Optimization of
modern web apps

     Eugene Lazutkin

   ClubAjax on 8/7/2012
       Dallas, TX
About me
• Eugene Lazutkin
• Open Source web developer
   • Majors: JavaScript & Python, Dojo & Django.
• Independent consultant
• Blog: lazutkin.com
• Twitter: @uhop, Google+: gplus.to/uhop
What’s new?
Browser landscape has
      changed
What else is new?

• We are transitioning from static web applications
  with JavaScript helpers to dynamic web
  applications.
   • One-page web applications.
   • Interactive grids, charts, CRUD.
   • Multimedia is on its way.
The waterfall
Important things
• Individual web requests.
• Event: DOMContentLoaded
   • DOM is fully parsed, but not laid out yet.
• Event: load
   • All external assets are loaded.
   • DOM geometry is calculated.
When can we use it?

• After DOMContentLoaded.
• After load.
• Sometimes between them.
   • Example: our app works, yet some images are
     being downloaded.
Problem: batching

• A network diagram frequently looks like a staircase.
• Requests are batched.
• Browser limits connections per host.
   • Usually 2-8 connections depending on browser
     and on HTTP version (1.0 or 1.1).
   • Prevents server overload.
Problem: bandwidth


• We need to download a lot of resources.
• Slow connections limit the app.
• The less we download, the better.
Anatomy of connection
• Lifecycle (add browser delays, and network latency
  liberally):
   1.Client does a DNS lookup (complex operation).
   2.Client sends a request (data, headers, cookies).
   3.Server gets it, processes it, and sends a
     response.
   4.Client receives and processes it.
Problem: connections


• Connections are expensive.
• We should reduce their number.
Solution: batching

• Sharding:
   • Serve different resources from different hosts.
• Pro: if batching is a bottleneck, that can help
  considerably.
• Con: more expensive DNS lookups.
CDN
• Can help with batching and bandwidth at the same
  time.
• Can reduce latency for geographically distributed
  clients.
• The same problems as sharding.
• You should factor in CDN service costs (usually
  inexpensive).
Solution: bandwidth
• Let’s compress all we can.
   • Images can be compressed lossy or losslessly.
   • Text (JavaScript, CSS, HTML) should be
     gzipped.
      • It can be preprocessed (minified) to be even
        more compressible.
• Use static compression whenever you can.
Solution: bandwidth

• If we bundle similar resources together usually we
  can compress them better.
   • Merge all JavaScript.
   • Merge all CSS.
   • Use sprites instead of separate images.
• Bundling conserves connections too!
Solution: bandwidth

• It makes sense to remove all inlined JavaScript
  (<script> blocks, event handlers), and CSS
  (<style> blocks) from HTML.
• Images should be converted to sprites.
   • Example: <img> can be represented as <div>
     with a proper background image.
What I use

• Both Dojo and RequireJS come with a build tool.
   • It bundles, and minifies JavaScript.
   • It bundles and minifies CSS.
• SmartSprites (http://csssprites.org)
   • It can handle vertically and horizontally tiled,
     and untiled images.
Problems with
           bundling

• 3rd party resources cannot be bundled easily.
• Bundled resources should have the same
  expiration.
• Dynamic data cannot be easily bundled.
Solution: connections


• We bundled all we could. Now what?
• Now it is time to go back to basics: network
  protocols starting with TCP/IP.
Really???
Oh, yes!

• The standard-compliant server sends 3 (three)
  packages and waits for ACK.
   • It is a part of congestion-controlling algorithm.
• What does it mean for us?
   • Client gets 3 packages relatively fast.
   • Useful payload is just over 1.5k.
TCP 3 packets rule

• How can we use it?
   • If we send an HTML page, try to fit all
     external resource requests in the first 1.5k.
   • If you can keep your HTML page under 1.5k
     (compressed) — awesome!
HTTP rules!

• HTTP/1.0 creates one connection per request.
   • Expensive.
• HTTP/1.1 allows to reuse the same connection to
  request different resources from the same host.
   • Double check that you use HTTP/1.1 on
     server.
HTTP pipelining
HTTP pipelining
• Part of HTTP/1.1.
• Allows to request several resources without waiting
  for response.
• Resources should come in the order of their
  requests.
• Frequently turned off.
• Improves high-latency/mobile scenarios.
SPDY

• Introduced by Google.
• Will likely be a part of HTTP/2.0.
• Allows asynchronous requests/responses over a
  single connection.
• Allows server push and server hint.
Who supports SPDY?

• Implemented by Chrome/Chromium and Firefox.
• Used by Google, Twitter.
• Announced by Facebook.
• Implemented by most vendors including Apache,
  nginx (experimental), most app servers like node.js.
• Server push and hint are rarely implemented.
Ideal web app
<!doctype html>
<html>
     <head>
        <link rel=”stylesheet” type=”text/css” href=”x.css”>
        <!— images are requested from CSS as one sprite —>
        <script src=”x.js”></script>
     </head>
     <body>
        <!— HTML here may be dynamically generated —>
     </body>
</html>


                          Now what?
Where to include JS?
• Most gurus recommend to include it in a body as a
  last node.
• That’s incorrect in general!
• It works only for “gradual enhancements” scripts.
   • Scripts, which provide convenience, not main
     functionality.
      • Error checking, calendars, and so on.
Where to include JS?

• It is unwise to make it last, if our app functionality
  depends on it.
    • It renders significant parts of out web page.
    • It requests data from a server.
    • It is the application.
• In our “ideal app” it doesn’t matter where to put it.
Can we reduce it more?
• We can inline CSS and JavaScript back.
• Images can be inlined too using “data:” URI.
• Cons:
   • Usually it violates “the same expiration” rule.
   • Prevents reuse between pages.
   • “data:” URI can increase a file size.
Problem: dynamic data
• We optimized the web app. Now what?
• Usually the dynamic data requests stick out like a
  sore thumb.
   • Unlike static files, such requests do take some
     server processing:
      • SQL queries, disk I/O, internal network
        services.
Solution: dynamic data

• We can try to consolidate several requests required
  to render a page into one request.
• We can request this data first thing.
   • Literally.
   • Both XHR and <script> can be used but I
     prefer scripts with JSONP.
Data-first idea part 1

• Let’s request the data first, if it takes a long time.
• In order to be efficient we cannot rely on any other
  JavaScript libraries.
• It will be loaded in parallel with the rest.
    • Con: it will occupy a connection slot.
• The result would be stored in a variable.
Data-first idea part 2

• When our main JS is loaded we can check that
  variable.
   • If it is populated, we can wait until DOM is
     ready to render data.
   • Otherwise we can override our JSONP callback
     function, and wait for data, and for DOM.
Data-first sketch
<!doctype html>
<html>
     <head>
        <script>
           function __load(data){...}
           var t = document.createElement("script");
           t.src = "/api?timeout=2&callback=__load";
           document.documentElement.appendChild(t);
        </script>
        <link...>
        <script...>
     </head>
     <body>
        <!— HTML, if any —>
Cache considerations


• If we expect our user to come again, or
• If we expect it to use other pages of our web app.
• We have to work with cache.
Server-side headers
• Determine expirations of your resources and set all
  proper HTTP headers:
   • Expires, Last-Modified, Cache-Control
   • If set properly, browser would not even attempt
     to connect within their expiration period.
• Set ETag header.
   • Sometimes timestamp is not reliable.
Server-side headers
• Proper settings reduce number of connections.
• It allows server to send 304 (not modified) response
  instead of a potentially big resource.
• Don’t forget that some companies and ISPs run
  intermediate caches.
• Read http://lazutkin.com/blog/2007/feb/1/
  improving-performance/ for more details.
Prime cache
• Sometimes it makes sense to load files not used by
  this web page, which can be used by other pages.
• Usually it is done asynchronously several seconds
  later after the page has started.
   • Invisible image can be created.
   • CSS and JS can be linked.
     • They should not interfere with the page!
Or use manifest

• Part of HTML5 to facilitate offline applications.
• A text file that lists what should be downloaded and
  placed into a permanent cache, network URLs,
  and fallback URLs.
• Should be served as “text/cache-manifest”.
• Supported by FF, Cr, Opera, Safari, IE10.
Cache manifest
            example
<!doctype html>
<html manifest=”cache.manifest”>
     ...

  <!— cache.manifest example content —>
  CACHE MANIFEST
  /y.js
  /y.css
  /y.jpg
  /y.html
  ...
Tools of trade

• Built-in debuggers of modern browsers.
   • Firebug.
• Network sniffers.
   • HTTPWatch, Fiddler.
• And...
Navigation timing


• For your debugging pleasure you can use
  Navigation Timing API.
• A lot of resource-specific timing information!
• Supported by FF, Cr, IE9.
That’s all
  folks!
Picture credits


pie: http://en.wikipedia.org/wiki/File:Wikimedia_browser_share_pie_chart_3.png
really: http://www.flickr.com/photos/zpeckler/3093588439/
http pipelining: http://en.wikipedia.org/wiki/File:HTTP_pipelining2.svg
1 of 46

More Related Content

Similar to Optimization of modern web applications(20)

Drupal is not your Website Drupal is not your Website
Drupal is not your Website
Phase22.1K views
Drupal Is Not Your Web SiteDrupal Is Not Your Web Site
Drupal Is Not Your Web Site
Phase2549 views
High performance websiteHigh performance website
High performance website
Chamnap Chhorn5.9K views
How_To_Soup_Up_Your_FarmHow_To_Soup_Up_Your_Farm
How_To_Soup_Up_Your_Farm
Nigel Price84 views
Cvcc performance tuningCvcc performance tuning
Cvcc performance tuning
John McCaffrey951 views
Javascript for Wep AppsJavascript for Wep Apps
Javascript for Wep Apps
Michael Puckett520 views
WebDev Crash CourseWebDev Crash Course
WebDev Crash Course
Cesar Martinez96 views
Best practices-wordpress-enterpriseBest practices-wordpress-enterprise
Best practices-wordpress-enterprise
Taylor Lovett680 views
performance.pptperformance.ppt
performance.ppt
fakeaccount22509516 views
RemixRemix
Remix
Talentica Software203 views
CI_CONF 2012: Scaling - Chris MillerCI_CONF 2012: Scaling - Chris Miller
CI_CONF 2012: Scaling - Chris Miller
The Huffington Post Tech Team414 views

More from Eugene Lazutkin

Service workersService workers
Service workersEugene Lazutkin
208 views36 slides
StreamsStreams
StreamsEugene Lazutkin
584 views63 slides

More from Eugene Lazutkin(19)

Service workersService workers
Service workers
Eugene Lazutkin208 views
Advanced I/O in browserAdvanced I/O in browser
Advanced I/O in browser
Eugene Lazutkin401 views
StreamsStreams
Streams
Eugene Lazutkin584 views
Functional practices in JavaScriptFunctional practices in JavaScript
Functional practices in JavaScript
Eugene Lazutkin551 views
Express: the web server for node.jsExpress: the web server for node.js
Express: the web server for node.js
Eugene Lazutkin572 views
TXJS 2013 in 10 minutesTXJS 2013 in 10 minutes
TXJS 2013 in 10 minutes
Eugene Lazutkin656 views
OOP in JSOOP in JS
OOP in JS
Eugene Lazutkin1.9K views
PulsarPulsar
Pulsar
Eugene Lazutkin944 views
SSJS, NoSQL, GAE and AppengineJSSSJS, NoSQL, GAE and AppengineJS
SSJS, NoSQL, GAE and AppengineJS
Eugene Lazutkin733 views
Dojo for programmers (TXJS 2010)Dojo for programmers (TXJS 2010)
Dojo for programmers (TXJS 2010)
Eugene Lazutkin1.2K views
RAD CRUDRAD CRUD
RAD CRUD
Eugene Lazutkin1.5K views
Exciting JavaScript - Part IExciting JavaScript - Part I
Exciting JavaScript - Part I
Eugene Lazutkin6.9K views
CRUD with DojoCRUD with Dojo
CRUD with Dojo
Eugene Lazutkin4.9K views
Dojo GFX workshop slidesDojo GFX workshop slides
Dojo GFX workshop slides
Eugene Lazutkin1.7K views
Dojo GFX: SVG in the real worldDojo GFX: SVG in the real world
Dojo GFX: SVG in the real world
Eugene Lazutkin3.2K views
Dojo (QCon 2007 Slides)Dojo (QCon 2007 Slides)
Dojo (QCon 2007 Slides)
Eugene Lazutkin789 views

Recently uploaded(20)

Liqid: Composable CXL PreviewLiqid: Composable CXL Preview
Liqid: Composable CXL Preview
CXL Forum114 views
ThroughputThroughput
Throughput
Moisés Armani Ramírez25 views
ChatGPT and AI for Web DevelopersChatGPT and AI for Web Developers
ChatGPT and AI for Web Developers
Maximiliano Firtman143 views

Optimization of modern web applications

  • 1. Optimization of modern web apps Eugene Lazutkin ClubAjax on 8/7/2012 Dallas, TX
  • 2. About me • Eugene Lazutkin • Open Source web developer • Majors: JavaScript & Python, Dojo & Django. • Independent consultant • Blog: lazutkin.com • Twitter: @uhop, Google+: gplus.to/uhop
  • 4. What else is new? • We are transitioning from static web applications with JavaScript helpers to dynamic web applications. • One-page web applications. • Interactive grids, charts, CRUD. • Multimedia is on its way.
  • 6. Important things • Individual web requests. • Event: DOMContentLoaded • DOM is fully parsed, but not laid out yet. • Event: load • All external assets are loaded. • DOM geometry is calculated.
  • 7. When can we use it? • After DOMContentLoaded. • After load. • Sometimes between them. • Example: our app works, yet some images are being downloaded.
  • 8. Problem: batching • A network diagram frequently looks like a staircase. • Requests are batched. • Browser limits connections per host. • Usually 2-8 connections depending on browser and on HTTP version (1.0 or 1.1). • Prevents server overload.
  • 9. Problem: bandwidth • We need to download a lot of resources. • Slow connections limit the app. • The less we download, the better.
  • 10. Anatomy of connection • Lifecycle (add browser delays, and network latency liberally): 1.Client does a DNS lookup (complex operation). 2.Client sends a request (data, headers, cookies). 3.Server gets it, processes it, and sends a response. 4.Client receives and processes it.
  • 11. Problem: connections • Connections are expensive. • We should reduce their number.
  • 12. Solution: batching • Sharding: • Serve different resources from different hosts. • Pro: if batching is a bottleneck, that can help considerably. • Con: more expensive DNS lookups.
  • 13. CDN • Can help with batching and bandwidth at the same time. • Can reduce latency for geographically distributed clients. • The same problems as sharding. • You should factor in CDN service costs (usually inexpensive).
  • 14. Solution: bandwidth • Let’s compress all we can. • Images can be compressed lossy or losslessly. • Text (JavaScript, CSS, HTML) should be gzipped. • It can be preprocessed (minified) to be even more compressible. • Use static compression whenever you can.
  • 15. Solution: bandwidth • If we bundle similar resources together usually we can compress them better. • Merge all JavaScript. • Merge all CSS. • Use sprites instead of separate images. • Bundling conserves connections too!
  • 16. Solution: bandwidth • It makes sense to remove all inlined JavaScript (<script> blocks, event handlers), and CSS (<style> blocks) from HTML. • Images should be converted to sprites. • Example: <img> can be represented as <div> with a proper background image.
  • 17. What I use • Both Dojo and RequireJS come with a build tool. • It bundles, and minifies JavaScript. • It bundles and minifies CSS. • SmartSprites (http://csssprites.org) • It can handle vertically and horizontally tiled, and untiled images.
  • 18. Problems with bundling • 3rd party resources cannot be bundled easily. • Bundled resources should have the same expiration. • Dynamic data cannot be easily bundled.
  • 19. Solution: connections • We bundled all we could. Now what? • Now it is time to go back to basics: network protocols starting with TCP/IP.
  • 21. Oh, yes! • The standard-compliant server sends 3 (three) packages and waits for ACK. • It is a part of congestion-controlling algorithm. • What does it mean for us? • Client gets 3 packages relatively fast. • Useful payload is just over 1.5k.
  • 22. TCP 3 packets rule • How can we use it? • If we send an HTML page, try to fit all external resource requests in the first 1.5k. • If you can keep your HTML page under 1.5k (compressed) — awesome!
  • 23. HTTP rules! • HTTP/1.0 creates one connection per request. • Expensive. • HTTP/1.1 allows to reuse the same connection to request different resources from the same host. • Double check that you use HTTP/1.1 on server.
  • 25. HTTP pipelining • Part of HTTP/1.1. • Allows to request several resources without waiting for response. • Resources should come in the order of their requests. • Frequently turned off. • Improves high-latency/mobile scenarios.
  • 26. SPDY • Introduced by Google. • Will likely be a part of HTTP/2.0. • Allows asynchronous requests/responses over a single connection. • Allows server push and server hint.
  • 27. Who supports SPDY? • Implemented by Chrome/Chromium and Firefox. • Used by Google, Twitter. • Announced by Facebook. • Implemented by most vendors including Apache, nginx (experimental), most app servers like node.js. • Server push and hint are rarely implemented.
  • 28. Ideal web app <!doctype html> <html> <head> <link rel=”stylesheet” type=”text/css” href=”x.css”> <!— images are requested from CSS as one sprite —> <script src=”x.js”></script> </head> <body> <!— HTML here may be dynamically generated —> </body> </html> Now what?
  • 29. Where to include JS? • Most gurus recommend to include it in a body as a last node. • That’s incorrect in general! • It works only for “gradual enhancements” scripts. • Scripts, which provide convenience, not main functionality. • Error checking, calendars, and so on.
  • 30. Where to include JS? • It is unwise to make it last, if our app functionality depends on it. • It renders significant parts of out web page. • It requests data from a server. • It is the application. • In our “ideal app” it doesn’t matter where to put it.
  • 31. Can we reduce it more? • We can inline CSS and JavaScript back. • Images can be inlined too using “data:” URI. • Cons: • Usually it violates “the same expiration” rule. • Prevents reuse between pages. • “data:” URI can increase a file size.
  • 32. Problem: dynamic data • We optimized the web app. Now what? • Usually the dynamic data requests stick out like a sore thumb. • Unlike static files, such requests do take some server processing: • SQL queries, disk I/O, internal network services.
  • 33. Solution: dynamic data • We can try to consolidate several requests required to render a page into one request. • We can request this data first thing. • Literally. • Both XHR and <script> can be used but I prefer scripts with JSONP.
  • 34. Data-first idea part 1 • Let’s request the data first, if it takes a long time. • In order to be efficient we cannot rely on any other JavaScript libraries. • It will be loaded in parallel with the rest. • Con: it will occupy a connection slot. • The result would be stored in a variable.
  • 35. Data-first idea part 2 • When our main JS is loaded we can check that variable. • If it is populated, we can wait until DOM is ready to render data. • Otherwise we can override our JSONP callback function, and wait for data, and for DOM.
  • 36. Data-first sketch <!doctype html> <html> <head> <script> function __load(data){...} var t = document.createElement("script"); t.src = "/api?timeout=2&callback=__load"; document.documentElement.appendChild(t); </script> <link...> <script...> </head> <body> <!— HTML, if any —>
  • 37. Cache considerations • If we expect our user to come again, or • If we expect it to use other pages of our web app. • We have to work with cache.
  • 38. Server-side headers • Determine expirations of your resources and set all proper HTTP headers: • Expires, Last-Modified, Cache-Control • If set properly, browser would not even attempt to connect within their expiration period. • Set ETag header. • Sometimes timestamp is not reliable.
  • 39. Server-side headers • Proper settings reduce number of connections. • It allows server to send 304 (not modified) response instead of a potentially big resource. • Don’t forget that some companies and ISPs run intermediate caches. • Read http://lazutkin.com/blog/2007/feb/1/ improving-performance/ for more details.
  • 40. Prime cache • Sometimes it makes sense to load files not used by this web page, which can be used by other pages. • Usually it is done asynchronously several seconds later after the page has started. • Invisible image can be created. • CSS and JS can be linked. • They should not interfere with the page!
  • 41. Or use manifest • Part of HTML5 to facilitate offline applications. • A text file that lists what should be downloaded and placed into a permanent cache, network URLs, and fallback URLs. • Should be served as “text/cache-manifest”. • Supported by FF, Cr, Opera, Safari, IE10.
  • 42. Cache manifest example <!doctype html> <html manifest=”cache.manifest”> ... <!— cache.manifest example content —> CACHE MANIFEST /y.js /y.css /y.jpg /y.html ...
  • 43. Tools of trade • Built-in debuggers of modern browsers. • Firebug. • Network sniffers. • HTTPWatch, Fiddler. • And...
  • 44. Navigation timing • For your debugging pleasure you can use Navigation Timing API. • A lot of resource-specific timing information! • Supported by FF, Cr, IE9.
  • 45. That’s all folks!

Editor's Notes

  1. \n
  2. \n
  3. \n
  4. \n
  5. \n
  6. \n
  7. \n
  8. \n
  9. \n
  10. \n
  11. \n
  12. \n
  13. \n
  14. \n
  15. \n
  16. \n
  17. \n
  18. \n
  19. \n
  20. \n
  21. \n
  22. \n
  23. \n
  24. \n
  25. \n
  26. \n
  27. \n
  28. \n
  29. \n
  30. \n
  31. \n
  32. \n
  33. \n
  34. \n
  35. \n
  36. \n
  37. \n
  38. \n
  39. \n
  40. \n
  41. \n
  42. \n
  43. \n
  44. \n
  45. \n
  46. \n
