In the last few years, one of the main problems of the cultural heritage institution is the progressive reduction of the investments. The hardware maintenance and licensing costs greatly affects IT budget. Virtualization addresses the need to streamline and consolidate infrastructure, even if the license costs remain high for commercial clouds. Open source solutions allow you to implement virtualization cloud which performance and functionality are suitable for the masses, without the constraints of hardware certifications and proibitive licenses costs.

Our infrastructure allowed us to build a ha virtualized environment using commodity hardware, regardless of specific products or manufacturers. Based on the interaction between a common linux kernel module and a software-based storage pool, is managed by an intuitive web interface. The system provides adequate performances provisioning services like web pages, OPAC, digital resources showcase, cataloging tools, library management, mail, etc.

Cristiano Corsani
Giovanni Toraldo

Published in: Technology
  • Be the first to comment

No Downloads
Total views
On SlideShare
From Embeds
Number of Embeds
Embeds 0
No embeds

No notes for slide

EVA Florence 2012 ~ Open low-cost HA cluster cloud

  1. 1. Open low cost HA cluster cloud Cristiano Corsani – system engineer - IT department - Florence National Library Giovanni Toraldo – OSS solutions architect at Libersoft Low cost cloud for BNCF EVA Florence 2012
  2. 2. BNCF services Cultural Heritage Ministry has progressively reduced the investment SBN - national cataloguing system OPAC - online public access catalogue WWW - our web interface Digital data access - public access to our digital storage Internal services - library management and Intranet servicesLow cost cloud for BNCF EVA Florence 2012
  3. 3. BNCF data center costs  Open Source – reduce costs of:  SOFTWARE: development and maintenance  LICENSING: server, apps and 250 workstation  Virtualization cloud – reduce costs of:  HARDWARE: maintenance and electricity costsLow cost cloud for BNCF EVA Florence 2012
  4. 4. VirtualizationLow cost cloud for BNCF EVA Florence 2012
  5. 5. Commercial solutions  Hypervisor license - depends on CPU and/or memory  Orchestrator license - live migration, HA, backup, …  Certified hardware – limited hardware supported  Centralized storage system – needed for HALow cost cloud for BNCF EVA Florence 2012
  6. 6. Our Open solution  Open hypervisor it comes with Linux kernel in standard distro  Orchestrator live migration, ha, backup, … intuitive and web based  Commodity hardware only very low requirements needed  No centralized storage system special network filesystem is used instead physical storageLow cost cloud for BNCF EVA Florence 2012
  7. 7. Compare3x Sun Fire (2 x quad-core Xeon, 24GB RAM, 2 x 500 GB SATA2) 3 HOSTS 6 CPU 72GB RAM 1TB Storage Commercial Our Open Hypervisor license 4000€ + 12000€/year --- Centralized storage 5000€ --- + FB lan Hardware 20000€ << 20000€ Installation + 500€/day 500€/day MaintenanceOur Open Cloud is: open, simple, easily scalable and affordableLow cost cloud for BNCF EVA Florence 2012
  8. 8. Open detailsGiovanni Toraldo, OSS solutions architect in LiberSoft  Virtualization (OpenNebula and Proxmox)  Massive long-term storage for digitalized resources (GlusterFS)  Migration to Open Source desktop/server platforms. (Ubuntu and MooseFS)Low cost cloud for BNCF EVA Florence 2012
  9. 9. Open hypervisor  Freely available: on your GNU/Linux distribution;  Enterprise-ready: powerful mix of enterprise features and a rich set of partners.  Support: widest range of hardware without hassles (Thanks Linux!)  High-performance: top-level virtualization benchmarks for Windows and Linux workloads.Low cost cloud for BNCF EVA Florence 2012
  10. 10. Open VM management software OpenNebula  Adaptable: highly modular.  Proven: massive scale production environments;  Interoperable: XML-RPC, EC2, OCCI Proxmox  Easy to deploy: ISO installer or from bare Debian  Easy to use: centralized web managementLow cost cloud for BNCF EVA Florence 2012
  11. 11. Low-end hardware requirements  The simplest virtualization host is... your laptop: CPU with virtualization extensions;  A bunch of available memory  A bunch of available disk space  Use your workstations to prepare VM before starting them in production.Low cost cloud for BNCF EVA Florence 2012
  12. 12. Focus on storage  Shared storage is not an option for live migration and High-Availability.  A good storage solution:  Availability: the sky should not fall on our heads;  Scalability: we add new bricks when needed;  Price.  Common choice is to use a dedicated NAS/SAN (NetApp, EMC, QNAP and so on).Low cost cloud for BNCF EVA Florence 2012
  13. 13. Our choice: GlusterFS  GlusterFS is an open source distributed network filesystem.  How it works?  Aggregate available disk space on your hosts;  Replicate data: HA and prevent data-loss;  Data available via LAN with standard protocols: FUSE, NFS, CIFS.Low cost cloud for BNCF EVA Florence 2012
  14. 14. GlusterFS advantages  Scalability: to Petabytes and beyond!  Affordability: use commodity hardware;  Flexibility: deploy in any environment;  Linear performances: no degradation;  HA: replicate data on multiple places;  Unified namespace: like a folder on a local diskLow cost cloud for BNCF EVA Florence 2012
  15. 15. CreditsCristiano Corsani – system engineer - IT departmentFlorence National Library  Email: cristiano.corsani@beniculturali.itGiovanni Toraldo – OSS solutions architect atLibersoft  Email: gt@libersoft.it Low cost cloud for BNCF EVA Florence 2012
