6 th  Grade Science  Chapter 18 Thermal Energy Notes Section 18.3 Chihuly at the New York Botanical Garden
<ul><li>What is heat engine? </li></ul><ul><li>A heat engine converts thermal energy into mechanical energy.  </li></ul><u...
<ul><li>A  heat engine  is a device that converts thermal energy into mechanical energy.   </li></ul><ul><li>The engines u...
A steam engine is one of the earliest heat engines. A fire box heats steam. The steam drives a piston that is connected to...
<ul><li>What is an internal combustion engine? </li></ul><ul><li>Internal combustion engines burn fuel in a combustion cha...
<ul><li>In  internal combustion  engines, the fuel burns in a combustion chamber inside the engine.  </li></ul>Internal Co...
Four cycle internal combustion engine
Two cycle internal combustion engine
<ul><li>What does a refrigerator do? </li></ul><ul><li>A refrigerator transfers the thermal energy from inside to outside ...
<ul><li>A refrigerator is a heat mover. </li></ul>Refrigerators  <ul><li>It absorbs heat from the food and other materials...
<ul><li>Liquid coolant is forced up a pipe toward the freezer unit.  </li></ul>Absorbing Heat   <ul><li>The liquid passes ...
<ul><li>When it changes into a gas, it becomes cold.   </li></ul>Absorbing Heat   <ul><li>The cold gas passes through pipe...
<ul><li>The heat absorbed by the coolant cannot be transferred to the air.  </li></ul>Releasing Heat <ul><li>The warm cool...
<ul><li>The gas then flows through the condenser coils, where it transfers heat to the cooler air in the room.   </li></ul...
<ul><li>How does an air conditioner work? </li></ul><ul><li>Most air conditioners work in the same way that a refrigerator...
Opened in November 2005, the indoor resort features an 60-meter high indoor mountain with 5 slopes of varying steepness an...
<ul><li>A heat pump moves heat from one place to another. </li></ul>Heat Pumps   <ul><li>In heating mode, the coolant abso...
<ul><li>Diagram the movement of coolant and the flow of heat when a heat pump is used to cool a building. Pg 537 </li></ul...
