Cassandra from the trenches:      migrating Netflix          Jason Brown    Senior Software Engineer             Netflix  ...
History, 2008• In the beginning, there was the webapp  – And a database  – In one datacenter• Then we grew, and grew, and ...
History, 2009• Time to rethink everything  – Abandon our datacenter  – Ditch the monolithic webapp  – Migrate single point...
History, 2010• SimpleDB/S3  – Managed by Amazon, not us  – Got us started with NoSQL in the cloud  – Problems:     • High ...
Shiny new toy (2011)• We switched to Cassandra  – Similar to SimpleDB, with limits removed  – Dynamo-model appealed to us ...
Data Modeling -  Where the rubber meets the road
About Netflix’s AB Testing• Basic concepts  – Test – An experiment where several competing    behaviors are implemented an...
Data Modeling - background• AB has two sets of data  – metadata about tests  – allocations
AB - allocations• Single table to hold allocations  – Currently at > 1 billion records  – Plus indices!• One record for ev...
AB – relational model• Typical parent-child table relationship• Not updated frequently, so service can cache
Data modeling in Cassandra• Every where I looked, the Internet told me to  understand my data use patterns• Identify the q...
Identifying the AB questions that need            to be answered• High traffic  – get all allocations for a customer• Low ...
Modeling allocations in Cassandra• Read all allocations for a customer  – as fast as possible• Find all of customers in a ...
Denormalization - HOWTO• No real world examples  – ‘Normalization is for sissies’, Pat Helland• Denormalize allocations pe...
Denormalized allocations• normalized data• denormalized (sparse) data
Implementing allocations• As allocation for a customer has a handful of  data points, they logically can be grouped  toget...
Composite columns• Composite columns are sorted by each ‘token’  in name• Allocation column naming convention  – <testId>:...
Modeling AB metadata in cassandra• Explored several models, including json  blobs, spreading across multiple CFs, differin...
Implementing metadata• One CF, one row for all test’s data  – Every data point is a column – no blobs• Composite columns  ...
Implementing indices• Cassandra’s secondary indices vs. hand-built  and maintained alternate indices• Secondary indices wo...
Hand-built Indices, 1• Reverse index  – Test/cell (key) to custIds (columns)     • Column value is timestamp• Updating ind...
Hand-built indices, 2• Counter column family  – Test/cell to count of customers in test columns  – Mutate on allocating a ...
Index rebuilding• To keep the index consistent, it needs to be  rebuilt occasionally• Even Oracle needs to have it’s indic...
Into the real world
Cassandra java clients• Hector  – github.com/rantav/hector• Astyanax  – Developed at Netflix (Eran Landau)  – github.com/n...
Astyanax features•   Clean object model•   Node discovery•   Node quarantine•   Request failover/retry•   JMX Monitoring• ...
Astyanax code example,1
Astyanax code example, 2
Astyanax code example, 3
Astyanax connection pools, 1• Round Robin uses coordinator node
Astyanax connection pooling, 2• Token aware knows where the data resides for  point reads
Astyanax latency aware• Samples response times from Cassandra  nodes• Favors faster responding nodes in pool• Use with tok...
Allocation mutates• AB allocations are immutable, so we need to  prevent mutating• Oracle - unique table constraint• Cassa...
Running cassandra• Compactions happen  – how Cassandra is maintained  – Mutations are written to memory (Memtable)  – Flus...
Compactions, 2• Latency spikes happen, especially on read-  heavy systems  – Everything can slow down  – Throttling in new...
Tunings, 1• Key and row caches  – Left unbounded can consume JVM memory    needed for normal work  – Latencies will spike ...
Tunings, 2• mmap() as in-memory cache  – When the Cassandra process is terminated, mmap    pages are returned to the free ...
Tunings, 3• Sizing memtable flushes for optimizing  compactions  – Easier when writes are uniformly    distributed, timewi...
Tunings, 4• Sharding  – If a single row has disproportionately high    gets/mutates, the nodes holding it will become    h...
Takeaways• Netflix is making all of our components  distributed and fault tolerant as we grow  domestically and internatio...
終わり(The End)• Q&A        @jasobrown jasedbrown@gmail.com        http://www.linkedin.com/in/jasedbrown
References• Pat Helland, ‘Normalization Is for Sissies”  http://blogs.msdn.com/b/pathelland/archive/  2007/07/23/normaliza...
