 2020 0 – 1%  (V Good) 1 – 5%  (Good) 5 – 10%  (Fair) 10 – 30%  (Poor) 30 – 100%  (...
Cracking (ACA) on Major & Local Roads - 2021 0 – 1%  (V Good) 1 – 5%  (Good) 5 – 10%  (Fair) 10 – 30%  (Poor) 30 – 100%  (...
Cracking (ACA) on Major & Local Roads - 2022 0 – 1%  (V Good) 1 – 5%  (Good) 5 – 10%  (Fair) 10 – 30%  (Poor) 30 – 100%  (...
Cracking (ACA) on Major & Local Roads - 2023 0 – 1%  (V Good) 1 – 5%  (Good) 5 – 10%  (Fair) 10 – 30%  (Poor) 30 – 100%  (...
Cracking (ACA) on Major & Local Roads - 2024 0 – 1%  (V Good) 1 – 5%  (Good) 5 – 10%  (Fair) 10 – 30%  (Poor) 30 – 100%  (...
Cracking (ACA) on Major & Local Roads - 2025 0 – 1%  (V Good) 1 – 5%  (Good) 5 – 10%  (Fair) 10 – 30%  (Poor) 30 – 100%  (...
Cracking (ACA) on Major & Local Roads 2025 Predicted condition in 2025 Major & Local:  $500,000/ year Annual Spending (Do ...
Cracking (ACA) on Major & Local Roads - 2025 0 – 1%  (V Good) 1 – 5%  (Good) 5 – 10%  (Fair) 10 – 30%  (Poor) 30 – 100%  (...
Pavement Asset Value Pavement Type  Replacement  2008 Value  2018 Value   (Recommended Budget) MRN Roads  $  74 million  $...

For Discussion
Calculating Pavement Value Pavement value = Cost of Excavation and Compaction + cost of Subbase + cost of Base + cost of A...
With time and traffic, pavement layers deteriorate Failure Rutting Cracking
Calculating current pavement asset value cracking Original Pavement value  minus  the cost in any given year to restore th...
Pavement Asset Value <ul><li>Pavement Type  Length  Replacement  2008 Value </li></ul><ul><li>MRN Roads   59 km  $  74 mil...
Distress Prediction Modeling World Bank Pavement Performance - Distress Prediction Modeling <ul><li>Structure </li></ul><u...
Analysis Inputs Maintenance / Rehabilitation Treatments and Costs Used <ul><li>Treatment Unit Cost </li></ul><ul><li>Crack...
