1.
Rails vs. Facebooker
Facebook-Apps mit Facebooker
Jan Krutisch <jan.krutisch@mindmatters.de>
10. Juni 2009
Rails Usergroup Hamburg
Donnerstag, 11. Juni 2009

2.
Facebook you say?
Donnerstag, 11. Juni 2009

3.
200 Gazillionen
Benutzer
Donnerstag, 11. Juni 2009

4.
(pro Tag)
Donnerstag, 11. Juni 2009

5.
(ungefähr)
Donnerstag, 11. Juni 2009

6.
verdammt viele
Donnerstag, 11. Juni 2009

7.
potentielle Kunden
Donnerstag, 11. Juni 2009

8.
für was?
Donnerstag, 11. Juni 2009

9.
for great justice
Donnerstag, 11. Juni 2009

10.
Step 3: Profit
Donnerstag, 11. Juni 2009

11.
Virales Wachstum und
so...
Donnerstag, 11. Juni 2009

12.
Donnerstag, 11. Juni 2009

13.
Glaubt mir!
Donnerstag, 11. Juni 2009

14.
anyway
Donnerstag, 11. Juni 2009

15.
facebook application?
Donnerstag, 11. Juni 2009

16.
Integrationspunkte
Donnerstag, 11. Juni 2009

17.
Canvas
Donnerstag, 11. Juni 2009

18.
Donnerstag, 11. Juni 2009

19.
Donnerstag, 11. Juni 2009

20.
• App in App (Proxy bzw. iFrame)
• HTML plus FBML
• Zusätzliche Parameter, Header etc.
Donnerstag, 11. Juni 2009

21.
FBML ZOMG WTF?
Donnerstag, 11. Juni 2009

22.
Face Book Markup
Language
Donnerstag, 11. Juni 2009

23.
<fb:fbml>
<fb:header>dings</fb:header>
<%- fb_tabs do -%>
<%= yield :tabs %>
<%- end -%>
<fb:add-section-button section=quot;profilequot; />
<%= yield %>
</fb:fbml>
Donnerstag, 11. Juni 2009

24.
loads of tags
Donnerstag, 11. Juni 2009

25.
BML
hp/F
ind ex.p
m/
oo k.co
rs.f aceb
eve lope
//w iki.d
http:
Text
Donnerstag, 11. Juni 2009

26.
• Daten-Integration
• Cache-Hilfen
• Forms
• Styling
• Visibility
Donnerstag, 11. Juni 2009

27.
API
Donnerstag, 11. Juni 2009

28.
(out of scope)
Donnerstag, 11. Juni 2009

29.
Profil-Widgets pushen
Donnerstag, 11. Juni 2009

30.
Donnerstag, 11. Juni 2009

31.
(Auch FBML)
Donnerstag, 11. Juni 2009

32.
Notifications
Donnerstag, 11. Juni 2009

33.
Donnerstag, 11. Juni 2009

34.
Publisher
Donnerstag, 11. Juni 2009

35.
Donnerstag, 11. Juni 2009

36.
Facebook Connect
Donnerstag, 11. Juni 2009

37.
(Think OAuth)
Donnerstag, 11. Juni 2009

38.
Weitere Technologien
Donnerstag, 11. Juni 2009

39.
FBJS
Donnerstag, 11. Juni 2009

40.
Face Book Just Sucks
Donnerstag, 11. Juni 2009

41.
Donnerstag, 11. Juni 2009

42.
<%= image_tag image.small_url,
:id => quot;gallery_image_#{image.id}quot;,
:class => quot;gallery-imagequot;,
:onclick => quot;setImage(#{image.id});return false;quot; %>
Donnerstag, 11. Juni 2009

43.
<img alt=quot;101_21480322_originalquot; class=quot;gallery-
imagequot; id=quot;app208488715334_gallery_image_29quot;
onclick=quot;fbjs_sandbox.instances.a208488715334.bo
otstrap();return
fbjs_dom.eventHandler.call([fbjs_dom.get_instanc
e(this,
208488715334),function(a208488715334_event)
{a208488715334_setImage(29);return false;},
208488715334],new fbjs_event(event));return
true;quot; src=quot;http://s3.amazonaws.com/com.dpa-
info.widget.staging/
101_21480322_original.small-1-1-200-126-0-582-45
6.jpgquot; fbcontext=quot;fa3facfe268fquot;>
Donnerstag, 11. Juni 2009

44.
Aber wie?
Donnerstag, 11. Juni 2009

45.
Facebooker
Donnerstag, 11. Juni 2009

46.
Chad Fowler
Donnerstag, 11. Juni 2009

47.
Mike Mangino
Donnerstag, 11. Juni 2009

48.
Donnerstag, 11. Juni 2009

49.
• Sehr coole API-Umsetzung
• before_filter f. Auth etc.
• Fast alle APIs abgedeckt
• Publisher (wie Mailer) f. Notifications,
Profile, Profile-Publisher
• FBML-Helper
Donnerstag, 11. Juni 2009

50.
Configure
Donnerstag, 11. Juni 2009

51.
Donnerstag, 11. Juni 2009

52.
Donnerstag, 11. Juni 2009

53.
development:
api_key: ---------------------------------
secret_key: ----------------------------------
canvas_page_name: example
callback_url: http://example:4007
pretty_errors: true
set_asset_host_to_callback_url: true
tunnel:
public_host_username: johndoe
public_host: example.com
public_port: 4007
local_port: 3000
server_alive_interval: 0
test:
api_key: ---------------------------------
secret_key: ----------------------------------
canvas_page_name: example
callback_url: http://example:4007
pretty_errors: true
set_asset_host_to_callback_url: true
tunnel:
public_host_username: johndoe
public_host: example.com
public_port: 4007
local_port: 3000
server_alive_interval: 0
Donnerstag, 11. Juni 2009

54.
rake facebooker:tunnel:start
Donnerstag, 11. Juni 2009

55.
ssh -R :4007:localhost:3000 johndoe@example.com sleep 999999
Donnerstag, 11. Juni 2009

56.
#/etc/ssh/sshd_config
GatewayPorts clientspecified
Donnerstag, 11. Juni 2009

57.
$ /script/server
Donnerstag, 11. Juni 2009

58.
client browser
facebook
example.com
dev machine
Donnerstag, 11. Juni 2009

59.
CodePorn.random
Donnerstag, 11. Juni 2009

60.
ApplicatioController
Donnerstag, 11. Juni 2009

61.
# Filters added to this controller apply to all controllers in the application.
# Likewise, all the methods added will be available for all controllers.
class ApplicationController < ActionController::Base
include ExceptionNotifiable
helper :all # include all helpers, all the time
protect_from_forgery # See ActionController::RequestForgeryProtection for d...
helper_attr :current_user
attr_accessor :current_user
ensure_authenticated_to_facebook
before_filter :create_facebook_session, :set_current_user
# Scrub sensitive parameters from your log
# filter_parameter_logging :password
def set_current_user
self.current_user = User.for(facebook_session.user.to_i, facebook_session)
end
end
Donnerstag, 11. Juni 2009

62.
<fb:fbml>
<style type=quot;text/cssquot; media=quot;screenquot;>
ul.image-list li h2 {
margin-bottom: 5px;
}
.single-image {
width:760px;
text-align:center;
margin-top:10px;
}
.single-image h2 {
margin-bottom: 5px;
}
</style>
<fb:header>dpa-info.com galerie</fb:header>
<%- fb_tabs do -%>
<%= yield :tabs %>
<%- end -%>
<fb:add-section-button section=quot;profilequot; />
<%= yield %>
</fb:fbml>
Donnerstag, 11. Juni 2009

63.
application.fbml.erb
Donnerstag, 11. Juni 2009

64.
<%- content_for :tabs do -%>
<%= fb_tab_item 'Gallery', root_url, :selected => true %>
<%= fb_tab_item 'Invite your friends', new_invitation_url %>
<%- end -%>
Donnerstag, 11. Juni 2009

65.
Profile Template
Donnerstag, 11. Juni 2009

66.
<%- @assigns[:images].each do |image| -%>
<%= link_to image_tag(image.small_url,
:title => h(image.title),
:alt => h(image.title)), root_url %>
<%- end -%>
<%= link_to quot;Mehr Bilder...quot;, gallery_url %>
Donnerstag, 11. Juni 2009

67.
Publisher
Donnerstag, 11. Juni 2009

68.
class GalleryPublisher < Facebooker::Rails::Publisher
def image_feed_template
app_link = link_to(quot;Mehr Photos...quot;,root_url)
one_line_story_template quot;{*actor*} mag das Photo '{*image_title*}'
#{app_link}quot;
short_story_template quot;{*actor*} mag das Photo '{*image_title*}' aus der dpa-
Galeriequot;, quot;#{app_link}quot;
end
def image_feed(user, image)
send_as :user_action
from user
data :image_title => image.title,
:images=>[image(image.small_url,root_url)]
end
def profile_update(user)
send_as :profile
recipients user
@images = DailyImage.latest.all(:limit => 10)
profile render(:partial => quot;profilequot;, :assigns => {:images => @images} )
profile_main render(:partial => quot;profile_narrowquot;, :assigns => {:images =>
@images[0..3]} )
end
end
Donnerstag, 11. Juni 2009

69.
ProfilePublisher
Donnerstag, 11. Juni 2009

70.
class ProfilePublisherController < ApplicationController
skip_before_filter :ensure_authenticated_to_facebook
def index
if current_user.nil? and facebook_params[:user]
self.current_user = User.for(facebook_params[:user])
end
if wants_interface?
@images = DailyImage.latest.all(:limit => 10)
render_publisher_interface(render_to_string(:partial=>quot;formquot;, :assigns =>
{:images => @images}))
else
@image = DailyImage.find(params[:app_params][:id])
render_publisher_response(GalleryPublisher.create_image_feed(current_user,
@image))
end
end
end
Donnerstag, 11. Juni 2009

71.
some more code...
Donnerstag, 11. Juni 2009

72.
fin
Donnerstag, 11. Juni 2009
