Intro to Apache Mahout

Machine Learning with Apache Mahout ,[object Object],Grant Ingersoll,[object Object],July 8, 2010,[object Object]

Introduction,[object Object],You,[object Object],Machine learning experience?,[object Object],Business Intelligence?,[object Object],Natural Lang. Processing?,[object Object],ApacheHadoop?,[object Object],Me,[object Object],Co-founder Apache Mahout,[object Object],Apache Lucene/Solr committer,[object Object],Co-founder Lucid Imagination,[object Object]

Topics,[object Object],What is Machine Learning?,[object Object],ML Use Cases,[object Object],What is Mahout?,[object Object],What can I do with it right now?,[object Object],Where’s Mahout headed?,[object Object]

Amazon.com,[object Object],What is Machine Learning?,[object Object],Google News,[object Object]

Really it’s…,[object Object],“Machine Learning is programming computers to optimize a performance criterion using example data or past experience”,[object Object],Intro. To Machine Learning by E. Alpaydin,[object Object],Subset of Artificial Intelligence,[object Object],Lots of related fields:,[object Object],Information Retrieval,[object Object],Stats,[object Object],Biology,[object Object],Linear algebra,[object Object],Many more,[object Object]

Common Use Cases,[object Object],Recommend friends/dates/products,[object Object],Classify content into predefined groups,[object Object],Find similar content based on object properties,[object Object],Find associations/patterns in actions/behaviors,[object Object],Identify key topics in large collections of text,[object Object],Detect anomalies in machine output,[object Object],Ranking search results,[object Object],Others?,[object Object]

Useful Terminology,[object Object],Vectors/Matrices,[object Object],Weights,[object Object],Sparse,[object Object],Dense,[object Object],Norms,[object Object],Features,[object Object],Feature reduction,[object Object],Occurrences and Co-occurrences,[object Object]

Getting Started with ML,[object Object],Get your data,[object Object],Decide on your features per your algorithm,[object Object],Prep the data,[object Object],Different approaches for different algorithms,[object Object],Run your algorithm(s),[object Object],Lather, rinse, repeat,[object Object],Validate your results,[object Object],Smell test, A/B testing, more formal methods,[object Object]

Apache Mahout,[object Object],http://dictionary.reference.com/browse/mahout,[object Object],An Apache Software Foundation project to create scalable machine learning libraries under the Apache Software License,[object Object],http://mahout.apache.org,[object Object],Why Mahout?,[object Object],Many Open Source ML libraries either:,[object Object],Lack Community,[object Object],Lack Documentation and Examples,[object Object],Lack Scalability,[object Object],Lack the Apache License,[object Object],Or are research-oriented,[object Object]

Focus: Machine Learning,[object Object],Applications,[object Object],Examples,[object Object],Recommenders,[object Object],Clustering,[object Object],Classification,[object Object],Freq. Pattern,[object Object],Mining,[object Object],Genetic,[object Object],Math,[object Object],Vectors/Matrices/SVD,[object Object],Utilities,[object Object],Lucene/Vectorizer,[object Object],Collections (primitives),[object Object],Apache Hadoop,[object Object],See http://cwiki.apache.org/confluence/display/MAHOUT/Algorithms,[object Object]

Focus: Scalable,[object Object],Goal: Be as fast and efficient as possible given the intrinsic design of the algorithm,[object Object],Some algorithms won’t scale to massive machine clusters,[object Object],Others fit logically on a Map Reduce framework like Apache Hadoop,[object Object],Still others will needalternative distributed programming models,[object Object],Be pragmatic,[object Object],Most Mahout implementations are Map Reduce enabled,[object Object],(Always a) Work in Progress,[object Object]

Prepare Data from Raw content,[object Object],Data Sources:,[object Object],Lucene integration,[object Object],bin/mahout lucenevector …,[object Object],Document Vectorizer,[object Object],bin/mahout seqdirectory …,[object Object],bin/mahout seq2sparse …,[object Object],Programmatically,[object Object],See the Utils module in Mahout,[object Object],Database,[object Object],File system,[object Object]

Recommendations,[object Object],Extensive framework for collaborative filtering,[object Object],Recommenders,[object Object],User based,[object Object],Item based,[object Object],Online and Offline support,[object Object],Offline can utilize Hadoop,[object Object],Many different Similarity measures,[object Object],Cosine, LLR, Tanimoto, Pearson, others,[object Object]

Clustering,[object Object],Document level,[object Object],Group documents based on a notion of similarity,[object Object],K-Means, Fuzzy K-Means, Dirichlet, Canopy, Mean-Shift,[object Object],Distance Measures,[object Object],Manhattan, Euclidean, other,[object Object],Topic Modeling ,[object Object],Cluster words across documents to identify topics,[object Object],Latent Dirichlet Allocation,[object Object]

Categorization,[object Object],Place new items into predefined categories:,[object Object],Sports, politics, entertainment,[object Object],Mahout has several implementations,[object Object],Naïve Bayes,[object Object],Complementary Naïve Bayes,[object Object],Decision Forests,[object Object],Logistic Regression (Almost done),[object Object]

Freq. Pattern Mining,[object Object],Identify frequently co-occurrent items,[object Object],Useful for:,[object Object],Query Recommendations,[object Object],Apple -> iPhone, orange, OS X,[object Object],Related product placement,[object Object],“Beer and Diapers”,[object Object],Spam Detection,[object Object],Yahoo: http://www.slideshare.net/hadoopusergroup/mail-antispam,[object Object],http://www.amazon.com,[object Object]

Evolutionary,[object Object],Map-Reduce ready fitness functions for genetic programming,[object Object],Integration with Watchmaker,[object Object],http://watchmaker.uncommons.org/index.php,[object Object],Problems solved:,[object Object],Traveling salesman,[object Object],Class discovery,[object Object],Many others,[object Object]

Singular Value Decomposition,[object Object],Reduces a big matrix into a much smaller matrix by amplifying the important parts while removing/reducing the less important parts,[object Object],Mahout has fully distributed Lanczos implementation,[object Object],<MAHOUT_HOME>/bin/mahout svd -Dmapred.input.dir=path/to/corpus --tempDir path/for/svd-output --rank 300 --numColumns <numcols> --numRows <num rows in the input>,[object Object],<MAHOUT_HOME>/bin/mahout cleansvd --eigenInput path/for/svd-output --corpusInput path/to/corpus --output path/for/cleanOutput --maxError 0.1 --minEigenvalue 10.0 ,[object Object],https://cwiki.apache.org/confluence/display/MAHOUT/Dimensional+Reduction,[object Object]

How To: Recommenders,[object Object],Data: ,[object Object],Users (abstract),[object Object],Items (abstract),[object Object],Ratings (optional),[object Object],Load the data model,[object Object],Ask for Recommendations:,[object Object],User-User,[object Object],Item-Item,[object Object]

Ugly Demo I,[object Object],Group Lens Data: http://www.grouplens.org,[object Object],http://lucene.apache.org/mahout/taste.html#demo,[object Object],http://localhost:8080/RecommenderServlet?userID=1&debug=true,[object Object],In other words: the reason why I work on servers, not UIs!,[object Object]

How to: Command Line,[object Object],Most algorithms have a Driver program,[object Object],Shell script in $MAHOUT_HOME/bin helps with most tasks,[object Object],Prepare the Data,[object Object],Different algorithms require different setup,[object Object],Run the algorithm,[object Object],Single Node,[object Object],Hadoop,[object Object],Print out the results,[object Object],Several helper classes: ,[object Object],LDAPrintTopics, ClusterDumper, etc.,[object Object]

Ugly Demo II - Prep,[object Object],Data Set: Reuters,[object Object],http://www.daviddlewis.com/resources/testcollections/reuters21578/,[object Object],Convert to Text via http://www.lucenebootcamp.com/lucene-boot-camp-preclass-training/,[object Object],Convert to Sequence File:,[object Object],bin/mahout seqdirectory –input <PATH> --output <PATH> --charset UTF-8,[object Object],Convert to Sparse Vector:,[object Object],bin/mahout seq2sparse --input <PATH>/content/reuters/seqfiles/ --norm 2 --weight TF --output <PATH>/content/reuters/seqfiles-TF/ --minDF 5 --maxDFPercent 90,[object Object]

Ugly Demo II: Topic Modeling,[object Object],Latent Dirichlet Allocation,[object Object],./mahout lda --input <PATH>/content/reuters/seqfiles-TF/vectors/ --output <PATH>/content/reuters/seqfiles-TF/lda-output --numWords 34000 –numTopics 10,[object Object],./mahout org.apache.mahout.clustering.lda.LDAPrintTopics --input <PATH>/content/reuters/seqfiles-TF/lda-output/state-19 --dict <PATH>/content/reuters/seqfiles-TF/dictionary.file-0 --words 10 --output <PATH>/content/reuters/seqfiles-TF/lda-output/topics --dictionaryTypesequencefile,[object Object],Good feature reduction (stopword removal) required,[object Object]

Ugly Demo III: Clustering,[object Object],K-Means,[object Object],Same Prep as UD II, except use TFIDF weight,[object Object],./mahout kmeans --input <PATH>/content/reuters/seqfiles-TFIDF/vectors/part-00000 --k 15 --output <PATH>/content/reuters/seqfiles-TFIDF/output-kmeans --clusters <PATH>/content/reuters/seqfiles-TFIDF/output-kmeans/clusters,[object Object],Print out the clusters: ./mahout clusterdump --seqFileDir <PATH>/content/reuters/seqfiles-TFIDF/output-kmeans/clusters-15/ --pointsDir <PATH>/content/reuters/seqfiles-TFIDF/output-kmeans/points/ --dictionary <PATH>/content/reuters/seqfiles-TFIDF/dictionary.file-0 --dictionaryTypesequencefile --substring 20,[object Object]

Ugly Demo IV: Frequent Pattern Mining,[object Object],Data: http://fimi.cs.helsinki.fi/data/,[object Object],./mahout fpg -i <PATH>/content/freqitemset/accidents.dat -o patterns -k 50 -method mapreduce -g 10 -regex [],[object Object], ./mahout seqdump --seqFile patterns/fpgrowth/part-r-00000 ,[object Object]

What’s Next?,[object Object],Google Summer of Code (GSOC),[object Object],Restricted Boltzmann Machines,[object Object],SVM,[object Object],EigenCuts (spectral clustering),[object Object],Neural Networks,[object Object],SVD-based Recommender,[object Object],0.4 release in Fall (after GSOC),[object Object],Stabilize API’s for 1.0 release,[object Object],Benchmarking,[object Object],http://cwiki.apache.org/MAHOUT/howtocontribute.html,[object Object]

Resources,[object Object],Slides will be posted at http://lucene.grantingersoll.com,[object Object],Examples at:,[object Object],http://lucene.grantingersoll.com/2010/02/13/intro-to-mahout-slides-and-demo-examples/ ,[object Object],More Examples in Mahout SVN in the examples directory,[object Object]

Resources,[object Object],http://mahout.apache.org,[object Object],http://cwiki.apache.org/MAHOUT,[object Object],{user|dev}@mahout.apache.org,[object Object],http://svn.apache.org/repos/asf/mahout/trunk,[object Object],http://hadoop.apache.org,[object Object]

Resources,[object Object],“Mahout in Action” by Owen and Anil,[object Object],http://lucene.li/E,[object Object],“Taming Text” by Ingersoll, Morton and Farris,[object Object],http://lucene.li/D,[object Object],“Introducing Apache Mahout” ,[object Object],http://lucene.li/F,[object Object],“Programming Collective Intelligence” by Toby Segaran,[object Object],http://lucene.li/G,[object Object],“Data Mining - Practical Machine Learning Tools and Techniques” by Ian H. Witten and Eibe Frank,[object Object],http://lucene.li/H,[object Object]

References,[object Object],HAL: http://en.wikipedia.org/wiki/File:Hal-9000.jpg,[object Object],Terminator: http://en.wikipedia.org/wiki/File:Terminator1984movieposter.jpg,[object Object],Matrix: http://en.wikipedia.org/wiki/File:The_Matrix_Poster.jpg,[object Object],Google News: http://news.google.com,[object Object],Amazon.com: http://www.amazon.com,[object Object],Facebook: http://www.facebook.com,[object Object],Mahout: http://lucene.apache.org/mahout,[object Object],Beer and Diapers: http://www.flickr.com/photos/baubcat/2484459070/,[object Object],http://www.theregister.co.uk/2006/08/15/beer_diapers/,[object Object],DMOZ: http://www.dmoz.org,[object Object]
